Dometic RM2611 3 Way Lp- 12V Dc- 110V AC Parts Diagram · Product # 921572201 › Replacement Refrigerator

Refrigerator · 48 assemblies · 48 diagram sheets · 235 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM2611 3 Way Lp- 12V Dc- 110V AC RV refrigerator: 48 assemblies (Product # 921572201 › Replacement Refrigerator, Product # 921572701 › Door Assembly, Product # 921572701 › Cabinet Rear View, Product # 921571301 › Cabinet Rear View, Product # 921572601 › Burner & Controls and more) and 235 manufacturer part numbers. 55 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Product # 921572201 › Replacement Refrigerator

Components

3 items

1. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N
2. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N
3. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R

Product # 921572701 › Door Assembly

Components

17 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
3. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
4. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
5. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
6. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
7. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
8. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
9. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
10. #LABEL, INSTRUCTION MFR # 2002356000
11. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
12. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
13. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
14. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
15. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
16. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
17. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921572701 › Cabinet Rear View

Components

19 items

1. #REMAN C/U MFR # 2934803095R
2. #Cooling Unit (Ups) MFR # 2934803095N
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #COVER MFR # 17343000
5. #DECAL RM3804 MFR # 2931503003
6. #DECAL RM38 04 MFR # 2007574029
7. #LABEL, IMPORTANT MFR # 2007689009
8. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
9. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
10. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
11. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
12. #TUBE, DRAIN MFR # 2943361002
13. #Refrigerator Drain Tube; Replacement For Dometic RM2453/ RM3962/ RM2554 Model Refrigerators MFR # 2932749019
14. #S,TUBE,OVERFILL MFR # 2931829010
15. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
16. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
17. #Plate Protection Rm2800 MFR # 2930785015
18. #DECAL, WARNING 2807/4801 MFR # 2002577001
19. #APPLIANCE COMPONENTS RV; Clamp Hose MFR # 2943414009

Product # 921571301 › Cabinet Rear View

Components

19 items

1. #Cooling Unit (Ups) MFR # 2934803095N
2. #REMAN C/U MFR # 2934803095R
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #COVER MFR # 17343000
5. #DECAL RM3804 MFR # 2931503003
6. #DECAL RM38 04 MFR # 2007574029
7. #LABEL, IMPORTANT MFR # 2007689009
8. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
9. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
10. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
11. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
12. #TUBE, DRAIN MFR # 2943361002
13. #Refrigerator Drain Tube; Replacement For Dometic RM2453/ RM3962/ RM2554 Model Refrigerators MFR # 2932749019
14. #S,TUBE,OVERFILL MFR # 2931829010
15. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
16. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
17. #Plate Protection Rm2800 MFR # 2930785015
18. #DECAL, WARNING 2807/4801 MFR # 2002577001
19. #APPLIANCE COMPONENTS RV; Clamp Hose MFR # 2943414009

Product # 921572601 › Burner & Controls

Components

73 items

1. #Nut MFR # 140107044
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #APPLIANCE COMPONENTS RV; Wire Electrode MFR # 2007668052
4. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
5. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
6. #SCREW M4 X 10 S MFR # 7241289615
7. #SOLENOID,VALVE USE 2943298030 RM2611 MFR # 2943298006 Superseded: see description
8. #VALVE, SOLENOID USE 2943298022 MFR # 2943298014 Superseded: see description
9. #SOLENOID,GAS USE 2943298022 MFR # 2943298030 Superseded: see description
10. #APPLIANCE COMPONENTS RV; Valve Solenoid MFR # 2943298022
11. #NUT MFR # 2943286001
12. #S,VALVE,GAS SHUT-OFF,RM3807 MFR # 2943299004
13. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
14. #ELBOW,BRASS (90 DEG.) S182 1-31 MFR # 2931916015
15. #APPLIANCE COMPONENTS RV; Bolt U MFR # 2943285003
16. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
17. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
18. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
19. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
20. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
21. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
22. #BRACKET, MOUNTING MFR # 2931822015
23. #APPLIANCE COMPONENTS RV; Nipple Test MFR # 2931824011
24. #NIPPLE,SOLENOID VALVE RM28 07 MFR # 2931825026
25. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
26. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
27. #Label 12VDC MFR # 2931827006
28. #BOARD, 3-WAY USE 2931843037 MFR # 2931843029 Superseded: see description
29. #DOM REPLACEMENT BRD MFR # MICROP711
30. #BOARD, PC W/CVR USE 2932882018 MFR # 2931843037 Superseded: see description
31. #BOARD, PC LOWER USE 3308742000 3-WAY MFR # 2932882018 Superseded: see description
32. #Refrigerator Control Board Kit; Replacement For Dometic RM3663/ RM3807/ RM3607/ RM2807/ RM2611/ RM2811/ RM3863/ RM2663 Series Refrigerators; 3-Way; Universal MFR # 3308742000
33. #LEAD, 5 WIRE USE 2954542037. MFR # 2931862037 Superseded: see description
34. #LEAD,5 WIRE USE 2931862037 RM2807 MFR # 2931862011 Superseded: see description
35. #Refrigerator Switch Wiring Kit; Conductor Wire MFR # 2954542037
36. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
37. #S,THERMISTOR,W/LEAD 64" MFR # 2931863019
38. #Refrigerator Thermistor Adjuster; Replacement For Dometic RM3807/ RM2611/ RM2852 Model Refrigerators MFR # 2932164011
39. #HARNESS KIT USE 46-4571 MFR # 6256 Superseded: see description
40. #APPLIANCE COMPONENTS RV; Harness Kit MFR # 3108702675
41. #LEAD,GAS VALVE USE 3108702675 MFR # 2931864017 Superseded: see description
42. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
43. #HOUSING BURNER MFR # 2931913012
44. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
45. #Refrigerator Burner Box Cover; Replacement For Dometic RM3807/ RM2620 Refrigerators MFR # 2931572016
46. #BRACKET, GAS VALVE MFR # 2931915017
47. #S,COVER,LESS DECALS MFR # 2931858019
48. #ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974
49. #ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386
50. #ELEMENT, HEATING USE 48-9357 295W/120V 2WIRE MFR # 173754045 Superseded: see description
51. #APPLIANCE COMPONENTS RV; Element Heating 215W/12V 1 17.9 AMPS MFR # 173757063
52. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
53. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
54. #3858022019 MFR # 3858022019
55. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
56. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
57. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
58. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
59. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
60. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
61. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
62. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
63. #STRIP, TERMINAL 6 POS. MFR # 2930327008
64. #S,BAFFLE ASM,781MM MFR # 2007590058
65. #CAP FLUE MFR # 2931540013
66. #DECAL 3 - WAY MFR # 2932003003
67. #FUSE, 5 AMP USE AGC5 MFR # 2943542007 Superseded: see description
68. #FUSE, 5 AMP USE 2943542007 MFR # 2943542001 Superseded: see description
69. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
70. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
71. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
72. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
73. #SHIELD, THERMOCOUPLE LEAD MFR # 2932001015

Product # 921571301 › Door Assembly

Components

17 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
3. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
4. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
5. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
6. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
7. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
8. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
9. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
10. #LABEL, INSTRUCTION MFR # 2002356000
11. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
12. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
13. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
14. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
15. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
16. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
17. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921574301 › Cabinet Rear View

Components

20 items

1. #Cooling Unit (Ups) MFR # 2934803095N
2. #REMAN C/U MFR # 2934803095R
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #Lid MFR # 2933557015
5. #DECAL RM3804 MFR # 2931503003
6. #DECAL RM38 04 MFR # 2007574029
7. #LABEL, IMPORTANT MFR # 2007689009
8. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
9. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
10. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
11. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
12. #HOSE,DRAIN (725MM) MFR # 2931578054
13. #TUBE,DRAIN USE 2931578054 MFR # 2931578070 Superseded: see description
14. #S,TUBE,OVERFILL MFR # 2931829010
15. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
16. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
17. #Plate Protection Rm2800 MFR # 2930785015
18. #DECAL, WARNING 2807/4801 MFR # 2002577001
19. #APPLIANCE COMPONENTS RV; Clamp Hose MFR # 2943414009
20. #Refrigerator Drain Hose Plug; Replacement For Dometic NDR1272/ RM7130/ RM4873 Refrigerators;Also Use New Number 3316102.9019 MFR # 2932115013 Superseded: see description

Product # 921572101 › Door Assembly

Components

17 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
3. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
4. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
5. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
6. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
7. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
8. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
9. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
10. #LABEL, INSTRUCTION MFR # 2002356000
11. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
12. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
13. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
14. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
15. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
16. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
17. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921571301 › Cabinet Front View

