Dometic RM3800 Parts Diagram · Vibration Suppression Kit

Refrigerator · 6 assemblies · 6 diagram sheets · 237 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM3800 RV refrigerator: 6 assemblies (Vibration Suppression Kit, Gas & Electric, Replacement Refrigerator, Cooling Unit, Cabinet Assembly and more) and 237 manufacturer part numbers. 71 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Vibration Suppression Kit

Components

1 item

1. #VIBRATION SUSPENSION KIT PRICED PER FOOT MFR # 3108704515

Gas & Electric

Components

77 items

1. #NUT MFR # 140207036
2. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
3. #N/A KNOB MFR # 2006067217
4. #SIGHT WINDOW MFR # ************
5. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
6. #APPLIANCE COMPONENTS RV; Wire Lead 2604 MFR # 2007668029
7. #VALVE, GAS USE 3108706023 MFR # 2007709047 Superseded: see description
8. #COCK, GAS USE 2007709047 MFR # 2007709013 Superseded: see description
9. #APPLIANCE COMPONENTS RV; Valve Kit Shut Off W/Pro MFR # 3108706023
10. #VALVE, SOLENOID USE 3108705272 MFR # 2007719020 Superseded: see description
11. #VALVE, SOLENOID USE 2007719020 MFR # 2007719012 Superseded: see description
12. #BOARD, MODULE MFR # 3106375015
13. #APPLIANCE COMPONENTS RV; Circuit Board, Refrigerator, Dometic MFR # MICROP1338REV5
14. #Refrigerator Power Supply Circuit Board; Replacement For Dometic Earlier Refrigerator Series Micro P-24 2-Way\ Micro P-24 3-Way\ Micro P-26; 3 Way; With Built In Microcontroller\ Self-Resetting Circuit Breaker MFR # MICROP246PLUS
15. #APPLIANCE COMPONENTS RV; Gas Valve & Board Kit MFR # 3108705272
16. #APPLIANCE COMPONENTS RV; Coil Solenoid Only MFR # 2007715010
17. #T-COUPLE MFR # 2930326000
18. #Thermocouple; Replacement For Dometic RGE400/ RM2310/ RM1303 Refrigerators; Probe Sensor MFR # 2931496042MC
19. #S,THERMOCOUPLE-232MM MFR # 2931496042
20. #Thermocouple; Use On Dometic Refrigerator Model RM1303 MFR # 2930326000MC Superseded: see description
21. #STRIP, TERMINAL 6 POS. MFR # 2930327008
22. #LEAD MFR # 2930894015
23. #N/A LEAD MFR # 2930750011
24. #NO PART # GIVEN BY VENDOR MFR # NPG
25. #APPLIANCE COMPONENTS RV; Relay 12V MFR # 2930385006
26. #Refrigerator Relay; Use On Dometic Refrigerator Models QCS135B/ RM100/ RM1303/ RM1350-921148302/ RM1350-921148307/ RM1350-921148319/ RM1350-921148320/ RM2354-921145025/ RM2354-921145027/ RM2354-921145030/ RM2354-921145031/ RM2354-921145051/ RM2354-921145052/ RM2454-921140114/ RM2454-921140115/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604-921580101/ RM3604-921580201/ RM3800/ RM3801/ RM3804-921600101/ RM3804-921600301/ RM4801/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006/ RM4804006/ RM663/ RM76/ RM763/ RM76D/ RM77/ RM77D MFR # 2930385006MC Superseded: see description
27. #APPLIANCE COMPONENTS RV; Block Terminal 4 Large MFR # 2930463001
28. #COMPONENT BOX 3600 ,3500 MFR # 2930642018
29. #RETAINER MFR # 2930648015
30. #Refrigerator Burner Box Cover; Replacement For Dometic RM2600/ S520014/ RM7030 Refrigerators MFR # 2930651019
31. #COVER MFR # 2930653015
32. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
33. #APPLIANCE COMPONENTS RV; Pipe Gas MFR # 2930685017
34. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
35. #APPLIANCE COMPONENTS RV; Insulator Circuit Board MFR # 2931007013
36. #Lead, 3 Way 6 Pin (Has 6 Wire) RM3801 MFR # 2930799024
37. #Wire, Lead (2 Wire) MFR # 2930728023
38. #Lead, One Wire RM4801 MFR # 2930729039
39. #Appliance Components RV; Lead Wire (1 Wire) MFR # 2930729047
40. #N/A LEAD MFR # 2950730011
41. #WIRE,LEAD MFR # 2930731019
42. #Dometic RM2652 RM2662 Gas Valve Assembly MFR # 2932759018
43. #APPLIANCE COMPONENTS RV; Plate Protection 3800/36 MFR # 2930786013
44. #N/A PURCHASE AT LOCAL HARDWARE MFR # ?
45. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
46. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
47. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
48. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
49. #Block Terminal Small 3 Poi MFR # 7627202562
50. #HOLDER, FUSE MFR # 7628801230
51. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
52. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
53. #IGNITER USE 2931132019 MFR # 7679100003 Superseded: see description
54. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
55. #Retainer MFR # 2930661018
56. #Dometic RM2652 Refrigerator Main Control Board MFR # 3850730569
57. #Refrigerator Gas Valve; Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM1303/ RM2800/ RM2802/ RM2803/ RM2810/ RM23804 Series Refrigerators; \#58 MFR # 2007419217
58. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
59. #LEAD,WIRE USE 2930782095 10 PIN 7' LONG MFR # 2930782061 Superseded: see description
60. #LEAD,10 WIRE MFR # 2930782095
61. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
62. #APPLIANCE COMPONENTS RV; Link Fuse 3 Amp Use AGC3 MFR # 7628211943 Superseded: see description
63. #INSERT, FUSE MFR # 7628801212
64. #S,CAP,FLUE MFR # 2007598010
65. #Refrigerator Cooling Unit Baffle Diffuser; Replacement For Dometic RM2811/ RM2812/ RM3807/ RM2801/ RM3801/ RM4804/ RM3607 Series Refrigerators MFR # 2007590066
66. #ELEMENT, HEATING USE 45-4113 275W 12V 3800 MFR # 173743030 Superseded: see description
67. #APPLIANCE COMPONENTS RV; Element Heating Use 48-9 MFR # 173742081 Superseded: see description
68. #ELEMENT, HEATING Q (25) 12V 275W 3/8" DIA 6-1/2 LONG MFR # 173743014
69. #ELEMENT, HEATING 120V 325W MFR # CS000022
70. #APPLIANCE COMPONENTS RV; Board Module MFR # 3106375003
71. #BOARD,CIRCUIT USE 87500351199 MFR # 4980557005 Superseded: see description
72. #APPLIANCE COMPONENTS RV; Circuit Board, Refrigerator, Dometic MFR # MICROP1338
73. #BOARD,CIRCUIT USE 3106375003 MFR # 87500351199 Superseded: see description
74. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
75. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
76. #CORD, FLEXIBLE USE 2002699037 MFR # 2002699029 Superseded: see description
77. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description

