Dometic M Series MA35A Parts Diagram

Refrigerator · 1 diagram sheet · 6 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagram for the Dometic M Series MA35A RV refrigerator: 6 manufacturer part numbers.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Burner Asm Type B

Components

6 items

1. #Head, Burner Large MFR # 64398001
2. #Ring, Small MFR # 63352009
3. #RING LARGE MFR # D7G63567002
4. #Burner, Ceramic Small MFR # 64356009
5. #Head, Burner Small MFR # 63353007
6. #Ring, Large MFR # 63567002
