Dometic RM2410 Freedom Parts Diagram · Replacement Refrigerator

Refrigerator · 9 assemblies · 9 diagram sheets · 133 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM2410 Freedom RV refrigerator: 9 assemblies (Replacement Refrigerator, Cabinet, Rear View 3-WAY, Cabinet, Interior 3-WAY, Cabinet, Exterior 3-WAY, Cabinet, Rear View 2-WAY and more) and 133 manufacturer part numbers. 21 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Replacement Refrigerator

Components

4 items

1. #Refrigerator; Single Compartment Refrigerator With Freezer; Portable; 3.8 Cubic Foot; 22.83 Inch Width x 33-1/2 Inch Height x 24-7/8 Inch Depth; 120 Volt AC/ 1.3 Amp; 2-Way Alternating Current/ LP Gas; Right Hand Door Hinge Location; Taupe; Door Panel Must Be Ordered Separately; FOR BLACK DOOR PANELS USE 3106863008C FOR WOODGRAIN DOOR PANELS USE 3106863008B MFR # RM24102R Superseded: see description
2. #REFER, 4 CU FT 2 WAY 32 7/16"H X 21 3/16"W X 24; FOR BLACK DOOR PANELS USE 3106863008C FOR WOODGRAIN DOOR PANELS USE 3106863008B; 2 WAY SMALL SINGLE DOOR 7/29/02 - ON B/O W/DOMETIC UNTIL 9/1/02. JDH ... MFR # RM24102N Superseded: see description
3. #REFER, 4 CU FT 3 WAY 32 7/16"H X 22 13/16"W MFR # RM24103N
4. #Appliance Components RV; 3106863.008C Door Panel RM2351RB1F MFR # 106863008C

Cabinet, Rear View 3-WAY

Components

14 items

1. #Remanufactured Cooling Unit MFR # 9283359009R
2. #FLAT BLACK MFR # 5546
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #COVER, ELEMENT MFR # 2800821007
5. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
6. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
7. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
8. #DECAL RM3804 MFR # 2931503003
9. #APPLIANCE COMPONENTS RV; Plate Sign MFR # 2007574011
10. #LABEL, IMPORTANT MFR # 2007689009
11. #Decal; Replacement For Dometic NDR1272/ RM2410/ NDR1062 Refrigerators; Electrical Ground MFR # 2932733005
12. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
13. #SCREW M4 X 10 S MFR # 7241289615
14. #DECAL, WARNING 2807/4801 MFR # 2002577001

Cabinet, Interior 3-WAY

Components

21 items

1. #FIN, COOLING MFR # 2932273010
2. #APPLIANCE COMPONENTS RV; Shelf Wire 12" MFR # 2930133067
3. #SHELF, 9.5" X 17 7/8" MFR # 2002652242
4. #Refrigerator Thermostat Cover Plate; Replacement For Dometic RM2452/ RGE400/ RM36/ RM360/ RM2510/ RM2552/ RM2332/ RM2353/ RM2452 Model Refrigerator; Clamp MFR # 2890050004
5. #APPLIANCE COMPONENTS RV; Screw MFR # 7295344407
6. #SCREW MFR # 7295414119
7. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
8. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
9. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
10. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
11. #S,DRIP TRAY,WHT,RM2410/2510.2 MFR # 2007507011
12. #SHUTTER,BROWN; USE 2002239271 MFR # 2002239164 Superseded: see description
13. #S,LID,FRZ,RM2410,RM2350 MFR # 2002239271
14. #Refrigerator Door Hinge Plate; Replacement For Dometic RM66E/ RM67/ RM66D/ RM2352/ RM663/ RM66F/ RM2501/RM2301/ RM2354/ RM2351 Series Refrigerators; Polar White MFR # 2002244008
15. #S,GASKET,EVAP FLAP,6"*17",WHT MFR # 2000917019
16. #Dometic RM2652 Refrigerator Door Panel Assembly MFR # 2002236004
17. #Dometic RM2652 RM2652RB Refrigerator Door Bin Shelf MFR # 2002236012
18. #Appliance Components RV; Spring, Freezer Door LH MFR # 2002237002
19. #Spring, Freezer Door RH MFR # 2002237010
20. #Refrigerator Door Hinge Pin; Replacement For Dometic RM2451/ RM2301/ RM2352/ RM2410/ RM2501/ RM2551/ RM2354/ RM2510/ RM2552 Series Refrigerators MFR # 2002238000
21. #PARTS BAG MFR # 2931610014

