Kwikee by Lippert Electric Steps Single Step Parts Diagram · 37 Series › Step Motor Assembly

Entry Step · 28 assemblies · 84 diagram sheets · 166 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Kwikee by Lippert Electric Steps Single Step RV entry step: 28 assemblies (37 Series › Step Motor Assembly, 38 Series › Step Motor Assembly, 37 Series Van Step › Parts List, 39 Series › Step Improvement Bulletin, 38 Series Van Step › Parts List and more) and 166 manufacturer part numbers. 33 parts are marked as superseded — the description gives the replacement number to order instead.

Kwikee/Lippert step model and serial numbers are on a label on the step frame or the control unit. Motor, gearbox and linkage parts change with the series (25, 27, 32 …), so identify the series before ordering.

37 Series › Step Motor Assembly

Components

50 items

1. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
2. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
5. #BEARING USE 5208K MFR # 9045 Superseded: see description
6. #MOTOR,USED W/ORNG OR WHT CNTRLS MFR # 9520
7. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 28/ 31/ 37/ 39; With Step Motor/ Pin And Clevis Kit/ B Linkage Gear Box MFR # 909772000
8. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
9. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781006
10. #MOTOR ASM USE 909772000 MFR # 9579 Superseded: see description
11. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert® supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for triple or quad Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 379769
12. #NO GENERIC NAME; Motor & Gear MFR # 909501000
13. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
14. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
15. #TRAILER JACKS; Gear & Shaft MFR # 9528
16. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
17. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
18. #Entry Step Linkage Arm; Kwikee ®; For 28/ 31/ 33/ 37/ 39 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Straight; 2- 9/16 Inch Drive Link Shaft; With Linkage Assembly B/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909533000 MFR # 379648
19. #Entry Step Linkage Arm; Replacement Parts For 28/ 31/ 33/ 37/ 39 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly B/ Cotter Pin/ Clevis Pin MFR # 909533000
20. #Entry Step Gear; Replacement Part For Series Steps 28/ 31/ 37/ 39; With Gear/ B Linkage Straight MFR # 1101426
21. #Entry Step Linkage Arm; Kwikee ®; For 28/ 31/ 33/ 37/ 39 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Straight; 2-9/16 Inch Drive Link Shaft; With Linkage Assembly B/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909533000 MFR # 9533
22. #Entry Step Linkage Arm Clevis Pin; Entry Step Hardware; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 5205K Superseded: see description
23. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
24. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
25. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
26. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
27. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
28. #GEAR CASE ASM MFR # 9524
29. #GEAR CASE MFR # 9527
30. #AIR COMMAND SINGLE ECU; MFR # 9535
31. #LEADWIRE KIT MFR # 9537
32. #The perfect companion for any Kwikee® RV step, the Kwikee Glow-in-the-Dark tread strip will have your RV's steps glowing with more safety and convenience. Designed with a luminating, phosphorous glow-in-the-dark strip, a reflective strip and non-slip treading -- this easy-to-install tread strip makes your RV's stairs easier to see at night and it enhances the treading on your steps. This is a simple way to help make your campsite safer for everybody -- plus, the kids will love your glow-in-the-dark steps! MFR # 379600
33. #Entry Step Rug; Self Adhesive; 21 Inch Width; Yellow; Glow In The Dark; Replacement MFR # 909342000
34. #Entry Step Switch; Replacement Power Switch For RV Electric Sliding Steps; Plunger Door Switch; Normally Open; Black MFR # 5328000
35. #Get your steps back to work with an exact-match replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379606
36. #Get your steps back to work with an exact-match 9510 replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379146
37. #Entry Step Control Module; For Use With 22/ 23/ 26/ 28/ 30/ 31/ 32/ 33/ 34/ 35/ 36/ 37/ 38/ 39/ 40/ MFR # 909510000 Superseded: see description
38. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
39. #CONTROL UNIT USE 9506003 W/LAST OUT FEATURE MFR # 9506000 Superseded: see description
40. #Entry Step Control Module; Replaces Old Style Control Module For 9616/ 9515/ 9514/ 9513/ 9517/ 9613; With 5323/ 5327 Switch Kits MFR # 9506003
41. #Get your steps back to work with an exact-match pleated plunger door switch from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement switch assembly is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379407
42. #Entry Step Switch; Replacement Power Switch For RV Electric Sliding Steps; Plunger Door Switch; Normally Open; Black MFR # 905328000
43. #CONTROL UNIT USE 9506003 MFR # 95060047 Superseded: see description
44. #Get your steps back to work with an exact-match 4-way plug with Packard connector from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement plug is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 369243
45. #Entry Step Wiring Harness; Use To Connect The KwikTest Diagnostic Tool To Step Control Module; 4 Way Plug; With Packard Connector Pigtail MFR # 909306000 Superseded: see description
46. #Entry Step Wiring Harness; Use With Kwikee 32 Series Double Step And Platinum Series Steps MFR # 9306000 Superseded: see description
47. #NO GENERIC NAME; Plug 4 Wayw/Packard Conne MFR # 9336
48. #NO GENERIC NAME; Motor & Gear MFR # 9501
49. #12V EXTENSION CORD MFR # 9331
50. #37 SERIES STEP FRAME BLACK MFR # 8037K