Components

77 items

1. #Shelf, Freezer MFR # 2007535020
2. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
3. #Refrigerator Shelf MFR # 2931117044
4. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
5. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
6. #Refrigerator Shelf MFR # 2930133141
7. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W Use 29301 MFR # 2930133109 Superseded: see description
8. #Refrigerator Shelf MFR # 2002652218
9. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
10. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
11. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
12. #PLATE RETAINING MFR # 2007649011
13. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
14. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
15. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
16. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
17. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
18. #CRISPER,BLACK USE 2002726061 MFR # 2002726103 Superseded: see description
19. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
20. #Refrigerator Drip Tray; Replacement For Dometic RM2607/ RM2611/ RM3607 Model Refrigerator MFR # 2931869016
21. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
22. #DECAL, 3-WAY MFR # 2931883009
23. #PARTS BAG RM26 11/2811 MFR # 2931610048
24. #S,HINGE,UPR,CLASSIC MFR # 2931291013
25. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
26. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
27. #PLATE, MOUNTING 3-WAY MFR # 955000104
28. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
29. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
30. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
31. #BOARD, CIRCUIT USE 2932884030 3 WAY MFR # 2932697093 Superseded: see description
32. #BOARD, PC USE 2932697093 UPPER,W/MTG PLT 3 WAY MFR # 2931845016 Superseded: see description
33. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 3 Way MFR # 2932884030 Superseded: see description
34. #Refrigerator Trim; Replacement For Dometic RM2611/ RM2607 Refrigerators MFR # 2931865048
35. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
36. #Refrigerator Door Latch Plate Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1303/ RM2510/ RM2551/ RM360/ RM3862/ RM3863/ RM663/ RM760/ RM761/ RM763 Model Refrigerator; B6 x 13 MFR # 7295281401
37. #Appliance Components RV MFR # 2931289017
38. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
39. #SUPPORT MFR # 2930774019
40. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
41. #PLATE,MOUNTING LH MFR # 2931459016
42. #PLATE,MOUNTING RH MFR # 2931459024
43. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
44. #HINGE, LOWER LH RM26 04 MFR # 2931283010
45. #HINGE, LOWER RH MFR # 2931283028
46. #S,HINGE PIN,MID,25MM MFR # 2931287011
47. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
48. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
49. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
50. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
51. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
52. #Refrigerator Vent Cover Back Plate MFR # 2930664012
53. #APPLIANCE COMPONENTS RV; Runner Right MFR # 2931281014
54. #APPLIANCE COMPONENTS RV; Runner Left MFR # 2931281022
55. #APPLIANCE COMPONENTS RV; Base Front MFR # 2931282038
56. #INSULATION MFR # 2930711011
57. #APPLIANCE COMPONENTS RV; Trim Bottom MFR # 2931628016
58. #Refrigerator Thermostat Cover MFR # 2931285015
59. #REINFORCEMENT MFR # 2931504019
60. #Refrigerator Door Latch; Replacement For Dometic RM2807/ RM2611/ RM2620/ RM2820 Model Refrigerators MFR # 2931284017
61. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
62. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
63. #S,STRIKE 9*35*24MM MFR # 2931511014
64. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
65. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
66. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
67. #Dometic RM2193 Refrigerator Control Board Assembly MFR # 2931856013
68. #BRACKET,MOUNTING MFR # 2931298018
69. #Lead T-Stat MFR # 2930735010
70. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
71. #SHADE, LAMP MFR # 2004043002
72. #APPLIANCE COMPONENTS RV; Light 12V MFR # 2930744012
73. #BULB 2/PK MFR # 2007290006
74. #COVER, LIGHT SWITCH MFR # 2004044109
75. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
76. #SCREW MFR # 7295283407
77. #Refrigerator Thermostat Cover; Use With Dometic RM3807/ RM2611/ RM7732 Refrigerators MFR # 2930611013 Superseded: see description

Product # 921571401 › Door Assembly

Components

17 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
3. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
4. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
5. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
6. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
7. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
8. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
9. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
10. #LABEL, INSTRUCTION MFR # 2002356000
11. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
12. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
13. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
14. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
15. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
16. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
17. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921573601 › Burner & Controls

Components

73 items

1. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
2. #SHIELD, THERMOCOUPLE LEAD MFR # 2932001015
3. #APPLIANCE COMPONENTS RV; Wire Electrode MFR # 2007668052
4. #APPLIANCE COMPONENTS RV; Valve Kit Shut Off W/Pro MFR # 3108706023
5. #VALVE, GAS USE 3108706023 MFR # 2007709047 Superseded: see description
6. #Refrigerator Gas Inlet Tube; Use With Dometic Refrigerator Model RM3807 MFR # 2932117019 Superseded: see description
7. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
8. #SCREW M4 X 10 S MFR # 7241289615
9. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
10. #APPLIANCE COMPONENTS RV; Valve Solenoid MFR # 2943298022
11. #SOLENOID,GAS USE 2943298022 MFR # 2943298030 Superseded: see description
12. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
13. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
14. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
15. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
16. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
17. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
18. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
19. #BRACKET, MOUNTING MFR # 2931822015
20. #APPLIANCE COMPONENTS RV; Nipple Test MFR # 2931824011
21. #Refrigerator Gas Valve Adapter Fitting; Replacement For Dometic RM2811/ RM3807/ RM7832 Model Refrigerator; Solenoid Inlet Nipple MFR # 2932063015
22. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
23. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
24. #Label 12VDC MFR # 2931827006
25. #DOM REPLACEMENT BRD MFR # MICROP711
26. #BOARD, PC W/CVR USE 2932882018 MFR # 2931843037 Superseded: see description
27. #Refrigerator Control Board Kit; Replacement For Dometic RM3663/ RM3807/ RM3607/ RM2807/ RM2611/ RM2811/ RM3863/ RM2663 Series Refrigerators; 3-Way; Universal MFR # 3308742000
28. #BOARD, PC LOWER USE 3308742000 3-WAY MFR # 2932882018 Superseded: see description
29. #BOARD, 3-WAY USE 2931843037 MFR # 2931843029 Superseded: see description
30. #S,COVER,LESS DECALS MFR # 2931858019
31. #LEAD,5 WIRE USE 2931862037 RM2807 MFR # 2931862011 Superseded: see description
32. #Refrigerator Switch Wiring Kit; Conductor Wire MFR # 2954542037
33. #LEAD, 5 WIRE USE 2954542037. MFR # 2931862037 Superseded: see description
34. #Thermistor; Use 3851059042 with lead 44" MFR # 2931863035 Superseded: see description
35. #Refrigerator Thermistor Assembly; Replacement Refrigerator Thermistor; 51 Inch Length MFR # 3851059042
36. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
37. #Refrigerator Thermistor Assembly; Replacement For Dometic Refrigerator Thermistor MFR # 3851210025
38. #APPLIANCE COMPONENTS RV; Harness Kit MFR # 3108702675
39. #LEAD,GAS VALVE USE 3108702675 MFR # 2931864017 Superseded: see description
40. #HARNESS KIT USE 46-4571 MFR # 6256 Superseded: see description
41. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
42. #HOUSING BURNER MFR # 2931913012
43. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
44. #Refrigerator Burner Box Cover; Replacement For Dometic RM3807/ RM2620 Refrigerators MFR # 2931572016
45. #APPLIANCE COMPONENTS RV; Bracket Manual Gas Valve MFR # 2932116011
46. #ELEMENT, HEATER USE 3108702386 120V 295W MFR # 173754102 Superseded: see description
47. #ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386
48. #ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974
49. #APPLIANCE COMPONENTS RV; Element Heating 215W/12V 1 17.9 AMPS MFR # 173757063
50. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
51. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
52. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
53. #3858022019 MFR # 3858022019
54. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
55. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
56. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
57. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
58. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
59. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
60. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
61. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
62. #STRIP, TERMINAL 6 POS. MFR # 2930327008
63. #S,BAFFLE ASM,781MM MFR # 2007590058
64. #CAP FLUE MFR # 2931540013
65. #DECAL 3 - WAY MFR # 2932003003
66. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
67. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
68. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
69. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
70. #APPLIANCE COMPONENTS RV; Protector Washer MFR # 2930811019
71. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
72. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
73. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description

