Diagrams › Dometic › RM2600 Dometic RM2600 Parts Diagram · Replacement Refrigerator
Refrigerator · 6 assemblies · 6 diagram sheets · 207 parts · by Andrew Strick, mobile RV technician
OEM exploded parts diagrams for the Dometic RM2600 RV refrigerator: 6 assemblies (Replacement Refrigerator, Vibration Suppression Kit, Door Assembly, Cabinet Assembly, Gas-electric Assembly and more) and 207 manufacturer part numbers. 69 parts are marked as superseded — the description gives the replacement number to order instead.
The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.
Replacement Refrigerator
Dometic RM2600 replacement refrigerator — parts list sheet Full-resolution diagram + every part number →
Components 10 items # N/A REFER 51 1/2 X 21 13/16 23 3/4 MFR # RM2600N # Refrigerator / Freezer;;Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand MFR # N641N # APPLIANCE COMPONENTS RV;;Refrigerator/Lp-Ac/Ss MFR # N641IMSS # Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Stainless Steel Doors; With Crispers/ Shelving And Door Bins MFR # N641SS # REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R # Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 4.2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; With Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Door; With Crispers/ Shelving And Door Bins MFR # N641IMBK # REFER,6 CU 2-W 52 7/8"H X 23 1/2"W X 24"D SUGGESTED ALTERNATE: STAINLESS IS NOW N/A. USE BLACK, RM2652B, FOR A SUGGESTED ALTERNATE. MFR # N641WH Superseded: see description # REFER,6 CU FT 3W WHITE 52 7/8"H X 23 1/2"W X 2 MFR # N641IMWH # REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N # Refrigerator - Built In; N641; 6.3 cu ft; 2 Door; Without Ice Maker; AC/ LP; 52-7/8 Inches High x 23-1/2 Inches Wide x 24 Inches Deep; Not Included; Black; Gas Absorption; MFR # N641BK
Vibration Suppression Kit
Door Assembly
Dometic RM2600 door assembly — parts list sheet Full-resolution diagram + every part number →
Components 38 items # Refrigerator Door; Use With Dometic Refrigerator Models RM3601/ RM3600/ RM2600; Upper MFR # 2930926130 Superseded: see description # APPLIANCE COMPONENTS RV; Gasket Kit MFR # 3103688002 # DOOR, LOWER USE 2930925157 MFR # 2930925116 Superseded: see description # DOOR, FREEZER USE 2930926130 MFR # 2930682063 Superseded: see description # DOOR USE 2930925157 MFR # 2930681065 Superseded: see description # DOOR USE 2930926130 N MFR # 2930926114 Superseded: see description # DOOR, LOWER USE 2930925157 MFR # 2930925157 Superseded: see description # APPLIANCE COMPONENTS RV; Bushing Door Hinge Lower MFR # 2002619001 # CATCH, RETAINER MFR # 2931093013 # APPLIANCE COMPONENTS RV; RETAINER, CATCH MFR # 2931093021 # Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400 # APPLIANCE COMPONENTS RV; Plug Use 2930736026 MFR # 2930736018 Superseded: see description # Refrigerator Door Bin; Replacement For Dometic RM47D/ RM75/ RM760/ RM763/ RM36A/ M28C Model Refrigerator; Journal Axle Only MFR # 2001170014 # APPLIANCE COMPONENTS RV; Screw 8.4 X 13 MFR # 7296227056 # APPLIANCE COMPONENTS RV; Handle Door MFR # 2930763012 # Appliance Components RV; Screw 4 X 9.5 MFR # 7296225019 # COVER, BUTTER RM2600 MFR # 2000572079 # HOLDER,BOTTLE USE 2930715061 GREY/BEIGE 8" MFR # 2930715046 Superseded: see description # Refrigerator Shelf Support; Replacement For Dometic RM2620/ RM2353/ RM2354 Refrigerators; 8 Inch; White MFR # 2930715061 # LABEL, INSTRUCTION MFR # 2002356000 # APPLIANCE COMPONENTS RV; Strip Decoration Lw 2600 MFR # 