Dometic RH250 Series RH250LD1 Minibar Parts Diagram · P#921864211 › Door Assembly

Refrigerator · 23 assemblies · 23 diagram sheets · 66 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RH250 Series RH250LD1 Minibar RV refrigerator: 23 assemblies (P#921864211 › Door Assembly, P#921864601 › Cabinet-front View Assembly, P#921864601 › Cooling Unit Assembly, P#921864211 › Cooling Unit Assembly, P#921864231 › Cabinet-front View Assembly and more) and 66 manufacturer part numbers. 5 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

P#921864211 › Door Assembly

Components

10 items

1. #DOOR W/SLIDE LOCK MFR # 2935749412
2. #SHELF, ASSEMBLY, UPPER MFR # 2923908004
3. #SHELF FINGERS MFR # 2923958009
4. #SHELF, BOTTLE LOWER DOOR MFR # 2924428010
5. #SHELF, ASSEMBLY, UPPER MFR # 2935366019
6. #SLIDER FOR MINI SHELF MFR # 2923826016
7. #SIGN PLATE, BROWN-BLACK, "DOMETIC" MFR # 2935717104
8. #BRACKET, SLIDE BAR, BROWN MFR # 2921090003
9. #APPLIANCE COMPONENTS RV; Bracket Ra138 MFR # 2921091100
10. #BRACKET, SLIDE BAR, GUIDE MFR # 2921277006

P#921864601 › Cabinet-front View Assembly

Components

23 items

1. #HINGE, UPPER RIGHT MFR # 2926415007
2. #HINGE, UPPER LEFT MFR # 2926414000
3. #HINGE, LOWER, RIGHT MFR # 2923257002
4. #HINGE, LOWER, LEFT MFR # 2923621004
5. #PIN, LOWER HINGE USE 2924892009 MFR # 2923005009 Superseded: see description
6. #Refrigerator Bolt; Use With Dometic Refrigerator RM2193; Upper Hinge Bolt MFR # 2924892009 Superseded: see description
7. #PIN, LOWER HINGE MFR # 2926265006
8. #FOOT MFR # 2923733006
9. #TUBE, DRAIN, NATURE MFR # 2926441128
10. #EVAPORATOR, RIGHT MFR # 2923851105
11. #EVAPORATOR, LEFT MFR # 2923852103
12. #RETAINER MFR # 2926236023
13. #RETAINER MFR # 2926235025
14. #SHELF, LOWER MFR # 2951002043
15. #SHELF, UPPER MFR # 2951011044
16. #LAMP, ASSEMBLY MFR # 2935714408
17. #BULB, E14, 6-10W, 110-140V MFR # 2923382101
18. #PLATE, STRIKE DOOR MFR # 2923677203
19. #CAP, HINGE, RIGHT MFR # 2935457008
20. #CAP, HINGE, LEFT MFR # 2935457107
21. #HINGE, COVER, BROWN MFR # 2926412004
22. #SCREW, FOR CAP MFR # 2935600003
23. #Refrigerator Control Knob; Thermostat Control Knob; Use With Dometic Refrigerators RH250/ RH250D/ RH250LD1 MFR # 2923835009 Superseded: see description

P#921864601 › Cooling Unit Assembly

Components

8 items

1. #COOLING UNIT W/ HEATING ELEMENT RECON MFR # 2935311106R
2. #COOLING UNIT RH260 W/HTR & FREEZER TUBE - THIS COOLING UNIT HAS NO FREEZER TUBE, BUT IT DOES COME W/THE ELEMENT. FOR COOLING UNIT W/FREEZER TUBE, USE PART NUMBER 2935310108N MFR # 2935311106N Superseded: see description
3. #COAT, INSULATION MFR # 2924082007
4. #APPLIANCE COMPONENTS RV; Insulation MFR # 2926680030
5. #LID, UPPER, BOILER MFR # 2924063007
6. #LID LOWER BOILER MFR # 2924089002
7. #Refrigerator Drip Tray; Replacement For Dometic RML8330/ RML8555/ RM7851L Refrigerators; For Fresh Food Compartment; By Burner Assembly MFR # 2923320002
8. #HEATING ELEMENT, 95W, 120V MFR # 2924439108

