Dometic FC140 Freezer Parts Diagram · Replacement Freezer

Refrigerator · 2 assemblies · 4 diagram sheets · 56 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic FC140 Freezer RV refrigerator: 2 assemblies (Replacement Freezer, Exploded View) and 56 manufacturer part numbers. 18 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Replacement Freezer

Components

1 item

1. #REFRIGERATORS & ICE MAKERS RV; NORCOLD COOLER/FREEZER MFR # MRFT40N

Exploded View

Components

55 items

1. #N/A CABINET, COMPLETE (WITH COOLING UNIT) MFR # 2960600118
2. #Refrigerator Door Panel MFR # 2960601108
3. #Refrigerator Gasket MFR # 2960072201
4. #Refrigerator Door Handle Screw MFR # 2960088603
5. #BASKET USE 2929427116 MFR # 2929427108 Superseded: see description
6. #BASKET, WHITE MFR # 2929427116
7. #BURNER COMPLETE WITH INJECTOR, SIZE 32 MFR # 2969626105
8. #APPLIANCE COMPONENTS RV MFR # 2960082119
9. #OLIVE RM182BEG RC150 TEG RM 182 MFR # 2922559006
10. #NUT USE 2922559006 MFR # 2922559022 Superseded: see description
11. #RING, SEALING USE 2922559006 MFR # 2922559030 Superseded: see description
12. #Nut MFR # 2928733001
13. #Igniter Electrode MFR # 2928727037
14. #APPLIANCE COMPONENTS RV MFR # 2928727003
15. #PIPE, BURNER MFR # 2928749033
16. #PIPE, BURNER MFR # 2928749031
17. #THERMOCOUPLE USE 2902551106 MFR # 2928742028 Superseded: see description
18. #THERMOCOUPLE USE 2928742028 MFR # 2928742010 Superseded: see description
19. #APPLIANCE COMPONENTS RV MFR # 2902551106
20. #APPLIANCE COMPONENTS RV MFR # 2922245002
21. #VALVE, SAFETY MFR # 293165
22. #Refrigerator Gas Valve; Use On Dometic Refrigerators; Safety Gas Valve MFR # 170755003MC Superseded: see description
23. #S,VALVE,THERMO ELEC,4601,S410G MFR # 2931656017
24. #VALVE, SAFETY USE 293165 MFR # 170755003 Superseded: see description
25. #VALVE, SAFETY USE 2931656017 MFR # 2922006016 Superseded: see description
26. #VALVE, SAFETY CV100041 NATURAL PIPE THREADING MFR # 8332921160100
27. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Gas Valves 0170755003/ 2000999009/ 2922006016; Use On Dometic Refrigerators Including RM2553/ RM2453/ RM2330 And RM4601; Safety Gas Valve MFR # 2931656017MC Superseded: see description
28. #APPLIANCE COMPONENTS RV MFR # 2922364019
29. #APPLIANCE COMPONENTS RV MFR # 2922396011
30. #APPLIANCE COMPONENTS RV MFR # 2922405028
31. #WASHER MFR # 7341156048
32. #APPLIANCE COMPONENTS RV MFR # 2922361007
33. #PIEZO IGNITER FOR DOMETIC REFRIGERATORS MFR # 2923024109MC
34. #LIGHTER, PIEZO USE 2922043050 MFR # 2923024000 Superseded: see description
35. #PIEZO MFR # 2923024109
36. #IGNITER, PIEZO USE 2923024000 RC150TED,182 MFR # 2922043045 Superseded: see description
37. #LIGHTER, PIEZO USE 2923024208 RC160EGP MFR # 2922043050 Superseded: see description
38. #Refrigerator Thermostat Control Assembly; For Dometic FC140 Freezer MFR # 2929363048
39. #Refrigerator Thermostat Control Knob; Use With Dometic RC1070/ RC1600EGP/ RC160TEG/ RC2000/ RC3000/ RC150TEG/ RC160E Refrigerators MFR # 531017708938 Superseded: see description
40. #KNOB, T-STAT USE 531017708938 FC140 MFR # 2922644006 Superseded: see description
41. #Refrigerator Thermostat Control Knob; Use With Dometic Refrigerator FC140 MFR # 2929487011 Superseded: see description
42. #ELEMENT, HEATING 160W/120V 2WIRE 3/8 X 7 1/4 MFR # 2960343123
43. #APPLIANCE COMPONENTS RV; Element Heating160W/12V 2 MFR # 2960342117
44. #APPLIANCE COMPONENTS RV; Element Heating160W/12V 2 MFR # 2960342117D
45. #HANDLE MFR # 2928504006
46. #FRAME, CONTROL FC140 MFR # 2960029300
47. #PANEL, CONTROL FC140 MFR # 2960062111
48. #BAFFLE, FLUE FC140 USE 46 MFR # 2960507826 Superseded: see description
49. #CHAIN F/LID FC140 MFR # 2929455018
50. #Refrigerator Power Cord Fuse; Use With Dometic RC2000/ RM182AGA/ RC1600EGP Refrigerators MFR # 2929368039 Superseded: see description
51. #CABLE RETAINER MFR # 2960034135
52. #PANEL, BACK MFR # 2960634109
53. #CABLE SLEEVE MFR # 2922368002
54. #Refrigerator Power Cord Fuse; Use With Dometic Refrigerator FC140 MFR # 2929354070 Superseded: see description
55. #LIGHTER,PIEZO MFR # 2923024208