38 Series › Step Motor Assembly

Components

48 items

1. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
2. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #BEARING USE 5208K MFR # 9045 Superseded: see description
5. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
6. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
7. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Step Motor/ Pin And Clevis Kit/ A Linkage Gear Box MFR # 909770000
8. #CONVERSION KIT USE 909770000 MFR # 9572 Superseded: see description
9. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
10. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert® supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for triple or quad Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 379145
11. #CONVERSION KIT USE 909770000 MFR # 9577 Superseded: see description
12. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781005
13. #Entry Step Control Module; For Use With 22/ 23/ 26/ 28/ 30/ 31/ 32/ 33/ 34/ 35/ 36/ 37/ 38/ 39/ 40/ MFR # 909510000 Superseded: see description
14. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
15. #Get your steps back to work with an exact-match 9510 replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379146
16. #TRAILER JACKS; Gear & Shaft MFR # 9528
17. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
18. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
19. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 379649
20. #Entry Step Gear; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Gear/ A Linkage Curved MFR # 1101425
21. #Entry Step Linkage Arm; Replacement Parts For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly A/ Cotter Pin/ Clevis Pin MFR # 909534000
22. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 9534
23. #Kwikee® Gear Box Linkage with “A" by Lippert® is specifically designed for certain electric steps in the Kwikee® series. MFR # 379160
24. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
25. #Entry Step Linkage Arm Clevis Pin; Entry Step Hardware; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 5205K Superseded: see description
26. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
27. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
28. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
29. #GEAR CASE ASM MFR # 9524
30. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
31. #GEAR CASE MFR # 9527
32. #AIR COMMAND SINGLE ECU; MFR # 9535
33. #LEADWIRE KIT MFR # 9537
34. #The perfect companion for any Kwikee® RV step, the Kwikee Glow-in-the-Dark tread strip will have your RV's steps glowing with more safety and convenience. Designed with a luminating, phosphorous glow-in-the-dark strip, a reflective strip and non-slip treading -- this easy-to-install tread strip makes your RV's stairs easier to see at night and it enhances the treading on your steps. This is a simple way to help make your campsite safer for everybody -- plus, the kids will love your glow-in-the-dark steps! MFR # 379600
35. #Entry Step Rug; Self Adhesive; 21 Inch Width; Yellow; Glow In The Dark; Replacement MFR # 909342000
36. #CONTROL UNIT USE 9506003 W/LAST OUT FEATURE MFR # 9506000 Superseded: see description
37. #Entry Step Control Module; Replaces Old Style Control Module For 9616/ 9515/ 9514/ 9513/ 9517/ 9613; With 5323/ 5327 Switch Kits MFR # 9506003
38. #CONTROL UNIT USE 9506003 MFR # 95060047 Superseded: see description
39. #Get your steps back to work with an exact-match replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379606
40. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
41. #Entry Step Wiring Harness; Use With Kwikee 32 Series Double Step And Platinum Series Steps MFR # 9306000 Superseded: see description
42. #Get your steps back to work with an exact-match 4-way plug with Packard connector from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement plug is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 369243
43. #Entry Step Wiring Harness; Use To Connect The KwikTest Diagnostic Tool To Step Control Module; 4 Way Plug; With Packard Connector Pigtail MFR # 909306000 Superseded: see description
44. #NO GENERIC NAME; Plug 4 Wayw/Packard Conne MFR # 9336
45. #& 39 SERIES STEPS THE PART # FOR THE HARNESS THAT PLUGS INTO THIS MOTOR IS 180993...,, MFR # 38
46. #12V EXTENSION CORD MFR # 9331
47. #CONTROL UNIT BLUE MFR # 8310K
48. #SERIES 38 STEP FRAME ONLY MFR # 8038K

37 Series Van Step › Parts List

Components

5 items

1. #STEP,37 SERIES W/MOTOR USE 903700900 MFR # 903700000 Superseded: see description
2. #STEP,SINGLE 37 SERIES MFR # 3707000
3. #Entry Step Wiring Harness; Used For Kwikee Van Step Installation; With Wiring Harness MFR # 907543000
4. #SERIES 37 F/VAN W/MOTOR AND MFR # 903709000
5. #SERIES 37 F/VAN W/MOTOR W/O MFR # 903700900

39 Series › Step Improvement Bulletin

Components

47 items

1. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
2. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
5. #BEARING USE 5208K MFR # 9045 Superseded: see description
6. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
7. #CONVERSION KIT USE 909772000 W/DELCO MOTOR MFR # 9576 Superseded: see description
8. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
9. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert® supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for triple or quad Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 379769
10. #NO GENERIC NAME; Conversion Kit Use 909772 MFR # 9570 Superseded: see description
11. #Entry Step Control Module; For Use With 22/ 23/ 26/ 28/ 30/ 31/ 32/ 33/ 34/ 35/ 36/ 37/ 38/ 39/ 40/ MFR # 909510000 Superseded: see description
12. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781006
13. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
14. #Get your steps back to work with an exact-match 9510 replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379146
15. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 28/ 31/ 37/ 39; With Step Motor/ Pin And Clevis Kit/ B Linkage Gear Box MFR # 909772000
16. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
17. #TRAILER JACKS; Gear & Shaft MFR # 9528
18. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
19. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 379649
20. #Entry Step Gear; Replacement Part For Series Steps 28/ 31/ 37/ 39; With Gear/ B Linkage Straight MFR # 1101426
21. #Entry Step Linkage Arm; Replacement Parts For 28/ 31/ 33/ 37/ 39 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly B/ Cotter Pin/ Clevis Pin MFR # 909533000
22. #Entry Step Gear; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Gear/ A Linkage Curved MFR # 1101425
23. #Entry Step Linkage Arm; Kwikee ®; For 28/ 31/ 33/ 37/ 39 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Straight; 2- 9/16 Inch Drive Link Shaft; With Linkage Assembly B/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909533000 MFR # 379648
24. #Kwikee® Gear Box Linkage with “A" by Lippert® is specifically designed for certain electric steps in the Kwikee® series. MFR # 379160
25. #Entry Step Linkage Arm; Replacement Parts For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly A/ Cotter Pin/ Clevis Pin MFR # 909534000
26. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 9534
27. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
28. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
29. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
30. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
31. #GEAR CASE ASM MFR # 9524
32. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
33. #GEAR CASE MFR # 9527
34. #AIR COMMAND SINGLE ECU; MFR # 9535
35. #LEADWIRE KIT MFR # 9537
36. #The perfect companion for any Kwikee® RV step, the Kwikee Glow-in-the-Dark tread strip will have your RV's steps glowing with more safety and convenience. Designed with a luminating, phosphorous glow-in-the-dark strip, a reflective strip and non-slip treading -- this easy-to-install tread strip makes your RV's stairs easier to see at night and it enhances the treading on your steps. This is a simple way to help make your campsite safer for everybody -- plus, the kids will love your glow-in-the-dark steps! MFR # 379600
37. #Entry Step Rug; Self Adhesive; 21 Inch Width; Yellow; Glow In The Dark; Replacement MFR # 909342000
38. #CONTROL UNIT USE 9506003 MFR # 95060047 Superseded: see description
39. #CONTROL UNIT USE 9506003 W/LAST OUT FEATURE MFR # 9506000 Superseded: see description
40. #Get your steps back to work with an exact-match replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379606
41. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
42. #Entry Step Wiring Harness; Use To Connect The KwikTest Diagnostic Tool To Step Control Module; 4 Way Plug; With Packard Connector Pigtail MFR # 909306000 Superseded: see description
43. #Get your steps back to work with an exact-match 4-way plug with Packard connector from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement plug is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 369243
44. #NO GENERIC NAME; Plug 4 Wayw/Packard Conne MFR # 9336
45. #CONTROL UNIT BLUE MFR # 8310K
46. #STEPS & STEP RUGS RV; Series 39 Step Frame Only MFR # 8039
47. #12V EXTENSION CORD MFR # 9331