P#921864211 › Cooling Unit Assembly

Components

8 items

1. #COOLING UNIT W/ HEATING ELEMENT RECON MFR # 2935311106R
2. #COOLING UNIT RH260 W/HTR & FREEZER TUBE - THIS COOLING UNIT HAS NO FREEZER TUBE, BUT IT DOES COME W/THE ELEMENT. FOR COOLING UNIT W/FREEZER TUBE, USE PART NUMBER 2935310108N MFR # 2935311106N Superseded: see description
3. #COAT, INSULATION MFR # 2924082007
4. #APPLIANCE COMPONENTS RV; Insulation MFR # 2926680030
5. #LID, UPPER, BOILER MFR # 2924063007
6. #LID LOWER BOILER MFR # 2924089002
7. #Refrigerator Drip Tray; Replacement For Dometic RML8330/ RML8555/ RM7851L Refrigerators; For Fresh Food Compartment; By Burner Assembly MFR # 2923320002
8. #HEATING ELEMENT, 95W, 120V MFR # 2924439108

P#921864231 › Cabinet-front View Assembly

Components

23 items

1. #HINGE, UPPER RIGHT MFR # 2926415007
2. #HINGE, UPPER LEFT MFR # 2926414000
3. #HINGE, LOWER, RIGHT MFR # 2923257002
4. #HINGE, LOWER, LEFT MFR # 2923621004
5. #Refrigerator Bolt; Use With Dometic Refrigerator RM2193; Upper Hinge Bolt MFR # 2924892009 Superseded: see description
6. #PIN, LOWER HINGE USE 2924892009 MFR # 2923005009 Superseded: see description
7. #PIN, LOWER HINGE MFR # 2926265006
8. #FOOT MFR # 2923733006
9. #TUBE, DRAIN, NATURE MFR # 2926441128
10. #EVAPORATOR, RIGHT MFR # 2923851105
11. #EVAPORATOR, LEFT MFR # 2923852103
12. #RETAINER MFR # 2926236023
13. #RETAINER MFR # 2926235025
14. #SHELF, LOWER MFR # 2951002043
15. #SHELF, UPPER MFR # 2951011044
16. #LAMP, ASSEMBLY MFR # 2935714408
17. #BULB, E14, 6-10W, 110-140V MFR # 2923382101
18. #PLATE, STRIKE DOOR MFR # 2923677203
19. #CAP, HINGE, RIGHT MFR # 2935457008
20. #CAP, HINGE, LEFT MFR # 2935457107
21. #HINGE, COVER, BROWN MFR # 2926412004
22. #SCREW, FOR CAP MFR # 2935600003
23. #Refrigerator Control Knob; Thermostat Control Knob; Use With Dometic Refrigerators RH250/ RH250D/ RH250LD1 MFR # 2923835009 Superseded: see description

P#921864221 › Cabinet-rear View Assembly

Components

9 items

1. #COVER, GRAY FROM 3/1/1990 MFR # 2923629113
2. #T-STAT, ELECTRIC W/CAPILLARY MFR # 2926531100
3. #NUT M10 RH25 MFR # 2927881009
4. #INSULATING PLATE MFR # 2923178004
5. #TERMINAL BLOCK, 4-POL. MFR # 2923079004
6. #APPLIANCE COMPONENTS RV; Relief Strain Blk. MFR # 2926560000
7. #CABLE, CLAMP, SIZE 8 MFR # 2926564002
8. #APPLIANCE COMPONENTS RV; Timer Automatic MFR # 2935492104
9. #ELECTRIC CORD MFR # 2923772087

P#921864201 › Cooling Unit Assembly

Components

8 items

1. #COOLING UNIT RH260 W/HTR & FREEZER TUBE - THIS COOLING UNIT HAS NO FREEZER TUBE, BUT IT DOES COME W/THE ELEMENT. FOR COOLING UNIT W/FREEZER TUBE, USE PART NUMBER 2935310108N MFR # 2935311106N Superseded: see description
2. #COOLING UNIT W/ HEATING ELEMENT RECON MFR # 2935311106R
3. #COAT, INSULATION MFR # 2924082007
4. #APPLIANCE COMPONENTS RV; Insulation MFR # 2926680030
5. #LID, UPPER, BOILER MFR # 2924063007
6. #LID LOWER BOILER MFR # 2924089002
7. #Refrigerator Drip Tray; Replacement For Dometic RML8330/ RML8555/ RM7851L Refrigerators; For Fresh Food Compartment; By Burner Assembly MFR # 2923320002
8. #HEATING ELEMENT, 95W, 120V MFR # 2924439108

