Dometic RM1282 Elite Product # 921148085 Parts Diagram · Replacement Refrigerator

Refrigerator · 7 assemblies · 7 diagram sheets · 211 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM1282 Elite Product # 921148085 RV refrigerator: 7 assemblies (Replacement Refrigerator, Cabinet Rear View, Door Assembly, Burner & Controls, Exploded View and more) and 211 manufacturer part numbers. 46 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Replacement Refrigerator

Components

12 items

1. #REFER, 14 CU FT 2WAY STAINLESS 59 1/16"H X 36 1/2"W X 24"D; SHIPPING WEIGHT IS 290 LBS. MFR # NDR1492SSFN
2. #REFER,12 CU FT 2 WAY WHITE 63 1/4" X 32 11/16" X 24" MFR # 1200LRWH
3. #REFER,12 CU FT 2 WAY 59 1/16"H X 32 3/4"W X 24"D MFR # NDR1292BF
4. #REFER, 14 CU FT 2 WAY BLACK 59 1/16"H X 36 1/2"W X 24"D; 2 WAY EXTRA LARGE SIDE BY SIDE WITH BLACK METAL FRAME. FOR TAUPE METAL FRAME USE NDR1492N MFR # NDR1492BN Superseded: see description
5. #REFER, 14 CU FT W/ICEMAKER 59 31/32 X 37 3/8 X 26 11/16; 2 WAY SIDE BY SIDE WITH ICE MAKER & FAN TAUPE METAL FRAME. FOR BLACK METAL FRAME USE NDR1492BIMHFN MFR # NDR1492IMHFN Superseded: see description
6. #REFER, 14 CU FT W/ICEMAKER 59 31/32 X 37 3/8 X 26 11/16; NEW DIMENSIONS 2 WAY SIDE BY SIDE WITH ICE MAKER & FAN BLACK METAL FRAME. FOR TAUPE METAL FRAME USE NDR1492IMHFN MFR # NDR1492BIMHFN Superseded: see description
7. #REFER, 12 CU FT USE NDR1292BF 59 1/16" X 32 3/4" X 24" MFR # NDR1292BN Superseded: see description
8. #REFER, 14 CU FT 2 WAY BEIGE 59 1/16"H X 36 1/2"W X 24"D; 2 WAY EXTRA LARGE SIDE BY SIDE WITH TAUPE METAL FRAME FOR BLACK METAL FRAME USE NDR1492BN MFR # NDR1492N Superseded: see description
9. #REFER,12 CU FT 2 WAY STAINLESS 59 1/16"H X 32 3/4"W X 24"D MFR # NDR1292SSFN
10. #REFER,12 CU FT STNLS USE 72-4861 MFR # 1200LRSSN Superseded: see description
11. #REFER, 14 CU FT STNLS W/ICEMAKR 59 1/16"H X 36 1/2"W X 24"D MFR # NDR1492SSIMHF
12. #REFER, 12 CU FT 2 W USE 1210LR USE 72-4886; REFER IS 8.4 CU FT AND FREEZER SECTIONS 3.6 CU FT. USE PART # 1200LRL FOR BLACK PLEXIGLASS DOOR PANELS USE PART # 1200LRW FOR WHITE PLEXIGLASS MFR # 1200LRN Superseded: see description

Cabinet Rear View

Components

15 items

1. #REMAN C/U USE 5532 RM7732 MFR # 2934945094R Superseded: see description
2. #A/C COMPONENTS RV; COOLING UNIT MFR # 5532
3. #COOLING UNIT W/THERMAL FUSE TYPE 945 MFR # 2934945102
4. #COOLING UNIT USE 2934945102 MFR # 2934945094N Superseded: see description
5. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
6. #COVER,HEATER MFR # 2933557023
7. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
8. #Cord Set for Absorption System MFR # 2002699086
9. #Decal; Replacement For Dometic NDR1272/ RM2410/ NDR1062 Refrigerators; Electrical Ground MFR # 2932733005
10. #PLATE MFR # 2932176015
11. #PLATE MFR # 2932185016
12. #S,PROTECTION PLATE,REAR MFR # 2932155019
13. #APPLIANCE COMPONENTS RV; Label MFR # 2932723006
14. #Refrigerator Vent Fan; For Use With Dometic RM1272/ RM1282 Double Door Refrigerators MFR # 3108705744 Superseded: see description
15. #VENTILATOR USE 3108705744 F/FRIDGE MFR # 3104131002 Superseded: see description