Product # 921573601 › Cabinet Front View

Components

69 items

1. #S,HINGE,UPR,CLASSIC MFR # 2931291013
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
4. #PLATE, MOUNTING 3-WAY MFR # 955000104
5. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
6. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
7. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
8. #BOARD, CIRCUIT USE 2932884030 3 WAY MFR # 2932697093 Superseded: see description
9. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 3 Way MFR # 2932884030 Superseded: see description
10. #BOARD, PC USE 2932697093 UPPER,W/MTG PLT 3 WAY MFR # 2931845016 Superseded: see description
11. #FRONT MFR # 2931865105
12. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
13. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
14. #Appliance Components RV MFR # 2931289017
15. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
16. #BRACKET, MOUNTING RH MFR # 2932125012
17. #BRACKET, MOUNTING LH MFR # 2932125020
18. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
19. #S,HINGE,LWR,L,CLASSIC 6/8,PNTD MFR # 2932111012
20. #S,HINGE,LWR,R,CLASSIC 6/8,PNTD MFR # 2932111020
21. #S,HINGE PIN,MID,25MM MFR # 2931287011
22. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
23. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
24. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
25. #Refrigerator Vent Cover Back Plate MFR # 2930664012
26. #Refrigerator Door Rail; Replacement For Dometic RM3807/ RM2620/ RM2607 Refrigerators; Lower Door MFR # 2932110014
27. #Refrigerator Trim; Replacement For Dometic RM2607/ RM2620/ RM2611 Refrigerators; Front Lower MFR # 2932112036
28. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
29. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
30. #DECAL MFR # 2932165000
31. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
32. #S,STRIKE 9*35*24MM MFR # 2931511014
33. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
34. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
35. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
36. #Shelf, Freezer MFR # 2007535020
37. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
38. #Refrigerator Shelf MFR # 2931117044
39. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
40. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
41. #Refrigerator Shelf MFR # 2930133141
42. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W Use 29301 MFR # 2930133109 Superseded: see description
43. #Refrigerator Shelf MFR # 2002652218
44. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
45. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
46. #PLATE RETAINING MFR # 2007649011
47. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
48. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
49. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
50. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
51. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
52. #CRISPER,BLACK USE 2002726061 MFR # 2002726103 Superseded: see description
53. #Refrigerator Drip Tray; Replacement For Dometic RM2607/ RM2611/ RM3607 Model Refrigerator MFR # 2931869016
54. #Refrigerator Interior Light Mounting Bracket; Replacement For Dometic RM3663/ RGE400/ RM3863 Refrigerators; Also Use New Number 2932520014 MFR # 2932523018 Superseded: see description
55. #SOCKET, LAMP; Use 2932523018 on Models RM4872 & RM4873 MFR # 2932107010 Superseded: see description
56. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
57. #SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description
58. #Refrigerator Interior Light Contact Pin; Replacement For Dometic DM2862/ RM1350/ RM3762/ RM3962 Model Refrigerator; Tin Bronze; Single MFR # 2932108018
59. #Refrigerator Interior Light Mounting Bracket; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator MFR # 2932106012
60. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
61. #BULB 2/PK MFR # 2007290006
62. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
63. #SCREW MFR # 7295283407
64. #DECAL, 3-WAY MFR # 2931883009
65. #Dometic RM2193 Refrigerator Control Board Assembly MFR # 2931856013
66. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
67. #Refrigerator Thermistor Assembly; Replacement For Dometic Refrigerator Thermistor MFR # 3851210025
68. #Refrigerator Thermistor Assembly; Replacement Refrigerator Thermistor; 51 Inch Length MFR # 3851059042
69. #Thermistor; Use 3851059042 with lead 44" MFR # 2931863035 Superseded: see description

Product # 921572201 › Burner & Controls

Components

74 items

1. #Nut MFR # 140107044
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #APPLIANCE COMPONENTS RV; Wire Electrode MFR # 2007668052
4. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
5. #SCREW M4 X 10 S MFR # 7241289615
6. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
7. #SOLENOID,VALVE USE 2943298030 RM2611 MFR # 2943298006 Superseded: see description
8. #APPLIANCE COMPONENTS RV; Valve Solenoid MFR # 2943298022
9. #SOLENOID,GAS USE 2943298022 MFR # 2943298030 Superseded: see description
10. #VALVE, SOLENOID USE 2943298022 MFR # 2943298014 Superseded: see description
11. #NUT MFR # 2943286001
12. #S,VALVE,GAS SHUT-OFF,RM3807 MFR # 2943299004
13. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
14. #ELBOW,BRASS (90 DEG.) S182 1-31 MFR # 2931916015
15. #APPLIANCE COMPONENTS RV; Bolt U MFR # 2943285003
16. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
17. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
18. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
19. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
20. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
21. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
22. #BRACKET, MOUNTING MFR # 2931822015
23. #APPLIANCE COMPONENTS RV; Nipple Test MFR # 2931824011
24. #NIPPLE,SOLENOID VALVE RM28 07 MFR # 2931825026
25. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
26. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
27. #Label 12VDC MFR # 2931827006
28. #BOARD, 3-WAY USE 2931843037 MFR # 2931843029 Superseded: see description
29. #BOARD, PC W/CVR USE 2932882018 MFR # 2931843037 Superseded: see description
30. #DOM REPLACEMENT BRD MFR # MICROP711
31. #BOARD, PC LOWER USE 3308742000 3-WAY MFR # 2932882018 Superseded: see description
32. #Refrigerator Control Board Kit; Replacement For Dometic RM3663/ RM3807/ RM3607/ RM2807/ RM2611/ RM2811/ RM3863/ RM2663 Series Refrigerators; 3-Way; Universal MFR # 3308742000
33. #LEAD,5 WIRE USE 2931862037 RM2807 MFR # 2931862011 Superseded: see description
34. #LEAD, 5 WIRE USE 2954542037. MFR # 2931862037 Superseded: see description
35. #Refrigerator Switch Wiring Kit; Conductor Wire MFR # 2954542037
36. #Refrigerator Thermistor Adjuster; Replacement For Dometic RM3807/ RM2611/ RM2852 Model Refrigerators MFR # 2932164011
37. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
38. #S,THERMISTOR,W/LEAD 64" MFR # 2931863019
39. #LEAD,GAS VALVE USE 3108702675 MFR # 2931864017 Superseded: see description
40. #HARNESS KIT USE 46-4571 MFR # 6256 Superseded: see description
41. #APPLIANCE COMPONENTS RV; Harness Kit MFR # 3108702675
42. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
43. #HOUSING BURNER MFR # 2931913012
44. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
45. #Refrigerator Burner Box Cover; Replacement For Dometic RM3807/ RM2620 Refrigerators MFR # 2931572016
46. #BRACKET, GAS VALVE MFR # 2931915017
47. #S,COVER,LESS DECALS MFR # 2931858019
48. #ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386
49. #ELEMENT, HEATING USE 48-9357 295W/120V 2WIRE MFR # 173754045 Superseded: see description
50. #ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974
51. #APPLIANCE COMPONENTS RV; Element Heating 215W/12V 1 17.9 AMPS MFR # 173757063
52. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
53. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
54. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
55. #3858022019 MFR # 3858022019
56. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
57. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
58. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
59. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
60. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
61. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
62. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
63. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
64. #STRIP, TERMINAL 6 POS. MFR # 2930327008
65. #S,BAFFLE ASM,781MM MFR # 2007590058
66. #CAP FLUE MFR # 2931540013
67. #NO PART # GIVEN BY VENDOR MFR # NPG
68. #FUSE, 5 AMP USE AGC5 MFR # 2943542007 Superseded: see description
69. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
70. #FUSE, 5 AMP USE 2943542007 MFR # 2943542001 Superseded: see description
71. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
72. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
73. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
74. #SHIELD, THERMOCOUPLE LEAD MFR # 2932001015

Product # 921574201 › Replacement Refrigerator

Components

3 items

1. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N
2. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R
3. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N

Product # 921572201 › Door Assembly

Components

17 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
3. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
4. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
5. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
6. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
7. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
8. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
9. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
10. #LABEL, INSTRUCTION MFR # 2002356000
11. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
12. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
13. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
14. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
15. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
16. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
17. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921571401 › Replacement Refrigerator

Components

1 item

1. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N

Product # 921574201 › Cabinet Front View

Components

38 items

1. #S,HINGE,UPR,CLASSIC MFR # 2931291013
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
4. #PLATE, MOUNTING 3-WAY MFR # 955000104
5. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
6. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
7. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
8. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 3 Way MFR # 2932884030 Superseded: see description
9. #BOARD, CIRCUIT USE 2932884030 3 WAY MFR # 2932697093 Superseded: see description
10. #BOARD, PC USE 2932697093 UPPER,W/MTG PLT 3 WAY MFR # 2931845016 Superseded: see description
11. #FRONT MFR # 2931865105
12. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
13. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
14. #Appliance Components RV MFR # 2931289017
15. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
16. #BRACKET, MOUNTING RH MFR # 2932125012
17. #BRACKET, MOUNTING LH MFR # 2932125020
18. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
19. #S,HINGE,LWR,L,CLASSIC 6/8,PNTD MFR # 2932111012
20. #S,HINGE,LWR,R,CLASSIC 6/8,PNTD MFR # 2932111020
21. #S,HINGE PIN,MID,25MM MFR # 2931287011
22. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
23. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
24. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
25. #Refrigerator Vent Cover Back Plate MFR # 2930664012
26. #Refrigerator Door Rail; Replacement For Dometic RM3807/ RM2620/ RM2607 Refrigerators; Lower Door MFR # 2932110014
27. #Refrigerator Trim; Replacement For Dometic RM2607/ RM2620/ RM2611 Refrigerators; Front Lower MFR # 2932112036
28. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
29. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
30. #DECAL MFR # 2932165000
31. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
32. #S,STRIKE 9*35*24MM MFR # 2931511014
33. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
34. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
35. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
36. #Shelf, Freezer MFR # 2007535020
37. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
38. #Refrigerator Shelf MFR # 2931117044