Cabinet, Exterior 3-WAY

Components

28 items

1. #S,HINGE,UPR,CLASSIC MFR # 2931291013
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
4. #Dometic RM2193 RM2652 Cooling Unit Assembly MFR # 2931293027
5. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
6. #SCREW MFR # 7298281119
7. #Refrigerator Door Hinge Plate; Replacement For Dometic RM2410/ RM2610/ RM2810 Model Refrigerator; Fits Right Hand Top; FOR LEFT MOUNTING PLATE USE 2931297028 MFR # 2931297010 Superseded: see description
8. #2931297 MFR # 2931297
9. #Refrigerator Door Hinge Plate; Replacement For Dometic RM2410/ RM2610/ RM2810 Model Refrigerators; Fits Left Hand Top; FOR RIGHT MOUNTING PLATE, USE PART NUMBER 2931297010 MFR # 2931297028 Superseded: see description
10. #CABINET BASE MFR # 2007465004
11. #Button, Push Use 2007479088 Grey/Brown MFR # 2007479054 Superseded: see description
12. #Refrigerator Door Light Switch; Replacement For Dometic RM2401/ RM2501/ RGE400/ RM2800/ RM760/ RM2310/ RM2810/ RM361/ RM2400 Series Refrigerators; Push Button MFR # 2007479088
13. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
14. #S,KNOB ASM,T-STAT,RM2410/2510 MFR # 2007480219
15. #Appliance Components RV; Knob Grey/Brown 12V/120V MFR # 2007480177
16. #S,HINGE,LWR,R,PNTD,2410.2/2510 MFR # 2931539015
17. #S,HINGE,LWR,L,PNTD,2410.2/2510 MFR # 2931538017
18. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
19. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
20. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
21. #Refrigerator Trim; Replacement For 2-Way Or 3-Way Cabinet RM2410 Refrigerator; Front Lower MFR # 2931528018
22. #Sign plate MFR # 2930754003
23. #PLUG MFR # 2930083049
24. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
25. #S,STRIKE 9*35*24MM MFR # 2931511014
26. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
27. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
28. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032

Cabinet, Rear View 2-WAY

Components

15 items

1. #FLAT BLACK MFR # 5546
2. #Cooling Unit; Use 2934335098N RM460 RM2401 MFR # 9283359009N Superseded: see description
3. #Appliance Components RV; Cooling Unit MFR # 2934335098N
4. #Remanufactured Cooling Unit MFR # 9283359009R
5. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
6. #COVER, ELEMENT MFR # 2800821007
7. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
8. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
9. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
10. #DECAL RM3804 MFR # 2931503003
11. #APPLIANCE COMPONENTS RV; Plate Sign MFR # 2007574011
12. #Decal; Replacement For Dometic NDR1272/ RM2410/ NDR1062 Refrigerators; Electrical Ground MFR # 2932733005
13. #SCREW M4 X 10 S MFR # 7241289615
14. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
15. #DECAL, WARNING 2807/4801 MFR # 2002577001

