Dometic RM1272 Elite Product # 921148087 Beige Parts Diagram · Rear View

Refrigerator · 9 assemblies · 9 diagram sheets · 218 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM1272 Elite Product # 921148087 Beige RV refrigerator: 9 assemblies (Rear View, Cabinet Exterior, Cabinet Interior, Icemaker Exploded Assembly, Front View and more) and 218 manufacturer part numbers. 48 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Rear View

Components

22 items

1. #FERRULE, WATER VALVE MFR # D7E3108706296
2. #NUT, WATER VALVE MFR # D7E3108706288
3. #S,NUT,PLASTIC,1/4" TB,7-16"-20 MFR # 2930839010
4. #APPLIANCE COMPONENTS RV; Diagram Wiring MFR # 2931988006
5. #Ice Maker Water Inlet Hose; Replacement For Dometic RM2862/ RM4872/ RM7030/ RM7832/ NDR1062 Model Refrigerator Ice Maker; 5 Foot Length; Plastic MFR # 3108705637
6. #Refrigerator Water Supply Line; Replacement For Norcold 1200/ 1210/ 2117/ N1095/ N641/ N84X Series Refrigerator Icemaker; 68 Inch Length MFR # 617869
7. #Refrigerator Cooling Unit Heater Element; Replacement For Dometic RM7732/ NDR1272/ NDR1282 Refrigerators MFR # 3108706080
8. #TERMINAL, 4-WAY MFR # 2931963018
9. #CORD, SET STRAIGHT MFR # 2002699080
10. #WARNING LABEL MFR # 2931975003
11. #VALVE KIT WATER MFR # 3108706114
12. #APPLIANCE COMPONENTS RV; Insert Water Hose MFR # 3108708185
13. #INSERT,SOLENOID USE 3108708185 MFR # 2930841016 Superseded: see description
14. #HARNESS, WIRE 73" RM7732 MFR # 3105585008
15. #TUBE KIT, WATER USE 3105349017 MFR # 3105349009 Superseded: see description
16. #Refrigerator Drain Tube; Use With Dometic Refrigerator Model NDR1062 MFR # 3105349017 Superseded: see description
17. #Ring, Hog Use 3107614012 MFR # 3106315009 Superseded: see description
18. #RING, HOG MFR # 3107614012
19. #BRACKET, SOLENOID MFR # 3108703003
20. #Ice Maker Water Solenoid Valve; For Eaton Ice Maker; With Fittings MFR # 3108706270
21. #HEATER KIT, ICEMAKER MFR # DMT3108706080
22. #SCREW # 8 X 1/2" TA MFR # 3106317005

Cabinet Exterior

Components

37 items

1. #APPLIANCE COMPONENTS RV; Screw MFR # 2801026010
2. #Refrigerator Door Hinge Pin; Replacement For Dometic NDR1272/ RM4872/ RM4873 Refrigerators; Fits Top Hinge; Also Use New Number 29326430300 MFR # 2932647015 Superseded: see description
3. #APPLIANCE COMPONENTS RV; Hinge Upper Lh MFR # 2932646017
4. #APPLIANCE COMPONENTS RV; Hinge Upper Rh MFR # 2932646025
5. #Board Control Assm ***Us MFR # 2932884022
6. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 2 Way MFR # 2932884014 Superseded: see description
7. #APPLIANCE COMPONENTS RV; Strip Front MFR # 2932047026
8. #APPLIANCE COMPONENTS RV; Plate Side Left MFR # 2932040013
9. #APPLIANCE COMPONENTS RV; Plate Side Right MFR # 2932040021
10. #Refrigerator Emblem; Use With Dometic RM Series/ Americana/ Americana Plus/ Royale Refrigerators MFR # 2932779008 Superseded: see description
11. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
12. #APPLIANCE COMPONENTS RV; Latch Travel MFR # 2932048016
13. #PLUG MFR # 2932742014
14. #APPLIANCE COMPONENTS RV; Hinge Lwr Lh THE FOLLOWING CAN ONLY BE USED ON REFERS WITH BLACK OR BEIGE TRIM, NOT STAINLESS STEEL. MFR # 2932846013
15. #Refrigerator Door Hinge; Replacement For Dometic NDR1272/ RM1272/ RM1282/ RM7832/ RM7732/ RM7832/ NDR1292 Model Refrigerator; Fits Lower Cabinet Side; Bottom Right Hand; Black MFR # 2932846047
16. #HINGE, LOWER RH BEIGE... MFR # 2932846021
17. #S,HINGE PIN,LWR MFR # 2932649029
18. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
19. #APPLIANCE COMPONENTS RV; Strip Front Decoration MFR # 2932664051
20. #FLAP MFR # 2932655042
21. #APPLIANCE COMPONENTS RV; SWITCH,DOOR/CLIMATE CONTR MFR # 2932680024
22. #PLATE, FREEZER MFR # 2932078021
23. #APPLIANCE COMPONENTS RV; Shelf Freezer White MFR # 2932077023
24. #COVERPLATE, PLASTIC MFR # 2932853027
25. #SCREW USE 3858037025 MFR # 2801059011 Superseded: see description
26. #Screw; Use With Dometic RM1272 ELITE/ RM1282 ELITE/ NDR1292 Refrigerators MFR # 7241332019 Superseded: see description
27. #SCREW MFR # 7241327407
28. #FREEZER UNIT MFR # 2931474015
29. #PLATE, MOUNTING MFR # 3850206016
30. #APPLIANCE COMPONENTS RV; Bracket Freezer Unit MFR # 2931484014
31. #DECAL MFR # 2932438001
32. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM1272/ RM1282 Model Refrigerator; M4 x 6 Pan MFR # 7241285019
33. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
34. #SCREW M4 X 10 S MFR # 7241289615
35. #APPLIANCE COMPONENTS RV; Washer MFR # 7341153018
36. #APPLIANCE COMPONENTS RV; Nut Hinge Pin MFR # 7314316014
37. #APPLIANCE COMPONENTS RV; Label MFR # 2932091008

