Dometic RM3607 Product # 921581701 3-WAY Parts Diagram · Cabinet Front View

Refrigerator · 5 assemblies · 5 diagram sheets · 208 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM3607 Product # 921581701 3-WAY RV refrigerator: 5 assemblies (Cabinet Front View, Burner & Controls, Replacement Refrigerator, Doors, Cabinet Rear View) and 208 manufacturer part numbers. 48 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Cabinet Front View

Components

77 items

1. #S,HINGE,UPR,CLASSIC MFR # 2931291013
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
4. #APPLIANCE COMPONENTS RV; Plate W/Decal Mounting MFR # 955002720
5. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
6. #Dometic RM2820 Series Refrigerator Main Control Board MFR # 2931866012
7. #Refrigerator Door Hinge Cover; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator; Fits Top Hinge Left Hand MFR # 2931866020
8. #Appliance Components RV; Board Circuit MFR # 2932884048
9. #Board, Circuit Use 2932884048 MFR # 2932697101 Superseded: see description
10. #Board, PC Use 2932697101 Upper with Mounting Plate 3 Way MFR # 2931846014 Superseded: see description
11. #FRONT MFR # 2931865105
12. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
13. #Screw,BOxg,S,zincplated (2 req.) MFR # 7298279113
14. #Refrigerator Trim; Replacement For Dometic RM3604/ RM3607 Refrigerators; Middle MFR # 2931290023
15. #BRACKET, MOUNTING RH MFR # 2932125012
16. #BRACKET, MOUNTING LH MFR # 2932125020
17. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
18. #S,HINGE,LWR,L,CLASSIC 6/8,PNTD MFR # 2932111012
19. #S,HINGE,LWR,R,CLASSIC 6/8,PNTD MFR # 2932111020
20. #S,HINGE PIN,MID,25MM MFR # 2931287011
21. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
22. #APPLIANCE COMPONENTS RV; WASHER, HINGE MFR # 7344904037
23. #BRACKET USE 2932456011 F/THERMISTER MFR # 2931976019 Superseded: see description
24. #BRACKET USE 3851088017 F/THERMISTER MFR # 2932456011 Superseded: see description
25. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
26. #Refrigerator Door Rail; Replacement For Dometic RM3807/ RM2620/ RM2607 Refrigerators; Lower Door MFR # 2932110014
27. #APPLIANCE COMPONENTS RV; Base Front Rm26 11 MFR # 2931282079
28. #INSULATION MFR # 2930711011
29. #Refrigerator Vent Cover Back Plate MFR # 2930664012
30. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
31. #S,STRIKE 9*35*24MM MFR # 2931511014
32. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
33. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
34. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
35. #Sign plate (3-way) MFR # 2931909002
36. #Dometic RM2193 Refrigerator Control Board Assembly MFR # 2931856013
37. #SHELF, FREEZER MFR # 2007535004
38. #Refrigerator Cooling Unit; Use With Dometic RM2611/ RM2620/ RM2607/ RM761/ RM760/ RM2602/ RM3600/ RM3604/ RM3607 Model Refrigerators MFR # 2007351006 Superseded: see description
39. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W Use 29301 MFR # 2930133109 Superseded: see description
40. #Refrigerator Shelf MFR # 2930133141
41. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
42. #APPLIANCE COMPONENTS RV; Shelf Wire 8"W X 17 7/8L MFR # 2002652234
43. #Refrigerator Shelf MFR # 2002652218
44. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
45. #PLATE RETAINING MFR # 2007649011
46. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
47. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
48. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
49. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
50. #S,DRAWER,VEG,WHT,RM2510/2620 MFR # 2002726061
51. #CRISPER USE 2002726061 MFR # 2002726038 Superseded: see description
52. #Refrigerator Drip Tray; Replacement For Dometic RM2607/ RM2611/ RM3607 Model Refrigerator MFR # 2931869016
53. #Refrigerator Interior Light Mounting Bracket; Replacement For Dometic RM2607/ RM2611/ RM2612/ RM2620/ RM2807/ RM2811/ RM2812/ RM2820/ RM3607/ RM3807 Model Refrigerator MFR # 2932106012
54. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
55. #SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description
56. #APPLIANCE COMPONENTS RV; Shelf Tray MFR # 2930136011
57. #BULB 2/PK MFR # 2007290006
58. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
59. #APPLIANCE COMPONENTS RV; Bar L Approx. 13.5" Rm76 MFR # 2007337005
60. #Appliance Components RV; Bar L Approx 15" 460-66 MFR # 2007337039
61. #APPLIANCE COMPONENTS RV; Bar L Approx 8" 460-660 MFR # 2007337062
62. #S WIRE SHELF RAILS/HOLDERS MFR # 2007372111
63. #Refrigerator Door Rail; Replacement For Dometic NDR1272/ NDR1282 Refrigerators MFR # 2930693045
64. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
65. #Appliance Components RV; Strip Decoration MFR # 2055366013
66. #Strip, Deco Use 2055366013 MFR # 2005111360 Superseded: see description
67. #Strip, Deco Use 2005111360 RM3601 MFR # 2005111071 Superseded: see description
68. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
69. #Refrigerator Shelf MFR # 2931117044
70. #Appliance Components RV; Parts Bag MFR # 2931317016
71. #APPLIANCE COMPONENTS RV; Switch Climate Control MFR # 2931876011
72. #SWITCH,CLIMATE CONTROL (300) MFR # 19011103
73. #DECAL MFR # 2932165000
74. #SCREW MFR # 7295283407
75. #SOCKET, LAMP; Use 2932523018 on Models RM4872 & RM4873 MFR # 2932107010 Superseded: see description
76. #Refrigerator Interior Light Mounting Bracket; Replacement For Dometic RM3663/ RGE400/ RM3863 Refrigerators; Also Use New Number 2932520014 MFR # 2932523018 Superseded: see description
77. #Refrigerator Interior Light Contact Pin; Replacement For Dometic DM2862/ RM1350/ RM3762/ RM3962 Model Refrigerator; Tin Bronze; Single MFR # 2932108018

