Dometic DMR702 Product # 936002903 Parts Diagram · Exploded View

Refrigerator · 2 assemblies · 2 diagram sheets · 76 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic DMR702 Product # 936002903 RV refrigerator: 2 assemblies (Exploded View, Replacement) and 76 manufacturer part numbers. 3 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Exploded View

Components

75 items

1. #Refrigerator Door Bin; Replacement For Dometic DMR702 Series; Upper Door; 18-3/8 Inch Length x 2-3/4 Inch Depth x 3-7/8 Inch Height; Clear; Plastic MFR # 385151001
2. #APPLIANCE COMPONENTS RV; BUSHING, HINGE BLACK MFR # 2931171066
3. #door freezer compartment MFR # 4450008362
4. #Refrigerator Trim; Replacement For Dometic DMR702 Series Refrigerator; Bottom Of Freezer Section MFR # 4450007732
5. #APPLIANCE COMPONENTS RV; REFRIGERATOR - TRIM - HANDLE SIDE T MFR # 3851509012
6. #retainer bottles MFR # 385158501
7. #fixing clamp bottles MFR # 385151801
8. #Dometic 8-Series Refrigerator Main Control Board MFR # 4450018323
9. #S,CORD,AC POWER,1000MM,7,9,13, MFR # 2002699219
10. #cooling unit complete MFR # 4450008360
11. #hinge pin upper MFR # 293241501
12. #APPLIANCE COMPONENTS RV; HINGE UPPER MFR # 3851563019
13. #cabinet electronic MFR # 385152203
14. #APPLIANCE COMPONENTS RV; HINGE MIDDLE MFR # 3851564017
15. #Refrigerator Door Hinge; Replacement For Dometic NDR1062/ RM2652/ RM2663 Refrigerators; Fits Top Hinge; Black; Also Use New Number 29326430300 MFR # 2932648021 Superseded: see description
16. #Refrigerator Power Supply Circuit Board; Replacement For Dometic DMR702 Series Refrigerator MFR # 4450010940
17. #DISPLAY - RV; S, CVR, DISPLAY PCB, NEW LOGO MFR # 4450014859
18. #BOLT D=4.0X11MM MFR # 4450005802
19. #bar upper MFR # 385152001
20. #cover cap plastic MFR # 4450007759
21. #SIDE LIST MFR # 385151601
22. #FREEZER COMPARTMENT MFR # 3851576011
23. #rear-evaporator MFR # 4450003411
24. #GRATING FREEZER COMPARTMENT MFR # 385156901
25. #retainer compartment MFR # 4450007748
26. #grating fridge MFR # 385156902
27. #NO GENERIC NAME; WIRE SHELF MFR # 385156903
28. #compartment dairy MFR # 385155501
29. #COMPARTMENT VEGETABLES MFR # 385155401
30. #APPLIANCE COMPONENTS RV; REFRIGERATOR - CRISPER DRAWER - FOR MFR # 3851511018
31. #APPLIANCE COMPONENTS RV; DIVIDER MFR # 3851552012
32. #NTC MFR # 385105903
33. #PLUG MFR # 200230100
34. #DRIP PROTECTION MFR # 3851553010
35. #APPLIANCE COMPONENTS RV; REFRIGERATOR - BOTTOM DOOR TRIM/DEC MFR # 3851519011
36. #APPLIANCE COMPONENTS RV; TWIST PROTECTION MFR # 4450007753
37. #APPLIANCE COMPONENTS RV; HINGE LOWER MFR # 3851564025
38. #APPLIANCE COMPONENTS RV; PIN LOWER MFR # 3850269014
39. #APPLIANCE COMPONENTS RV; REFRIGERATOR - LIGHT HOUSING - 3851 MFR # 3851574016
40. #Refrigerator Light Bulb; Replacement For Dometic DMR702 Series Refrigerator MFR # 4450010552
41. #push button MFR # 4450007763
42. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
43. #protection MFR # 4450007755
44. #RETAINER SOLENOID VALVE MFR # 385037701
45. #PROTECTIVE PLATE MFR # 293112601
46. #COVER PLATE MFR # 3851300016
47. #DRAIN HOSE MFR # 4450017567
48. #DISCHARGE PIPE PLUG MFR # 293211501
49. #CAP, DRAIN HOSE MFR # 4450017252
50. #RETAINER ELECTRIC MFR # 385147401
51. #INLET PLATE MFR # 4450005050
52. #APPLIANCE COMPONENTS RV; S, TERMINAL BLOCK/WIRE PROT, VL3 MFR # 3858022027
53. #3858022019 MFR # 3858022019
54. #ANTI-STRAIN CLIP MFR # 293234201
55. #RETAINER THERMAL CUT-OUT MFR # 385139601
56. #RIVET MFR # 3858001070
57. #safety thermal switch MFR # 4450001841
58. #COVER PLATE,SIDE MFR # 3851301014
59. #COVER PLATE BACK MFR # 385130201
60. #Refrigerator Cooling Unit Heater Element; Use With Dometic Refrigerator Models DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ NDM1062/ NDR1062/ RM2652/ RM2852/ RM3862/ RM3962; 120 Volt; 325 Watt MFR # 3850644422 Superseded: see description
61. #RETAINER VENTILATOR MFR # 385157301
62. #RETAINER, VENTILATOR MFR # 4450011509
63. #ventilator MFR # 4450009628
64. #Dometic RM2652 Refrigerator Cooling Unit Assembly MFR # 4450001848
65. #Dometic Series 8 Refrigerator Door Bin White MFR # 3851331011
66. #SOLENOID VALVE MFR # 293261501
67. #Washer; Use With Dometic Refrigerators; 12.5 x 18.5 x 1 MFR # 3858010071 Superseded: see description
68. #nut copper MFR # 4450003722
69. #WASHER MFR # 200745700
70. #JET COMPLETE MFR # 200741921
71. #RETAINER TUBE MFR # 293065204
72. #electrode MFR # 4450010945
73. #NO GENERIC NAME;;REFRIGERATOR - BURNER TUBE ONLY - D MFR # 2007484047
74. #Dometic RM2652 Refrigerator Circuit Board Control Module MFR # 2932603018
75. #COVER GAS BURNER MFR # 293266101

Replacement

Components

1 item

1. #Refrigerator / Freezer;;Dual Compartment 2 Door Refrigerator With Freezer; 7 Cubic Foot; 54-3/4 Inc MFR # DMR702LBE