Product # 921572601 › Cabinet Front View

Components

82 items

1. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
2. #Refrigerator Shelf MFR # 2931117044
3. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
4. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
5. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W Use 29301 MFR # 2930133109 Superseded: see description
6. #Refrigerator Shelf MFR # 2930133141
7. #Refrigerator Shelf MFR # 2002652218
8. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
9. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
10. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
11. #PLATE RETAINING MFR # 2007649011
12. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
13. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
14. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
15. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
16. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
17. #CRISPER,BLACK USE 2002726061 MFR # 2002726103 Superseded: see description
18. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
19. #Refrigerator Drip Tray; Replacement For Dometic RM2607/ RM2611/ RM3607 Model Refrigerator MFR # 2931869016
20. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
21. #DECAL, 3-WAY MFR # 2931883009
22. #PARTS BAG RM26 11/2811 MFR # 2931610048
23. #S,HINGE,UPR,CLASSIC MFR # 2931291013
24. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
25. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
26. #PLATE, MOUNTING 3-WAY MFR # 955000104
27. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
28. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
29. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
30. #BOARD, CIRCUIT USE 2932884030 3 WAY MFR # 2932697093 Superseded: see description
31. #BOARD, PC USE 2932697093 UPPER,W/MTG PLT 3 WAY MFR # 2931845016 Superseded: see description
32. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 3 Way MFR # 2932884030 Superseded: see description
33. #Refrigerator Trim; Replacement For Dometic RM2611/ RM2607 Refrigerators MFR # 2931865048
34. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
35. #Refrigerator Door Latch Plate Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1303/ RM2510/ RM2551/ RM360/ RM3862/ RM3863/ RM663/ RM760/ RM761/ RM763 Model Refrigerator; B6 x 13 MFR # 7295281401
36. #Appliance Components RV MFR # 2931289017
37. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
38. #SUPPORT MFR # 2930774019
39. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
40. #PLATE,MOUNTING LH MFR # 2931459016
41. #PLATE,MOUNTING RH MFR # 2931459024
42. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
43. #HINGE, LOWER LH RM26 04 MFR # 2931283010
44. #HINGE, LOWER RH MFR # 2931283028
45. #S,HINGE PIN,MID,25MM MFR # 2931287011
46. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
47. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
48. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
49. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
50. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
51. #Refrigerator Vent Cover Back Plate MFR # 2930664012
52. #DECAL,ON/OFF SWITCH MFR # 2931877001
53. #APPLIANCE COMPONENTS RV; Runner Right MFR # 2931281014
54. #APPLIANCE COMPONENTS RV; Runner Left MFR # 2931281022
55. #APPLIANCE COMPONENTS RV; Base Front Rm26 11 MFR # 2931282079
56. #INSULATION MFR # 2930711011
57. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
58. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
59. #APPLIANCE COMPONENTS RV; Trim Bottom MFR # 2931628016
60. #Refrigerator Thermostat Cover MFR # 2931285015
61. #REINFORCEMENT MFR # 2931504019
62. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
63. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
64. #S,STRIKE 9*35*24MM MFR # 2931511014
65. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
66. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
67. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
68. #Dometic RM2193 Refrigerator Control Board Assembly MFR # 2931856013
69. #BRACKET,MOUNTING MFR # 2931298018
70. #COVER, LIGHT USE 2004044091 MFR # 2004044083 Superseded: see description
71. #COVER, LIGHT SWITCH MFR # 2004044109
72. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
73. #SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description
74. #Lead T-Stat MFR # 2930735010
75. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
76. #SHADE, LAMP MFR # 2004043002
77. #BULB 2/PK MFR # 2007290006
78. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
79. #COVER, CAPILLARY USE 2004056012 MFR # 2004056046 Superseded: see description
80. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
81. #SCREW MFR # 7295283407
82. #Refrigerator Thermostat Cover; Use With Dometic RM3807/ RM2611/ RM7732 Refrigerators MFR # 2930611013 Superseded: see description

Product # 921572201 › Cabinet Front View

Components

70 items

1. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
2. #Refrigerator Shelf MFR # 2931117044
3. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
4. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
5. #Refrigerator Shelf MFR # 2930133141
6. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W Use 29301 MFR # 2930133109 Superseded: see description
7. #Refrigerator Shelf MFR # 2002652218
8. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
9. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
10. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
11. #PLATE RETAINING MFR # 2007649011
12. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
13. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
14. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
15. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
16. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
17. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
18. #CRISPER,BLACK USE 2002726061 MFR # 2002726103 Superseded: see description
19. #Refrigerator Drip Tray; Replacement For Dometic RM2607/ RM2611/ RM3607 Model Refrigerator MFR # 2931869016
20. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
21. #DECAL, 3-WAY MFR # 2931883009
22. #PARTS BAG RM26 11/2811 MFR # 2931610048
23. #S,HINGE,UPR,CLASSIC MFR # 2931291013
24. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
25. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
26. #PLATE, MOUNTING 3-WAY MFR # 955000104
27. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
28. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
29. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
30. #BOARD, PC USE 2932697093 UPPER,W/MTG PLT 3 WAY MFR # 2931845016 Superseded: see description
31. #BOARD, CIRCUIT USE 2932884030 3 WAY MFR # 2932697093 Superseded: see description
32. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 3 Way MFR # 2932884030 Superseded: see description
33. #Refrigerator Trim; Replacement For Dometic RM2611/ RM2607 Refrigerators MFR # 2931865048
34. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
35. #Refrigerator Door Latch Plate Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1303/ RM2510/ RM2551/ RM360/ RM3862/ RM3863/ RM663/ RM760/ RM761/ RM763 Model Refrigerator; B6 x 13 MFR # 7295281401
36. #Appliance Components RV MFR # 2931289017
37. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
38. #SUPPORT MFR # 2930774019
39. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
40. #PLATE,MOUNTING LH MFR # 2931459016
41. #PLATE,MOUNTING RH MFR # 2931459024
42. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
43. #HINGE, LOWER LH RM26 04 MFR # 2931283010
44. #HINGE, LOWER RH MFR # 2931283028
45. #S,HINGE PIN,MID,25MM MFR # 2931287011
46. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
47. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
48. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
49. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
50. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
51. #Refrigerator Vent Cover Back Plate MFR # 2930664012
52. #DECAL,ON/OFF SWITCH MFR # 2931877001
53. #APPLIANCE COMPONENTS RV; Runner Right MFR # 2931281014
54. #APPLIANCE COMPONENTS RV; Runner Left MFR # 2931281022
55. #APPLIANCE COMPONENTS RV; Base Front Rm26 11 MFR # 2931282079
56. #INSULATION MFR # 2930711011
57. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
58. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
59. #APPLIANCE COMPONENTS RV; Trim Bottom MFR # 2931628016
60. #Refrigerator Thermostat Cover MFR # 2931285015
61. #REINFORCEMENT MFR # 2931504019
62. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
63. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
64. #S,STRIKE 9*35*24MM MFR # 2931511014
65. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
66. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
67. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
68. #BRACKET MFR # 2931565019
69. #Refrigerator Mounting Plate; Replacement For Dometic RM2607/ RM2807/ RM2804 Refrigerators MFR # 2931381010
70. #Refrigerator Door Latch; Replacement For Dometic RM2611/ RM2620/ RM2607 Refrigerators MFR # 2931512010

Product # 921574301 › Door Assembly

Components

17 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
3. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
4. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
5. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
6. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
7. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
8. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
9. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
10. #LABEL, INSTRUCTION MFR # 2002356000
11. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
12. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
13. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
14. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
15. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
16. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
17. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921573701 › Burner & Controls