38 Series Van Step › Parts List

Components

4 items

1. #SERIES 38 F/VAN W/MOTOR AND MFR # 903809000
2. #STEP,VAN 38 SER.USE 903809000 24" TREAD W/MOTOR & CONTROL MFR # 903806000 Superseded: see description
3. #STEP,38 SERIES W/ MOTOR NO CONTROL MFR # 903800000
4. #Entry Step Wiring Harness; Used For Kwikee Van Step Installation; With Wiring Harness MFR # 907543000

42 Series › Replacement › Replacement Step

Components

1 item

1. #Entry Step; Series 42; Double Electric Folding Step; 26-1/4 Inch Tread Width x 9 Inch Depth; With 6 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; MFR # 3727791

33 Series › Replacement Step

Components

8 items

1. #Entry Step; Single Electric Folding Step; 28.13 Inch Width x 16-3/4 Inch Depth; With 8 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 4-1/4 Inch Collapsed Height; Not Illuminated; With Step Control MFR # 903309000
2. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 372266
3. #Entry Step; Single Series; Single Electric Folding Step; 28.13 Inch Width x 16-3/4 Inch Depth; With 8 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 4-1/4 Inch Collapsed Height; Without Step Control MFR # 903300906
4. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3722661
5. #STEP,VAN USE 903309000 33 SERIES MFR # 903306000 Superseded: see description
6. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3722662
7. #STEP,SINGLE USE 3309025 33 SERIES MFR # 3306025 Superseded: see description
8. #Entry Step; Single Series; Single Electric Folding Step; 28.13 Inch Width x 16-3/4 Inch Depth; With 8 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 4-1/4 Inch Collapsed Height; With Step Control MFR # 903309025

33 Series Van Step › Replacement › Replacement Step

Components

4 items

1. #STEP,33 SERIES W/ MOTOR NO CONTROL MFR # 903300000
2. #PLASTIC SPLASH COVER F/VAN MFR # 9315
3. #STEP,VAN USE 903309000 33 SERIES MFR # 903306000 Superseded: see description
4. #Entry Step Wiring Harness; Used For Kwikee Van Step Installation; With Wiring Harness MFR # 907543000

38 Series › Replacement Step

Components

7 items

1. #STEP,SINGLE ELECTRIC W/O CONTROL UNIT MFR # 3800016
2. #Entry Step; Single Series; Single Electric Folding Step; 24 Inch Width x 14 Inch Depth; With 4 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 5-3/4 Inch Collapsed Height; Without Step Control MFR # 903800906
3. #Entry Step; Single Series; Single Electric Folding Step; 24 Inch Width x 14 Inch Depth; With 4 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 5-3/4 Inch Collapsed Height; With Step Control MFR # 903809025
4. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert® will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3723383
5. #SERIES 38 STEP FRAME ONLY MFR # 8038K
6. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 372338
7. #STEP,SINGLE USE 903809025 38 SERIES MFR # 3806025 Superseded: see description