Cabinet, Interior 2-WAY

Components

21 items

1. #FIN, COOLING MFR # 2932273010
2. #APPLIANCE COMPONENTS RV; Shelf Wire 12" MFR # 2930133067
3. #SHELF, 9.5" X 17 7/8" MFR # 2002652242
4. #Refrigerator Thermostat Cover Plate; Replacement For Dometic RM2452/ RGE400/ RM36/ RM360/ RM2510/ RM2552/ RM2332/ RM2353/ RM2452 Model Refrigerator; Clamp MFR # 2890050004
5. #APPLIANCE COMPONENTS RV; Screw MFR # 7295344407
6. #SCREW MFR # 7295414119
7. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
8. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
9. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
10. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
11. #S,DRIP TRAY,WHT,RM2410/2510.2 MFR # 2007507011
12. #SHUTTER,BROWN; USE 2002239271 MFR # 2002239164 Superseded: see description
13. #S,LID,FRZ,RM2410,RM2350 MFR # 2002239271
14. #Refrigerator Door Hinge Plate; Replacement For Dometic RM66E/ RM67/ RM66D/ RM2352/ RM663/ RM66F/ RM2501/RM2301/ RM2354/ RM2351 Series Refrigerators; Polar White MFR # 2002244008
15. #S,GASKET,EVAP FLAP,6"*17",WHT MFR # 2000917019
16. #Dometic RM2652 Refrigerator Door Panel Assembly MFR # 2002236004
17. #Dometic RM2652 RM2652RB Refrigerator Door Bin Shelf MFR # 2002236012
18. #Appliance Components RV; Spring, Freezer Door LH MFR # 2002237002
19. #Spring, Freezer Door RH MFR # 2002237010
20. #Refrigerator Door Hinge Pin; Replacement For Dometic RM2451/ RM2301/ RM2352/ RM2410/ RM2501/ RM2551/ RM2354/ RM2510/ RM2552 Series Refrigerators MFR # 2002238000
21. #PARTS BAG MFR # 2931610014