P#921864201 › Cabinet-front View Assembly

Components

23 items

1. #HINGE, UPPER RIGHT MFR # 2926415007
2. #HINGE, UPPER LEFT MFR # 2926414000
3. #HINGE, LOWER, RIGHT MFR # 2923257002
4. #HINGE, LOWER, LEFT MFR # 2923621004
5. #Refrigerator Bolt; Use With Dometic Refrigerator RM2193; Upper Hinge Bolt MFR # 2924892009 Superseded: see description
6. #PIN, LOWER HINGE USE 2924892009 MFR # 2923005009 Superseded: see description
7. #PIN, LOWER HINGE MFR # 2926265006
8. #FOOT MFR # 2923733006
9. #TUBE, DRAIN, NATURE MFR # 2926441128
10. #EVAPORATOR, RIGHT MFR # 2923851105
11. #EVAPORATOR, LEFT MFR # 2923852103
12. #RETAINER MFR # 2926236023
13. #RETAINER MFR # 2926235025
14. #SHELF, LOWER MFR # 2951002043
15. #SHELF, UPPER MFR # 2951011044
16. #LAMP, ASSEMBLY MFR # 2935714408
17. #BULB, E14, 6-10W, 110-140V MFR # 2923382101
18. #PLATE, STRIKE DOOR MFR # 2923677203
19. #CAP, HINGE, RIGHT MFR # 2935457008
20. #CAP, HINGE, LEFT MFR # 2935457107
21. #HINGE, COVER, BROWN MFR # 2926412004
22. #SCREW, FOR CAP MFR # 2935600003
23. #Refrigerator Control Knob; Thermostat Control Knob; Use With Dometic Refrigerators RH250/ RH250D/ RH250LD1 MFR # 2923835009 Superseded: see description

P#921864231 › Cooling Unit Assembly

Components

8 items

1. #COOLING UNIT RH260 W/HTR & FREEZER TUBE - THIS COOLING UNIT HAS NO FREEZER TUBE, BUT IT DOES COME W/THE ELEMENT. FOR COOLING UNIT W/FREEZER TUBE, USE PART NUMBER 2935310108N MFR # 2935311106N Superseded: see description
2. #COOLING UNIT W/ HEATING ELEMENT RECON MFR # 2935311106R
3. #COAT, INSULATION MFR # 2924082007
4. #APPLIANCE COMPONENTS RV; Insulation MFR # 2926680030
5. #LID, UPPER, BOILER MFR # 2924063007
6. #LID LOWER BOILER MFR # 2924089002
7. #Refrigerator Drip Tray; Replacement For Dometic RML8330/ RML8555/ RM7851L Refrigerators; For Fresh Food Compartment; By Burner Assembly MFR # 2923320002
8. #HEATING ELEMENT, 95W, 120V MFR # 2924439108

P#921864601 › Cabinet-rear View Assembly

Components

9 items

1. #COVER, GRAY FROM 3/1/1990 MFR # 2923629113
2. #T-STAT, ELECTRIC W/CAPILLARY MFR # 2926531100
3. #NUT M10 RH25 MFR # 2927881009
4. #INSULATING PLATE MFR # 2923178004
5. #TERMINAL BLOCK, 4-POL. MFR # 2923079004
6. #APPLIANCE COMPONENTS RV; Relief Strain Blk. MFR # 2926560000
7. #CABLE, CLAMP, SIZE 8 MFR # 2926564002
8. #APPLIANCE COMPONENTS RV; Timer Automatic MFR # 2935492104
9. #ELECTRIC CORD MFR # 2923772087

P#921865401 › Cabinet-rear View Assembly

Components

9 items

1. #COVER, GRAY FROM 3/1/1990 MFR # 2923629113
2. #T-STAT, ELECTRIC W/CAPILLARY MFR # 2926531100
3. #NUT M10 RH25 MFR # 2927881009
4. #INSULATING PLATE MFR # 2923178004
5. #TERMINAL BLOCK, 4-POL. MFR # 2923079004
6. #APPLIANCE COMPONENTS RV; Relief Strain Blk. MFR # 2926560000
7. #CABLE, CLAMP, SIZE 8 MFR # 2926564002
8. #APPLIANCE COMPONENTS RV; Timer Automatic MFR # 2935492104
9. #ELECTRIC CORD MFR # 2923772087