36 Series › Step Motor Assembly

Components

47 items

1. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
2. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #BEARING USE 5208K MFR # 9045 Superseded: see description
5. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
6. #MOTOR,USED W/ORNG OR WHT CNTRLS MFR # 9520
7. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
8. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
9. #CONVERSION KIT USE 909770000 MFR # 9577 Superseded: see description
10. #Entry Step Control Module; For Use With 22/ 23/ 26/ 28/ 30/ 31/ 32/ 33/ 34/ 35/ 36/ 37/ 38/ 39/ 40/ MFR # 909510000 Superseded: see description
11. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
12. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781005
13. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Step Motor/ Pin And Clevis Kit/ A Linkage Gear Box MFR # 909770000
14. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert® supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for triple or quad Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 379145
15. #Get your steps back to work with an exact-match 9510 replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379146
16. #TRAILER JACKS; Gear & Shaft MFR # 9528
17. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
18. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
19. #Entry Step Linkage Arm; Replacement Parts For 28/ 31/ 33/ 37/ 39 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly B/ Cotter Pin/ Clevis Pin MFR # 909533000
20. #Entry Step Linkage Arm; Kwikee ®; For 28/ 31/ 33/ 37/ 39 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Straight; 2- 9/16 Inch Drive Link Shaft; With Linkage Assembly B/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909533000 MFR # 379648
21. #Kwikee® Gear Box Linkage with “B" by Lippert® is specifically designed for certain electric steps in the Kwikee® series. MFR # 379161
22. #Entry Step Linkage Arm; Kwikee ®; For 28/ 31/ 33/ 37/ 39 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Straight; 2-9/16 Inch Drive Link Shaft; With Linkage Assembly B/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909533000 MFR # 9533
23. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
24. #Entry Step Linkage Arm Clevis Pin; Entry Step Hardware; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 5205K Superseded: see description
25. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
26. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
27. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
28. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
29. #Kwikee® Gear Box Linkage with “A" by Lippert® is specifically designed for certain electric steps in the Kwikee® series. MFR # 379160
30. #GEAR CASE ASM MFR # 9524
31. #Entry Step Gear; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Gear/ A Linkage Curved MFR # 1101425
32. #GEAR CASE MFR # 9527
33. #AIR COMMAND SINGLE ECU; MFR # 9535
34. #LEADWIRE KIT MFR # 9537
35. #The perfect companion for any Kwikee® RV step, the Kwikee Glow-in-the-Dark tread strip will have your RV's steps glowing with more safety and convenience. Designed with a luminating, phosphorous glow-in-the-dark strip, a reflective strip and non-slip treading -- this easy-to-install tread strip makes your RV's stairs easier to see at night and it enhances the treading on your steps. This is a simple way to help make your campsite safer for everybody -- plus, the kids will love your glow-in-the-dark steps! MFR # 379600
36. #Entry Step Rug; Self Adhesive; 21 Inch Width; Yellow; Glow In The Dark; Replacement MFR # 909342000
37. #CONTROL UNIT USE 9506003 W/LAST OUT FEATURE MFR # 9506000 Superseded: see description
38. #Entry Step Control Module; Replaces Old Style Control Module For 9616/ 9515/ 9514/ 9513/ 9517/ 9613; With 5323/ 5327 Switch Kits MFR # 9506003
39. #Get your steps back to work with an exact-match replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379606
40. #CONTROL UNIT USE 9506003 MFR # 95060047 Superseded: see description
41. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
42. #Entry Step Wiring Harness; Use To Connect The KwikTest Diagnostic Tool To Step Control Module; 4 Way Plug; With Packard Connector Pigtail MFR # 909306000 Superseded: see description
43. #Entry Step Wiring Harness; Use With Kwikee 32 Series Double Step And Platinum Series Steps MFR # 9306000 Superseded: see description
44. #Get your steps back to work with an exact-match 4-way plug with Packard connector from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement plug is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 369243
45. #NO GENERIC NAME; Plug 4 Wayw/Packard Conne MFR # 9336
46. #CONTROL UNIT BLUE MFR # 8310K
47. #CONVERSION KIT USE 909770000 MFR # 9572 Superseded: see description

35 Series › Replacement Step

Components

8 items

1. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert® will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3691461
2. #SERIES 35 STEP FRAME ONLY MFR # 8035K
3. #Entry Step; Single Series; Single Electric Folding Step; 24 Inch Width x 11 Inch Depth; With 4 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 5-3/4 Inch Collapsed Height; Without Step Control MFR # 903500906
4. #Entry Step; Single Series; Single Electric Folding Step; 24 Inch Width x 11 Inch Depth; With 4 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 5-3/4 Inch Collapsed Height; With Step Control MFR # 903509025
5. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 369146
6. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert® will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3691462
7. #STEP,SINGLE USE 3509025 35 SERIES MFR # 3506025 Superseded: see description
8. #Entry Step; Single Electric Folding Step; 24 Inch Width x 11 Inch Depth; With 4 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 5-3/4 Inch Collapsed Height; Not Illuminated; With Step Control MFR # 903509000

28 Series › Replacement Step

Components

9 items

1. #Entry Step; Single Series; Single Electric Folding Step; 23-3/4 Inch Width x 10 Inch Depth; With 7 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 5.88 Inch Collapsed Height; With Step Control MFR # 902809025
2. #Entry Step; Single Electric Folding Step; 23-3/4 Inch Width x 10 Inch Depth; With 7 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 5.88 Inch Collapsed Height; Not Illuminated; With Step Control MFR # 902809000
3. #Entry Step; Single Series; Single Electric Folding Step; 23-3/4 Inch Width x 10 Inch Depth; With 7 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 5.88 Inch Collapsed Height; Without Step Control MFR # 902800906
4. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3747453
5. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert® will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3747452
6. #STEP,SINGLE USE 902809025 28 SERIES MFR # 2806025 Superseded: see description
7. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert make it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like anti-slip grips on each step for increased traction. MFR # 3747451
8. #Looking for a way to upgrade your RV steps? Kwikee Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3747457
9. #STEP,SINGLE 28 SERIES W/O CONTROL UNIT MFR # 2800016

26 Series › Replacement Step

Components

7 items

1. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 371136
2. #STEP,SINGLE USE 902609025 26 SERIES MFR # 2606025 Superseded: see description
3. #STEP,SINGL USE 902600906 26 SERIES MFR # 2600PM16 Superseded: see description
4. #Entry Step; Single Electric Folding Step; 23-1/2 Inch Width x 8-1/2 Inch Depth; With 5 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 6.88 Inch Collapsed Height; Not Illuminated; With Step Control MFR # 902609000
5. #Looking for a way to upgrade your RV steps? Kwikee electric RV steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. These steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods, stainless-steel bushings, and a black, powder-coated finish. The Kwikee step assembly also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3711361
6. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert® will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3711363
7. #Entry Step; Single Series; Single Electric Folding Step; 23-1/2 Inch Width x 8-1/2 Inch Depth; With 5 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 6.88 Inch Collapsed Height; With Step Control MFR # 902609025

31 Series › Replacement Step

Components

3 items

1. #STEP,SINGLE ELECTRIC W/O CONTROL UNIT MFR # 3100016
2. #STEP, SERIES 31 W/MOTOR,SWITCH & CONTROL MFR # 903109025
3. #STEP,SINGLE USE 903109025 31 SER W/MOTOR & CONTROL UNIT MFR # 3106025 Superseded: see description

30 Series Van Step › Replacement Step

Components

2 items

1. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 369411
2. #Entry Step; Single Electric Folding Step; 36 Inch Width x 16-3/4 Inch Depth; With 7-1/2 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 7-1/4 Inch Collapsed Height; Not Illuminated; With Wiring Harness And Switch MFR # 3694113

30 Series Van Step › Parts List

Components

2 items

1. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 369411
2. #Entry Step; Single Electric Folding Step; 36 Inch Width x 16-3/4 Inch Depth; With 7-1/2 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 7-1/4 Inch Collapsed Height; Not Illuminated; With Wiring Harness And Switch MFR # 3694113