Door Assembly

Components

32 items

1. #Refrigerator Gasket; Replacement For Dometic NDR1272/ NDR1282 Refrigerators; Door Gasket MFR # 3108708458
2. #Appliance Components RV; Door Refer MFR # 2932985019
3. #APPLIANCE COMPONENTS RV; Door Asm Freezer MFR # 2932986017
4. #S,BUSH,DR HINGE,NYL,17,LT GRY MFR # 2931171041
5. #Refrigerator Door; Replacement For Dometic DM2652/ DM2662/ DM2852/ NDE1292/ NDM1062/ NDR1062/ NDR1272/ RM1282/ RM2351/ RM2352/ RM4872/ RM7732 Model Refrigerator; Fits Lower Door Right Hand Side MFR # 2932588011
6. #Appliance Components RV; Handle Door Beige MFR # 3850227012
7. #Handle, Door Use 3850227012 MFR # 2932094028 Superseded: see description
8. #Appliance Components RV; Control Right MFR # 2932407014
9. #Appliance Components RV; Control Left MFR # 2932407022
10. #Appliance Components RV; Screw MFR # 2801049020
11. #APPLIANCE COMPONENTS RV; Shelf Door MFR # 2932576024
12. #Refrigerator Door Bin; Replacement For Dometic DM2652/ DM2852 Refrigerators; Top Or Middle MFR # 2932576016
13. #Refrigerator Door Bin; Replacement For Dometic RK400/ RM2652 Refrigerators; White; Also Use New Number 29325760166 MFR # 2932575018 Superseded: see description
14. #SHELF, DOOR USE 2932575018 MFR # 2932575026 Superseded: see description
15. #S,DR DECOR,FRZ,BRN MFR # 3850381017
16. #Appliance Components RV; Strip, Decoration MFR # 3850919014
17. #Strip, Deco Use 3850381017 MFR # 2932642016 Superseded: see description
18. #DECORATION MFR # 2932642222
19. #Decoration, Freezer Bottom MFR # 2932642024
20. #DECORATION MFR # 2932642123
21. #Refrigerator Shelf; Use With Dometic NDR1272/ RM4872 Refrigerators; Bottle Holder; Fresh Food Compartment; Plastic; Polar White MFR # 2932658012 Superseded: see description
22. #Refrigerator Shelf; Magic Fingers; Use With Dometic Refrigerator Models NDR1272/ RM4872; Bottle Holder; Polar White MFR # 3106753001 Superseded: see description
23. #Refrigerator Door Bin; Refrigerator Shelf; Replacement For Dometic RM2662/ NDR1062/ RM3662 Refrigerators; Wire MFR # 2932585033
24. #Decal; Replacement For Dometic RM2652/ RM2852/ RM4873 Refrigerators MFR # 2932722008
25. #Refrigerator Door Bin; Replacement For Dometic RM4872/ RM4873 Refrigerators; Dairy MFR # 2932580018
26. #Refrigerator Door Bin; Replacement For Dometic RM1272/ NDR1492/ NDR1272 Refrigerators; Upper Door; Dairy MFR # 2932581016
27. #APPLIANCE COMPONENTS RV; Tray Egg MFR # 2932582014
28. #BRACKET MFR # 2932634013
29. #RIVET MFR # 2932679018
30. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
31. #Appliance Components RV; Repair Kit Hinge Beige MFR # 3307896005
32. #Refrigerator Door Hinge Plate Reinforcement Kit; Replacement For Dometic RM1272/ RM3663/ RM3863/ NDR1292 Model Refrigerator; Black; With 2 Hinges/ 2 Bushing/ 3 Screws/ 1 Installation Instructions MFR # 3307910004