P#921864231 › Cabinet-rear View Assembly

Components

9 items

1. #COVER, GRAY FROM 3/1/1990 MFR # 2923629113
2. #T-STAT, ELECTRIC W/CAPILLARY MFR # 2926531100
3. #NUT M10 RH25 MFR # 2927881009
4. #INSULATING PLATE MFR # 2923178004
5. #TERMINAL BLOCK, 4-POL. MFR # 2923079004
6. #APPLIANCE COMPONENTS RV; Relief Strain Blk. MFR # 2926560000
7. #CABLE, CLAMP, SIZE 8 MFR # 2926564002
8. #APPLIANCE COMPONENTS RV; Timer Automatic MFR # 2935492104
9. #ELECTRIC CORD MFR # 2923772087

P#921864211 › Cabinet-rear View Assembly

Components

9 items

1. #COVER, GRAY FROM 3/1/1990 MFR # 2923629113
2. #T-STAT, ELECTRIC W/CAPILLARY MFR # 2926531100
3. #NUT M10 RH25 MFR # 2927881009
4. #INSULATING PLATE MFR # 2923178004
5. #TERMINAL BLOCK, 4-POL. MFR # 2923079004
6. #APPLIANCE COMPONENTS RV; Relief Strain Blk. MFR # 2926560000
7. #CABLE, CLAMP, SIZE 8 MFR # 2926564002
8. #APPLIANCE COMPONENTS RV; Timer Automatic MFR # 2935492104
9. #ELECTRIC CORD MFR # 2923772087

P#921864241 › Door Assembly

Components

8 items

1. #COMBINED DOOR ASSEMBLY MFR # 2935736310
2. #SHELF, ASSEMBLY, UPPER MFR # 2923908004
3. #SHELF FINGERS MFR # 2923958009
4. #SHELF, BOTTLE LOWER DOOR MFR # 2924428010
5. #DECORATION PANEL BROWN MFR # 2926362100
6. #SHELF, ASSEMBLY, UPPER MFR # 2935366019
7. #SLIDER FOR MINI SHELF MFR # 2923826016
8. #Refrigerator Door Handle; Use With Dometic Minibar RH250D Refrigerators MFR # 2935697207 Superseded: see description

P#92186421 › Cabinet-front View Assembly

Components

23 items

1. #HINGE, UPPER RIGHT MFR # 2926415007
2. #HINGE, UPPER LEFT MFR # 2926414000
3. #HINGE, LOWER, RIGHT MFR # 2923257002
4. #HINGE, LOWER, LEFT MFR # 2923621004
5. #Refrigerator Bolt; Use With Dometic Refrigerator RM2193; Upper Hinge Bolt MFR # 2924892009 Superseded: see description
6. #PIN, LOWER HINGE USE 2924892009 MFR # 2923005009 Superseded: see description
7. #PIN, LOWER HINGE MFR # 2926265006
8. #FOOT MFR # 2923733006
9. #TUBE, DRAIN, NATURE MFR # 2926441128
10. #EVAPORATOR, RIGHT MFR # 2923851105
11. #EVAPORATOR, LEFT MFR # 2923852103
12. #RETAINER MFR # 2926236023
13. #RETAINER MFR # 2926235025
14. #SHELF, LOWER MFR # 2951002043
15. #SHELF, UPPER MFR # 2951011044
16. #LAMP, ASSEMBLY MFR # 2935714408
17. #BULB, E14, 6-10W, 110-140V MFR # 2923382101
18. #PLATE, STRIKE DOOR MFR # 2923677203
19. #CAP, HINGE, RIGHT MFR # 2935457008
20. #CAP, HINGE, LEFT MFR # 2935457107
21. #HINGE, COVER, BROWN MFR # 2926412004
22. #SCREW, FOR CAP MFR # 2935600003
23. #Refrigerator Control Knob; Thermostat Control Knob; Use With Dometic Refrigerators RH250/ RH250D/ RH250LD1 MFR # 2923835009 Superseded: see description

