Dometic RM3801 Parts Diagram · Door Assembly

Refrigerator · 6 assemblies · 6 diagram sheets · 224 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM3801 RV refrigerator: 6 assemblies (Door Assembly, Cooling Unit, Replacement Refrigerator, Gas-electric, Cabinet Assembly and more) and 224 manufacturer part numbers. 61 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Door Assembly

Components

45 items

1. #Gasket Kit (100) Contains: 1 - 3304001 Freezer Gasket 16-3/16 X 24-3/16, 1 - 3304002 Main Gasket 24-3/16 X 36-9/16, 1 - DC732RTV Tube Silicone, 1 - 6141 6... MFR # 3103690008D
2. #DOOR, LOWER USE 2930933110 RM3801 MFR # 2930931122 Superseded: see description
3. #DOOR, LWR USE 2930933110 MFR # 2930931114 Superseded: see description
4. #DOOR, FREEZER MFR # 2930932112
5. #DOOR, LOWER MFR # 2930933110
6. #APPLIANCE COMPONENTS RV; Door Upper Use 293093211 MFR # 2930932120 Superseded: see description
7. #Gasket Kit Use 3103690008D Contains: 1 - 3304001 Freezer Gasket 16-3/16 X 24-3/16, 1 - 3304002 Main Gasket 24-3/16 X 36-9/16, 1 - DC732RTV Tube Silicone, 1 - 6141 6... MFR # 3103690008 Superseded: see description
8. #APPLIANCE COMPONENTS RV; Bushing Door Hinge Lower MFR # 2002619001
9. #APPLIANCE COMPONENTS RV; RETAINER, CATCH MFR # 2931093021
10. #CATCH, RETAINER USE 2931093021 MFR # 2930817024 Superseded: see description
11. #APPLIANCE COMPONENTS RV; Plug Use 2930736026 MFR # 2930736018 Superseded: see description
12. #PLUG MFR # 2930736026
13. #APPLIANCE COMPONENTS RV; Strip Decoration RM3801 MFR # 2930639212
14. #STRIP,DECORATION 3800,3801 MFR # 2930639105
15. #APPLIANCE COMPONENTS RV; Cover Ice Box Use 2930537 MFR # 2930537002 Superseded: see description
16. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930537010
17. #Box, Ice Center Use 2930536020. Look At Inventory In All W/H's On This Part Before Using Use #. This Is Smoke Colored And The Use # Is White. Offer Customer Their Choice Of Color. MFR # 2930536004 Superseded: see description
18. #BOX, ICE WHITE MFR # 2930536020
19. #SHELF, FREEZER USE 2930558016 MFR # 2930558008 Superseded: see description
20. #SHELF, BROWN USE 2930558024 MFR # 2930558016 Superseded: see description
21. #SHELF, DOOR USE 2930558057 MFR # 2930558024 Superseded: see description
22. #APPLIANCE COMPONENTS RV; Shelf Freezer Door MFR # 2930558057
23. #Refrigerator Shelf; Use With Dometic RM2607/ RM100/ RA1302 Refrigerators; Juice Rack; Beige MFR # 2930533019 Superseded: see description
24. #HOLDER, JUICE USE 2930533019 MFR # 2930533001 Superseded: see description
25. #APPLIANCE COMPONENTS RV; Shelf Dairy MFR # 2930534025
26. #SHELF,BUTTER USE 2930534025 MFR # 2930534009 Superseded: see description
27. #DOOR USE 2930540022 MFR # 2930541020 Superseded: see description
28. #APPLIANCE COMPONENTS RV; Cover Butter Rh MFR # 2930540022
29. #Door, Dairy RH Smoked; Specs: For RM3807 Product #'s 921602301, 921602401, 921602501, 921602601; Use Part# 2930540014 MFR # 2930540014 Superseded: see description
30. #RETAINER MFR # 2930594003
31. #RIVET, EXPANSION MFR # 165521022
32. #APPLIANCE COMPONENTS RV; Shelf Door Rm3800 MFR # 2930535006
33. #Shelf, Door Use 2001732136 MFR # 2001732128 Superseded: see description
34. #APPLIANCE COMPONENTS RV; Shelf Door Clear MFR # 2001732136
35. #Refrigerator Shelf Support; Replacement For Dometic RM2620/ RM2353/ RM2354 Refrigerators; 8 Inch; White MFR # 2930715061
36. #Holder, Bottle Use 2002794168; Can Use 2002794010 For Brown MFR # 2002794069 Superseded: see description
37. #APPLIANCE COMPONENTS RV; Holder Btlwhite MFR # 2002794168
38. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
39. #APPLIANCE COMPONENTS RV; Holder Bottle 8" Brown MFR # 2930715020
40. #HOLDER,BOTTLE 7" BROWN MFR # 2930715012
41. #APPLIANCE COMPONENTS RV; Rack Wire MFR # 2001734009
42. #HANDLE USE 45-9988 MFR # 2930763020 Superseded: see description
43. #APPLIANCE COMPONENTS RV; Handle Door MFR # 2930763012
44. #Appliance Components RV; Screw 4 X 9.5 MFR # 7296225019
45. #Door Panels (Black Plexiglass, Top & Bottom) MFR # RM2801L