Cabinet Interior

Components

37 items

1. #APPLIANCE COMPONENTS RV; Hose Drain MFR # 2932749035
2. #Refrigerator Shelf Support; Replacement For Dometic RM2663/ RM2652/ RM2662 Refrigerators; Left Side;Also Use New Number 3316450.9019 MFR # 2932101013 Superseded: see description
3. #Refrigerator Interior Light Mounting Bracket; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator MFR # 2932106012
4. #SHELF MFR # 3850213012
5. #APPLIANCE COMPONENTS RV; Fins Cooling Rh MFR # 2932761014
6. #COOLING FLANGE, LEFT MFR # 2932761030
7. #SHELF, PLASTIC MFR # 2931117168
8. #APPLIANCE COMPONENTS RV; Coupler Hose MFR # 2932877018
9. #Refrigerator Drain Hose Plug; Replacement For Dometic NDR1272/ RM7130/ RM4873 Refrigerators;Also Use New Number 3316102.9019 MFR # 2932115013 Superseded: see description
10. #Refrigerator Drain Hose Plug; Use With Dometic NDR1272/ RM4873/ NDR1062 Refrigerators; Fins Only; With Handle MFR # 2932635010 Superseded: see description
11. #APPLIANCE COMPONENTS RV; Hose Drainage MFR # 2932749068
12. #S,COVER,NEA1402 MFR # 2931715011
13. #SHELF MFR # 3850212022
14. #SHELF MFR # 3850212014
15. #SHELF MFR # 3850212030
16. #APPLIANCE COMPONENTS RV; Cover Crisper MFR # 2932622018
17. #APPLIANCE COMPONENTS RV; Meat Locker Kit MFR # 3106749009
18. #APPLIANCE COMPONENTS RV; Crisper MFR # 2932621028
19. #Refrigerator Shelf Support; Replacement For Dometic NDR1062/ NDR1292 Refrigerators MFR # 2932102011
20. #Refrigerator Shelf Support; Replacement For Dometic RM3862/ RM2352/ RM3762 Refrigerators; Left Side; Also Use New Number 3316450.9019 MFR # 2932103019 Superseded: see description
21. #TRAY, DRIP MFR # 2932972017
22. #Refrigerator Interior Light Mounting Bracket; Replacement For Dometic RM3663/ RGE400/ RM3863 Refrigerators; Also Use New Number 2932520014 MFR # 2932523018 Superseded: see description
23. #S,BIN,STORAGE,MILK SHELF,WHT MFR # 2932636018
24. #Refrigerator Interior Light Contact Pin; Replacement For Dometic DM2862/ RM1350/ RM3762/ RM3962 Model Refrigerator; Tin Bronze; Single MFR # 2932108018
25. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
26. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
27. #Refrigerator Door Light Switch; Replacement For Dometic NDR1292/ DM2852/ RM3862 Refrigerators; Also Use New Number 29326650177 MFR # 2932665017 Superseded: see description
28. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
29. #BULB 2/PK MFR # 2007290006
30. #Refrigerator Shelf; Replacement For Dometic NDR1062/ NDM1062 Series Refrigerators; Wire MFR # 2007337203
31. #S,RAIL,SHELF,236MM,NDM1062 MFR # 2007337187
32. #S WIRE SHELF RAILS/HOLDERS MFR # 2007372111
33. #Refrigerator Door Rail; Replacement For Dometic NDR1272/ NDR1282 Refrigerators MFR # 2930693045
34. #S,RAIL,SHELF,164MM MFR # 2007337161
35. #Screw; Use With Dometic RM1272 ELITE/ RM1282 ELITE/ NDR1292 Refrigerators MFR # 7241332019 Superseded: see description
36. #SHELF, PLASTIC MFR # 2932391010
37. #APPLIANCE COMPONENTS RV; Shelf Freezer MFR # 3850208012