Replacement Refrigerator

Components

12 items

1. #Refrigerator - Built In; N841; 7.5 Cu Ft; 2 Door; Without Ice Maker; AC/ LP; 59-7/8 Inches High x 23-1/2 Inches Wide x 24 Inches Deep; Stainless Steel Wrap; Stainless Steel; Gas Absorption MFR # N841SS
2. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 4.2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; With Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Doors; With Crispers/ Shelving And Door Bins MFR # N841IMBK
3. #REFER,8 CU FT 2-W WHITE 59 7/8"H X 29 1/2"W X MFR # N841WH
4. #Refer, 8 Cu Ft. 2 Way 55 3/8 X 23 5/8 X 24 MFR # RM2820N
5. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Trim; With Crispers/ Shelving And Door Bins; Door Panels Must Be Ordered Separately MFR # NXA841R
6. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 4.2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; With Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Frame; Stainless Steel Wrapped Edge Door; With Crispers/ Shelving And Door Bins MFR # NX841IMSSR
7. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Trim; With Crispers/ Shelving And Door Bins; Door Panels Sold Separately MFR # N841N
8. #REFER, 8 CU FT 55 1/4 X 23 1/2 X 24 MFR # RM3800N
9. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 4.2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; With Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Stainless Steel Doors; With Crispers/ Shelving And Door Bins MFR # N841IMSS
10. #Refer, 7.5 Cu Ft W/IM 59 7/8"H X 29 1/2"W X 24"D MFR # N841IMWH
11. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Frame; Stainless Steel Wrapped Edge Door; With Crispers/ Shelving And Door Bins MFR # NX841SSR
12. #Refrigerators & Ice Makers RV; Refrigerator/LP-AC/Black MFR # N841BK