Revolution Series › Replacement Step

Components

3 items

1. #Looking for a way to upgrade your RV steps? Kwikee® Revolution Single Electric RV Steps by Lippert® will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Revolution step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 372604
2. #Entry Step; Revolution; Single Electric Folding Step; 750 Pound Weight Capacity; Black Powder Coated Steel; Without Lighting MFR # 3726041
3. #Entry Step; Revolution Series; Single Step; Permanent Mount; Square Edge Step; Steel MFR # 9010000880

36 Series › Replacement Step

Components

6 items

1. #Entry Step; Single Series; Single Electric Folding Step; 30 Inch Width x 12 Inch Depth; With 5 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 5.56 Inch Collapsed Height; Not Illuminated; Without Step Control MFR # 903600906
2. #STEP,36 SERIES USE 903600906 W/MOTOR & SWITCH KIT MFR # 903600016 Superseded: see description
3. #Entry Step; Series 36; Single Electric Folding Step; 30 Inch Tread Width x 10-3/4 Inch Depth; With 5 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; MFR # 372296
4. #Entry Step; Single Series; Single Electric Folding Step; 30 Inch Width x 12 Inch Depth; With 5 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 5.56 Inch Collapsed Height; Not Illuminated; With Step Control And Switch MFR # 903609025
5. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert® will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3756271
6. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3756272

30 Series › Replacement Step

Components

9 items

1. #SERIES 30 STEP FRAME ONLY MFR # 8030K
2. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3694112
3. #Entry Step; Single Electric Folding Step; 36 Inch Width x 16-3/4 Inch Depth; With 7-1/2 Inch Rise; Up To 750 Pound Weight Capacity; Permanent Mount; Square Edge Steps; Powder Coated/ Heavy Gauge Steel; 7-1/4 Inch Collapsed Height; Not Illuminated; With Wiring Harness And Switch MFR # 903009002
4. #Entry Step; Single Series; Single Electric Folding Step; 36 Inch Width x 16-3/4 Inch Depth; With 7- 1/2 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 7-1/4 Inch Collapsed Height; Without Step Control MFR # 903000900
5. #Single Electric Folding Step; 36 Inch Width x 16- 3/4 Inch Depth; With 7-1/2 Inch Rise MFR # 903000000
6. #STEP,SINGLE USE 903009000 30 SERIES MFR # 3006000 Superseded: see description
7. #Entry Step; Single Series; Single Electric Folding Step; 36 Inch Width x 16-3/4 Inch Depth; With 7- 1/2 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 7-1/4 Inch Collapsed Height; With Step Control MFR # 903009000
8. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 369411
9. #STEP,30" HEAVY DUTY MANUAL SINGLE TREAD MFR # 900103

28 Series › Exploded View

Components

36 items

1. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
2. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #BEARING USE 5208K MFR # 9045 Superseded: see description
5. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
6. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 28/ 31/ 37/ 39; With Step Motor/ Pin And Clevis Kit/ B Linkage Gear Box MFR # 909772000
7. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
8. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
9. #NO GENERIC NAME; Conversion Kit Use 909772 MFR # 9570 Superseded: see description
10. #CONVERSION KIT USE 909772000 W/DELCO MOTOR MFR # 9576 Superseded: see description
11. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert® supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for triple or quad Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 379769
12. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781006
13. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
14. #TRAILER JACKS; Gear & Shaft MFR # 9528
15. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
16. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
17. #Entry Step Gear; Replacement Part For Series Steps 28/ 31/ 37/ 39; With Gear/ B Linkage Straight MFR # 1101426
18. #Entry Step Linkage Arm; Kwikee ®; For 28/ 31/ 33/ 37/ 39 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Straight; 2- 9/16 Inch Drive Link Shaft; With Linkage Assembly B/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909533000 MFR # 379648
19. #Entry Step Linkage Arm; Kwikee ®; For 28/ 31/ 33/ 37/ 39 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Straight; 2-9/16 Inch Drive Link Shaft; With Linkage Assembly B/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909533000 MFR # 9533
20. #Entry Step Linkage Arm; Replacement Parts For 28/ 31/ 33/ 37/ 39 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly B/ Cotter Pin/ Clevis Pin MFR # 909533000
21. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
22. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
23. #Entry Step Linkage Arm Clevis Pin; Entry Step Hardware; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 5205K Superseded: see description
24. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
25. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
26. #GEAR CASE ASM MFR # 9524
27. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
28. #GEAR CASE MFR # 9527
29. #AIR COMMAND SINGLE ECU; MFR # 9535
30. #Entry Step Control Module; Replaces Old Style Control Module For 9616/ 9515/ 9514/ 9513/ 9517/ 9613; With 5323/ 5327 Switch Kits MFR # 9506003
31. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
32. #RT FUSE BLOCK 6 POS W/ LED INDICATI MFR # 8028
33. #Entry Step Wiring Harness; Use With Kwikee 32 Series Double Step And Platinum Series Steps MFR # 9306000 Superseded: see description
34. #CONTROL UNIT USE 9506003 W/LAST OUT FEATURE MFR # 9506000 Superseded: see description
35. #CONTROL UNIT USE 9506003 MFR # 95060047 Superseded: see description
36. #Entry Step Switch; Replacement Power Switch For RV Electric Sliding Steps; Plunger Door Switch; Normally Open; Black MFR # 905328000

29 Series › Replacement › Replacement Step

Components

2 items

1. #Entry Step; Single Series; Single Electric Folding Step; 23-3/4 Inch Width x 10 Inch Depth; With 7 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 4-1/4 Inch Collapsed Height; With Step Control MFR # 903909025
2. #REFRIGERATOR BODY MFR # *

Revolution Series › Parts List

Components

2 items

1. #Get your steps back to work with an exact-match replacement step control module from Lippert™. When it comes to fixing your Kwikee® Revolution Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control module assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 363980
2. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Revolution Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 380073