Control & Burner 3-WAY

Components

67 items

1. #Refrigerator Door Panel Retainer; Replacement For Dometic RM2301/ RM2410/ RGE400 Series Refrigerators MFR # 2007648005
2. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Models RA1302-926724501/ RA1302-926727101/ RGE400-921172008/ RGE400-921172010/ RM1300/ RM1301/ RM2300/ RM2301-9266930/ RM2310-926693401/ RM2310-926693501/ RM2310-926694001/ RM2310-926694101/ RM2310-926694401; Compression Mount; Safety Gas Valve; With O-Rings MFR # 2931657015
3. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Models RA1302-926724501/ RA1302-926727101/ RGE400-921172008/ RGE400-921172010/ RM1300/ RM1301/ RM2300/ RM2301-9266930/ RM2310-926693401/ RM2310-926693501/ RM2310-926694001/ RM2310-926694101/ RM2310-926694401; Compression Mount; Safety Gas Valve; With O-Rings MFR # 2931657015MC
4. #S,THERMOCOUPLE-232MM MFR # 2931496042
5. #Thermocouple; Replacement For Dometic RGE400/ RM2310/ RM1303 Refrigerators; Probe Sensor MFR # 2931496042MC
6. #Coupling MFR # 2007518000
7. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
8. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
9. #DOMETIC DUAL T-STAT MFR # 2007199009
10. #T-STAT USE 2007199009 ALSO NEED 140748005 (2) MFR # V61P105003 Superseded: see description
11. #Refrigerator Thermostat Control Assembly; Use On Dometic RM Series Refrigerators Requiring Combination Gas/ Electric Thermostat; With O-Rings MFR # 2007199009MC Superseded: see description
12. #Thermostat Bypass Screw; Replaces #14 Bypass Screw On Ranco Gas Thermostat MFR # 172819039MC
13. #SCREW, BYPASS ALT 172819039MC S14 MFR # 172819039
14. #SHUT OFF VALVE FOR DOMETIC REFRIGERATORS MFR # 2007430008MC
15. #S,VALVE,GAS SHUT OFF,RM2410, MFR # 2007430008
16. #Refrigerator Gas Valve Adapter Fitting; Replacement For Dometic RM2310/ RM2601/ RGE400/ RM1301/ RM661 Model Refrigerator MFR # 2007429000
17. #Appliance Components RV; Nut Union MFR # 172809006
18. #Refrigerator Door Panel Retainer; Replacement For Dometic RM460/ RM660/ RM2410/ RM2510/ RM761/ RM461/ RM1300/ RM1301/ RM2810/ RA1302/ RM360/ RM760/ RM2310/ RM361/ RA1302 Series Refrigerators MFR # 2007418003
19. #S,SWITCH,RM2410-2810 MFR # 2007432004
20. #Appliance Components RV; Cover Switch MFR # 2007439009
21. #Screw MFR # 140730011
22. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
23. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
24. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
25. #Refrigerator Door Handle Spring; Replacement For Dometic RM2310/ RM1350/ RM2352/ RM2601/ RM2353/ RGE400/ RM2452/ RM2333/ RM2510 Series Refrigerators MFR # 2007577014
26. #Refrigerator Door Handle Spring; Replacement For Dometic RG1350/ RM361/ RM2510/ RM2552/ RM2553/ RG1350/ RM2310/ RM1300/ RM1301/ RM2452/ RM2410 Series Refrigerators MFR # 2007578004
27. #Igniter; Use On Push Button Start Refrigerators; With Piezo/ Jumper Wire And Electrode MFR # 2007423003MC Superseded: see description
28. #Igniter, Piezo MFR # 2007423003
29. #Appliance Components RV; Retainer MFR # 2007424001
30. #Refrigerator Door Handle Spring; Replacement For Dometic RM2310/ RM2510/ RM661/ RM2400/ RM1301/ RM360/ RGE400/ RM461/ RM660/ RM2301 Series Refrigerators MFR # 2007425008
31. #Bracket Mount MFR # 2007410000
32. #Washer; Replacement For Dometic RGE400/ RM663/ RA1302 Model Refrigerators; Use With Thermocouple MFR # 7344915108 Superseded: see description
33. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
34. #Block Terminal Small 3 Poi MFR # 7627202562
35. #Ring, Sealing 2 Req. MFR # 140748005
36. #Refrigerator Gasket; Use With Dometic 2007199009 And MC Enterprise 2007199009MC Thermostats; Rubber O-Ring; Set Of 2 MFR # 140748005MC Superseded: see description
37. #Catch Snap 12/120 (Fus) MFR # 2930066028
38. #Refrigerator Burner Tube; Replacement For Dometic RGE400/ RK400/ RM2310/ RM2510/ RM763/ RM1301/ RM1302/ RM1300/ RM460 Model Refrigerators; With Electrode MFR # 2007503036
39. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
40. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
41. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
42. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
43. #Retainer, Burner MFR # 2007651017
44. #Refrigerator Burner Control Module Mounting Bracket; Replacement For Dometic RM1302/ RM1300/ RM661/ RM2410/ RM2510/ RGE400/ RM2810 Series Refrigerator MFR # 2007567007
45. #Refrigerator Drain Tube Clamp; Replacement For Dometic RGE400 Model Refrigerators MFR # 2005112004
46. #Washer; Replacement For Dometic RM2410/ RA1302/ RGE400 Model Refrigerators; E-Shape; Use Refrigerator Gas Valve Adapter Fitting MFR # 7353113215 Superseded: see description
47. #Refrigerator Burner Box Cover; Replacement For Dometic RM2400/ RM2800/ RGE400/ RM2801/ RM2601/ RGE2601/ RM661/ RM761/ RM2510 Series Refrigerator MFR # 2007440007
48. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
49. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
50. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
51. #SCREW M4 X 10 S MFR # 7241289615
52. #Refrigerator Burner Box Cover; Replacement For Dometic RM2410/ RM361/ RM2510/ RM360/ RM2310/ RGE400/ RM1303/ RM1301/ RM760/ RM661 Model Refrigerator MFR # 2007505007
53. #APPLIANCE COMPONENTS RV; Baffle MFR # 2007590009
54. #S,BAFFLE ASM,551.5MM MFR # 2007590017
55. #Refrigerator Burner Orifice; Replacement For Dometic RM2354/ RM2333/ RM2351/ RM2410/ RM2310/ RM2301/ RM2300 Series Refrigerators; #39 MFR # 2007419159
56. #CAP FLUE MFR # 2931540013
57. #Refrigerator Door Latch Plate; Replacement For Dometic RGE400/ RM663/ RM2510/ RM1300/ RM660/ RA1302/ RGE400/ RM761/ RM1303/ RM763 Series Refrigerators MFR # 2007458017
58. #Refrigerator Interior Light Contact Pin; Replacement For Dometic RM2410 Refrigerators; Single MFR # 2931530014
59. #APPLIANCE COMPONENTS RV; Rod Push RM4-6-760 MFR # 2007468008
60. #S,PUSH ROD ASM,RM2410/2510.2 MFR # 2007468016
61. #S,SHAFT ASM,T-STAT,RM2410-2510 MFR # 2007471002
62. #S,SHAFT EXT ASM,RM2410/2510.2 MFR # 2007475003
63. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
64. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
65. #ELEMENT,HEATING 120V MFR # CS000012
66. #Refrigerator Cooling Unit Heater Element; Use With Dometic Refrigerator Models RM2300/ RM2400; 120 Volt; 160 Watts MFR # 173756016MC Superseded: see description
67. #APPLIANCE COMPONENTS RV; Element Heating 120V MFR # 173756016