Burner & Controls

Components

69 items

1. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
2. #SHIELD, THERMOCOUPLE LEAD MFR # 2932001015
3. #APPLIANCE COMPONENTS RV; Wire Electrode MFR # 2007668052
4. #APPLIANCE COMPONENTS RV; Valve Kit Shut Off W/Pro MFR # 3108706023
5. #VALVE, GAS USE 3108706023 MFR # 2007709047 Superseded: see description
6. #Refrigerator Gas Inlet Tube; Use With Dometic Refrigerator Model RM3807 MFR # 2932117019 Superseded: see description
7. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
8. #SCREW M4 X 10 S MFR # 7241289615
9. #Screw; MRX Screw; Use With Dometic Refrigerators; M4 x 10; Zinc Plated MFR # 3858039047 Superseded: see description
10. #APPLIANCE COMPONENTS RV; Valve Solenoid MFR # 2943298022
11. #SOLENOID,GAS USE 2943298022 MFR # 2943298030 Superseded: see description
12. #APPLIANCE COMPONENTS RV; Washer S MFR # 7345842012
13. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
14. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
15. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
16. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
17. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
18. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
19. #BRACKET, MOUNTING MFR # 2931822015
20. #APPLIANCE COMPONENTS RV; Nipple Test MFR # 2931824011
21. #Refrigerator Gas Valve Adapter Fitting; Replacement For Dometic RM2811/ RM3807/ RM7832 Model Refrigerator; Solenoid Inlet Nipple MFR # 2932063015
22. #Thermocouple; Use With Dometic Refrigerator Models RM2607/ RM2611/ RM2612/ RM2807/ RM2811/ RM2812/ RM3607/ RM3807/ RM7030/ RM7130/ RM7732/ RM7832/ S1521/ S1531/ S1821/ S1831; 2-Wire Plug-In Unit MFR # 2931826016MC Superseded: see description
23. #THERMOCOUPLE FOR DOMETIC MFR # 2931826016
24. #Label 12VDC MFR # 2931827006
25. #BOARD, PC W/CVR USE 2932882018 MFR # 2931843037 Superseded: see description
26. #Refrigerator Control Board Kit; Replacement For Dometic RM3663/ RM3807/ RM3607/ RM2807/ RM2611/ RM2811/ RM3863/ RM2663 Series Refrigerators; 3-Way; Universal MFR # 3308742000
27. #BOARD, PC LOWER USE 3308742000 3-WAY MFR # 2932882018 Superseded: see description
28. #DOM REPLACEMENT BRD MFR # MICROP711
29. #S,COVER,LESS DECALS MFR # 2931858019
30. #Refrigerator Switch Wiring Kit; Conductor Wire MFR # 2954542037
31. #LEAD, 5 WIRE USE 2954542037. MFR # 2931862037 Superseded: see description
32. #LEAD,5 WIRE USE 2931862037 RM2807 MFR # 2931862011 Superseded: see description
33. #Refrigerator Thermistor Assembly; Replacement For Dometic Refrigerator Thermistor MFR # 3851210025
34. #Refrigerator Thermistor Assembly; Replacement For Dometic RM2852/ RM1272/ RM3807/ RM3663/ RM2807/ RM3807/ RM2812/ RM3662 Series Refrigerators MFR # 3307872006
35. #THERMISTER USE 2931863035 MFR # 2931863068 Superseded: see description
36. #Refrigerator Thermistor Assembly; Replacement Refrigerator Thermistor; 51 Inch Length MFR # 3851059042
37. #Thermistor; Use 3851059042 with lead 44" MFR # 2931863035 Superseded: see description
38. #LEAD,GAS VALVE USE 3108702675 MFR # 2931864017 Superseded: see description
39. #HARNESS KIT USE 46-4571 MFR # 6256 Superseded: see description
40. #APPLIANCE COMPONENTS RV; Harness Kit MFR # 3108702675
41. #Refrigerator Reigniter Board Cover; Replacement For Dometic NDR1282/ RM1730/ S1821/ S1831/ RM4873/ RM4872/ RM3807/ RM/ NDR1272 Model Refrigerator MFR # 2931886010
42. #HOUSING BURNER MFR # 2931913012
43. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
44. #Refrigerator Burner Box Cover; Replacement For Dometic RM3807/ RM2620 Refrigerators MFR # 2931572016
45. #APPLIANCE COMPONENTS RV; Bracket Manual Gas Valve MFR # 2932116011
46. #ELEMENT, HEATING USE 48-9357 295W/120V 2WIRE MFR # 173754045 Superseded: see description
47. #ELEMENT, HEATING 295W/120V 2WIRE 3/8 X 6-7/8 MFR # CHX17974
48. #ELEMENT, HEATING **ALT 48-9357 W/120V 2WIRE 3/8 X 6-7/8 MFR # 3108702386
49. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
50. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
51. #3858022019 MFR # 3858022019
52. #APPLIANCE COMPONENTS RV; Block Terminal Use 385802 MFR # 2930463019 Superseded: see description
53. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
54. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
55. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
56. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
57. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
58. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
59. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
60. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
61. #STRIP, TERMINAL 6 POS. MFR # 2930327008
62. #S,BAFFLE ASM,781MM MFR # 2007590058
63. #CAP FLUE MFR # 2931540013
64. #APPLIANCE COMPONENTS RV; S, FUSE, 3AMP MFR # 2943541009
65. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
66. #FUSE, 5 AMP BUSS USE 55-9692 MFR # AGC5 Superseded: see description
67. #Refrigerator Ignition Control Module; Replacement For Older Dometic Refrigerator Circuit Board Part Number 3850712-01; With Built-In Re-Ignitor MFR # BPAGC5
68. #FUSE, 5 AMP USE AGC5 MFR # 2943542007 Superseded: see description
69. #DECAL 3 - WAY MFR # 2932003003