Cooling Unit

Components

16 items

1. #APPLIANCE COMPONENTS RV; Coil Solenoid Only MFR # 2007715010
2. #COVER MFR # 2930653015
3. #ELEC. GROUNDING INSTRUCTIONS MFR # 2002576003
4. #CORD, FLEXIBLE USE 2002699037 MFR # 2002699029 Superseded: see description
5. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
6. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
7. #Refrigerator Cooling Unit; Use With Dometic RM2800/ RM2801/ RM2802/ RM2803/ RM2810/ RM3800/ RM3801/ RM3802/ RM3803/ RM3804 Model Refrigerators MFR # 5528 Superseded: see description
8. #REMAN C/U USE 5528 MFR # 2934901097R Superseded: see description
9. #APPLIANCE COMPONENTS RV; Cooling Unit MFR # 2934901097N
10. #RETAINING PLATE MFR # 2007653005
11. #LABEL, IMPORTANT MFR # 2007689009
12. #DECAL, WARNING 2807/4801 MFR # 2002577001
13. #LABEL, CAUTION RM48 01 MFR # 2930750001
14. #WIRING DIAGRAM MFR # 2930897000
15. #PLATE INSTALLATION CLEARANCE MFR # 29307571000
16. #DECAL RM38 04 MFR # 2007574029

