Dometic DMC2841 Product # 936001576 Parts Diagram · Door Assembly

Refrigerator · 4 assemblies · 4 diagram sheets · 71 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic DMC2841 Product # 936001576 RV refrigerator: 4 assemblies (Door Assembly, Cabinet Rear, Replacement Refrigerator, Cabinet Exterior & Interior) and 71 manufacturer part numbers.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Door Assembly

Components

16 items

1. #Door shelf, freezer compartment MFR # 4450010636
2. #DOOR DECOR STRIP, BLACK MFR # 385091902
3. #FREEZER DOOR ASSEMBLY MFR # 4450012371
4. #FREEZER DOOR PANEL CUSHION MFR # 293246907
5. #FRESH FOOD DOOR PANEL, SILVER, 527MM X 403MM MFR # 385140601
6. #FOAM DOOR ASM MFR # 4450012378
7. #PANEL STOP MFR # 293258801
8. #FRESH FOOD DOOR PANEL CUSHION 524MM X 980MM MFR # 293246906
9. #FRESH FOOD DOOR PANEL, SILVER, 527MM X 983MM MFR # 385140603
10. #AIRING POSITION CARD MFR # 385078101
11. #DOOR HANDLE, BLACK, 6/8 CU FT MFR # 385117402
12. #DOOR SHELF, LOWER, WHITE MFR # 293257501
13. #DOOR SHELF, MIDDLE, WHITE MFR # 293257601
14. #DOOR SHELF RAIL, WHITE MFR # 293258503
15. #FREEZER DOOR ASM MFR # 4450011261
16. #REFRIGERATOR DOOR ASM MFR # 4450012373

Cabinet Rear

Components

18 items

1. #PC BOARD COVER MFR # 4450011659
2. #MAIN PC BOARD MFR # 4450011795
3. #PC BOARD BASE MFR # 4450011660
4. #ANTI-STRAIN CLIP MFR # 293234201
5. #COMPRESSOR PLATE MFR # 4450010645
6. #LEFT HOLDER MFR # 4450010643
7. #PROTECT PLATE MFR # 4450003380
8. #RUBBER RING MFR # 4450002489
9. #RIGHT HOLDER MFR # 4450010642
10. #CONDENSER MFR # 4450010722
11. #dryer MFR # 4450001808
12. #DC FAN, 12V MFR # 4450010729
13. #COMPRESSOR FEET SHAFT MFR # 4450003510
14. #SOUND DEADENING COMPRESSOR FEET PADS MFR # 4450002483
15. #COMPRESSOR FEET CLIP MFR # 4450003033
16. #Compressor MFR # 4450001717
17. #POWER CORD MFR # 4450011680
18. #FLEX COMPLETE MFR # 4450011667

Replacement Refrigerator

Components

2 items

1. #REFRIGERATOR, 6 CU FT, LH, AC VOLTAGE MFR # DMC2841LB
2. #REFRIGERATORS & ICE MAKERS RV; AMERICANA DMC REFRIGERATORS MFR # DMC2841RB

Cabinet Exterior & Interior

Components

35 items

1. #APPLIANCE COMPONENTS RV; TOP D COR MFR # 293264107
2. #operating panel MFR # 4450012128
3. #CAP MFR # 4450010698
4. #HINGE PIN, UPPER MFR # 293264701
5. #HINGE, LEFT/RIGHT, BLACK MFR # 293264303
6. #ICE CUBE TRAY MFR # 293040000
7. #WIRE SHELF MFR # 4450010800
8. #SHELF RAIL, 416MM MFR # 200733721
9. #MILK SHELF STORAGE TRAY MFR # 293263601
10. #PLUG MFR # 293210101
11. #SHELF BACK HOLDER, WHITE MFR # 293069304
12. #WIRE MILK SHELF, WHITE, 501MM X 259MM MFR # 385032501
13. #SHELF RAIL, 218MM MFR # 200733712
14. #WIRE SHELF, WHITE, 501MM X 259.5MM MFR # 385032401
15. #WIRE SHELF, WHITE, 501MM X 222.5MM MFR # 385032402
16. #PLASTIC SHELF MFR # 4450011616
17. #CRISPER BIN, WHITE MFR # 293262101
18. #retainer for grid MFR # 4450009518
19. #PLUG MFR # 293210301
20. #FRONT BASE, PAINTED MFR # 293269003
21. #HINGE PLUG, BLACK MFR # 385058503
22. #HINGE HOLE PLUG, BLACK MFR # 293074007
23. #HINGE PIN, LOWER MFR # 293264901
24. #LAMP GLASS MFR # 4450010640
25. #SWITCH MFR # 385100001
26. #APPLIANCE COMPONENTS RV; 291 LED LAMP #207.7717.01 MFR # 4450006254
27. #LAMP HOUSING MFR # 4450010637
28. #HINGE PIN, MIDDLE, BLACK MFR # 293264802
29. #retainer decoration strip upper MFR # 4450003222
30. #NTC ASSEMBLY MFR # 4450010261
31. #NTC COVER MFR # 4450011623
32. #DOOR LATCH MFR # 293285501
33. #drainage hose white MFR # 293274911
34. #DISCHARGE PIPE PLUG MFR # 293211501
35. #BOTTOM RUNNER, STEEL MFR # 293266001
