Dometic RM2610 Parts Diagram · Climate Control Kit

Refrigerator · 5 assemblies · 5 diagram sheets · 183 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM2610 RV refrigerator: 5 assemblies (Climate Control Kit, Rear View Cab Assy Gas & Elec, Replacement Refrigerator, Front View Cabinet Assembly, Door Assembly) and 183 manufacturer part numbers. 43 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Climate Control Kit

Components

1 item

1. #CONTROL,CLIMATE KIT RM2610 MFR # 2943700753

Rear View Cab Assy Gas & Elec

Components

90 items

1. #REMAN C/U USE 5526 (UPS) RM2600/01/02/03 MFR # 2934801099R Superseded: see description
2. #SG TNT 12 X 18 MFR # 5526
3. #Cooling Unit MFR # 2934801990N
4. #Refrigerator Cooling Unit; Replacement For Dometic RM2602/ RM2601/ RM3600 Model Refrigerators MFR # 2934801099N
5. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
6. #Lid MFR # 2933557015
7. #DECAL RM3804 MFR # 2931503003
8. #DECAL RM38 04 MFR # 2007574029
9. #LABEL, IMPORTANT MFR # 2007689009
10. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
11. #Plate, Drip RM2600 MFR # 2930713017
12. #Plate Protection Rm2800 MFR # 2930785015
13. #DECAL, WARNING 2807/4801 MFR # 2002577001
14. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
15. #VALVE,SAFETY USE 2931657015 MFR # 2007422005 Superseded: see description
16. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Models RA1302-926724501/ RA1302-926727101/ RGE400-921172008/ RGE400-921172010/ RM1300/ RM1301/ RM2300/ RM2301-9266930/ RM2310-926693401/ RM2310-926693501/ RM2310-926694001/ RM2310-926694101/ RM2310-926694401; Compression Mount; Safety Gas Valve; With O-Rings MFR # 2931657015
17. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Models RA1302-926724501/ RA1302-926727101/ RGE400-921172008/ RGE400-921172010/ RM1300/ RM1301/ RM2300/ RM2301-9266930/ RM2310-926693401/ RM2310-926693501/ RM2310-926694001/ RM2310-926694101/ RM2310-926694401; Compression Mount; Safety Gas Valve; With O-Rings MFR # 2931657015MC
18. #Thermocouple MFR # 2931496091MC
19. #THERMOCOUPLE (350MM) MFR # 2931496091
20. #T-Couple Use 2931496091 MFR # 2931496026 Superseded: see description
21. #Thermocouple MFR # 2930665019
22. #T-COUPLE USE 2931496026 RM3801,3601,2802 MFR # 2930326018 Superseded: see description
23. #Thermocouple; Use On Dometic Refrigerator Model RM3800 MFR # 2930326018MC Superseded: see description
24. #Coupling MFR # 2007518000
25. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
26. #Refrigerator Thermostat Control Assembly; Use On Dometic RM Series Refrigerators Requiring Combination Gas/ Electric Thermostat; With O-Rings MFR # 2007199009MC Superseded: see description
27. #T-STAT USE 2007199009 ALSO NEED 140748005 (2) MFR # V61P105003 Superseded: see description
28. #DOMETIC DUAL T-STAT MFR # 2007199009
29. #SCREW, BYPASS ALT 172819039MC S14 MFR # 172819039
30. #Thermostat Bypass Screw; Replaces #14 Bypass Screw On Ranco Gas Thermostat MFR # 172819039MC
31. #S,VALVE,GAS SHUT OFF,RM2410, MFR # 2007430008
32. #SHUT OFF VALVE FOR DOMETIC REFRIGERATORS MFR # 2007430008MC
33. #Refrigerator Gas Valve Adapter Fitting; Replacement For Dometic RM2310/ RM2601/ RGE400/ RM1301/ RM661 Model Refrigerator MFR # 2007429000
34. #Appliance Components RV; Nut Union MFR # 172809006
35. #Refrigerator Door Panel Retainer; Replacement For Dometic RM460/ RM660/ RM2410/ RM2510/ RM761/ RM461/ RM1300/ RM1301/ RM2810/ RA1302/ RM360/ RM760/ RM2310/ RM361/ RA1302 Series Refrigerators MFR # 2007418003
36. #SWITCH, SELECTOR MFR # 2007664002
37. #S,SWITCH,PWR/SELECTOR-MCT MFR # 2007664010
38. #S,COVER,CONTROLS,INNER MFR # 2007661008
39. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
40. #Refrigerator Door Handle Spring; Replacement For Dometic RM2310/ RM1350/ RM2352/ RM2601/ RM2353/ RGE400/ RM2452/ RM2333/ RM2510 Series Refrigerators MFR # 2007577014
41. #Refrigerator Door Handle Spring; Replacement For Dometic RG1350/ RM361/ RM2510/ RM2552/ RM2553/ RG1350/ RM2310/ RM1300/ RM1301/ RM2452/ RM2410 Series Refrigerators MFR # 2007578004
42. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
43. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
44. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
45. #APPLIANCE COMPONENTS RV; Tube Gas MFR # 2930618018
46. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
47. #Bracket Mount MFR # 2007410000
48. #APPLIANCE COMPONENTS RV; Retainer MFR # 2930659012
49. #WASHER 4X12 MM MFR # 2007457019
50. #Block Terminal Small 3 Poi MFR # 7627202562
51. #Refrigerator Gasket; Use With Dometic 2007199009 And MC Enterprise 2007199009MC Thermostats; Rubber O-Ring; Set Of 2 MFR # 140748005MC Superseded: see description
52. #Ring, Sealing 2 Req. MFR # 140748005
53. #CATCH, SNAP USE 2930066028 MFR # 2930071010 Superseded: see description
54. #CATCH, SNAP USE 2930071010 MFR # 2007428002 Superseded: see description
55. #Catch Snap 12/120 (Fus) MFR # 2930066028
56. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
57. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
58. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
59. #BLOCK, TERMINA USE 2930463019 LARGE RM2800, 2801 MFR # 2002633010 Superseded: see description
60. #3858022019 MFR # 3858022019
61. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
62. #PLATE/SIGN,12 VOLT DC MFR # 2007452002
63. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
64. #RETAINER MFR # 293066010
65. #Refrigerator Burner Control Module Mounting Bracket; Replacement For Dometic RM1302/ RM1300/ RM661/ RM2410/ RM2510/ RGE400/ RM2810 Series Refrigerator MFR # 2007567007
66. #Refrigerator Drain Tube Clamp; Replacement For Dometic RGE400 Model Refrigerators MFR # 2005112004
67. #APPLIANCE COMPONENTS RV; Ring Retainer MFR # 7353113231
68. #Refrigerator Burner Box Cover; Replacement For Dometic RM2400/ RM2800/ RGE400/ RM2801/ RM2601/ RGE2601/ RM661/ RM761/ RM2510 Series Refrigerator MFR # 2007440007
69. #Refrigerator Gas Valve Adapter Fitting; Use With Dometic Refrigerator Models RM2601/ RM2801/ RM2810; MALE CONNECTOR: 3/8" O.D TUBE X 1/4" O.D. TUBE MFR # 2930619008 Superseded: see description
70. #S,BAFFLE ASM,781MM MFR # 2007590058
71. #NIPPLE FOR GAS TUBE MFR # 2930752015
72. #CAP FLUE MFR # 2931540013
73. #APPLIANCE COMPONENTS RV; Relay 12V MFR # 2930385006
74. #Refrigerator Relay; Use On Dometic Refrigerator Models QCS135B/ RM100/ RM1303/ RM1350-921148302/ RM1350-921148307/ RM1350-921148319/ RM1350-921148320/ RM2354-921145025/ RM2354-921145027/ RM2354-921145030/ RM2354-921145031/ RM2354-921145051/ RM2354-921145052/ RM2454-921140114/ RM2454-921140115/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604-921580101/ RM3604-921580201/ RM3800/ RM3801/ RM3804-921600101/ RM3804-921600301/ RM4801/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006/ RM4804006/ RM663/ RM76/ RM763/ RM76D/ RM77/ RM77D MFR # 2930385006MC Superseded: see description
75. #RELAY USE 2930385006 MFR # 2930385014 Superseded: see description
76. #SIGN PLATE, 12 VOLT MFR # 2007686013
77. #S,PUSH ROD ASM,RM2410/2510.2 MFR # 2007468016
78. #S,SHAFT ASM,T-STAT,RM2410-2510 MFR # 2007471002
79. #S,SHAFT EXT ASM,RM2410/2510.2 MFR # 2007475003
80. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
81. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
82. #PLUG W/CORD USE 2002699037 MOLDED MFR # 2002699011 Superseded: see description
83. #Refrigerator Burner Box Cover; Replacement For Dometic RM2600/ S520014/ RM7030 Refrigerators MFR # 2930651019
84. #APPLIANCE COMPONENTS RV; ELEMENT, HEATING 12V; 17.9 AMPS MFR # 173757014
85. #ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974
86. #ELEMENT, HEATING USE 173754045 SEE NOTES MFR # 173754011 Superseded: see description
87. #ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386
88. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
89. #APPLIANCE COMPONENTS RV; Conductor MFR # 2007445006
90. #Refrigerator Burner Box Cover; Replacement For Dometic RM3807/ RM2620 Refrigerators MFR # 2931572016