Components

29 items

1. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
2. #SHIELD, THERMOCOUPLE LEAD MFR # 2932001015
3. #APPLIANCE COMPONENTS RV; Wire Electrode MFR # 2007668052
4. #VALVE, GAS USE 3108706023 MFR # 2007709047 Superseded: see description
5. #APPLIANCE COMPONENTS RV; Valve Kit Shut Off W/Pro MFR # 3108706023
6. #Refrigerator Gas Inlet Tube; Use With Dometic Refrigerator Model RM3807 MFR # 2932117019 Superseded: see description
7. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
8. #SCREW M4 X 10 S MFR # 7241289615
9. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
10. #APPLIANCE COMPONENTS RV; Valve Solenoid MFR # 2943298022
11. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
12. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
13. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
14. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
15. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
16. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
17. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
18. #BRACKET, MOUNTING MFR # 2931822015
19. #APPLIANCE COMPONENTS RV; Nipple Test MFR # 2931824011
20. #Refrigerator Gas Valve Adapter Fitting; Replacement For Dometic RM2811/ RM3807/ RM7832 Model Refrigerator; Solenoid Inlet Nipple MFR # 2932063015
21. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
22. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
23. #Label 12VDC MFR # 2931827006
24. #DOM REPLACEMENT BRD MFR # MICROP711
25. #BOARD, PC W/CVR USE 2932882018 MFR # 2931843037 Superseded: see description
26. #Refrigerator Control Board Kit; Replacement For Dometic RM3663/ RM3807/ RM3607/ RM2807/ RM2611/ RM2811/ RM3863/ RM2663 Series Refrigerators; 3-Way; Universal MFR # 3308742000
27. #BOARD, PC LOWER USE 3308742000 3-WAY MFR # 2932882018 Superseded: see description
28. #BOARD, 3-WAY USE 2931843037 MFR # 2931843029 Superseded: see description
29. #S,COVER,LESS DECALS MFR # 2931858019

Product # 921572101 › Replacement Refrigerator

Components

3 items

1. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R
2. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N
3. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N

Product # 921572701 › Cabinet Front View

Components

83 items

1. #Shelf, Freezer MFR # 2007535020
2. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
3. #Refrigerator Shelf MFR # 2931117044
4. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
5. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
6. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W Use 29301 MFR # 2930133109 Superseded: see description
7. #Refrigerator Shelf MFR # 2930133141
8. #Refrigerator Shelf MFR # 2002652218
9. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
10. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
11. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
12. #PLATE RETAINING MFR # 2007649011
13. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
14. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
15. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
16. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
17. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
18. #CRISPER,BLACK USE 2002726061 MFR # 2002726103 Superseded: see description
19. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
20. #Refrigerator Drip Tray; Replacement For Dometic RM2607/ RM2611/ RM3607 Model Refrigerator MFR # 2931869016
21. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
22. #DECAL, 3-WAY MFR # 2931883009
23. #PARTS BAG RM26 11/2811 MFR # 2931610048
24. #S,HINGE,UPR,CLASSIC MFR # 2931291013
25. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
26. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
27. #PLATE, MOUNTING 3-WAY MFR # 955000104
28. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
29. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
30. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
31. #BOARD, CIRCUIT USE 2932884030 3 WAY MFR # 2932697093 Superseded: see description
32. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 3 Way MFR # 2932884030 Superseded: see description
33. #BOARD, PC USE 2932697093 UPPER,W/MTG PLT 3 WAY MFR # 2931845016 Superseded: see description
34. #Refrigerator Trim; Replacement For Dometic RM2611/ RM2607 Refrigerators MFR # 2931865048
35. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
36. #Refrigerator Door Latch Plate Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1303/ RM2510/ RM2551/ RM360/ RM3862/ RM3863/ RM663/ RM760/ RM761/ RM763 Model Refrigerator; B6 x 13 MFR # 7295281401
37. #Appliance Components RV MFR # 2931289017
38. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
39. #SUPPORT MFR # 2930774019
40. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
41. #PLATE,MOUNTING LH MFR # 2931459016
42. #PLATE,MOUNTING RH MFR # 2931459024
43. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
44. #HINGE, LOWER LH RM26 04 MFR # 2931283010
45. #HINGE, LOWER RH MFR # 2931283028
46. #S,HINGE PIN,MID,25MM MFR # 2931287011
47. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
48. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
49. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
50. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
51. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
52. #Refrigerator Vent Cover Back Plate MFR # 2930664012
53. #DECAL,ON/OFF SWITCH MFR # 2931877001
54. #APPLIANCE COMPONENTS RV; Runner Right MFR # 2931281014
55. #APPLIANCE COMPONENTS RV; Runner Left MFR # 2931281022
56. #APPLIANCE COMPONENTS RV; Base Front Rm26 11 MFR # 2931282079
57. #INSULATION MFR # 2930711011
58. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
59. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
60. #APPLIANCE COMPONENTS RV; Trim Bottom MFR # 2931628016
61. #Refrigerator Thermostat Cover MFR # 2931285015
62. #REINFORCEMENT MFR # 2931504019
63. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
64. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
65. #S,STRIKE 9*35*24MM MFR # 2931511014
66. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
67. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
68. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
69. #Dometic RM2193 Refrigerator Control Board Assembly MFR # 2931856013
70. #BRACKET,MOUNTING MFR # 2931298018
71. #2004044091 MFR # 2004044091
72. #COVER, LIGHT SWITCH MFR # 2004044109
73. #SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description
74. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
75. #Lead T-Stat MFR # 2930735010
76. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
77. #SHADE, LAMP MFR # 2004043002
78. #BULB 2/PK MFR # 2007290006
79. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
80. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
81. #COVER, CAPILLARY USE 2004056012 MFR # 2004056046 Superseded: see description
82. #SCREW MFR # 7295283407
83. #Refrigerator Thermostat Cover; Use With Dometic RM3807/ RM2611/ RM7732 Refrigerators MFR # 2930611013 Superseded: see description

Product # 921574201 › Cabinet Rear View

Components

20 items

1. #REMAN C/U MFR # 2934803095R
2. #Cooling Unit (Ups) MFR # 2934803095N
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #Lid MFR # 2933557015
5. #DECAL RM3804 MFR # 2931503003
6. #DECAL RM38 04 MFR # 2007574029
7. #LABEL, IMPORTANT MFR # 2007689009
8. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
9. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
10. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
11. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
12. #TUBE,DRAIN USE 2931578054 MFR # 2931578070 Superseded: see description
13. #HOSE,DRAIN (725MM) MFR # 2931578054
14. #S,TUBE,OVERFILL MFR # 2931829010
15. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
16. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
17. #Plate Protection Rm2800 MFR # 2930785015
18. #DECAL, WARNING 2807/4801 MFR # 2002577001
19. #APPLIANCE COMPONENTS RV; Clamp Hose MFR # 2943414009
20. #Refrigerator Drain Hose Plug; Replacement For Dometic NDR1272/ RM7130/ RM4873 Refrigerators;Also Use New Number 3316102.9019 MFR # 2932115013 Superseded: see description

Product # 921573601 › Cabinet Rear View

Components

20 items

1. #REMAN C/U MFR # 2934803095R
2. #Cooling Unit (Ups) MFR # 2934803095N
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #Lid MFR # 2933557015
5. #DECAL RM3804 MFR # 2931503003
6. #DECAL RM38 04 MFR # 2007574029
7. #LABEL, IMPORTANT MFR # 2007689009
8. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
9. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
10. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
11. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
12. #TUBE,DRAIN USE 2931578054 MFR # 2931578070 Superseded: see description
13. #HOSE,DRAIN (725MM) MFR # 2931578054
14. #S,TUBE,OVERFILL MFR # 2931829010
15. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
16. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
17. #Plate Protection Rm2800 MFR # 2930785015
18. #DECAL, WARNING 2807/4801 MFR # 2002577001
19. #Refrigerator Drain Hose Plug; Replacement For Dometic NDR1272/ RM7130/ RM4873 Refrigerators;Also Use New Number 3316102.9019 MFR # 2932115013 Superseded: see description
20. #APPLIANCE COMPONENTS RV; Clamp Hose MFR # 2943414009