Cabinet Assembly

Components

88 items

1. #Refrigerator Door Hinge Pin; Use With Dometic Refrigerator Models RM3600/ RM3800 MFR # 2007270016 Superseded: see description
2. #NO PART # GIVEN BY VENDOR MFR # NPG
3. #SHELF, FREEZER MFR # 2007535012
4. #Refrigerator Shelf; Replacement For Dometic RM1300/ RA1302/ RM2807/ RM2811/ RM2812/ RM2820/ RM3804/ RM3807 Model Refrigerator; Freezer Compartment MFR # 2007535038
5. #Flange, Cooling Use 2007605013 MFR # 2007605005 Superseded: see description
6. #Refrigerator Cooling Unit; Use With Dometic RM2807/ RM3807/ RM2820/ RM3807/ RM2811/ RM2807/ RM1303/ RM4804 Model Refrigerators MFR # 2007605013 Superseded: see description
7. #SHELF USE 2930133117 MFR # 2930133042 Superseded: see description
8. #Shelf, Milk Use 2930133042 11-3/4" W X 19-7/8" Long RM1303 MFR # 2930133018 Superseded: see description
9. #APPLIANCE COMPONENTS RV; Shelf Milk MFR # 2930133117
10. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
11. #Shelf, Middle Use 2002652259 MFR # 2002652168 Superseded: see description
12. #APPLIANCE COMPONENTS RV; Shelf Wire 7.5" X 19 3/4" MFR # 2002652267
13. #APPLIANCE COMPONENTS RV; Shelf Wire 11 5/8" X 19 3 MFR # 2002652259
14. #Shelf, Upper Use 2002652267 MFR # 2002652176 Superseded: see description
15. #Appliance Components RV; Screw RXSB 10X38 Ni.Pl MFR # 7295422112
16. #LATCH, TRAVEL USE 2930706052 MFR # 2930706029 Superseded: see description
17. #Refrigerator Door Latch; Travel Latch; Replacement For Dometic RM2802/ RM2803/ RM3800 Refrigerators MFR # 2930706052
18. #LATCH, TRAVEL USE 2930706052 MFR # 2930706045 Superseded: see description
19. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
20. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
21. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
22. #Lock, Shelf Use 2007393024 N MFR # 2007393016 Superseded: see description
23. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
24. #APPLIANCE COMPONENTS RV; Lock Shelf Use 2007392026 MFR # 2007392018 Superseded: see description
25. #CARD, SWITCH MUST ALSO HAVE 2930710013 MFR # 4980572004
26. #KEY FOR SWITCH CARD MFR # 2930710013
27. #HOUSING, LATCH USE 2930707050 MFR # 2930707027 Superseded: see description
28. #HOUSING, CATCH GREY/BROWN MFR # 2930707050
29. #Refrigerator Crisper Bin; Replacement For Dometic RM2801/ RM2802/ RM3800 Model Refrigerators; White MFR # 2002726129
30. #CRISPER, SMOKE USE 2002726129 RM2810 MFR # 2002726095 Superseded: see description
31. #CRISPER, SMOKE USE 2002726095 MFR # 2002726020 Superseded: see description
32. #Decoration, Front MFR # 2930749011
33. #Decoration, Front CPL 3800 MFR # 2930749045
34. #Decoration Strip MFR # 2930746017
35. #STRIP,DECO USE 2930749078 MFR # 2930745019 Superseded: see description
36. #FRONT,DECORATION MFR # 2930749078
37. #Decoration, Front MFR # 2930748021
38. #Decoration, Front MFR # 2930748013
39. #Hinge, LH MFR # 2930709023
40. #Refrigerator Door Hinge; Replacement for Dometic RM3800/ RM4801/ RM3801 Refrigerators MFR # 2930708025
41. #APPLIANCE COMPONENTS RV; Cover Crisper Use 2002727 MFR # 2002727010 Superseded: see description
42. #2004044091 MFR # 2004044091
43. #COVER, CONTROLS USE 2004044091 MFR # 2004044075 Superseded: see description
44. #COVER, LIGHT USE 2004044091 MFR # 2004044083 Superseded: see description
45. #COVER, LIGHT SWITCH MFR # 2004044109
46. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
47. #SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description
48. #Pin, Hinge Upper MFR # 2930612003
49. #Refrigerator Thermostat Control Knob; Use With Dometic Refrigerator Model RM3500 MFR # 2930625013 Superseded: see description
50. #T-STAT USE K50P1336 MFR # K50P1317 Superseded: see description
51. #T-STAT USE 2930814021 MFR # K50P1336 Superseded: see description
52. #T-STAT; USE 2930814013 MFR # 2930523010 Superseded: see description
53. #APPLIANCE COMPONENTS RV; Level Spirit MFR # 2007645019
54. #Refrigerator Door Hinge; Replacement For Dometic RM2803/ RM4801/ RM2601 Refrigerators; Fits Upper Door Side MFR # 2930613001
55. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
56. #Washer; Replacement For Dometic RM2301/ RM2600/ RM3600 Model Refrigerator MFR # 2930714015
57. #SHADE, LAMP MFR # 2004043002
58. #TRAY, MILK USE 2930136011 MFR # 2930136003 Superseded: see description
59. #APPLIANCE COMPONENTS RV; Shelf Tray MFR # 2930136011
60. #APPLIANCE COMPONENTS RV; Light 12V MFR # 2930744012
61. #BULB 2/PK MFR # 2007290006
62. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
63. #Bar, L Approx 9" RM1300 MFR # 2007337070
64. #Appliance Components RV; Bar L Approx 15" 460-66 MFR # 2007337039
65. #Refrigerator Evaporator Door Torsion Bar; Use With Dometic RM2800/ RM2801 Model Refrigerators; 16-1/2 Inch Length MFR # 2007337047 Superseded: see description
66. #Appliance Components RV; Bar Freezer Shelf MFR # 2007537000
67. #S WIRE SHELF RAILS/HOLDERS MFR # 2007372111
68. #RETAINER USE 2930693045 MFR # 2930693029 Superseded: see description
69. #RETAINER USE 2930693029 MFR # 2930693011 Superseded: see description
70. #Refrigerator Door Rail; Replacement For Dometic NDR1272/ NDR1282 Refrigerators MFR # 2930693045
71. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
72. #BAR, DRIP TRAY MFR # 2930606005
73. #TRAY, DRIP MFR # 162322002
74. #INDEX MFR # 2001354022
75. #Plate, Covering Freezer MFR # 2930486036
76. #Strip, Deco Use 2055366013 MFR # 2005111360 Superseded: see description
77. #Strip, Decor Use 2005111071 MFR # 2005111113 Superseded: see description
78. #Appliance Components RV; Decoration Strip MFR # 2005111121
79. #Strip, Deco Use 2005111360 RM3601 MFR # 2005111071 Superseded: see description
80. #Appliance Components RV; Strip Decoration MFR # 2055366013
81. #GABLE, RH MFR # 2930604000
82. #PLATE, LEFT SIDE MFR # 2930603002
83. #Refrigerator Support Rail; Replacement For Dometic RM3501/ RM3800/ RM2603 Refrigerators; Right Hand Side MFR # 2930602004
84. #Refrigerator Support Rail; Replacement For Dometic RM3801/ RM2603/ RM3800 Refrigerators; Left Hand Side MFR # 2930601006
85. #BASE FRONT MFR # 2930600016
86. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
87. #Refrigerator Door Hinge Pin; Use With Dometic Refrigerator Model RM2301; Fits Bottom Hinge MFR # 2930614009 Superseded: see description
88. #Refrigerator Vent Cover Back Plate MFR # 2930664012