Replacement Refrigerator

Components

9 items

1. #Refrigerator / Freezer;;Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand MFR # N641N
2. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R
3. #Refrigerator - Built In; N641; 6.3 cu ft; 2 Door; Without Ice Maker; AC/ LP; 52-7/8 Inches High x 23-1/2 Inches Wide x 24 Inches Deep; Not Included; Black; Gas Absorption; MFR # N641BK
4. #REFER,6 CU FT 3W WHITE 52 7/8"H X 23 1/2"W X 2 MFR # N641IMWH
5. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Stainless Steel Doors; With Crispers/ Shelving And Door Bins MFR # N641SS
6. #REFER,6 CU 2-W 52 7/8"H X 23 1/2"W X 24"D SUGGESTED ALTERNATE: STAINLESS IS NOW N/A. USE BLACK, RM2652B, FOR A SUGGESTED ALTERNATE. MFR # N641WH Superseded: see description
7. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N
8. #APPLIANCE COMPONENTS RV;;Refrigerator/Lp-Ac/Ss MFR # N641IMSS
9. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 4.2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; With Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Door; With Crispers/ Shelving And Door Bins MFR # N641IMBK

Front View Cabinet Assembly

Components

61 items

1. #S,HINGE,UPR,CLASSIC MFR # 2931291013
2. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
3. #Dometic RM2193 RM2652 Cooling Unit Assembly MFR # 2931293027
4. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
5. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
6. #Appliance Components RV MFR # 2931289017
7. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
8. #Refrigerator Door Hinge Plate; Replacement For Dometic RM2410/ RM2610/ RM2810 Model Refrigerator; Fits Right Hand Top; FOR LEFT MOUNTING PLATE USE 2931297028 MFR # 2931297010 Superseded: see description
9. #Refrigerator Door Hinge Plate; Replacement For Dometic RM2410/ RM2610/ RM2810 Model Refrigerators; Fits Left Hand Top; FOR RIGHT MOUNTING PLATE, USE PART NUMBER 2931297010 MFR # 2931297028 Superseded: see description
10. #CABINET BASE MFR # 2007465004
11. #Button, Push Use 2007479088 Grey/Brown MFR # 2007479054 Superseded: see description
12. #Refrigerator Door Light Switch; Replacement For Dometic RM2401/ RM2501/ RGE400/ RM2800/ RM760/ RM2310/ RM2810/ RM361/ RM2400 Series Refrigerators; Push Button MFR # 2007479088
13. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
14. #Appliance Components RV; Knob Grey/Brown 12V/120V MFR # 2007480177
15. #S,KNOB ASM,SELECTOR,2410/2510 MFR # 2007480185
16. #PLUG,LG USE 2940347004 (DEAD HOLE COVER) RM2510 MFR # 2931531012 Superseded: see description
17. #APPLIANCE COMPONENTS RV; Plug Black MFR # 2940347004
18. #S,HINGE,LWR,R,PNTD,2410.2/2510 MFR # 2931539015
19. #S,HINGE,LWR,L,PNTD,2410.2/2510 MFR # 2931538017
20. #S,HINGE PIN,MID,25MM MFR # 2931287011
21. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
22. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
23. #S,BASE FRONT,L=573MM,RM2510 MFR # 2931528026
24. #SIGN PLATE MFR # 2930753005
25. #Appliance Components RV; Socket Lamp Grey/Brown MFR # 2007674019
26. #S,SOCKET,LAMP BISQUIT-RM2510.2 MFR # 2007674027
27. #Refrigerator Flame Indicator; Replacement For Dometic RM2401/ RM2501/ RM2601 Model Refrigerator; Clear; Single. WHEN USING PART# 2932810019 TO REPLACE PART# 2007675008 MODIFICATIONS TO THE WIRE LEAD CONNECTIONS TO THE LAMP WILL NEED TO BE MADE. MFR # 2932810019
28. #LAMP, PILOT USE 2932810019; THIS PILOT LAMP HAS THE FIXTURE INCLUDED. IT IS READY TO INSTALL AND NEEDS NO OTHER PARTS MFR # 2007675016 Superseded: see description
