Suburban Nt Series NT12SP Parts Diagram

Furnace · 1 diagram sheet · 2 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagram for the Suburban Nt Series NT12SP RV furnace: 2 manufacturer part numbers. 2 parts are marked as superseded — the description gives the replacement number to order instead.

The rating plate is on the furnace chassis — slide the unit's front panel off or look just inside the exterior access door. Suburban models (SF-30F, NT-34SP …) changed burners and boards over the years, so the serial number's date range matters as much as the model.

Replacement Furnace

Components

2 items

1. #USE 79-1814 MFR # NT12SEN Superseded: see description
2. #USE 79-1806 MFR # NT12SN Superseded: see description