2930640095 # APPLIANCE COMPONENTS RV; Strip Decoration Up 2600 MFR # 2930640111 # APPLIANCE COMPONENTS RV; Shelf Freezer Door MFR # 2930558057 # RACK, WIRE USE 2930558016 FREEZER DOOR MFR # 2007043009 Superseded: see description # SHELF, FREEZER USE 2930558016 MFR # 2930558008 Superseded: see description # SHELF, DOOR USE 2930558057 MFR # 2930558024 Superseded: see description # Shelf, Door; Use 2000571220 MFR # 2000571204 Superseded: see description # S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253 # SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description # Refrigerator Shelf; Use With Dometic RM2607/ RM100/ RA1302 Refrigerators; Juice Rack; Beige MFR # 2930533019 Superseded: see description # RACK, WIRE MFR # 2007040005 # HOLDER, JUICE USE 2930533019 MFR # 2930533027 Superseded: see description # Holder, Bottle Use 2002794168; Can Use 2002794010 For Brown MFR # 2002794069 Superseded: see description # APPLIANCE COMPONENTS RV; Holder Btlwhite MFR # 2002794168 # Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053 # APPLIANCE COMPONENTS RV; Holder Bottle 8" Brown MFR # 2930715020 # HOLDER,BOTTLE 7" BROWN MFR # 2930715012 # APPLIANCE COMPONENTS RV; Bar L MFR # 2007523000
Cabinet Assembly
Dometic RM2600 cabinet assembly — parts list sheet Full-resolution diagram + every part number →
Components 96 items # Refrigerator Door Hinge Pin; Use With Dometic Refrigerator Models RM3600/ RM3800 MFR # 2007270016 Superseded: see description # NO PART # GIVEN BY VENDOR MFR # NPG # CATCH, RETAINER MFR # 2931093013 # APPLIANCE COMPONENTS RV; RETAINER, CATCH MFR # 2931093021 # Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description # SHELF, WIRE USE 2930133067 11-1/2" W X 17-7/8" LONG MFR # 2930133026 Superseded: see description # APPLIANCE COMPONENTS RV; Shelf Wire 12" MFR # 2930133067 # Refrigerator Door Bin; Replacement For Dometic RM47D/ RM75/ RM760/ RM763/ RM36A/ M28C Model Refrigerator; Journal Axle Only MFR # 2001170014 # APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226 # APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234 # SHELF, WIRE USE 2002652234 MFR # 2002652143 Superseded: see description # SHELF USE 2002652226 MFR # 2002652135 Superseded: see description # APPLIANCE COMPONENTS RV; Handle Door MFR # 2930763012 # Appliance Components RV; Screw 4 X 9.5 MFR # 7296225019 # Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112 # LATCH, TRAVEL USE 2930706052 MFR # 2930706045 Superseded: see description # LATCH USE 2930706052 MFR # 2930706011 Superseded: see description # Refrigerator Door Latch; Travel Latch; Replacement For Dometic RM2802/ RM2803/ RM3800 Refrigerators MFR # 2930706052 # TRAY, ICE USE 2930400003 MFR # 2007330000 Superseded: see description # S,TRAY,ICE CUBE-RM2510 MFR # 2930400003 # Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description # Lock, Shelf Use 2007393024 N MFR # 2007393016 Superseded: see description # S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024 # APPLIANCE COMPONENTS RV; Lock Shelf Use 2007392026 MFR # 2007392018 Superseded: see description # Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026 # SHELF, BROWN USE 2930558024 MFR # 2930558016 Superseded: see description # SHELF, DOOR USE 2930558057 MFR # 2930558024 Superseded: see description # APPLIANCE COMPONENTS RV; Shelf Freezer Door MFR # 2930558057 # RACK, WIRE USE 2930558016 FREEZER DOOR MFR # 2007043009 Superseded: see description # SHELF, FREEZER USE 2930558016 MFR # 2930558008 Superseded: see description # SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER MFR # 2000571170 Superseded: see description # S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253 # Shelf, Door; Use 2000571220 MFR # 2000571204 Superseded: see description # HOUSING, CATCH GREY/BROWN MFR # 2930707050 # HOUSING, LATCH USE 2930707050 MFR # 2930707019 Superseded: see description # CRISPER, SMOKE USE 2002726129 RM2810 MFR # 2002726095 Superseded: see description # Refrigerator Crisper Bin; Replacement For Dometic RM2801/ RM2802/ RM3800 Model Refrigerators; White MFR # 2002726129 # CRISPER, SMOKE USE 2002726095 MFR # 2002726020 Superseded: see description # APPLIANCE COMPONENTS RV; Bar L MFR # 2007523000 # Pin, Hinge Upper MFR # 2930612003 # HINGE, MIDDLE MFR # 2930607003 # APPLIANCE COMPONENTS RV; Cover Crisper Use 2002727 MFR # 2002727010 Superseded: see description # Refrigerator Door Hinge Pin; Use With Dometic Refrigerator Model RM2301; Fits Bottom Hinge MFR # 2930614009 Superseded: see description # Appliance Components RV MFR # 2007519008 # APPLIANCE COMPONENTS RV; Light 12V MFR # 2930744012 # APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P # BULB 2/PK MFR # 2007290006 # SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description # S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010 # Button, Push Use 2007479088 Grey/Brown MFR # 2007479054 Superseded: see description # Refrigerator Door Light Switch; Replacement For Dometic RM2401/ RM2501/ RGE400/ RM2800/ RM760/ RM2310/ RM2810/ RM361/ RM2400 Series Refrigerators; Push Button MFR # 2007479088 # Knob, Push Use 2007479054 Black/Red MFR # 2007479047 Superseded: see description # Retainer, Lamp MFR # 2930557000 # KNOB,T-STAT MFR # 2007480151 # APPLIANCE COMPONENTS RV; Knob T-Stat Use 200748015 MFR # 2007480193 Superseded: see description # Appliance Components RV; Knob Selector 115V MFR # 2007480029 # APPLIANCE COMPONENTS RV; Level Spirit MFR # 2007645019 # APPLIANCE COMPONENTS RV; Hinge Lower Rh MFR # 2930232000 # APPLIANCE COMPONENTS RV; Hinge Lower Lh MFR # 2930233008 # Refrigerator Door Hinge; Replacement For Dometic RM2803/ RM4801/ RM2601 Refrigerators; Fits Upper Door Side MFR # 2930613001 # APPLIANCE COMPONENTS RV; Panel Grey/Brown MFR # 2007463058 # Base Front; Use 2930591090 25001,2600 MFR # 2930591108 Superseded: see description # BASE FRONT RM24 00, 2500 MFR # 2930591090 # APPLIANCE COMPONENTS RV; Shelf Tray MFR # 2930136011 # TRAY, MILK USE 2930136011 MFR # 2930136003 Superseded: see description # Dometic Refrigerator Main Control Board RM2652 RM2662 RM2852 RM2862 MFR # 2007464015 # Refrigerator Door Rail; Replacement For Dometic NDR1272/ NDR1282 Refrigerators MFR # 2930693045 # S WIRE SHELF RAILS/HOLDERS MFR # 2007372111 # RETAINER USE 2930693029 MFR # 2930693011 Superseded: see description # RETAINER USE 2930693045 MFR # 2930693029 Superseded: see description # APPLIANCE COMPONENTS RV; Bar L Approx. 13.5" Rm76 MFR # 2007337005 # APPLIANCE COMPONENTS RV; Bar L Approx 8" 460-660 MFR # 2007337062 # Appliance Components RV; Bar L Approx 15" 460-66 MFR # 2007337039 # Appliance Components RV; Bar Freezer Shelf MFR # 2007537000 # 2004044091 MFR # 2004044091 # COVER, LIGHT SWITCH MFR # 2004044109 # COVER, LIGHT USE 2004044091 MFR # 2004044083 Superseded: see description # COVER, CONTROLS USE 2004044091 MFR # 2004044075 Superseded: see description # SHADE, LAMP MFR # 2004043002 # PIN,RETAINING MFR # 2001281019 # Appliance Components RV; Socket Lamp MFR # 2007674001 # Lamp, Pilot Use 2932810019 MFR # 