Burner & Controls

Components

53 items

1. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
2. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
3. #Refrigerator Burner Box Cover; Replacement For Dometic RM1350/ NDA1402/ NDR1292 Model Refrigerator MFR # 2932161017
4. #S,VALVE,GAS,SOLENOID-1350,1402 MFR # 2932615020
5. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
6. #APPLIANCE COMPONENTS RV; BURNER ASM MFR # 955001672
7. #APPLIANCE COMPONENTS RV; Electrode W/Lead MFR # 2932781020
8. #Dometic RM2652 RM2662 Refrigerator Door Shelf Bin MFR # 2932781053
9. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
10. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
11. #BRACKET,POWER MODULE MOUNTING MFR # 2932031012
12. #PLATE,MOUNTING MFR # 2932032010
13. #APPLIANCE COMPONENTS RV; THERMOCOUPLE MFR # 2931826024
14. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
15. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
16. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
17. #SCREW USE 7295279405 MFR # 7295279017 Superseded: see description
18. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
19. #BOARD, W/COVER USE 3308741002 MFR # 2932881010 Superseded: see description
20. #Fuse; Glass Tube; AGC; 3 Amp; 1/4 Inch x 1-1/4 Inch; Pack Of 5; With English/ Spanish/ French Language Blister Packaging MFR # BPAGC3
21. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
22. #FUSE, 3 AMP USE BPAGC3 OR 55-9690 MFR # AGX3 Superseded: see description
23. #Fuse; Replacement Fuse For Dometic Refrigerators; Glass Tube; 5 Amp MFR # 3308897002
24. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
25. #Refrigerator Control Board Kit; Replacement For Dometic RM2607/ NDR1492/ RM1272/ RM2652/ RM2811/ RM3807/ RM2620/ RM2820/ RM2812 Series Refrigerators; 2-Way; Universal; With Screws/ Board/ Wire And Installation Instructions MFR # 3308741002
26. #S,COVER,LESS DECALS MFR # 2931858019
27. #LEAD,PC BOARD MFR # 2931862029
28. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
29. #S,THERMISTOR,W/LEAD 126" MFR # 2931863027
30. #HARNESS, GAS SOLENOID MFR # 2954437048
31. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
32. #Refrigerator Burner Orifice; Replacement For Dometic RM1350/ NDR1282/ RM1292/ NDA1402/ RG1350 Series Refrigerators; #76 MFR # 2007419332
33. #S,BAFFLE ASM-RM1350,1402 MFR # 2932667054
34. #Refrigerator Gas Valve; Refrigerator Thermocouple Bracket; Replacement For Dometic RM4872/ RM4873 Refrigerators MFR # 2932662014
35. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
36. #SCREW M4 X 10 S MFR # 7241289615
37. #SUPPORT PLATE MFR # 2932043017
38. #ELEMENT, HEATING 210W/120V 2WIRE 3/8 X 6 1/2 MFR # CHX17736
39. #REFRIGERATOR HEATING ELEMENT, (2X), 60V, 210W MFR # 3850644471
40. #ELEMENT, HEATING, USE 3850644471 210W/120V 2WIRE 3/8 X 6 1/2 MFR # 173758038 Superseded: see description
41. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
42. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
43. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
44. #3858022019 MFR # 3858022019
45. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
46. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
47. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
48. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
49. #Refrigerator Door Latch Plate Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1303/ RM2510/ RM2551/ RM360/ RM3862/ RM3863/ RM663/ RM760/ RM761/ RM763 Model Refrigerator; B6 x 13 MFR # 7295281401
50. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
51. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
52. #FUSE, 5 AMP USE AGC5 MFR # 2943542007 Superseded: see description
53. #S,SUPPORT,PRE-ELECTRODE MFR # 2931401018