Icemaker Exploded Assembly

Components

10 items

1. #APPLIANCE COMPONENTS RV; Bearing & Inlet MFR # 3108703426
2. #EJECTOR MFR # 3108703434
3. #APPLIANCE COMPONENTS RV; Stripper Ice MFR # 3108703442
4. #APPLIANCE COMPONENTS RV; T-Stat Mold MFR # 3108703467
5. #APPLIANCE COMPONENTS RV; Cam MFR # 3101295008
6. #Ice Maker Support Housing Cover; Use With Dometic Refrigerator Model RM7832; White MFR # 2930874025 Superseded: see description
7. #APPLIANCE COMPONENTS RV; Arm Shut Off MFR # 3108702881
8. #Refrigerator Door Handle Spring; Replacement For Dometic RM3862/ RM7732/ NDR1292 Model Refrigerator; Shut Off Arm Spring MFR # 3108702899
9. #PLUG 4 -PRONG FEMALE ELEC. 110V MFR # 3108702907
10. #THERMAL CUTOFF, ICEMAKER MFR # D7E3108706445

Front View

Components

11 items

1. #APPLIANCE COMPONENTS RV; Bolt Hexagon Cap MFR # 7252335133
2. #SHELF, WIRE FOR ICE BUCKET/MAKER MFR # 2931985010
3. #ICE MAKER SVC KIT NO WIN MFR # 3313470080
4. #APPLIANCE COMPONENTS RV; Cycle Ice MFR # 3108703517
5. #APPLIANCE COMPONENTS RV; Screw #8 X 1/2" L Bracke MFR # 3108071006
6. #Screw; Replacement For Dometic NDA1402/ NDR1062/ NDR1272/ NEA1402/ RM1272/ RM1350/ RM7732 Model Refrigerator; Stainless Steel MFR # 3312986064
7. #SCREW, USE 3312986064 #8 X 1/2 HEX SS MFR # 3108709027 Superseded: see description
8. #Refrigerator Basket; Use With Dometic RM7732 ELITE/ NDR1292/ NDR1492/ RM1272 ELITE/ RM3863 ROYALE/ RM4873 Refrigerators MFR # 3312986023 Superseded: see description
9. #APPLIANCE COMPONENTS RV; Bucket Ice Use 3312986023 MFR # 3108702998 Superseded: see description
10. #DECORATION, DOOR MFR # 3108706411
11. #DECORATION, DOOR MFR # 3108705322