2007675008 Superseded: see description # Refrigerator Flame Indicator; Replacement For Dometic RM2401/ RM2501/ RM2601 Model Refrigerator; Clear; Single. WHEN USING PART# 2932810019 TO REPLACE PART# 2007675008 MODIFICATIONS TO THE WIRE LEAD CONNECTIONS TO THE LAMP WILL NEED TO BE MADE. MFR # 2932810019 # Appliance Components RV; Sleeve Sealing MFR # 2007626001 # Appliance Components RV; Sleeve Protector RM130 MFR # 2007673003 # PLATE, SEALING MFR # 2930696014 # COVER USE 2930611013 RM2601/04 RM2800/04 MFR # 2930611005 Superseded: see description # Refrigerator Thermostat Cover; Use With Dometic RM3807/ RM2611/ RM7732 Refrigerators MFR # 2930611013 Superseded: see description # SCREW USE 7295283407 MFR # 7295283118 Superseded: see description # SCREW MFR # 7295283407 # CLAMP 2800 MFR # 2002798003 # APPLIANCE COMPONENTS RV; Screw MFR # 7295344407 # SCREW USE 7295344407 MFR # 7295344118 Superseded: see description # Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000 # Washer; Replacement For Dometic RM2301/ RM2600/ RM3600 Model Refrigerator MFR # 2930714015 # GROMMET MFR # 2930511007
Gas-electric Assembly
Dometic RM2600 gas-electric assembly — parts list sheet Full-resolution diagram + every part number →
Components 65 items # APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044 # Refrigerator Gas Valve; Replacement For Dometic Refrigerator Models RA1302-926724501/ RA1302-926727101/ RGE400-921172008/ RGE400-921172010/ RM1300/ RM1301/ RM2300/ RM2301-9266930/ RM2310-926693401/ RM2310-926693501/ RM2310-926694001/ RM2310-926694101/ RM2310-926694401; Compression Mount; Safety Gas Valve; With O-Rings MFR # 2931657015 # Refrigerator Gas Valve; Replacement For Dometic Refrigerator Models RA1302-926724501/ RA1302-926727101/ RGE400-921172008/ RGE400-921172010/ RM1300/ RM1301/ RM2300/ RM2301-9266930/ RM2310-926693401/ RM2310-926693501/ RM2310-926694001/ RM2310-926694101/ RM2310-926694401; Compression Mount; Safety Gas Valve; With O-Rings MFR # 2931657015MC # VALVE,SAFETY USE 2931657015 MFR # 2007422005 Superseded: see description # Thermocouple MFR # 2930665019 # Thermocouple MFR # 2931496091MC # T-Couple Use 2931496091 MFR # 2931496026 Superseded: see description # THERMOCOUPLE (350MM) MFR # 2931496091 # Thermocouple; Use On Dometic Refrigerator Model RM3800 MFR # 2930326018MC Superseded: see description # T-COUPLE USE 2931496026 RM3801,3601,2802 MFR # 2930326018 Superseded: see description # Coupling MFR # 2007518000 # APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003 # Refrigerator Thermostat Control Assembly; Use On Dometic RM Series Refrigerators Requiring Combination Gas/ Electric Thermostat; With O-Rings MFR # 2007199009MC Superseded: see description # T-STAT USE 2007199009 ALSO NEED 140748005 (2) MFR # V61P105003 Superseded: see description # DOMETIC DUAL T-STAT MFR # 2007199009 # Thermostat Bypass Screw; Replaces #14 Bypass Screw On Ranco Gas Thermostat MFR # 172819039MC # SCREW, BYPASS ALT 172819039MC S14 MFR # 172819039 # SHUT OFF VALVE FOR DOMETIC REFRIGERATORS MFR # 2007430008MC # S,VALVE,GAS SHUT OFF,RM2410, MFR # 2007430008 # Refrigerator Gas Valve Adapter Fitting; Replacement For Dometic RM2310/ RM2601/ RGE400/ RM1301/ RM661 Model Refrigerator MFR # 2007429000 # Appliance Components RV; Nut Union MFR # 172809006 # S,SWITCH,PWR/SELECTOR-MCT MFR # 2007664010 # SWITCH, SELECTOR MFR # 2007664002 # S,COVER,CONTROLS,INNER MFR # 2007661008 # Screw MFR # 140730011 # Screw; Use 7295279512 MFR # 7295279405 Superseded: see description # APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512 # APPLIANCE COMPONENTS RV; Spring MFR # 2007577006 # Refrigerator Door Handle Spring; Replacement For Dometic RG1350/ RM361/ RM2510/ RM2552/ RM2553/ RG1350/ RM2310/ RM1300/ RM1301/ RM2452/ RM2410 Series Refrigerators MFR # 2007578004 # DOMETIC REIGNITOR RM1303 MFR # 2931132019 # Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description # IGNITER USE 2931132019 MFR # 7679100003 Superseded: see description # Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC # APPLIANCE COMPONENTS RV; Tube Gas MFR # 2930618018 # APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012 # WASHER 4X12 MM MFR # 2007457019 # Ring, Sealing 2 Req. MFR # 140748005 # Refrigerator Gasket; Use With Dometic 2007199009 And MC Enterprise 2007199009MC Thermostats; Rubber O-Ring; Set Of 2 MFR # 140748005MC Superseded: see description # Catch Snap 12/120 (Fus) MFR # 2930066028 # CATCH, SNAP USE 2930071010 MFR # 2007428002 Superseded: see description # CATCH, SNAP USE 2930066028 MFR # 2930071010 Superseded: see description # APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020 # DOMETIC ELECTRODE 663-763 MFR # 2930379009 # IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC # Screw Use 3858002052 MFR # 7295221019 Superseded: see description # S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052 # ORIFICE #51 USE 2007419183 BUTANE 760 MFR # 2007419175 Superseded: see description # Refrigerator Burner Orifice; Replacement For Dometic RM660/ RM661/ RM2600/ RM2603/ RM2601/ RM2602/ RM760/ RM761/ RM3600 Series Refrigerators; #52 MFR # 2007419183 # Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191 # Refrigerator Drain Tube Clamp; Replacement For Dometic RGE400 Model Refrigerators MFR # 2005112004 # APPLIANCE COMPONENTS RV; Ring Retainer MFR # 7353113231 # Refrigerator Burner Box Cover; Replacement For Dometic RM2400/ RM2800/ RGE400/ RM2801/ RM2601/ RGE2601/ RM661/ RM761/ RM2510 Series Refrigerator MFR # 2007440007 # Refrigerator Gas Valve Adapter Fitting; Use With Dometic Refrigerator Models RM2601/ RM2801/ RM2810; MALE CONNECTOR: 3/8" O.D TUBE X 1/4" O.D. TUBE MFR # 2930619008 Superseded: see description # S,BAFFLE ASM,781MM MFR # 2007590058 # ELEMENT, HEATING USE 173754045 SEE NOTES MFR # 173754011 Superseded: see description # ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974 # ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386 # ELEMENT, HEATING USE 48-9357 295W/120V 2WIRE MFR # 173754045 Superseded: see description # NIPPLE FOR GAS TUBE MFR # 2930752015 # S,CAP,FLUE MFR # 2007598010 # S,PUSH ROD ASM,RM2410/2510.2 MFR # 2007468016 # S,SHAFT ASM,T-STAT,RM2410-2510 MFR # 2007471002 # S,SHAFT EXT ASM,RM2410/2510.2 MFR # 2007475003 # Refrigerator Burner Box Cover; Replacement For Dometic RM2600/ S520014/ RM7030 Refrigerators MFR # 2930651019 # Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
Cooling Unit Assembly
Dometic RM2600 cooling unit assembly — parts list sheet Full-resolution diagram + every part number →
Components 9 items # Refrigerator Cooling Unit; Replacement For Dometic RM2602/ RM2601/ RM3600 Model Refrigerators MFR # 2934801099N # REMAN C/U USE 5526 (UPS) RM2600/01/02/03 MFR # 2934801099R Superseded: see description # SG TNT 12 X 18 MFR # 5526 # COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084 # Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description # Plate, Drip RM2600 MFR # 2930713017 # Plate Protection Rm2800 MFR # 2930785015 # TUBE MFR # 2930638016 # Lid MFR # 2933557015