Cabinet, Exterior 2-WAY

Components

30 items

1. #S,HINGE,UPR,CLASSIC MFR # 2931291013
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
4. #Dometic RM2193 RM2652 Cooling Unit Assembly MFR # 2931293027
5. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
6. #SCREW MFR # 7298281119
7. #Refrigerator Door Hinge Plate; Replacement For Dometic RM2410/ RM2610/ RM2810 Model Refrigerator; Fits Right Hand Top; FOR LEFT MOUNTING PLATE USE 2931297028 MFR # 2931297010 Superseded: see description
8. #Refrigerator Door Hinge Plate; Replacement For Dometic RM2410/ RM2610/ RM2810 Model Refrigerators; Fits Left Hand Top; FOR RIGHT MOUNTING PLATE, USE PART NUMBER 2931297010 MFR # 2931297028 Superseded: see description
9. #CABINET BASE MFR # 2007465004
10. #Button, Push Use 2007479088 Grey/Brown MFR # 2007479054 Superseded: see description
11. #Refrigerator Door Light Switch; Replacement For Dometic RM2401/ RM2501/ RGE400/ RM2800/ RM760/ RM2310/ RM2810/ RM361/ RM2400 Series Refrigerators; Push Button MFR # 2007479088
12. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
13. #S,KNOB ASM,T-STAT,RM2410/2510 MFR # 2007480219
14. #S,KNOB ASM,SELECTOR,2410/2510 MFR # 2007480185
15. #S,HINGE,LWR,R,PNTD,2410.2/2510 MFR # 2931539015
16. #S,HINGE,LWR,L,PNTD,2410.2/2510 MFR # 2931538017
17. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
18. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
19. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
20. #Refrigerator Trim; Replacement For 2-Way Or 3-Way Cabinet RM2410 Refrigerator; Front Lower MFR # 2931528018
21. #Sign plate MFR # 2930754003
22. #PLUG MFR # 2930083049
23. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
24. #S,STRIKE 9*35*24MM MFR # 2931511014
25. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
26. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
27. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
28. #SEALER (12) GRAY 10.3 OZ TUBE MFR # 311COMPOUND
29. #Refrigerator Gasket; Replacement For Dometic RM2410 Refrigerator; [[[ WHEN INVENTORY IS DEPLETED ON THIS ITEM, PLEASE ORDER SUGGESTED ALTERNATE P#311COMPOUND; SPECS: THIS IS A 10.3 OZ. TUBE USED LIKE THE MASTIC... MFR # 2943419008
30. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description