33 Series › Step Motor Assembly

Components

52 items

1. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
2. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
5. #BEARING USE 5208K MFR # 9045 Superseded: see description
6. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781005
7. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Step Motor/ Pin And Clevis Kit/ A Linkage Gear Box MFR # 909770000
8. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert® supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for triple or quad Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 379145
9. #MOTOR,USED W/ORNG OR WHT CNTRLS MFR # 9520
10. #Entry Step Control Module; For Use With 22/ 23/ 26/ 28/ 30/ 31/ 32/ 33/ 34/ 35/ 36/ 37/ 38/ 39/ 40/ MFR # 909510000 Superseded: see description
11. #CONVERSION KIT USE 909770000 MFR # 9572 Superseded: see description
12. #Get your steps back to work with an exact-match 9510 replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379146
13. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
14. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
15. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
16. #TRAILER JACKS; Gear & Shaft MFR # 9528
17. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
18. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
19. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 9534
20. #Entry Step Gear; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Gear/ A Linkage Curved MFR # 1101425
21. #Entry Step Linkage Arm; Replacement Parts For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly A/ Cotter Pin/ Clevis Pin MFR # 909534000
22. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 379649
23. #Kwikee® Gear Box Linkage with “A" by Lippert® is specifically designed for certain electric steps in the Kwikee® series. MFR # 379160
24. #Entry Step Linkage Arm Clevis Pin; Entry Step Hardware; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 5205K Superseded: see description
25. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
26. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
27. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
28. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
29. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
30. #GEAR CASE ASM MFR # 9524
31. #GEAR CASE MFR # 9527
32. #AIR COMMAND SINGLE ECU; MFR # 9535
33. #LEADWIRE KIT MFR # 9537
34. #Entry Step Rug; Self Adhesive; 21 Inch Width; Yellow; Glow In The Dark; Replacement MFR # 909342000
35. #The perfect companion for any Kwikee® RV step, the Kwikee Glow-in-the-Dark tread strip will have your RV's steps glowing with more safety and convenience. Designed with a luminating, phosphorous glow-in-the-dark strip, a reflective strip and non-slip treading -- this easy-to-install tread strip makes your RV's stairs easier to see at night and it enhances the treading on your steps. This is a simple way to help make your campsite safer for everybody -- plus, the kids will love your glow-in-the-dark steps! MFR # 379600
36. #Get your steps back to work with an exact-match step light from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement light is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379414
37. #Get your steps back to work with an exact-match replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379606
38. #Entry Step Switch; Replacement Power Switch For RV Electric Sliding Steps; Plunger Door Switch; Normally Open; Black MFR # 5328000
39. #Entry Step Control Module; Replaces Old Style Control Module For 9616/ 9515/ 9514/ 9513/ 9517/ 9613; With 5323/ 5327 Switch Kits MFR # 9506003
40. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
41. #Entry Step Switch; Replacement Power Switch For RV Electric Sliding Steps; Plunger Door Switch; Normally Open; Black MFR # 905328000
42. #Get your steps back to work with an exact-match pleated plunger door switch from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement switch assembly is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379407
43. #CONTROL UNIT USE 9506003 W/LAST OUT FEATURE MFR # 9506000 Superseded: see description
44. #CONTROL UNIT USE 9506003 MFR # 95060047 Superseded: see description
45. #Entry Step Wiring Harness; Use To Connect The KwikTest Diagnostic Tool To Step Control Module; 4 Way Plug; With Packard Connector Pigtail MFR # 909306000 Superseded: see description
46. #Entry Step Wiring Harness; Use With Kwikee 32 Series Double Step And Platinum Series Steps MFR # 9306000 Superseded: see description
47. #NO GENERIC NAME; Plug 4 Wayw/Packard Conne MFR # 909336
48. #Get your steps back to work with an exact-match 4-way plug with Packard connector from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement plug is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 369243
49. #& 39 SERIES STEPS THE PART # FOR THE HARNESS THAT PLUGS INTO THIS MOTOR IS 180993...,, MFR # 38
50. #SERIES 33 STEP FRAME ONLY MFR # 8033
51. #CONVERSION KIT USE 909770000 MFR # 9577 Superseded: see description
52. #CONTROL UNIT BLUE MFR # 8310K

26 Series › Exploded View

Components

36 items

1. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
2. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #BEARING USE 5208K MFR # 9045 Superseded: see description
5. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
6. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
7. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 26; With Step Motor/ Pin And Clevis Kit/ C Linkage Gear Box MFR # 909774000
8. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
9. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
10. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781007
11. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
12. #TRAILER JACKS; Gear & Shaft MFR # 9528
13. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
14. #Entry Step Gear; Replacement Part For Series Steps 26; With Gear/ C Linkage Straight MFR # 1101427
15. #Entry Step Linkage Arm; Kwikee ®; For 26 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Straight; 2-7/16 Inch Drive Link Shaft; With Linkage Assembly C/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909532000 MFR # 9532
16. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
17. #Entry Step Linkage Arm Clevis Pin; Entry Step Hardware; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 5205K Superseded: see description
18. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
19. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
20. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
21. #Get your steps back to work with an exact-match 9510 replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379146
22. #Entry Step Control Module; For Use With 22/ 23/ 26/ 28/ 30/ 31/ 32/ 33/ 34/ 35/ 36/ 37/ 38/ 39/ 40/ MFR # 909510000 Superseded: see description
23. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
24. #GEAR CASE ASM MFR # 9524
25. #GEAR CASE MFR # 9527
26. #AIR COMMAND SINGLE ECU; MFR # 9535
27. #LEADWIRE KIT MFR # 9537
28. #Entry Step Wiring Harness; Use With Kwikee 32 Series Double Step And Platinum Series Steps MFR # 9306000 Superseded: see description
29. #Get your steps back to work with an exact-match 4-way plug with Packard connector from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement plug is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 369243
30. #CONVERSION KIT USE 909774000 MFR # 9574 Superseded: see description
31. #Entry Step Control Module; Replaces Old Style Control Module For 9616/ 9515/ 9514/ 9513/ 9517/ 9613; With 5323/ 5327 Switch Kits MFR # 9506003
32. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
33. #CONTROL UNIT USE 9506003 W/LAST OUT FEATURE MFR # 9506000 Superseded: see description
34. #BLOCK 12 POS W/GROUND & LED IND MFR # 8026
35. #CONTROL UNIT USE 9506003 MFR # 95060047 Superseded: see description
36. #Get your steps back to work with an exact-match replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379606