Cooling Unit

Components

20 items

1. #INSTRUCTIONS MFR # GROUNDING
2. #NO PART # GIVEN BY VENDOR MFR # NPG
3. #SCREW MFR # SCREW
4. #APPLIANCE COMPONENTS RV; Cooling Unit MFR # 2934901097N
5. #Refrigerator Cooling Unit; Use With Dometic RM2800/ RM2801/ RM2802/ RM2803/ RM2810/ RM3800/ RM3801/ RM3802/ RM3803/ RM3804 Model Refrigerators MFR # 5528 Superseded: see description
6. #REMAN C/U USE 5528 MFR # 2934901097R Superseded: see description
7. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
8. #Refrigerator Cooling Unit Cap; Use With Dometic RM Series 2 Way And 3 Way/ Servel/ Americana/ Americana Plus/ Royale Refrigerators MFR # 2933557007 Superseded: see description
9. #PLUG MFR # PLUG
10. #RETAINING PLATE MFR # RETAINING PLATE
11. #LABEL MFR # IMPORTANT
12. #LABEL MFR # TESTING
13. #3850583000 MFR # LABEL
14. #WIRING DIAGRAM MFR # WIRING DIAGRAM
15. #APPLIANCE COMPONENTS RV; Protect Splash MFR # 2930810011
16. #TRAY, EVAP. MFR # 2930950015
17. #TRAY, EVAPORATION MFR # 2931134015
18. #APPLIANCE COMPONENTS RV; Spillway MFR # 2930951013
19. #Refrigerator Drain Tube; Replacement For Dometic RM2801/ RM2802 Model Refrigerators MFR # 2930952011
20. #CLAMP 2800 ,3601,4801 MFR # 2930953019

