Dometic RM24 Parts Diagram · Door, Cabinet & Equipment Asm

Refrigerator · 2 assemblies · 2 diagram sheets · 89 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM24 RV refrigerator: 2 assemblies (Door, Cabinet & Equipment Asm, Refrigerator Replacement) and 89 manufacturer part numbers. 25 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Door, Cabinet & Equipment Asm

Components

84 items

1. #DOOR RETAINER MFR # 2901178000
2. #APPLIANCE COMPONENTS RV; Pin Lower Hinge 2201 MFR # 2900352002
3. #APPLIANCE COMPONENTS RV; Bearing Hinge Pin MFR # 2900348000
4. #GASKET, MAIN RM23-4 RM21 1/24/23 18-3/8 X 21 MFR # 2900733003
5. #SHELF, UPPER DOOR RM24 MFR # 2900608049
6. #SHELF, LOWER DOOR RM24 MFR # 2900607025
7. #DOOR LESS SHELVES MFR # 2900611084
8. #SEALING CHANNEL, TOP SECTION MFR # 2901232005
9. #SEALING CHANNEL, LEFT-HAND SIDE MFR # 2901231015
10. #SEALING CHANNEL, RIGHT-HAND SIDE MFR # 2901231007
11. #PLATE, FRONT FOOT MFR # 2901270021
12. #PLATE, REAR FOOT RM22 00A MFR # 2901272019
13. #SHELF, WIRE W/WRAP UPPER MFR # 2901174009
14. #SHELF, LOWER MFR # 2901171005
15. #FACING STRIP FOR UPPER CABINET SHELF MFR # 2901796000
16. #SLIDING BAR FOR LOWER CABINET MFR # 2901521000
17. #TRAY, UPPER SHELF MFR # 2901439000
18. #DIVIDER, ICE TRAY 2201 MFR # 2901713000
19. #APPLIANCE COMPONENTS RV; Tray Ice MFR # 2901681000
20. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
21. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
22. #PLUG W/CORD USE 2002699037 MFR # 2002699003 Superseded: see description
23. #CORD, FLEXIBLE USE 2002699037 MFR # 2002699029 Superseded: see description
24. #ELEMENT, HEATING USE 2901943000 3W 95W MFR # 2900749009 Superseded: see description
25. #APPLIANCE COMPONENTS RV; UNIV ELEMENT 95W SUGGESTED ALTERNATE: THIS PART IS NOT AN OE ORIGINAL BUT CAN BE USED AS AN ALTERNATE FOR P#2901943000. MFR # 2901943000MC
26. #ELEMENT, HEATING (25) USE 72-8460 SUGGESTED ALTERNATE F/DOMETIC: THIS PART IS NOT A DOMETIC ORIGINAL BUT CAN BE USED AS AN ALTERNATE TO THE DOMETIC P#2901943000. MFR # CS000027 Superseded: see description
27. #APPLIANCE COMPONENTS RV; Element Heating Alts Available. WHEN INVENTORY IS DEPLETED ON THIS ITEM, PLEASE ORDER SUGGESTED ALTERNATE P# CS000027 OR 2901943000MC. MFR # 2901943000
28. #T-STAT USE K50P2022 MFR # K50P2022 Superseded: see description
29. #T-STAT USE K50P2022 MFR # 2900702008 Superseded: see description
30. #Refrigerator Control Knob; Replacement For Dometic RM2200A/ RM2201/ RM3804 Refrigerators; Thermostat Control Knob MFR # 2901183026
31. #KNOB, T-STAT USE 2901183026 2150, 2201 MFR # 2901183018 Superseded: see description
32. #SWITCH, CONTROL MFR # 2002586002
33. #SWITCH COVER MFR # 2002587000
34. #APPLIANCE COMPONENTS RV; Knob Gas/Electric Rm22 MFR # 2002585004
35. #APPLIANCE COMPONENTS RV; Holder Fuse RM211-2201 MFR # 2901844000
36. #Refrigerator Power Cord Fuse; Replacement For Dometic RM761/ RM1303/ RM760/ RM763/ RM1300/ RM1301/ RM24 Series Refrigerator; 8 Amp MFR # 2002578025
37. #CLAMP, T-STAT MFR # 2900920006
38. #S,VALVE,GAS SHUT OFF,RM2410, MFR # 2007430008
39. #SHUT OFF VALVE FOR DOMETIC REFRIGERATORS MFR # 2007430008MC
40. #VALVE, GAS USE 2007430008 MFR # 2901885000 Superseded: see description
41. #VALVE, CUT OFF USE 172807000 MFR # 671059860 Superseded: see description
42. #APPLIANCE COMPONENTS RV; Valve Gas MFR # 172807000
43. #APPLIANCE COMPONENTS RV; Filter Gas MFR # 172810004
44. #T-STAT USE V35P01151 MFR # 2900703147 Superseded: see description
45. #T-STAT, GAS (200) MFR # V35P01151
46. #Thermostat Bypass Screw; Replaces #14 Bypass Screw On Ranco Gas Thermostat MFR # 172819039MC
47. #SCREW, BYPASS ALT 172819039MC S14 MFR # 172819039