Control & Burner 2-WAY

Components

67 items

1. #Refrigerator Door Panel Retainer; Replacement For Dometic RM2301/ RM2410/ RGE400 Series Refrigerators MFR # 2007648005
2. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Models RA1302-926724501/ RA1302-926727101/ RGE400-921172008/ RGE400-921172010/ RM1300/ RM1301/ RM2300/ RM2301-9266930/ RM2310-926693401/ RM2310-926693501/ RM2310-926694001/ RM2310-926694101/ RM2310-926694401; Compression Mount; Safety Gas Valve; With O-Rings MFR # 2931657015
3. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Models RA1302-926724501/ RA1302-926727101/ RGE400-921172008/ RGE400-921172010/ RM1300/ RM1301/ RM2300/ RM2301-9266930/ RM2310-926693401/ RM2310-926693501/ RM2310-926694001/ RM2310-926694101/ RM2310-926694401; Compression Mount; Safety Gas Valve; With O-Rings MFR # 2931657015MC
4. #S,THERMOCOUPLE-232MM MFR # 2931496042
5. #Thermocouple; Replacement For Dometic RGE400/ RM2310/ RM1303 Refrigerators; Probe Sensor MFR # 2931496042MC
6. #Coupling MFR # 2007518000
7. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
8. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
9. #DOMETIC DUAL T-STAT MFR # 2007199009
10. #T-STAT USE 2007199009 ALSO NEED 140748005 (2) MFR # V61P105003 Superseded: see description
11. #Refrigerator Thermostat Control Assembly; Use On Dometic RM Series Refrigerators Requiring Combination Gas/ Electric Thermostat; With O-Rings MFR # 2007199009MC Superseded: see description
12. #Thermostat Bypass Screw; Replaces #14 Bypass Screw On Ranco Gas Thermostat MFR # 172819039MC
13. #SCREW, BYPASS ALT 172819039MC S14 MFR # 172819039
14. #SHUT OFF VALVE FOR DOMETIC REFRIGERATORS MFR # 2007430008MC
15. #S,VALVE,GAS SHUT OFF,RM2410, MFR # 2007430008
16. #Refrigerator Gas Valve Adapter Fitting; Replacement For Dometic RM2310/ RM2601/ RGE400/ RM1301/ RM661 Model Refrigerator MFR # 2007429000
17. #Appliance Components RV; Nut Union MFR # 172809006
18. #Refrigerator Door Panel Retainer; Replacement For Dometic RM460/ RM660/ RM2410/ RM2510/ RM761/ RM461/ RM1300/ RM1301/ RM2810/ RA1302/ RM360/ RM760/ RM2310/ RM361/ RA1302 Series Refrigerators MFR # 2007418003
19. #S,SWITCH,RM2410-2810 MFR # 2007432004
20. #Appliance Components RV; Cover Switch MFR # 2007439009
21. #Screw MFR # 140730011
22. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
23. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
24. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
25. #Refrigerator Door Handle Spring; Replacement For Dometic RM2310/ RM1350/ RM2352/ RM2601/ RM2353/ RGE400/ RM2452/ RM2333/ RM2510 Series Refrigerators MFR # 2007577014
26. #Refrigerator Door Handle Spring; Replacement For Dometic RG1350/ RM361/ RM2510/ RM2552/ RM2553/ RG1350/ RM2310/ RM1300/ RM1301/ RM2452/ RM2410 Series Refrigerators MFR # 2007578004
27. #Igniter, Piezo MFR # 2007423003
28. #Igniter; Use On Push Button Start Refrigerators; With Piezo/ Jumper Wire And Electrode MFR # 2007423003MC Superseded: see description
29. #Appliance Components RV; Retainer MFR # 2007424001
30. #Refrigerator Door Handle Spring; Replacement For Dometic RM2310/ RM2510/ RM661/ RM2400/ RM1301/ RM360/ RGE400/ RM461/ RM660/ RM2301 Series Refrigerators MFR # 2007425008