Replacement Refrigerator

Components

12 items

1. #REFER,8 CU FT 2-W WHITE 59 7/8"H X 29 1/2"W X MFR # N841WH
2. #REFER,6 CU FT 2 WAY BLK FRM 53 3/4" X 23 11/16" X 24" MFR # RM2662B
3. #Refrigerator / Freezer; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 7.5 Cubic Ft MFR # N8413SS
4. #Refrigerator / Freezer; 2 Door; Right Hand; 8 Cubic Foot; 59-7/8 Inch x 23-1/2 Inch x 24 Inch; 3 Way MFR # N8413N
5. #Refrigerators & Ice Makers RV; Refrigerator/LP-AC/Black MFR # N841BK
6. #PANELS,DOOR USE RM2652BA STAINLESS STEEL MFR # RM2652SS Superseded: see description
7. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 52-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black; With Crispers/ Shelving And Door Bins MFR # N6413N
8. #Refrigerator / Freezer;;Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand MFR # N641N
9. #REFER, 6 CU FT 2 WAY BLACK 53 3/4"H X 23 11/16"W X 24"D MFR # RM2652B
10. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Trim; With Crispers/ Shelving And Door Bins; Door Panels Sold Separately MFR # N841N
11. #Refrigerator - Built In; N841; 7.5 Cu Ft; 2 Door; Without Ice Maker; AC/ LP; 59-7/8 Inches High x 23-1/2 Inches Wide x 24 Inches Deep; Stainless Steel Wrap; Stainless Steel; Gas Absorption MFR # N841SS
12. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 4.2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; With Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Stainless Steel Doors; With Crispers/ Shelving And Door Bins MFR # N841IMSS