Exploded View

Components

23 items

1. #APPLIANCE COMPONENTS RV; Crisper MFR # 2931471011
2. #Spacer Screw MFR # 2001759006
3. #Refrigerator Grommet; Use With Dometic Refrigerator Model RM7832 MFR # 2005993007 Superseded: see description
4. #APPLIANCE COMPONENTS RV; Compressor MFR # 2930850033
5. #APPLIANCE COMPONENTS RV; Device Start MFR # 955809009
6. #APPLIANCE COMPONENTS RV; Blade Fan RM4801 MFR # 2930854019
7. #Valve, Water MFR # 2932148022
8. #VALVE KIT WATER MFR # 3108706114
9. #Plate, Divider MFR # 2932174010
10. #APPLIANCE COMPONENTS RV; Motor Fan RM4804 MFR # 2943588000
11. #S,NUT,PLASTIC,1/4" TB,7-16"-20 MFR # 2930839010
12. #Plate, MTG. Comp./Fan MFR # 2932137017
13. #Coil, Condenser MFR # 2943926002
14. #Appliance Components RV; Heater Kit Icemaker Hose MFR # 3108706791
15. #WARNING LABEL MFR # 2931975003
16. #Cover MFR # 2932145010
17. #TUBE KIT, WATER USE 3105349017 MFR # 3105349009 Superseded: see description
18. #Refrigerator Drain Tube; Use With Dometic Refrigerator Model NDR1062 MFR # 3105349017 Superseded: see description
19. #Coil, Evap. MFR # 2932134014
20. #Wire Harness MFR # 2932144013
21. #ICEMAKER ASM USE 3108703517 MFR # 2932147016 Superseded: see description
22. #Refrigerator Shelf; Use With Dometic Refrigerator Model RM7832 MFR # 2932160019 Superseded: see description
23. #Drier MFR # 2053836025

Cabinet Interior

Components

34 items

1. #Refrigerator Shelf Support; Replacement For Dometic RM2852/ RM2454/ RM3663 Refrigerators MFR # 2932668011
2. #APPLIANCE COMPONENTS RV; Fins Cooling Rh MFR # 2932761014
3. #COOLING FLANGE, LEFT MFR # 2932761030
4. #COVER, CRISPER SHELF MFR # 2931117101
5. #APPLIANCE COMPONENTS RV; Coupler Hose MFR # 2932877018
6. #Refrigerator Drain Hose Plug; Replacement For Dometic NDR1272/ RM7130/ RM4873 Refrigerators;Also Use New Number 3316102.9019 MFR # 2932115013 Superseded: see description
7. #Refrigerator Drain Hose Plug; Use With Dometic NDR1272/ RM4873/ NDR1062 Refrigerators; Fins Only; With Handle MFR # 2932635010 Superseded: see description
8. #APPLIANCE COMPONENTS RV; Hose Drainage MFR # 2932749068
9. #S,COVER,NEA1402 MFR # 2931715011
10. #APPLIANCE COMPONENTS RV; Shelf Lower MFR # 2932979020
11. #Refrigerator Shelf; Replacement For Dometic NDR1062/ RM1282/ NDR1272/ NDR1282/ NDR1062/ RM1272 Model Refrigerator; Freezer Compartment; Wire; Without Cutout MFR # 2932979012
12. #APPLIANCE COMPONENTS RV; Hose Drain MFR # 2932749035
13. #APPLIANCE COMPONENTS RV; Cover Crisper MFR # 2932622018
14. #LOCKER, MEAT USE 3106749009 MFR # 2932621036 Superseded: see description
15. #APPLIANCE COMPONENTS RV; Meat Locker Kit MFR # 3106749009
16. #APPLIANCE COMPONENTS RV; Crisper MFR # 2932621028
17. #TRAY, DRIP MFR # 2932972017
18. #Refrigerator Interior Light Mounting Bracket; Replacement For Dometic RM3663/ RGE400/ RM3863 Refrigerators; Also Use New Number 2932520014 MFR # 2932523018 Superseded: see description
19. #S,BIN,STORAGE,MILK SHELF,WHT MFR # 2932636018
20. #Refrigerator Interior Light Contact Pin; Replacement For Dometic DM2862/ RM1350/ RM3762/ RM3962 Model Refrigerator; Tin Bronze; Single MFR # 2932108018
21. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
22. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
23. #Refrigerator Interior Light Mounting Bracket; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator MFR # 2932106012
24. #Refrigerator Door Light Switch; Replacement For Dometic NDR1292/ DM2852/ RM3862 Refrigerators; Also Use New Number 29326650177 MFR # 2932665017 Superseded: see description
25. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
26. #BULB 2/PK MFR # 2007290006
27. #Refrigerator Shelf; Replacement For Dometic RM2620 CLASSIC/ NDR1272/ NDR1282/ RM2820 CLASSIC Series Refrigerators MFR # 2007337138
28. #S WIRE SHELF RAILS/HOLDERS MFR # 2007372111
29. #S,RAIL,SHELF,218MM,6-10CF MFR # 2007337120
30. #Refrigerator Door Rail; Replacement For Dometic NDR1272/ NDR1282 Refrigerators MFR # 2930693045
31. #SCREW MFR # 7241333405
32. #SHELF, PLASTIC MFR # 2932391010
33. #APPLIANCE COMPONENTS RV; Shelf Wire MFR # 2932979038
34. #APPLIANCE COMPONENTS RV; Shelf Wire MFR # 2932997014