P#921864221 › Cabinet-front View Assembly /

Components

23 items

1. #HINGE, UPPER RIGHT MFR # 2926415007
2. #HINGE, UPPER LEFT MFR # 2926414000
3. #HINGE, LOWER, RIGHT MFR # 2923257002
4. #HINGE, LOWER, LEFT MFR # 2923621004
5. #PIN, LOWER HINGE USE 2924892009 MFR # 2923005009 Superseded: see description
6. #Refrigerator Bolt; Use With Dometic Refrigerator RM2193; Upper Hinge Bolt MFR # 2924892009 Superseded: see description
7. #PIN, LOWER HINGE MFR # 2926265006
8. #FOOT MFR # 2923733006
9. #TUBE, DRAIN, NATURE MFR # 2926441128
10. #EVAPORATOR, RIGHT MFR # 2923851105
11. #EVAPORATOR, LEFT MFR # 2923852103
12. #RETAINER MFR # 2926236023
13. #RETAINER MFR # 2926235025
14. #SHELF, LOWER MFR # 2951002043
15. #SHELF, UPPER MFR # 2951011044
16. #LAMP, ASSEMBLY MFR # 2935714408
17. #BULB, E14, 6-10W, 110-140V MFR # 2923382101
18. #PLATE, STRIKE DOOR MFR # 2923677203
19. #CAP, HINGE, RIGHT MFR # 2935457008
20. #CAP, HINGE, LEFT MFR # 2935457107
21. #HINGE, COVER, BROWN MFR # 2926412004
22. #SCREW, FOR CAP MFR # 2935600003
23. #Refrigerator Control Knob; Thermostat Control Knob; Use With Dometic Refrigerators RH250/ RH250D/ RH250LD1 MFR # 2923835009 Superseded: see description

P#921864201 › Door Assembly

Components

11 items

1. #COMBINED DOOR ASSEMBLY MFR # 2935736716
2. #SHELF, ASSEMBLY, UPPER MFR # 2923908004
3. #SHELF FINGERS MFR # 2923958009
4. #SHELF, BOTTLE LOWER DOOR MFR # 2924428010
5. #DECORATION PANEL BROWN MFR # 2926362100
6. #SHELF, ASSEMBLY, UPPER MFR # 2935366019
7. #SLIDER FOR MINI SHELF MFR # 2923826016
8. #LOCK ASM., CHISMA, 2 KEYS MFR # 2935538203
9. #KEY, CHISMA MFR # 2927660205
10. #ROSETTE, BRASS MINIBARS MFR # 2924441104
11. #Refrigerator Door Handle; Use With Dometic Minibar RH250D Refrigerators MFR # 2935697207 Superseded: see description

P#921864221 › Door Assembly

Components

11 items

1. #DOOR W/SIS LOCK MFR # 2935768719
2. #SHELF, ASSEMBLY, UPPER MFR # 2923908004
3. #SHELF FINGERS MFR # 2923958009
4. #SHELF, BOTTLE LOWER DOOR MFR # 2924428010
5. #DECORATION PANEL SHORT MFR # 2927917100
6. #SHELF, ASSEMBLY, UPPER MFR # 2935366019
7. #SLIDER FOR MINI SHELF MFR # 2923826016
8. #LOCK ASM., CHISMA, 2 KEYS MFR # 2935538203
9. #KEY, CHISMA MFR # 2927660205
10. #ROSETTE, BRASS MINIBARS MFR # 2924441104
11. #Refrigerator Door Handle; Use With Dometic Minibar RH250D Refrigerators MFR # 2935697207 Superseded: see description

P#921864601 › Door Assembly

Components

16 items

1. #DOOR SIS LOCK & RED DOT MFR # 2935736617
2. #SHELF, ASSEMBLY, UPPER MFR # 2923908004
3. #SHELF FINGERS MFR # 2923958009
4. #SHELF, BOTTLE LOWER DOOR MFR # 2924428010
5. #DECORATION PANEL BROWN MFR # 2926362209
6. #SHELF, ASSEMBLY, UPPER MFR # 2935366019
7. #SLIDER FOR MINI SHELF MFR # 2923826016
8. #LOCK ASM., CHISMA, 2 KEYS MFR # 2935538203
9. #KEY, CHISMA MFR # 2927660205
10. #ROSETTE, BRASS MINIBARS MFR # 2924441104
11. #DOOR OPENING CONTROL, ASSEMBLY MFR # 2951142005
12. #KEY, RED DOT MECH. MFR # 2935657003
13. #LIGHT CONDUCTOR, ASSEMBLY MFR # 2926351012
14. #Light Conductor, Assembly MFR # 2935709200
15. #PIPE RIVET MFR # 2926626017
16. #Refrigerator Door Handle; Use With Dometic Minibar RH250D Refrigerators MFR # 2935697207 Superseded: see description