Replacement Refrigerator

Components

12 items

1. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 6.3 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Frame; Stainless Steel Wrapped Edge Door; With Crispers/ Shelving And Door Bins MFR # NX841SSR
2. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 4.2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; With Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Stainless Steel Doors; With Crispers/ Shelving And Door Bins MFR # N841IMSS
3. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Trim; With Crispers/ Shelving And Door Bins; Door Panels Sold Separately MFR # N841N
4. #REFER,8 CU FT 2 WAY BLK FRM 59 15/16" X 23 11/16" MFR # RM2862B
5. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand Hinge; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 3 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Trim; With Crispers/ Shelving And Door Bins; Door Panels Must Be Ordered Separately MFR # NXA841R
6. #Refrigerator - Built In; N841; 7.5 Cu Ft; 2 Door; Without Ice Maker; AC/ LP; 59-7/8 Inches High x 23-1/2 Inches Wide x 24 Inches Deep; Stainless Steel Wrap; Stainless Steel; Gas Absorption MFR # N841SS
7. #Refrigerator / Freezer;;Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; Right Hand MFR # N641N
8. #REFER,8 CU FT 2-W WHITE 59 7/8"H X 29 1/2"W X MFR # N841WH
9. #Refer, 7.5 Cu Ft W/IM 59 7/8"H X 29 1/2"W X 24"D MFR # N841IMWH
10. #Refer, 8 Cu Ft. 2 Way 55 3/8 X 23 5/8 X 24 MFR # RM2820N
11. #Refrigerators & Ice Makers RV; Refrigerator/LP-AC/Black MFR # N841BK
12. #REFER,8CUFT BEIGE USE RM3862BN MFR # RM3862N Superseded: see description