Cabinet Exterior

Components

46 items

1. #Refrigerator Door Hinge Pin; Replacement For Dometic NDR1272/ RM4872/ RM4873 Refrigerators; Fits Top Hinge; Also Use New Number 29326430300 MFR # 2932647015 Superseded: see description
2. #APPLIANCE COMPONENTS RV; Hinge Upper Lh MFR # 2932646017
3. #APPLIANCE COMPONENTS RV; Hinge Upper Rh MFR # 2932646025
4. #SCREW M6S 5 X 20 MFR # 7252331405
5. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
6. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
7. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 2 Way MFR # 2932884014 Superseded: see description
8. #Board Control Assm ***Us MFR # 2932884022
9. #APPLIANCE COMPONENTS RV; Strip Front MFR # 2932047026
10. #APPLIANCE COMPONENTS RV; Plate Side Left MFR # 2932040013
11. #APPLIANCE COMPONENTS RV; Screw MFR # 2801026010
12. #Refrigerator Emblem; Use With Dometic RM Series/ Americana/ Americana Plus/ Royale Refrigerators MFR # 2932779008 Superseded: see description
13. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
14. #APPLIANCE COMPONENTS RV; Latch Travel MFR # 2932048016
15. #PLUG MFR # 2932742014
16. #APPLIANCE COMPONENTS RV; Hinge Lwr Lh THE FOLLOWING CAN ONLY BE USED ON REFERS WITH BLACK OR BEIGE TRIM, NOT STAINLESS STEEL. MFR # 2932846013
17. #Refrigerator Door Hinge; Replacement For Dometic NDR1272/ RM1272/ RM1282/ RM7832/ RM7732/ RM7832/ NDR1292 Model Refrigerator; Fits Lower Cabinet Side; Bottom Right Hand; Black MFR # 2932846047
18. #HINGE, LOWER RH BEIGE... MFR # 2932846021
19. #S,HINGE PIN,LWR MFR # 2932649029
20. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
21. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
22. #APPLIANCE COMPONENTS RV; Strip Front Decoration MFR # 2932664051
23. #FLAP MFR # 2932655034
24. #APPLIANCE COMPONENTS RV; SWITCH,DOOR/CLIMATE CONTR MFR # 2932680024
25. #Plate Freezer MFR # 2931476028
26. #Shelf MFR # 2931477026
27. #Plate Lower Freezer Tube MFR # 2931478016
28. #Plate Cover MFR # 2932853019
29. #SCREW MFR # 7243327405
30. #SCREW MFR # 7241333405
31. #SCREW MFR # 7241327407
32. #FREEZER UNIT MFR # 2931474015
33. #SHELF MFR # 2931982025
34. #PLATE, FREEZER MFR # 2931483024
35. #APPLIANCE COMPONENTS RV; Bracket Freezer Unit MFR # 2931484014
36. #INST. SIGN PLATE FROM SERIAL NO.737 INCLUSIVE MFR # 2932439009
37. #DECAL MFR # 2932060003
38. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM1272/ RM1282 Model Refrigerator; M4 x 6 Pan MFR # 7241285019
39. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
40. #SCREW M4 X 10 S MFR # 7241289615
41. #APPLIANCE COMPONENTS RV; Washer MFR # 7341153018
42. #APPLIANCE COMPONENTS RV; Nut Hinge Pin MFR # 7314316014
43. #APPLIANCE COMPONENTS RV; Label MFR # 2932091008
44. #SWITCH, ICEMAKER MFR # 2930891011
45. #S,COVER,NEA1402 MFR # 2931715011
46. #ALARM, REFER TEMPERATURE (100); THIS ENABLES YOU TO MONITOR THE VITAL TEMP OF YOUR FOOD IN YOUR REFER WITHOUT OPENING THE DOOR. IT HAS A HIGH & LOW ALERT THAT PROVIDES YOU WITH AN AUDIBLE ALARM WHEN THE TEMPERATURE EXCEEDS A SET LIMIT MFR # 401012RV