Product # 921574301 › Burner & Controls

Components

74 items

1. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
2. #SHIELD, THERMOCOUPLE LEAD MFR # 2932001015
3. #APPLIANCE COMPONENTS RV; Wire Electrode MFR # 2007668052
4. #APPLIANCE COMPONENTS RV; Valve Kit Shut Off W/Pro MFR # 3108706023
5. #VALVE, GAS USE 3108706023 MFR # 2007709047 Superseded: see description
6. #Refrigerator Gas Inlet Tube; Use With Dometic Refrigerator Model RM3807 MFR # 2932117019 Superseded: see description
7. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
8. #SCREW M4 X 10 S MFR # 7241289615
9. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
10. #APPLIANCE COMPONENTS RV; Valve Solenoid MFR # 2943298022
11. #SOLENOID,GAS USE 2943298022 MFR # 2943298030 Superseded: see description
12. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
13. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
14. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
15. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
16. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
17. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
18. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
19. #BRACKET, MOUNTING MFR # 2931822015
20. #APPLIANCE COMPONENTS RV; Nipple Test MFR # 2931824011
21. #Refrigerator Gas Valve Adapter Fitting; Replacement For Dometic RM2811/ RM3807/ RM7832 Model Refrigerator; Solenoid Inlet Nipple MFR # 2932063015
22. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
23. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
24. #Label 12VDC MFR # 2931827006
25. #BOARD, PC W/CVR USE 2932882018 MFR # 2931843037 Superseded: see description
26. #Refrigerator Control Board Kit; Replacement For Dometic RM3663/ RM3807/ RM3607/ RM2807/ RM2611/ RM2811/ RM3863/ RM2663 Series Refrigerators; 3-Way; Universal MFR # 3308742000
27. #DOM REPLACEMENT BRD MFR # MICROP711
28. #BOARD, 3-WAY USE 2931843037 MFR # 2931843029 Superseded: see description
29. #BOARD, PC LOWER USE 3308742000 3-WAY MFR # 2932882018 Superseded: see description
30. #S,COVER,LESS DECALS MFR # 2931858019
31. #Refrigerator Switch Wiring Kit; Conductor Wire MFR # 2954542037
32. #LEAD,5 WIRE USE 2931862037 RM2807 MFR # 2931862011 Superseded: see description
33. #LEAD, 5 WIRE USE 2954542037. MFR # 2931862037 Superseded: see description
34. #Refrigerator Thermistor Assembly; Replacement For Dometic Refrigerator Thermistor MFR # 3851210025
35. #Thermistor; Use 3851059042 with lead 44" MFR # 2931863035 Superseded: see description
36. #Refrigerator Thermistor Assembly; Replacement Refrigerator Thermistor; 51 Inch Length MFR # 3851059042
37. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
38. #HARNESS KIT USE 46-4571 MFR # 6256 Superseded: see description
39. #APPLIANCE COMPONENTS RV; Harness Kit MFR # 3108702675
40. #LEAD,GAS VALVE USE 3108702675 MFR # 2931864017 Superseded: see description
41. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
42. #HOUSING BURNER MFR # 2931913012
43. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
44. #Refrigerator Burner Box Cover; Replacement For Dometic RM3807/ RM2620 Refrigerators MFR # 2931572016
45. #APPLIANCE COMPONENTS RV; Bracket Manual Gas Valve MFR # 2932116011
46. #ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974
47. #ELEMENT, HEATER USE 3108702386 120V 295W MFR # 173754102 Superseded: see description
48. #ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386
49. #APPLIANCE COMPONENTS RV; Element Heating 215W/12V 1 17.9 AMPS MFR # 173757063
50. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
51. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
52. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
53. #3858022019 MFR # 3858022019
54. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
55. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
56. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
57. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
58. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
59. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
60. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
61. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
62. #STRIP, TERMINAL 6 POS. MFR # 2930327008
63. #S,BAFFLE ASM,781MM MFR # 2007590058
64. #CAP FLUE MFR # 2931540013
65. #DECAL 3 - WAY MFR # 2932003003
66. #FUSE, 5 AMP USE AGC5 MFR # 2943542007 Superseded: see description
67. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
68. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
69. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
70. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
71. #APPLIANCE COMPONENTS RV; Protector Washer MFR # 2930811019
72. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
73. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
74. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110

Product # 921573701 › Cabinet Rear View

Components

19 items

1. #REMAN C/U MFR # 2934803095R
2. #Cooling Unit (Ups) MFR # 2934803095N
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #Lid MFR # 2933557015
5. #DECAL RM3804 MFR # 2931503003
6. #DECAL RM38 04 MFR # 2007574029
7. #LABEL, IMPORTANT MFR # 2007689009
8. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
9. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
10. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
11. #HOSE,DRAIN (725MM) MFR # 2931578054
12. #TUBE,DRAIN USE 2931578054 MFR # 2931578070 Superseded: see description
13. #S,TUBE,OVERFILL MFR # 2931829010
14. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
15. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
16. #Plate Protection Rm2800 MFR # 2930785015
17. #DECAL, WARNING 2807/4801 MFR # 2002577001
18. #APPLIANCE COMPONENTS RV; Clamp Hose MFR # 2943414009
19. #Refrigerator Drain Hose Plug; Replacement For Dometic NDR1272/ RM7130/ RM4873 Refrigerators;Also Use New Number 3316102.9019 MFR # 2932115013 Superseded: see description

Product # 921573601 › Door Assembly

Components

17 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
3. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
4. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
5. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
6. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
7. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
8. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
9. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
10. #LABEL, INSTRUCTION MFR # 2002356000
11. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
12. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
13. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
14. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
15. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
16. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
17. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921574301 › Replacement Refrigerator

Components

3 items

1. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R
2. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N
3. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N

Product # 921573701 › Door Assembly

Components

17 items

1. #DOOR,UPPER W/O SHELF RM2610 MFR # 2931589119
2. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
3. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
4. #DOOR,LOWER WITHOUT SHELVES RM26/2410 MFR # 2931588111
5. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
6. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
7. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
8. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
9. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
10. #LABEL, INSTRUCTION MFR # 2002356000
11. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
12. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
13. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
14. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
15. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
16. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
17. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921572601 › Door Assembly

Components

14 items

1. #APPLIANCE COMPONENTS RV; Gasket Kit RM2611 RM261 MFR # 3108704250
2. #GASKET TAPE 210" USE 6141 DOUBLE DOOR REFER 210" MFR # TAPE2 Superseded: see description
3. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
4. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
5. #Refrigerator Door Handle; Replacement For Dometic RM2811/ RM2612/ RM2620 Refrigerators; Fits Lower Door Hand Side; SPECS: FOR RM2820/2620, PRODUCT #'S921575009, 921596007 USE PART # 3850541016. FOR ALL OTHER PRODUCT #'S USE 2931600023 MFR # 2931600023 Superseded: see description
6. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
7. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
8. #LABEL, INSTRUCTION MFR # 2002356000
9. #APPLIANCE COMPONENTS RV; Strip Deco Use 3850382015 MFR # 2931583013 Superseded: see description
10. #STRIP, DECO USE 2931583013 RM2611 MFR # 2931583138 Superseded: see description
11. #S,DOOR COMPART,WHT,2820R/2620R MFR # 2931418038
12. #SHELF,FREEZER USE 2931418038 RM2610 MFR # 2931418020 Superseded: see description
13. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
14. #LABEL, WARNING FOR DOOR MFR # 2931620005

Product # 921573601 › Replacement Refrigerator

Components

3 items

1. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R
2. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N
3. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N

Product # 921572101 › Cabinet Front View

Components

83 items

1. #Shelf, Freezer MFR # 2007535020
2. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
3. #Refrigerator Shelf MFR # 2931117044
4. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
5. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
6. #Refrigerator Shelf MFR # 2930133141
7. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W Use 29301 MFR # 2930133109 Superseded: see description
8. #Refrigerator Shelf MFR # 2002652218
9. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
10. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
11. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
12. #PLATE RETAINING MFR # 2007649011
13. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
14. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
15. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
16. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
17. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
18. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
19. #CRISPER,BLACK USE 2002726061 MFR # 2002726103 Superseded: see description
20. #Refrigerator Drip Tray; Replacement For Dometic RM2607/ RM2611/ RM3607 Model Refrigerator MFR # 2931869016
21. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
22. #DECAL, 3-WAY MFR # 2931883009
23. #PARTS BAG RM26 11/2811 MFR # 2931610048
24. #S,HINGE,UPR,CLASSIC MFR # 2931291013
25. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
26. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
27. #PLATE, MOUNTING 3-WAY MFR # 955000104
28. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
29. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
30. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
31. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 3 Way MFR # 2932884030 Superseded: see description
32. #BOARD, PC USE 2932697093 UPPER,W/MTG PLT 3 WAY MFR # 2931845016 Superseded: see description
33. #BOARD, CIRCUIT USE 2932884030 3 WAY MFR # 2932697093 Superseded: see description
34. #Refrigerator Trim; Replacement For Dometic RM2611/ RM2607 Refrigerators MFR # 2931865048
35. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
36. #Refrigerator Door Latch Plate Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1303/ RM2510/ RM2551/ RM360/ RM3862/ RM3863/ RM663/ RM760/ RM761/ RM763 Model Refrigerator; B6 x 13 MFR # 7295281401
37. #Appliance Components RV MFR # 2931289017
38. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
39. #SUPPORT MFR # 2930774019
40. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
41. #PLATE,MOUNTING LH MFR # 2931459016
42. #PLATE,MOUNTING RH MFR # 2931459024
43. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
44. #HINGE, LOWER LH RM26 04 MFR # 2931283010
45. #HINGE, LOWER RH MFR # 2931283028
46. #S,HINGE PIN,MID,25MM MFR # 2931287011
47. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
48. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
49. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
50. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
51. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
52. #Refrigerator Vent Cover Back Plate MFR # 2930664012
53. #DECAL,ON/OFF SWITCH MFR # 2931877001
54. #APPLIANCE COMPONENTS RV; Runner Right MFR # 2931281014
55. #APPLIANCE COMPONENTS RV; Runner Left MFR # 2931281022
56. #APPLIANCE COMPONENTS RV; Base Front MFR # 2931282038
57. #INSULATION MFR # 2930711011
58. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
59. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
60. #APPLIANCE COMPONENTS RV; Trim Bottom MFR # 2931628016
61. #Refrigerator Thermostat Cover MFR # 2931285015
62. #REINFORCEMENT MFR # 2931504019
63. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
64. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
65. #S,STRIKE 9*35*24MM MFR # 2931511014
66. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
67. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
68. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
69. #Dometic RM2193 Refrigerator Control Board Assembly MFR # 2931856013
70. #BRACKET,MOUNTING MFR # 2931298018
71. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
72. #SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description
73. #Lead T-Stat MFR # 2930735010
74. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
75. #SHADE, LAMP MFR # 2004043002
76. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
77. #BULB 2/PK MFR # 2007290006
78. #APPLIANCE COMPONENTS RV; Light 12V MFR # 2930744012
79. #COVER, LIGHT SWITCH MFR # 2004044109
80. #2004044091 MFR # 2004044091
81. #COVER, CAPILLARY USE 2004056012 MFR # 2004056046 Superseded: see description
82. #SCREW MFR # 7295283407
83. #Refrigerator Thermostat Cover; Use With Dometic RM3807/ RM2611/ RM7732 Refrigerators MFR # 2930611013 Superseded: see description