30 Series › Exploded View

Components

40 items

1. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
2. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
5. #BEARING USE 5208K MFR # 9045 Superseded: see description
6. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
7. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781005
8. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
9. #CONVERSION KIT USE 909770000 MFR # 9572 Superseded: see description
10. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert® supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for triple or quad Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 379145
11. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Step Motor/ Pin And Clevis Kit/ A Linkage Gear Box MFR # 909770000
12. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
13. #TRAILER JACKS; Gear & Shaft MFR # 9528
14. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
15. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
16. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 9534
17. #Kwikee® Gear Box Linkage with “A" by Lippert® is specifically designed for certain electric steps in the Kwikee® series. MFR # 379160
18. #Entry Step Linkage Arm; Replacement Parts For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly A/ Cotter Pin/ Clevis Pin MFR # 909534000
19. #Entry Step Gear; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Gear/ A Linkage Curved MFR # 1101425
20. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 379649
21. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
22. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
23. #Entry Step Linkage Arm Clevis Pin; Entry Step Hardware; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 5205K Superseded: see description
24. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
25. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
26. #GEAR CASE ASM MFR # 9524
27. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
28. #GEAR CASE MFR # 9527
29. #AIR COMMAND SINGLE ECU; MFR # 9535
30. #LEADWIRE KIT MFR # 9537
31. #& 39 SERIES STEPS THE PART # FOR THE HARNESS THAT PLUGS INTO THIS MOTOR IS 180993...,, MFR # 38
32. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
33. #Entry Step Switch; Replacement Power Switch For RV Electric Sliding Steps; Plunger Door Switch; Normally Open; Black MFR # 5328000
34. #Get your steps back to work with an exact-match 4-way plug with Packard connector from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement plug is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 369243
35. #NO GENERIC NAME; Plug 4 Wayw/Packard Conne MFR # 9336
36. #Entry Step Switch; Replacement Power Switch For RV Electric Sliding Steps; Plunger Door Switch; Normally Open; Black MFR # 905328000
37. #Entry Step Control Module; For Use With 22/ 23/ 26/ 28/ 30/ 31/ 32/ 33/ 34/ 35/ 36/ 37/ 38/ 39/ 40/ MFR # 909510000 Superseded: see description
38. #The perfect companion for any Kwikee® RV step, the Kwikee Glow-in-the-Dark tread strip will have your RV's steps glowing with more safety and convenience. Designed with a luminating, phosphorous glow-in-the-dark strip, a reflective strip and non-slip treading -- this easy-to-install tread strip makes your RV's stairs easier to see at night and it enhances the treading on your steps. This is a simple way to help make your campsite safer for everybody -- plus, the kids will love your glow-in-the-dark steps! MFR # 379600
39. #Get your steps back to work with an exact-match pleated plunger door switch from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement switch assembly is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379407
40. #Get your steps back to work with an exact-match replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379606

37 Series › Replacement Step

Components

8 items

1. #STEP,SINGLE ELECTRIC W/O CONTROL UNIT MFR # 3700016
2. #SERIES 37 W/MOTOR & SWITCH -C MFR # 903706025
3. #37 SERIES STEP FRAME BLACK MFR # 8037K
4. #SERIES 37 USE 903709025 W/MOTOR & SWITCH MFR # 3716000 Superseded: see description
5. #SERIES 37 STEP FRAME ONLY MFR # 908037000
6. #STEP,SINGLE 37 SERIES MFR # 903709025
7. #STEP,SINGLE ELECTRIC W/CONTROL UNIT MFR # 3707025
8. #STEP,SINGLE 37 SERIES MFR # 3707000

39 Series › Replacement Step

Components

6 items

1. #STEP,SINGL USE 903900906 39 SER W/MOTOR SWITCH KIT MFR # 3900016 Superseded: see description
2. #Looking for a way to upgrade your RV steps? Kwikee® Electric RV Steps by Lippert® will automatically extend and retract when your RV's entryway door opens and closes — making it easier for you and your guests to get in and out of your camper. Known by RV owners for over 40 years, Kwikee steps are loved for their durable build and reliable operation. Made right here in America, these steps are constructed from heavy-gauge steel, waterproof, sealed wiring connections, solid steel drive rods and stainless-steel bushings and a black, powder-coated finish. The Kwikee step assembly also comes with a hidden light that illuminates to make it easy going in and out of your RV in the dark. It also has added safety features like automatic retraction when an obstacle is sensed near your stairs and anti-slip grips on each step for increased traction. MFR # 3724742
3. #Entry Step; Series 39; Single Electric Folding Step; 23-3/4 Inch Tread Width x 10 Inch Depth; With 7 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; MFR # 3724741
4. #STEPS & STEP RUGS RV; Series 39 Step Frame Only MFR # 3724744
5. #Entry Step; Single Series; Single Electric Folding Step; 23-3/4 Inch Width x 10 Inch Depth; With 7 Inch Rise; Up To 750 Pound Weight Capacity; Powder Coated/ Heavy Gauge Steel; 4-1/4 Inch Collapsed Height; Without Step Control MFR # 903900906
6. #STEP,SINGLE USE 3909025 W/MOTOR,CONTROL UNIT & SWITCH MFR # 3906025 Superseded: see description