Burner & Controls

Components

54 items

1. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
2. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
3. #Refrigerator Burner Box Cover; Replacement For Dometic RM1350/ NDA1402/ NDR1292 Model Refrigerator MFR # 2932161017
4. #S,VALVE,GAS,SOLENOID-1350,1402 MFR # 2932615020
5. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
6. #APPLIANCE COMPONENTS RV; BURNER ASM MFR # 955001672
7. #Dometic RM2652 RM2662 Refrigerator Door Shelf Bin MFR # 2932781053
8. #APPLIANCE COMPONENTS RV; Electrode W/Lead MFR # 2932781020
9. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
10. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
11. #BRACKET,POWER MODULE MOUNTING MFR # 2932031012
12. #PLATE,MOUNTING MFR # 2932032010
13. #APPLIANCE COMPONENTS RV; THERMOCOUPLE MFR # 2931826024
14. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
15. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
16. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
17. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
18. #SCREW USE 7295279405 MFR # 7295279017 Superseded: see description
19. #BOARD, W/COVER USE 3308741002 MFR # 2932881010 Superseded: see description
20. #FUSE, 3 AMP USE AGX3 OR 55-9690 MFR # 3308897010 Superseded: see description
21. #FUSE, 3 AMP USE BPAGC3 OR 55-9690 MFR # AGX3 Superseded: see description
22. #Fuse; Replacement Fuse For Dometic Refrigerators; Glass Tube; 5 Amp MFR # 3308897002
23. #Fuse; Glass Tube; AGC; 3 Amp; 1/4 Inch x 1-1/4 Inch; Pack Of 5; With English/ Spanish/ French Language Blister Packaging MFR # BPAGC3
24. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
25. #Refrigerator Control Board Kit; Replacement For Dometic RM2607/ NDR1492/ RM1272/ RM2652/ RM2811/ RM3807/ RM2620/ RM2820/ RM2812 Series Refrigerators; 2-Way; Universal; With Screws/ Board/ Wire And Installation Instructions MFR # 3308741002
26. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
27. #S,COVER,LESS DECALS MFR # 2931858019
28. #LEAD,PC BOARD MFR # 2931862029
29. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
30. #S,THERMISTOR,W/LEAD 126" MFR # 2931863027
31. #HARNESS, GAS SOLENOID MFR # 2954437048
32. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
33. #Refrigerator Burner Orifice; Replacement For Dometic RM1350/ NDR1282/ RM1292/ NDA1402/ RG1350 Series Refrigerators; #76 MFR # 2007419332
34. #S,BAFFLE ASM-RM1350,1402 MFR # 2932667054
35. #Refrigerator Gas Valve; Refrigerator Thermocouple Bracket; Replacement For Dometic RM4872/ RM4873 Refrigerators MFR # 2932662014
36. #SCREW M4 X 10 S MFR # 7241289615
37. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
38. #SUPPORT PLATE MFR # 2932043017
39. #ELEMENT, HEATING 210W/120V 2WIRE 3/8 X 6 1/2 MFR # CHX17736
40. #ELEMENT, HEATING, USE 3850644471 210W/120V 2WIRE 3/8 X 6 1/2 MFR # 173758038 Superseded: see description
41. #REFRIGERATOR HEATING ELEMENT, (2X), 60V, 210W MFR # 3850644471
42. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
43. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
44. #3858022019 MFR # 3858022019
45. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
46. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
47. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
48. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
49. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
50. #Refrigerator Door Latch Plate Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1303/ RM2510/ RM2551/ RM360/ RM3862/ RM3863/ RM663/ RM760/ RM761/ RM763 Model Refrigerator; B6 x 13 MFR # 7295281401
51. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
52. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
53. #FUSE, 5 AMP USE AGC5 MFR # 2943542007 Superseded: see description
54. #S,SUPPORT,PRE-ELECTRODE MFR # 2931401018

Cabinet Rear View

Components

8 items

1. #REMAN C/U USE 5532 RM7732 MFR # 2934945094R Superseded: see description
2. #A/C COMPONENTS RV; COOLING UNIT MFR # 5532
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #COVER,HEATER MFR # 2933557023
5. #Decal; Replacement For Dometic NDR1272/ RM2410/ NDR1062 Refrigerators; Electrical Ground MFR # 2932733005
6. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
7. #S,PROTECTION PLATE,REAR MFR # 2932155019
8. #APPLIANCE COMPONENTS RV; Label MFR # 2932723006

Replacement Refrigerator

Components

11 items

1. #REFER, 12 CU FT 2 W USE 1210LR USE 72-4886; REFER IS 8.4 CU FT AND FREEZER SECTIONS 3.6 CU FT. USE PART # 1200LRL FOR BLACK PLEXIGLASS DOOR PANELS USE PART # 1200LRW FOR WHITE PLEXIGLASS MFR # 1200LRN Superseded: see description
2. #REFER, 14 CU FT STNLS W/ICEMAKR 59 1/16"H X 36 1/2"W X 24"D MFR # NDR1492SSIMHF
3. #REFER, 14 CU FT W/ICEMAKER 59 31/32 X 37 3/8 X 26 11/16; 2 WAY SIDE BY SIDE WITH ICE MAKER & FAN TAUPE METAL FRAME. FOR BLACK METAL FRAME USE NDR1492BIMHFN MFR # NDR1492IMHFN Superseded: see description
4. #REFER, 14 CU FT W/ICEMAKER 59 31/32 X 37 3/8 X 26 11/16; NEW DIMENSIONS 2 WAY SIDE BY SIDE WITH ICE MAKER & FAN BLACK METAL FRAME. FOR TAUPE METAL FRAME USE NDR1492IMHFN MFR # NDR1492BIMHFN Superseded: see description
5. #REFER, 14 CU FT 2 WAY BLACK 59 1/16"H X 36 1/2"W X 24"D; 2 WAY EXTRA LARGE SIDE BY SIDE WITH BLACK METAL FRAME. FOR TAUPE METAL FRAME USE NDR1492N MFR # NDR1492BN Superseded: see description
6. #REFER,12 CU FT 2 WAY 59 1/16"H X 32 3/4"W X 24"D MFR # NDR1292BF
7. #REFER, 14 CU FT 2 WAY BEIGE 59 1/16"H X 36 1/2"W X 24"D; 2 WAY EXTRA LARGE SIDE BY SIDE WITH TAUPE METAL FRAME FOR BLACK METAL FRAME USE NDR1492BN MFR # NDR1492N Superseded: see description
8. #REFER, 14 CU FT 2WAY STAINLESS 59 1/16"H X 36 1/2"W X 24"D; SHIPPING WEIGHT IS 290 LBS. MFR # NDR1492SSFN
9. #REFER,12 CU FT STNLS USE 72-4861 MFR # 1200LRSSN Superseded: see description
10. #REFER,12 CU FT 2 WAY STAINLESS 59 1/16"H X 32 3/4"W X 24"D MFR # NDR1292SSFN
11. #REFER,12 CU FT 2 WAY WHITE 63 1/4" X 32 11/16" X 24" MFR # 1200LRWH