Product # 921572701 › Replacement Refrigerator

Components

3 items

1. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N
2. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R
3. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N

Product # 921573701 › Replacement Refrigerator

Components

3 items

1. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N
2. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R
3. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N

Product # 921572601 › Cabinet Rear View

Components

66 items

1. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
2. #Appliance Components RV MFR # 2931289017
3. #SUPPORT MFR # 2930774019
4. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
5. #PLATE,MOUNTING LH MFR # 2931459016
6. #PLATE,MOUNTING RH MFR # 2931459024
7. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
8. #HINGE, LOWER LH RM26 04 MFR # 2931283010
9. #HINGE, LOWER RH MFR # 2931283028
10. #S,HINGE PIN,MID,25MM MFR # 2931287011
11. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
12. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
13. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
14. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
15. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
16. #Refrigerator Vent Cover Back Plate MFR # 2930664012
17. #DECAL,ON/OFF SWITCH MFR # 2931877001
18. #APPLIANCE COMPONENTS RV; Runner Right MFR # 2931281014
19. #APPLIANCE COMPONENTS RV; Runner Left MFR # 2931281022
20. #APPLIANCE COMPONENTS RV; Base Front Rm26 11 MFR # 2931282079
21. #INSULATION MFR # 2930711011
22. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
23. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
24. #APPLIANCE COMPONENTS RV; Trim Bottom MFR # 2931628016
25. #Refrigerator Thermostat Cover MFR # 2931285015
26. #REINFORCEMENT MFR # 2931504019
27. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
28. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
29. #S,STRIKE 9*35*24MM MFR # 2931511014
30. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
31. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
32. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931509007
33. #Dometic RM2193 Refrigerator Control Board Assembly MFR # 2931856013
34. #BRACKET,MOUNTING MFR # 2931298018
35. #REMAN C/U MFR # 2934803095R
36. #Cooling Unit (Ups) MFR # 2934803095N
37. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
38. #COVER MFR # 17343000
39. #DECAL RM3804 MFR # 2931503003
40. #DECAL RM38 04 MFR # 2007574029
41. #LABEL, IMPORTANT MFR # 2007689009
42. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
43. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
44. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
45. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
46. #TUBE, DRAIN MFR # 2943361002
47. #Refrigerator Drain Tube; Replacement For Dometic RM2453/ RM3962/ RM2554 Model Refrigerators MFR # 2932749019
48. #S,TUBE,OVERFILL MFR # 2931829010
49. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
50. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
51. #Plate Protection Rm2800 MFR # 2930785015
52. #DECAL, WARNING 2807/4801 MFR # 2002577001
53. #APPLIANCE COMPONENTS RV; Clamp Hose MFR # 2943414009
54. #COVER, LIGHT USE 2004044091 MFR # 2004044083 Superseded: see description
55. #COVER, LIGHT SWITCH MFR # 2004044109
56. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
57. #SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description
58. #Lead T-Stat MFR # 2930735010
59. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
60. #SHADE, LAMP MFR # 2004043002
61. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
62. #BULB 2/PK MFR # 2007290006
63. #COVER, CAPILLARY USE 2004056012 MFR # 2004056046 Superseded: see description
64. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
65. #SCREW MFR # 7295283407
66. #Refrigerator Thermostat Cover; Use With Dometic RM3807/ RM2611/ RM7732 Refrigerators MFR # 2930611013 Superseded: see description

Product # 921572201 › Cabinet Rear View

Components

18 items

1. #Cooling Unit (Ups) MFR # 2934803095N
2. #REMAN C/U MFR # 2934803095R
3. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
4. #COVER MFR # 17343000
5. #DECAL RM3804 MFR # 2931503003
6. #DECAL RM38 04 MFR # 2007574029
7. #LABEL, IMPORTANT MFR # 2007689009
8. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
9. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
10. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
11. #TUBE, DRAIN MFR # 2943361002
12. #Refrigerator Drain Tube; Replacement For Dometic RM2453/ RM3962/ RM2554 Model Refrigerators MFR # 2932749019
13. #S,TUBE,OVERFILL MFR # 2931829010
14. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
15. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
16. #Plate Protection Rm2800 MFR # 2930785015
17. #DECAL, WARNING 2807/4801 MFR # 2002577001
18. #APPLIANCE COMPONENTS RV; Clamp Hose MFR # 2943414009

Product # 921571401 › Cabinet Front View

Components

81 items

1. #Shelf, Freezer MFR # 2007535020
2. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
3. #Refrigerator Shelf MFR # 2931117044
4. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
5. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
6. #Refrigerator Shelf MFR # 2930133141
7. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W Use 29301 MFR # 2930133109 Superseded: see description
8. #Refrigerator Shelf MFR # 2002652218
9. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
10. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
11. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
12. #PLATE RETAINING MFR # 2007649011
13. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
14. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
15. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
16. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
17. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
18. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
19. #CRISPER,BLACK USE 2002726061 MFR # 2002726103 Superseded: see description
20. #Refrigerator Drip Tray; Replacement For Dometic RM2607/ RM2611/ RM3607 Model Refrigerator MFR # 2931869016
21. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
22. #DECAL, 3-WAY MFR # 2931883009
23. #PARTS BAG RM26 11/2811 MFR # 2931610048
24. #S,HINGE,UPR,CLASSIC MFR # 2931291013
25. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
26. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
27. #PLATE, MOUNTING 3-WAY MFR # 955000104
28. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
29. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
30. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
31. #Refrigerator Control Board Kit; Use With Dometic Refrigerators; 3 Way MFR # 2932884030 Superseded: see description
32. #BOARD, CIRCUIT USE 2932884030 3 WAY MFR # 2932697093 Superseded: see description
33. #BOARD, PC USE 2932697093 UPPER,W/MTG PLT 3 WAY MFR # 2931845016 Superseded: see description
34. #Refrigerator Trim; Replacement For Dometic RM2611/ RM2607 Refrigerators MFR # 2931865048
35. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
36. #Refrigerator Door Latch Plate Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1303/ RM2510/ RM2551/ RM360/ RM3862/ RM3863/ RM663/ RM760/ RM761/ RM763 Model Refrigerator; B6 x 13 MFR # 7295281401
37. #Appliance Components RV MFR # 2931289017
38. #S,HINGE,MID,CLASSIC 6/8CF,PNTD MFR # 3850957014
39. #SUPPORT MFR # 2930774019
40. #APPLIANCE COMPONENTS RV; Gasket Hinge MFR # 2931574012
41. #PLATE,MOUNTING LH MFR # 2931459016
42. #PLATE,MOUNTING RH MFR # 2931459024
43. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
44. #HINGE, LOWER LH RM26 04 MFR # 2931283010
45. #HINGE, LOWER RH MFR # 2931283028
46. #S,HINGE PIN,MID,25MM MFR # 2931287011
47. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
48. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
49. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
50. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
51. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
52. #Refrigerator Vent Cover Back Plate MFR # 2930664012
53. #DECAL,ON/OFF SWITCH MFR # 2931877001
54. #APPLIANCE COMPONENTS RV; Runner Right MFR # 2931281014
55. #APPLIANCE COMPONENTS RV; Runner Left MFR # 2931281022
56. #APPLIANCE COMPONENTS RV; Base Front Rm26 11 MFR # 2931282079
57. #INSULATION MFR # 2930711011
58. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
59. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
60. #APPLIANCE COMPONENTS RV; Trim Bottom MFR # 2931628016
61. #Refrigerator Thermostat Cover MFR # 2931285015
62. #REINFORCEMENT MFR # 2931504019
63. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
64. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
65. #S,STRIKE 9*35*24MM MFR # 2931511014
66. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
67. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
68. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
69. #Dometic RM2193 Refrigerator Control Board Assembly MFR # 2931856013
70. #BRACKET,MOUNTING MFR # 2931298018
71. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
72. #Lead T-Stat MFR # 2930735010
73. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
74. #SHADE, LAMP MFR # 2004043002
75. #COVER, LIGHT USE 2004044091 MFR # 2004044083 Superseded: see description
76. #BULB 2/PK MFR # 2007290006
77. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
78. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
79. #COVER, CAPILLARY USE 2004056012 MFR # 2004056046 Superseded: see description
80. #SCREW MFR # 7295283407
81. #Refrigerator Thermostat Cover; Use With Dometic RM3807/ RM2611/ RM7732 Refrigerators MFR # 2930611013 Superseded: see description