35 Series › Step Motor Assembly

Components

50 items

1. #PINION ASM W/SHAFT MFR # LIP379645
2. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # M6V379646
3. #BRACKET KIT,MOTOR BEARING MFR # 9536
4. #PARTS KIT F/PERMANENT MAGNET MOTOR MFR # 909530000
5. #BEARING USE 5208K MFR # 9045 Superseded: see description
6. #Entry Step Gear; Replacement Pinion Gear For Kwikee Entry Steps; With Shaft MFR # 9529
7. #MISC. PARTS KIT USE 909530000 MFR # 5208K Superseded: see description
8. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379608
9. #Get your steps back to work with an exact-match replacement motor from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This motor assembly is just like your original motor. In no time, your steps will be operating like usual at the campsite. MFR # 379147
10. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert® supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for triple or quad Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 379145
11. #CONVERSION KIT USE 909770000 MFR # 9572 Superseded: see description
12. #CONVERSION KIT USE 909770000 MFR # 9577 Superseded: see description
13. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Motor And Screws MFR # 1101428
14. #Looking to upgrade or replace the motor unit on your Kwikee RV steps? Lippert supplies a motor upgrade kit that lets you enhance or repair your step assembly with total ease. This kit is designed for single and double Kwikee step assemblies and comes with all equipment needed for a swift, easy installation so you can get back to enjoying the benefits of your electric RV steps. MFR # 781005
15. #Entry Step Motor/ Gearbox Upgrade; Replacement Part For Series Steps 22/ 23/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Step Motor/ Pin And Clevis Kit/ A Linkage Gear Box MFR # 909770000
16. #TRAILER JACKS; Gear & Shaft MFR # 9528
17. #STEPS & STEP RUGS RV; Gear Adapter MFR # 9556
18. #ADAPTOR GEAR SHAFT USE 909530000 MFR # 9557 Superseded: see description
19. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 9534
20. #Entry Step Linkage Arm; Kwikee ®; For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps Prior To The Integrated Motor Gear Linkage (IMGL) Upgrade; Curved; With Linkage Assembly A/ Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Cotter Pin/ Clevis Pin; Kwikee 909534000 MFR # 379649
21. #Entry Step Gear; Replacement Part For Series Steps 22/ 23/ 28A/ 30/ 32/ 33/ 34/ 35/ 36/ 38/ 40; With Gear/ A Linkage Curved MFR # 1101425
22. #Entry Step Linkage Arm; Replacement Parts For 22/ 30/ 32/ 34/ 35/ 36/ 38 Series Steps; With Self Tapping Hexagonal Washer Headed Screw/ Bearing/ Linkage Assembly A/ Cotter Pin/ Clevis Pin MFR # 909534000
23. #Kwikee® Gear Box Linkage with “A" by Lippert® is specifically designed for certain electric steps in the Kwikee® series. MFR # 379160
24. #Get your steps back to work with an exact-match cotter and clevis pin assembly from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement pin kit is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 379178
25. #Entry Step Linkage Arm Clevis Pin; Entry Step Hardware; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 5205K Superseded: see description
26. #Entry Step Linkage Arm Clevis Pin; Fits Kwikee Entry Steps With A Linkage Arm That Attaches To The Step Frame; Not For Use With The 25 Series Steps; With Split Pin And Clevis MFR # 905205000 Superseded: see description
27. #PIN,COTTER USE 5205K MFR # 9018K Superseded: see description
28. #PIN,COTTER USE 5205K MFR # 9017 Superseded: see description
29. #STEPS & STEP RUGS RV; GEAR KIT MFR # 909525000
30. #GEAR CASE ASM MFR # 9524
31. #GEAR CASE MFR # 9527
32. #AIR COMMAND SINGLE ECU; MFR # 9535
33. #LEADWIRE KIT MFR # 9537
34. #Entry Step Rug; Self Adhesive; 21 Inch Width; Yellow; Glow In The Dark; Replacement MFR # 909342000
35. #The perfect companion for any Kwikee® RV step, the Kwikee Glow-in-the-Dark tread strip will have your RV's steps glowing with more safety and convenience. Designed with a luminating, phosphorous glow-in-the-dark strip, a reflective strip and non-slip treading -- this easy-to-install tread strip makes your RV's stairs easier to see at night and it enhances the treading on your steps. This is a simple way to help make your campsite safer for everybody -- plus, the kids will love your glow-in-the-dark steps! MFR # 379600
36. #Entry Step Control Module; Replacement Control Unit For Pre IMGL 9510 Control Steps; With 5323 And 5327 Switches MFR # 909506003
37. #Get your steps back to work with an exact-match 9510 replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379146
38. #Entry Step Control Module; For Use With 22/ 23/ 26/ 28/ 30/ 31/ 32/ 33/ 34/ 35/ 36/ 37/ 38/ 39/ 40/ MFR # 909510000 Superseded: see description
39. #CONTROL UNIT USE 9506003 MFR # 95060047 Superseded: see description
40. #Entry Step Control Module; Replaces Old Style Control Module For 9616/ 9515/ 9514/ 9513/ 9517/ 9613; With 5323/ 5327 Switch Kits MFR # 9506003
41. #Get your steps back to work with an exact-match replacement control unit from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This control unit assembly is just like your original unit. In no time, your steps will be operating like usual at the campsite. MFR # 379606
42. #CONTROL UNIT USE 9506003 W/LAST OUT FEATURE MFR # 9506000 Superseded: see description
43. #Entry Step Wiring Harness; Use With Kwikee 32 Series Double Step And Platinum Series Steps MFR # 9306000 Superseded: see description
44. #NO GENERIC NAME; Plug 4 Wayw/Packard Conne MFR # 9336
45. #Entry Step Wiring Harness; Use To Connect The KwikTest Diagnostic Tool To Step Control Module; 4 Way Plug; With Packard Connector Pigtail MFR # 909306000 Superseded: see description
46. #Get your steps back to work with an exact-match 4-way plug with Packard connector from Lippert™. When it comes to fixing your Kwikee® Electric RV Steps, Lippert keeps you from looking high and low for parts that work with your equipment. This replacement plug is just like your original part. In no time, your steps will be operating like usual at the campsite. MFR # 369243
47. #& 39 SERIES STEPS THE PART # FOR THE HARNESS THAT PLUGS INTO THIS MOTOR IS 180993...,, MFR # 38
48. #SERIES 35 STEP FRAME ONLY MFR # 8035K
49. #CONTROL UNIT BLUE MFR # 8310K
50. #12V EXTENSION CORD MFR # 9331
