Dometic M Series M16B Parts Diagram

Refrigerator · 2 diagram sheets · 5 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic M Series M16B RV refrigerator: 5 manufacturer part numbers.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Burner Asm Type B

Components

5 items

1. #Ring, Large MFR # 63567002
2. #Head, Burner Large MFR # 64398001
3. #Ring, Small MFR # 63352009
4. #Head, Burner Small MFR # 63353007
5. #Orifice, LP #48 for Type "H" Burner Only MFR # 169352002