31. #Bracket Mount MFR # 2007410000
32. #Washer; Replacement For Dometic RGE400/ RM663/ RA1302 Model Refrigerators; Use With Thermocouple MFR # 7344915108 Superseded: see description
33. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
34. #Block Terminal Small 3 Poi MFR # 7627202562
35. #Refrigerator Gasket; Use With Dometic 2007199009 And MC Enterprise 2007199009MC Thermostats; Rubber O-Ring; Set Of 2 MFR # 140748005MC Superseded: see description
36. #Ring, Sealing 2 Req. MFR # 140748005
37. #Catch Snap 12/120 (Fus) MFR # 2930066028
38. #Refrigerator Burner Tube; Replacement For Dometic RGE400/ RK400/ RM2310/ RM2510/ RM763/ RM1301/ RM1302/ RM1300/ RM460 Model Refrigerators; With Electrode MFR # 2007503036
39. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
40. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
41. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
42. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
43. #Retainer, Burner MFR # 2007651017
44. #Refrigerator Burner Control Module Mounting Bracket; Replacement For Dometic RM1302/ RM1300/ RM661/ RM2410/ RM2510/ RGE400/ RM2810 Series Refrigerator MFR # 2007567007
45. #Refrigerator Drain Tube Clamp; Replacement For Dometic RGE400 Model Refrigerators MFR # 2005112004
46. #Washer; Replacement For Dometic RM2410/ RA1302/ RGE400 Model Refrigerators; E-Shape; Use Refrigerator Gas Valve Adapter Fitting MFR # 7353113215 Superseded: see description
47. #Refrigerator Burner Box Cover; Replacement For Dometic RM2400/ RM2800/ RGE400/ RM2801/ RM2601/ RGE2601/ RM661/ RM761/ RM2510 Series Refrigerator MFR # 2007440007
48. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
49. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
50. #SCREW M4 X 10 S MFR # 7241289615
51. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
52. #Refrigerator Burner Box Cover; Replacement For Dometic RM2410/ RM361/ RM2510/ RM360/ RM2310/ RGE400/ RM1303/ RM1301/ RM760/ RM661 Model Refrigerator MFR # 2007505007
53. #S,BAFFLE ASM,551.5MM MFR # 2007590017
54. #APPLIANCE COMPONENTS RV; Baffle MFR # 2007590009
55. #Refrigerator Burner Orifice; Replacement For Dometic RM2354/ RM2333/ RM2351/ RM2410/ RM2310/ RM2301/ RM2300 Series Refrigerators; #39 MFR # 2007419159
56. #CAP FLUE MFR # 2931540013
57. #Refrigerator Door Latch Plate; Replacement For Dometic RGE400/ RM663/ RM2510/ RM1300/ RM660/ RA1302/ RGE400/ RM761/ RM1303/ RM763 Series Refrigerators MFR # 2007458017
58. #Refrigerator Interior Light Contact Pin; Replacement For Dometic RM2410 Refrigerators; Single MFR # 2931530014
59. #APPLIANCE COMPONENTS RV; Rod Push RM4-6-760 MFR # 2007468008
60. #S,PUSH ROD ASM,RM2410/2510.2 MFR # 2007468016
61. #S,SHAFT ASM,T-STAT,RM2410-2510 MFR # 2007471002
62. #S,SHAFT EXT ASM,RM2410/2510.2 MFR # 2007475003
63. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
64. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
65. #Refrigerator Cooling Unit Heater Element; Use With Dometic Refrigerator Models RM2300/ RM2400; 120 Volt; 160 Watts MFR # 173756016MC Superseded: see description
66. #APPLIANCE COMPONENTS RV; Element Heating 120V MFR # 173756016
67. #ELEMENT,HEATING 120V MFR # CS000012