Door Assembly

Components

50 items

1. #Gasket Kit (100) Contains: 1 - 3304001 Freezer Gasket 16-3/16 X 24-3/16, 1 - 3304002 Main Gasket 24-3/16 X 36-9/16, 1 - DC732RTV Tube Silicone, 1 - 6141 6... MFR # 3103690008D
2. #DOOR, LOWER MFR # 2930683046
3. #Gasket Kit Use 3103690008D Contains: 1 - 3304001 Freezer Gasket 16-3/16 X 24-3/16, 1 - 3304002 Main Gasket 24-3/16 X 36-9/16, 1 - DC732RTV Tube Silicone, 1 - 6141 6... MFR # 3103690008 Superseded: see description
4. #APPLIANCE COMPONENTS RV; Door Upper Use 293093211 MFR # 2930932120 Superseded: see description
5. #DOOR, LOWER MFR # 2930933110
6. #DOOR,FREEZER USE 2930932112 MFR # 2930684044 Superseded: see description
7. #DOOR, LWR USE 2930933110 MFR # 2930931114 Superseded: see description
8. #DOOR, FREEZER MFR # 2930932112
9. #APPLIANCE COMPONENTS RV; Bushing Door Hinge Lower MFR # 2002619001
10. #CATCH RETAINER MFR # 29306090I7
11. #NO PART # GIVEN BY VENDOR MFR # NPG
12. #PLUG MFR # 2930736026
13. #APPLIANCE COMPONENTS RV; Plug Use 2930736026 MFR # 2930736018 Superseded: see description
14. #STRIP,DECORATION 3800,3801 MFR # 2930639105
15. #STRIP,DECORATION MFR # 2930639097
16. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930537010
17. #APPLIANCE COMPONENTS RV; Cover Ice Box Use 2930537 MFR # 2930537002 Superseded: see description
18. #BOX, ICE WHITE MFR # 2930536020
19. #Box, Ice Center Use 2930536020. Look At Inventory In All W/H's On This Part Before Using Use #. This Is Smoke Colored And The Use # Is White. Offer Customer Their Choice Of Color. MFR # 2930536004 Superseded: see description
20. #SHELF, BROWN USE 2930558024 MFR # 2930558016 Superseded: see description
21. #APPLIANCE COMPONENTS RV; Shelf Freezer Door MFR # 2930558057
22. #SHELF, DOOR USE 2930558057 MFR # 2930558024 Superseded: see description
23. #SHELF, FREEZER USE 2930558016 MFR # 2930558008 Superseded: see description
24. #HOLDER, JUICE USE 2930533019 MFR # 2930533001 Superseded: see description
25. #Refrigerator Shelf; Use With Dometic RM2607/ RM100/ RA1302 Refrigerators; Juice Rack; Beige MFR # 2930533019 Superseded: see description
26. #SHELF,BUTTER USE 2930534025 MFR # 2930534009 Superseded: see description
27. #APPLIANCE COMPONENTS RV; Shelf Dairy MFR # 2930534025
28. #Door, Dairy RH Smoked; Specs: For RM3807 Product #'s 921602301, 921602401, 921602501, 921602601; Use Part# 2930540014 MFR # 2930540014 Superseded: see description
29. #DOOR,DAIRY USE 2930540014 MFR # 2930541012 Superseded: see description
30. #APPLIANCE COMPONENTS RV; Cover Butter Rh MFR # 2930540022
31. #DOOR USE 2930540022 MFR # 2930541020 Superseded: see description
32. #RETAINER MFR # 2930594003
33. #RIVET, EXPANSION MFR # 165521022
34. #APPLIANCE COMPONENTS RV; Shelf Door Rm3800 MFR # 2930535006
35. #Shelf, Door Use 2001732136 MFR # 2001732128 Superseded: see description
36. #APPLIANCE COMPONENTS RV; Shelf Door Clear MFR # 2001732136
37. #Holder, Bottle Use 2002794168; Can Use 2002794010 For Brown MFR # 2002794069 Superseded: see description
38. #APPLIANCE COMPONENTS RV; Holder Btlwhite MFR # 2002794168
39. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
40. #Refrigerator Shelf Support; Replacement For Dometic RM2620/ RM2353/ RM2354 Refrigerators; 8 Inch; White MFR # 2930715061
41. #APPLIANCE COMPONENTS RV; Holder Bottle 8" Brown MFR # 2930715020
42. #HOLDER,BOTTLE 7" BROWN MFR # 2930715012
43. #APPLIANCE COMPONENTS RV; Rack Wire MFR # 2001734009
44. #HANDLE USE 45-9988 MFR # 2930763020 Superseded: see description
45. #APPLIANCE COMPONENTS RV; Handle Door MFR # 2930763012
46. #SCREW FXS B4 x9 5 Z. PL . MFR # 72962250I9
47. #Refrigerator Door Bin; Replacement For Dometic RM47D/ RM75/ RM760/ RM763/ RM36A/ M28C Model Refrigerator; Journal Axle Only MFR # 2001170014
48. #LABEL, INSTRUCTION MFR # 2002356000
49. #PANELS,DOOR BLACK PLEXIGLASS TOP/BOTTOM PANELS MFR # RM3800L
50. #PANELS,DOOR WOODGRAIN TOP/BOTTOM PANELS MFR # RM3800G