P#921864221 › Cooling Unit Assembly

Components

8 items

1. #COOLING UNIT RH260 W/HTR & FREEZER TUBE - THIS COOLING UNIT HAS NO FREEZER TUBE, BUT IT DOES COME W/THE ELEMENT. FOR COOLING UNIT W/FREEZER TUBE, USE PART NUMBER 2935310108N MFR # 2935311106N Superseded: see description
2. #COOLING UNIT W/ HEATING ELEMENT RECON MFR # 2935311106R
3. #COAT, INSULATION MFR # 2924082007
4. #APPLIANCE COMPONENTS RV; Insulation MFR # 2926680030
5. #LID, UPPER, BOILER MFR # 2924063007
6. #LID LOWER BOILER MFR # 2924089002
7. #Refrigerator Drip Tray; Replacement For Dometic RML8330/ RML8555/ RM7851L Refrigerators; For Fresh Food Compartment; By Burner Assembly MFR # 2923320002
8. #HEATING ELEMENT, 95W, 120V MFR # 2924439108

P#921864241 › Cabinet-rear View Assembly

Components

9 items

1. #COVER, GRAY FROM 3/1/1990 MFR # 2923629113
2. #T-STAT, ELECTRIC W/CAPILLARY MFR # 2926531100
3. #NUT M10 RH25 MFR # 2927881009
4. #INSULATING PLATE MFR # 2923178004
5. #TERMINAL BLOCK, 4-POL. MFR # 2923079004
6. #APPLIANCE COMPONENTS RV; Relief Strain Blk. MFR # 2926560000
7. #CABLE, CLAMP, SIZE 8 MFR # 2926564002
8. #APPLIANCE COMPONENTS RV; Timer Automatic MFR # 2935492104
9. #ELECTRIC CORD MFR # 2923772087

P# 92186540 › Door Assembly

Components

9 items

1. #COMBINED DOOR ASSEMBLY MFR # 2935736716
2. #SHELF, ASSEMBLY, UPPER MFR # 2923908004
3. #DECORATION PANEL SHORT MFR # 2927917100
4. #SHELF, ASSEMBLY, UPPER MFR # 2935366019
5. #SLIDER FOR MINI SHELF MFR # 2923826016
6. #LOCK ASM., CHISMA, 2 KEYS MFR # 2935538203
7. #KEY, CHISMA MFR # 2927660205
8. #ROSETTE, BRASS MINIBARS MFR # 2924441104
9. #Refrigerator Door Handle; Use With Dometic Minibar RH250D Refrigerators MFR # 2935697207 Superseded: see description

P#921864201 › Cabinet-rear View Assembly

Components

23 items

1. #HINGE, UPPER RIGHT MFR # 2926415007
2. #HINGE, UPPER LEFT MFR # 2926414000
3. #HINGE, LOWER, RIGHT MFR # 2923257002
4. #HINGE, LOWER, LEFT MFR # 2923621004
5. #Refrigerator Bolt; Use With Dometic Refrigerator RM2193; Upper Hinge Bolt MFR # 2924892009 Superseded: see description
6. #PIN, LOWER HINGE USE 2924892009 MFR # 2923005009 Superseded: see description
7. #PIN, LOWER HINGE MFR # 2926265006
8. #FOOT MFR # 2923733006
9. #TUBE, DRAIN, NATURE MFR # 2926441128
10. #EVAPORATOR, RIGHT MFR # 2923851105
11. #EVAPORATOR, LEFT MFR # 2923852103
12. #RETAINER MFR # 2926236023
13. #RETAINER MFR # 2926235025
14. #SHELF, LOWER MFR # 2951002043
15. #SHELF, UPPER MFR # 2951011044
16. #LAMP, ASSEMBLY MFR # 2935714408
17. #BULB, E14, 6-10W, 110-140V MFR # 2923382101
18. #PLATE, STRIKE DOOR MFR # 2923677203
19. #CAP, HINGE, RIGHT MFR # 2935457008
20. #CAP, HINGE, LEFT MFR # 2935457107
21. #HINGE, COVER, BROWN MFR # 2926412004
22. #SCREW, FOR CAP MFR # 2935600003
23. #Refrigerator Control Knob; Thermostat Control Knob; Use With Dometic Refrigerators RH250/ RH250D/ RH250LD1 MFR # 2923835009 Superseded: see description