Door Assembly

Components

31 items

1. #Appliance Components RV; Door Refer MFR # 2932985019
2. #Refrigerator Gasket; Replacement For Dometic NDR1272/ NDR1282 Refrigerators; Door Gasket MFR # 3108708458
3. #APPLIANCE COMPONENTS RV; Door Asm Freezer MFR # 2932986017
4. #S,BUSH,DR HINGE,NYL,17,LT GRY MFR # 2931171041
5. #Refrigerator Door; Replacement For Dometic DM2652/ DM2662/ DM2852/ NDE1292/ NDM1062/ NDR1062/ NDR1272/ RM1282/ RM2351/ RM2352/ RM4872/ RM7732 Model Refrigerator; Fits Lower Door Right Hand Side MFR # 2932588011
6. #Appliance Components RV; Handle Door Beige MFR # 3850227012
7. #Handle, Door Use 3850227012 MFR # 2932094028 Superseded: see description
8. #Appliance Components RV; Control Right MFR # 2932407014
9. #Appliance Components RV; Control Left MFR # 2932407022
10. #Appliance Components RV; Screw MFR # 2801049020
11. #Refrigerator Door Bin; Replacement For Dometic DM2652/ DM2852 Refrigerators; Top Or Middle MFR # 2932576016
12. #APPLIANCE COMPONENTS RV; Shelf Door MFR # 2932576024
13. #Refrigerator Door Bin; Replacement For Dometic RK400/ RM2652 Refrigerators; White; Also Use New Number 29325760166 MFR # 2932575018 Superseded: see description
14. #SHELF, DOOR USE 2932575018 MFR # 2932575026 Superseded: see description
15. #Appliance Components RV; Strip, Decoration MFR # 3850919014
16. #S,DR DECOR,FRZ,BRN MFR # 3850381017
17. #Strip, Deco Use 3850381017 MFR # 2932642016 Superseded: see description
18. #DECORATION MFR # 2932642222
19. #Decoration, Freezer Bottom MFR # 2932642024
20. #DECORATION MFR # 2932642123
21. #Refrigerator Shelf; Use With Dometic NDR1272/ RM4872 Refrigerators; Bottle Holder; Fresh Food Compartment; Plastic; Polar White MFR # 2932658012 Superseded: see description
22. #Refrigerator Shelf; Magic Fingers; Use With Dometic Refrigerator Models NDR1272/ RM4872; Bottle Holder; Polar White MFR # 3106753001 Superseded: see description
23. #Refrigerator Door Bin; Refrigerator Shelf; Replacement For Dometic RM2662/ NDR1062/ RM3662 Refrigerators; Wire MFR # 2932585033
24. #Decal; Replacement For Dometic RM2652/ RM2852/ RM4873 Refrigerators MFR # 2932722008
25. #Refrigerator Door Bin; Replacement For Dometic RM4872/ RM4873 Refrigerators; Dairy MFR # 2932580018
26. #Refrigerator Door Bin; Replacement For Dometic RM1272/ NDR1492/ NDR1272 Refrigerators; Upper Door; Dairy MFR # 2932581016
27. #APPLIANCE COMPONENTS RV; Tray Egg MFR # 2932582014
28. #BRACKET MFR # 2932634013
29. #RIVET MFR # 2932679018
30. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
31. #Appliance Components RV; Repair Kit Hinge Beige MFR # 3307896005