Product # 921572101 › Burner & Controls

Components

73 items

1. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #APPLIANCE COMPONENTS RV; Wire Electrode MFR # 2007668052
4. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
5. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
6. #SCREW M4 X 10 S MFR # 7241289615
7. #APPLIANCE COMPONENTS RV; Valve Solenoid MFR # 2943298022
8. #SOLENOID,VALVE USE 2943298030 RM2611 MFR # 2943298006 Superseded: see description
9. #SOLENOID,GAS USE 2943298022 MFR # 2943298030 Superseded: see description
10. #NUT MFR # 2943286001
11. #S,VALVE,GAS SHUT-OFF,RM3807 MFR # 2943299004
12. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
13. #ELBOW,BRASS (90 DEG.) S182 1-31 MFR # 2931916015
14. #APPLIANCE COMPONENTS RV; Bolt U MFR # 2943285003
15. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
16. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
17. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
18. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
19. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
20. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
21. #BRACKET, MOUNTING MFR # 2931822015
22. #APPLIANCE COMPONENTS RV; Nipple Test MFR # 2931824011
23. #NIPPLE,SOLENOID VALVE RM28 07 MFR # 2931825026
24. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
25. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
26. #Label 12VDC MFR # 2931827006
27. #DOM REPLACEMENT BRD MFR # MICROP711
28. #BOARD, PC LOWER USE 3308742000 3-WAY MFR # 2932882018 Superseded: see description
29. #BOARD, PC W/CVR USE 2932882018 MFR # 2931843037 Superseded: see description
30. #Refrigerator Control Board Kit; Replacement For Dometic RM3663/ RM3807/ RM3607/ RM2807/ RM2611/ RM2811/ RM3863/ RM2663 Series Refrigerators; 3-Way; Universal MFR # 3308742000
31. #BOARD,PC USE 2932695014 COMPLETE W/COVER MFR # 2931842021 Superseded: see description
32. #LEAD, 5 WIRE USE 2954542037. MFR # 2931862037 Superseded: see description
33. #LEAD,5 WIRE USE 2931862037 RM2807 MFR # 2931862011 Superseded: see description
34. #Refrigerator Switch Wiring Kit; Conductor Wire MFR # 2954542037
35. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
36. #S,THERMISTOR,W/LEAD 64" MFR # 2931863019
37. #APPLIANCE COMPONENTS RV; Harness Kit MFR # 3108702675
38. #LEAD,GAS VALVE USE 3108702675 MFR # 2931864017 Superseded: see description
39. #HARNESS KIT USE 46-4571 MFR # 6256 Superseded: see description
40. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
41. #HOUSING BURNER MFR # 2931913012
42. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
43. #Refrigerator Burner Box Cover; Replacement For Dometic RM3807/ RM2620 Refrigerators MFR # 2931572016
44. #BRACKET, GAS VALVE MFR # 2931915017
45. #S,COVER,LESS DECALS MFR # 2931858019
46. #ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974
47. #ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386
48. #ELEMENT, HEATING USE 48-9357 295W/120V 2WIRE MFR # 173754045 Superseded: see description
49. #APPLIANCE COMPONENTS RV; Element Heating 215W/12V 1 17.9 AMPS MFR # 173757063
50. #Dometic Series 8 Refrigerator Door Bin White MFR # 3851331011
51. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
52. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
53. #3858022019 MFR # 3858022019
54. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
55. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
56. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
57. #SCREW, RXS. B6 X L9, STAINLESS (2 REQ.) MFR # 729528402
58. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
59. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
60. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
61. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
62. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
63. #STRIP, TERMINAL 6 POS. MFR # 2930327008
64. #S,BAFFLE ASM,781MM MFR # 2007590058
65. #CAP FLUE MFR # 2931540013
66. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
67. #FUSE, 5 AMP USE AGC5 MFR # 2943542007 Superseded: see description
68. #FUSE, 5 AMP USE 2943542007 MFR # 2943542001 Superseded: see description
69. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
70. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
71. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
72. #NO PART # GIVEN BY VENDOR MFR # NPG
73. #SHIELD, THERMOCOUPLE LEAD MFR # 2932001015

Product # 921571301 › Burner & Controls

Components

71 items

1. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #APPLIANCE COMPONENTS RV; Wire Electrode MFR # 2007668052
4. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
5. #SCREW M4 X 10 S MFR # 7241289615
6. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
7. #SOLENOID,GAS USE 2943298022 MFR # 2943298030 Superseded: see description
8. #APPLIANCE COMPONENTS RV; Valve Solenoid MFR # 2943298022
9. #SOLENOID,VALVE USE 2943298030 RM2611 MFR # 2943298006 Superseded: see description
10. #NUT MFR # 2943286001
11. #S,VALVE,GAS SHUT-OFF,RM3807 MFR # 2943299004
12. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
13. #ELBOW,BRASS (90 DEG.) S182 1-31 MFR # 2931916015
14. #APPLIANCE COMPONENTS RV; Bolt U MFR # 2943285003
15. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
16. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
17. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
18. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
19. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
20. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
21. #BRACKET, MOUNTING MFR # 2931822015
22. #APPLIANCE COMPONENTS RV; Nipple Test MFR # 2931824011
23. #NIPPLE,SOLENOID VALVE RM28 07 MFR # 2931825026
24. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
25. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
26. #Label 12VDC MFR # 2931827006
27. #BOARD, PC USE 2931843037 MFR # 2931843011 Superseded: see description
28. #BOARD, PC W/CVR USE 2932882018 MFR # 2931843037 Superseded: see description
29. #BOARD, PC LOWER USE 3308742000 3-WAY MFR # 2932882018 Superseded: see description
30. #Refrigerator Control Board Kit; Replacement For Dometic RM3663/ RM3807/ RM3607/ RM2807/ RM2611/ RM2811/ RM3863/ RM2663 Series Refrigerators; 3-Way; Universal MFR # 3308742000
31. #DOM REPLACEMENT BRD MFR # MICROP711
32. #Refrigerator Switch Wiring Kit; Conductor Wire MFR # 2954542037
33. #LEAD,5 WIRE USE 2931862037 RM2807 MFR # 2931862011 Superseded: see description
34. #LEAD, 5 WIRE USE 2954542037. MFR # 2931862037 Superseded: see description
35. #S,THERMISTOR,W/LEAD 64" MFR # 2931863019
36. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
37. #APPLIANCE COMPONENTS RV; Harness Kit MFR # 3108702675
38. #LEAD,GAS VALVE USE 3108702675 MFR # 2931864017 Superseded: see description
39. #HARNESS KIT USE 46-4571 MFR # 6256 Superseded: see description
40. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
41. #HOUSING BURNER MFR # 2931913012
42. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
43. #Refrigerator Burner Box Cover; Replacement For Dometic RM3807/ RM2620 Refrigerators MFR # 2931572016
44. #BRACKET, GAS VALVE MFR # 2931915017
45. #S,COVER,LESS DECALS MFR # 2931858019
46. #ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974
47. #ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386
48. #APPLIANCE COMPONENTS RV; Element Heating 215W/12V 1 17.9 AMPS MFR # 173757063
49. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
50. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
51. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
52. #3858022019 MFR # 3858022019
53. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
54. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
55. #SCREW, RXS. B6 X L9, STAINLESS (2 REQ.) MFR # 729528402
56. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
57. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
58. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
59. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
60. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
61. #STRIP, TERMINAL 6 POS. MFR # 2930327008
62. #S,BAFFLE ASM,781MM MFR # 2007590058
63. #CAP FLUE MFR # 2931540013
64. #FUSE, 5 AMP USE 2943542007 MFR # 2943542001 Superseded: see description
65. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
66. #FUSE, 5 AMP USE AGC5 MFR # 2943542007 Superseded: see description
67. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
68. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
69. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
70. #NO PART # GIVEN BY VENDOR MFR # NPG
71. #SHIELD, THERMOCOUPLE LEAD MFR # 2932001015

Product # 921571301 › Replacement Refrigerator

Components

3 items

1. #REFER,6 CU FT 2 WAY 49 1/2"H X 21 3/4" W X 24" MFR # RM2620N
2. #REFER,6 CU FT 2 WAY 49 1/2 X 21 3/4 X 24 MFR # RM2620R
3. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N
