Dometic DM2882 Product # 9600007234 Parts Diagram

Refrigerator · 1 diagram sheet · 1 part · by Andrew Strick, mobile RV technician

OEM exploded parts diagram for the Dometic DM2882 Product # 9600007234 RV refrigerator: 1 manufacturer part numbers.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Replacement

Components

1 item

1. #Refrigerator; Americana II; Dual Compartment 2 Door Refrigerator With Freezer; Permanent Bolt-In; Right Hand Hinge; 8 Cubic Foot; 60-3/4 Inch Height x 24-7/8 Inch Width x 26 Inch Depth; 110 Volt AC; 2-Way Alternating Current/ LP Gas; Ice Maker; Eye-Level Electronic Control With Temperature Control; Black Frame; With Fan/ Door Bins/ LED Light/ Ergonomic Handle With 'Click-Lock' Sound When Locked; Door Panels Must Be Ordered Separately MFR # DM882RBIM2