Gas-electric

Components

76 items

1. #NUT MFR # 140207036
2. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
3. #N/A KNOB MFR # 2006067217
4. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
5. #APPLIANCE COMPONENTS RV; Wire Lead 2604 MFR # 2007668029
6. #APPLIANCE COMPONENTS RV; Valve Kit Shut Off W/Pro MFR # 3108706023
7. #VALVE, GAS USE 3108706023 MFR # 2007709047 Superseded: see description
8. #COCK, GAS USE 2007709047 MFR # 2007709013 Superseded: see description
9. #Refrigerator Power Supply Circuit Board; Replacement For Dometic Earlier Refrigerator Series Micro P-24 2-Way\ Micro P-24 3-Way\ Micro P-26; 3 Way; With Built In Microcontroller\ Self-Resetting Circuit Breaker MFR # MICROP246PLUS
10. #BOARD, MODULE MFR # 3106375015
11. #VALVE, SOLENOID USE 2007719020 MFR # 2007719012 Superseded: see description
12. #APPLIANCE COMPONENTS RV; Gas Valve & Board Kit MFR # 3108705272
13. #APPLIANCE COMPONENTS RV; Circuit Board, Refrigerator, Dometic MFR # MICROP1338REV5
14. #VALVE, SOLENOID USE 3108705272 MFR # 2007719020 Superseded: see description
15. #APPLIANCE COMPONENTS RV; Coil Solenoid Only MFR # 2007715010
16. #Thermocouple; Use On Dometic Refrigerator Model RM1303 MFR # 2930326000MC Superseded: see description
17. #Thermocouple; Replacement For Dometic RGE400/ RM2310/ RM1303 Refrigerators; Probe Sensor MFR # 2931496042MC
18. #S,THERMOCOUPLE-232MM MFR # 2931496042
19. #T-COUPLE MFR # 2930326000
20. #STRIP, TERMINAL 6 POS. MFR # 2930327008
21. #LEAD MFR # 2930894015
22. #N/A LEAD MFR # 2930750011
23. #NO PART # GIVEN BY VENDOR MFR # NPG
24. #APPLIANCE COMPONENTS RV; Relay 12V MFR # 2930385006
25. #Refrigerator Relay; Use On Dometic Refrigerator Models QCS135B/ RM100/ RM1303/ RM1350-921148302/ RM1350-921148307/ RM1350-921148319/ RM1350-921148320/ RM2354-921145025/ RM2354-921145027/ RM2354-921145030/ RM2354-921145031/ RM2354-921145051/ RM2354-921145052/ RM2454-921140114/ RM2454-921140115/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604-921580101/ RM3604-921580201/ RM3800/ RM3801/ RM3804-921600101/ RM3804-921600301/ RM4801/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006/ RM4804006/ RM663/ RM76/ RM763/ RM76D/ RM77/ RM77D MFR # 2930385006MC Superseded: see description
26. #APPLIANCE COMPONENTS RV; Block Terminal 4 Large MFR # 2930463001
27. #COMPONENT BOX 3600 ,3500 MFR # 2930642018
28. #RETAINER MFR # 2930648015
29. #Refrigerator Burner Box Cover; Replacement For Dometic RM2600/ S520014/ RM7030 Refrigerators MFR # 2930651019
30. #COVER MFR # 2930653015
31. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
32. #APPLIANCE COMPONENTS RV; Pipe Gas MFR # 2930685017
33. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
34. #APPLIANCE COMPONENTS RV; Insulator Circuit Board MFR # 2931007013
35. #Lead, 3 Way 6 Pin (Has 6 Wire) RM3801 MFR # 2930799024
36. #Wire, Lead (2 Wire) MFR # 2930728023
37. #Lead, One Wire RM4801 MFR # 2930729039
38. #Appliance Components RV; Lead Wire (1 Wire) MFR # 2930729047
39. #N/A LEAD MFR # 2950730011
40. #WIRE,LEAD MFR # 2930731019
41. #Dometic RM2652 RM2662 Gas Valve Assembly MFR # 2932759018
42. #APPLIANCE COMPONENTS RV; Plate Protection 3800/36 MFR # 2930786013
43. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
44. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
45. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
46. #Screw; Replacement For Dometic RM1300/ S1521/ RM2607 Model Refrigerators; Use With 3 Point 115 Volt AC Terminal Block MFR # 7295287408 Superseded: see description
47. #Block Terminal Small 3 Poi MFR # 7627202562
48. #HOLDER, FUSE MFR # 7628801230
49. #IGNITER USE 2931132019 MFR # 7679100003 Superseded: see description
50. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
51. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
52. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
53. #Retainer MFR # 2930661018
54. #Refrigerator Burner Orifice; Replacement For Dometic RM2612/ RM2620/ RM2611/ RM2607/ RM2603/ RM2600/ RM2800/RM2802/ RM3607/RM761/RM4801/ RM3600 Series Refrigerators; #53 MFR # 2007419191
55. #Refrigerator Gas Valve; Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM1303/ RM2800/ RM2802/ RM2803/ RM2810/ RM23804 Series Refrigerators; \#58 MFR # 2007419217
56. #Dometic RM2652 Refrigerator Main Control Board MFR # 3850730569
57. #LEAD,10 WIRE MFR # 2930782095
58. #LEAD,WIRE USE 2930782095 10 PIN 7' LONG MFR # 2930782061 Superseded: see description
59. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
60. #APPLIANCE COMPONENTS RV; Link Fuse 3 Amp Use AGC3 MFR # 7628211943 Superseded: see description
61. #INSERT, FUSE MFR # 7628801212
62. #S,CAP,FLUE MFR # 2007598010
63. #Refrigerator Cooling Unit Baffle Diffuser; Replacement For Dometic RM2811/ RM2812/ RM3807/ RM2801/ RM3801/ RM4804/ RM3607 Series Refrigerators MFR # 2007590066
64. #ELEMENT, HEATING 120V 325W MFR # CS000022
65. #ELEMENT, HEATING USE 45-4113 275W 12V 3800 MFR # 173743030 Superseded: see description
66. #ELEMENT, HEATING Q (25) 12V 275W 3/8" DIA 6-1/2 LONG MFR # 173743014
67. #APPLIANCE COMPONENTS RV; Element Heating Use 48-9 MFR # 173742081 Superseded: see description
68. #BOARD,CIRCUIT USE 87500351199 MFR # 4980557005 Superseded: see description
69. #Refrigerator Power Supply Circuit Board; Replacement For Dometic Refrigerators; 3 Way MFR # MICROP243
70. #BOARD,CIRCUIT USE 3106375003 MFR # 87500351199 Superseded: see description
71. #Refrigerator Interface Circuit Board; Replacement Control Board For Dometic Refrigerators; AC/ DC/ Gas Operation MFR # MICROP246
72. #APPLIANCE COMPONENTS RV; Board Module MFR # 3106375003
73. #Screw; Replacement For Dometic NDR1062/ NDR1292/ NDR1492/ RM1272/ RM2652/ RM2807/ RM2811/ RM2812/ RM2852/ RM3607/ RM3662/ RM7732 Model Refrigerator; M4 x 8 MFR # 7241287619
74. #CORD, FLEXIBLE USE 2002699037 MFR # 2002699029 Superseded: see description
75. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
76. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description