Doors

Components

36 items

1. #Door, Upper MFR # 2931638114
2. #DOOR, LOWER RM3604 PLASTIC FRAME MFR # 2931637116
3. #Refrigerator Gasket; Use With Dometic Refrigerator Models RM2604/ RM2610/ RM2607/ RM3604/ RM3607; Door Gasket; With Two Roll Double Sided Stick Tape/ One Roll Silicone MFR # 3108700 Superseded: see description
4. #Refrigerator Door Hinge Bushing; Replacement For Dometic RM7130/ RM2607/ RM2652 Refrigerators; Fits Top Hinge MFR # 2931171017
5. #APPLIANCE COMPONENTS RV; Insert Hinge (Beige) MFR # 2931512012
6. #APPLIANCE COMPONENTS RV; Insert Hinge (Beige) MFR # 2931512020
7. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
8. #Refrigerator Shelf; Use With Dometic RM2607/ RM100/ RA1302 Refrigerators; Juice Rack; Beige MFR # 2930533019 Superseded: see description
9. #Refrigerator Trim Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2804/ RM2807/ RM2812/ RM2820/ RM3604/ RM3607/ RM4804002/ RM4804005/ RM4804006 Model Refrigerator MFR # 7295229400
10. #APPLIANCE COMPONENTS RV; Handle Door MFR # 2931199026
11. #HANDLE RM2804 USE 2931199026 MFR # 2931199018 Superseded: see description
12. #Refrigerator Door Handle Screw; Replacement For Dometic RM2610/ RM1272/ RM2807 Model Refrigerator MFR # 7295225010
13. #HOLDER,BOTTLE USE 2930715053 GREY/BEIGE 7" MFR # 2930715038 Superseded: see description
14. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
15. #HOLDER,BOTTLE USE 2930715061 GREY/BEIGE 8" MFR # 2930715046 Superseded: see description
16. #Refrigerator Shelf Support; Replacement For Dometic RM2620/ RM2353/ RM2354 Refrigerators; 8 Inch; White MFR # 2930715061
17. #Plate Cover MFR # 2931571018
18. #Handle Kit Door MFR # 3107766010
19. #DECAL MFR # 2930757006
20. #LABEL, INSTRUCTION MFR # 2002356000
21. #APPLIANCE COMPONENTS RV; Compartment Butter MFR # 2930530015
22. #Cover, Butter Compartment 2 Way LH MFR # 2930531062
23. #Cover, Butter Compartment RH MFR # 2930531047
24. #STRIP, DECO UPPER MFR # 2931163022
25. #Decoration Strip MFR # 2931163105
26. #SHELF, DOOR USE 2000571196 RM3604 MFR # 2000571212 Superseded: see description
27. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
28. #SHELF, DOOR USE 2000571220 LOWER MFR # 2000571196 Superseded: see description
29. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
30. #APPLIANCE COMPONENTS RV; Bar L MFR # 2007523000
31. #Refrigerator Door Bin; Replacement For Dometic RM47D/ RM75/ RM760/ RM763/ RM36A/ M28C Model Refrigerator; Journal Axle Only MFR # 2001170014
32. #SHELF, DOOR USE 2930558057 MFR # 2930558024 Superseded: see description
33. #APPLIANCE COMPONENTS RV; Shelf Freezer Door MFR # 2930558057
34. #LABEL, WARNING FOR DOOR MFR # 2931620005
35. #APPLIANCE COMPONENTS RV; Service Kit Hinge Plate MFR # Explored View
36. #Refrigerator Door Hinge Plate; Replacement For Dometic RM3604/ RM3607 Model Refrigerator MFR # 2930593013

Cabinet Rear View

Components

17 items

1. #Cooling Unit (Ups) MFR # 2934803095N
2. #FILLING CAP MFR # 173558008
3. #COVER MFR # 17343000
4. #DECAL RM3804 MFR # 2931503003
5. #DECAL RM38 04 MFR # 2007574029
6. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
7. #CORD, POWER USE 2002699037 MFR # 2002699060 Superseded: see description
8. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
9. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
10. #Hose MFR # 2931578047
11. #S,TUBE,OVERFILL MFR # 2931829010
12. #Refrigerator Drip Tray; Replacement For Dometic RM2352/ RM2611/ RM2811/ RM3607 Model Refrigerator MFR # 2931828012
13. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
14. #Plate Protection Rm2800 MFR # 2930785015
15. #DECAL, WARNING 2807/4801 MFR # 2002577001
16. #LABEL, IMPORTANT MFR # 2007689009
17. #Refrigerator Drain Hose Plug; Replacement For Dometic NDR1272/ RM7130/ RM4873 Refrigerators;Also Use New Number 3316102.9019 MFR # 2932115013 Superseded: see description