29. #Appliance Components RV; Sleeve Sealing MFR # 2007626001
30. #SLEEVE RM2510-RM2810 MFR # 2007673011
31. #Refrigerator Drain Tube; Replacement For Dometic RM2510/ RM2601/ RM2810 Model Refrigerator MFR # 2007349067
32. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
33. #S,STRIKE 9*35*24MM MFR # 2931511014
34. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
35. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
36. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
37. #Shelf, Freezer MFR # 2007535020
38. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
39. #Refrigerator Shelf MFR # 2002652218
40. #Refrigerator Shelf MFR # 2931117044
41. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
42. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
43. #APPLIANCE COMPONENTS RV; Shelf Wire 12" MFR # 2930133067
44. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
45. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
46. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
47. #PLATE RETAINING MFR # 2007649011
48. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
49. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
50. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
51. #Lock, Shelf Use 2007393024 N MFR # 2007393016 Superseded: see description
52. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
53. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
54. #APPLIANCE COMPONENTS RV; Lock Shelf Use 2007392026 MFR # 2007392018 Superseded: see description
55. #CRISPER,BLACK USE 2002726061 MFR # 2002726103 Superseded: see description
56. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
57. #Appliance Components RV MFR # 2007519008
58. #CLAMP 2800 MFR # 2002798003
59. #APPLIANCE COMPONENTS RV; Screw MFR # 7295344407
60. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
61. #PARTS BAG MFR # 2931610014

Door Assembly

Components

22 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #Refrigerator Gasket; Use With Dometic Refrigerator Models RM2604/ RM2610/ RM2607/ RM3604/ RM3607; Door Gasket; With Two Roll Double Sided Stick Tape/ One Roll Silicone MFR # 3108700 Superseded: see description
3. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
4. #PLUG MFR # 2031510032
5. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
6. #SCREW USE 7295229400 MFR # 7295229012 Superseded: see description
7. #HANDLE, TOP USE 2931600023 46-0408 MFR # 2931600015 Superseded: see description
8. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
9. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
10. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
11. #HOLDER BOTTLE APPROX. 8' MFR # 2030715061
12. #LABEL, INSTRUCTION MFR # 2002356000
13. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
14. #STRIP,DECORATION MFR # 2931583070
15. #SHELF, BROWN USE 2930558024 MFR # 2930558016 Superseded: see description
16. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
17. #RACK, WIRE USE 2930558016 FREEZER DOOR MFR # 2007043009 Superseded: see description
18. #APPLIANCE COMPONENTS RV; Shelf Freezer Door MFR # 2930558057
19. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
20. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
21. #Refrigerator Shelf; Use With Dometic RM2607/ RM100/ RA1302 Refrigerators; Juice Rack; Beige MFR # 2930533019 Superseded: see description
22. #PANELS, DOOR WOODGRAIN TOP & BOTTOM PANELS MFR # RM2611G