48. #SCREW, BYPASS USE 172819039 MFR # 342737149 Superseded: see description
49. #VALVE, SAFETY USE 2904991003 MFR # 2901156006 Superseded: see description
50. #VALVE MFR # 2904991003
51. #THERMOCOUPLE MFR # 169372000MC
52. #Thermocouple; 27 Inch Length; With 2 Metric Thermocouple Nuts SUGGESTED ALTERNATE: THIS PART IS NOT AN OE ORIGINAL BUT CAN BE USED AS AN ALTERNATE FOR P#50484. SINCE THIS IS NOT AN ORIGINAL PART, IT... MFR # 50484MC
53. #QUICK CHECK MFR # 423
54. #THERMOCOUPLE-JUNKERS 29" USE 47-1302 MFR # 454 Superseded: see description
55. #T-COUPLE, 24" USE 72-0146 (DUPLICATE PART#) REPLACES: IS A USE # FOR 1639372002,330300,41511512,3800503SPECS: IF YOU ARE USING THIS T-COUPLE FOR INSTAMATIC OR COLD STAR: THIS IS THE JU... MFR # 169372002 Superseded: see description
56. #THERMOCOUPLE, 18" MFR # 169372002MC
57. #T-COUPLE, 24" (10+) USE 47-1302 IS A USE # FOR 169372002,169372000, 50484 WHEN USING TO REPLACE FRIGIKING TCOUPLE PART # 3800503 YOU MUST ALSO ORDER: 1 OF PART # SPLITFITTING AND... MFR # 290031 Superseded: see description
58. #T-COUPLE, 18" ALT 72-8143 CAN USE 50484MC UNTIL GONE. IF THEY NEED THE NUT (169386000) IF INSTALLING THIS T-COUPLE IN A FRIDGIKING REFER, YOU MUST ALSO ORDER THE SPLIT FITT... MFR # 169372000 Superseded: see description
59. #Nut; Use To Mount 0169372002 Thermocouple On Older RV Refrigerators; 3/8 Inch Female Thread SUGGESTED ALTERNATE F/DOMETIC: THIS PART IS NOT A DOMETIC ORIGINAL BUT CAN BE USED AS AN ALTERNATE TO THE DOMETIC P#169386000. MFR # 169386000MC Superseded: see description
60. #NUT, T-COUPLE ALT 45-3744 MFR # 169386000
61. #TUBE, PILOT DLS RM24 HR2 MFR # 2901161006
62. #APPLIANCE COMPONENTS RV; Nut Union MFR # 2901369005
63. #APPLIANCE COMPONENTS RV; Ferrule Gas Line Use 2001 MFR # 173213000 Superseded: see description
64. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
65. #CONNECTION USE 2002470009 MFR # 173214008 Superseded: see description
66. #HOUSING, PRESSURE TEST - NLA MFR # 2002470009
67. #NUT, LOCK USE 272562000 MFR # 173366006 Superseded: see description
68. #APPLIANCE COMPONENTS RV; NUT LOCK MFR # 272562000
69. #ORIFICE, JET #29 MFR # 2890039106
70. #TUBE, BURNER MFR # 2890010008
71. #APPLIANCE COMPONENTS RV; Lighter RM24 MFR # 2901208005
72. #Wheel Stud; Knurled MFR # 270130008
73. #FLINT MFR # 270127004
74. #SPRING MFR # 2890018001
75. #SPACER NUT MFR # 170827000
76. #SPACER SLEEVE MFR # 173344011
77. #SPIRAL SPEED NUT MFR # 291420008
78. #APPLIANCE COMPONENTS RV; Glass Sight 2002220-00/8 MFR # 2002220008
79. #BAFFLE, FLUE W/O WIRE 24 1 MFR # 339202000
80. #BAFFLE SUPPORT WIRE 24, 190, 211, 211B MFR # 2900246014
81. #COOLING UNIT MFR # 9282571000
82. #APPLIANCE COMPONENTS RV; Block Terminal MFR # 2901228003
83. #APPLIANCE COMPONENTS RV; Blade Hinge MFR # 2901572053
84. #Refrigerator Door Hinge; Use With Dometic Refrigerator Model RM215 Van Fridge; Fits Upper Door Side MFR # 2901572020 Superseded: see description

Refrigerator Replacement

Components

5 items

1. #REFER, 1.9 CF, 3 WAY, RH, BLK, 21" X 17 3/4" X 21 1/2" MFR # RM2193RB
2. #REFER, 1.7 CU FT.3WAY ***USE 72-4823*** MFR # 323TN Superseded: see description
3. #REFER, 1.9 CU FT 3 WAY USE RM2193RB MFR # RM2193N Superseded: see description
4. #Refrigerator; Single Compartment Adjustable For Refrigerator; Flange Mount; Right Hand Hinge; 1.7 Cubic Foot; 17-1/2 Inch Width x 21-1/4 Inch Depth x 20-5/8 Inch Height; 1.4 Amps At 120 Volt AC/ 11.7 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; Taupe Door; With Shelving MFR # 323TR
5. #REFER, 1.7 CU FT 2W USE 323TN 20 5/8 X 17 1/4 X 21 1/4 MFR # 322N Superseded: see description