Cabinet Assembly

Components

75 items

1. #NO PART # GIVEN BY VENDOR MFR # NPG
2. #SCREW MFR # SCREW
3. #Refrigerator Shelf; Replacement For Dometic RM1300/ RA1302/ RM2807/ RM2811/ RM2812/ RM2820/ RM3804/ RM3807 Model Refrigerator; Freezer Compartment MFR # 2007535038
4. #APPLIANCE COMPONENTS RV; Shelf Milk MFR # 2930133117
5. #SHELF USE 2930133117 MFR # 2930133042 Superseded: see description
6. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
7. #APPLIANCE COMPONENTS RV; Shelf Wire 11 5/8" X 19 3 MFR # 2002652259
8. #APPLIANCE COMPONENTS RV; Shelf Wire 7.5" X 19 3/4" MFR # 2002652267
9. #RETAINING PLATE MFR # RETAINING PLATE
10. #Refrigerator Door Latch; Travel Latch; Replacement For Dometic RM2802/ RM2803/ RM3800 Refrigerators MFR # 2930706052
11. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
12. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
13. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
14. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
15. #APPLIANCE COMPONENTS RV; Card Switch On Circ. Boar MFR # 87500350258
16. #PLUG MFR # PLUG
17. #HOUSING, CATCH GREY/BROWN MFR # 2930707050
18. #Refrigerator Crisper Bin; Replacement For Dometic RM2801/ RM2802/ RM3800 Model Refrigerators; White MFR # 2002726129
19. #CRISPER, SMOKE USE 2002726095 MFR # 2002726020 Superseded: see description
20. #CRISPER, SMOKE USE 2002726129 RM2810 MFR # 2002726095 Superseded: see description
21. #Decoration, Front CPL 3800 MFR # 2930749045
22. #APPLIANCE COMPONENTS RV; Strip Decoration MFR # 2930989021
23. #APPLIANCE COMPONENTS RV; Strip Decoration MFR # 2930987017
24. #Decoration, Front MFR # 2930748021
25. #Hinge, LH MFR # 2930709023
26. #Refrigerator Door Hinge; Replacement for Dometic RM3800/ RM4801/ RM3801 Refrigerators MFR # 2930708025
27. #APPLIANCE COMPONENTS RV; Lid Crisper Rm660-760 MFR # 2002727028
28. #COVER, CRISPER 9 1/2" X 12" MFR # 2002727077
29. #APPLIANCE COMPONENTS RV; Cover Crisper Use 2002727 MFR # 2002727010 Superseded: see description
30. #Tray, Drip Use 2007610013 MFR # 2007610005 Superseded: see description
31. #APPLIANCE COMPONENTS RV; PAN, DRIP MFR # 2007610013
32. #COVER, LIGHT SWITCH MFR # 2004044109
33. #COVER, CONTROLS USE 2004044091 MFR # 2004044075 Superseded: see description
34. #2004044091 MFR # 2004044091
35. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
36. #SWITCH, LIGHT WH USE 3850959010 DOOR-ACTIVA MFR # 2940825009 Superseded: see description
37. #LEAD MFR # LEAD
38. #KEY USE 2930982018 MFR # 2930982015 Superseded: see description
39. #APPLIANCE COMPONENTS RV; Key MFR # 2930982018
40. #Pin, Hinge Upper MFR # 2930612003
41. #KNOB, T-STAT USE 2930625039 MFR # 2930625021 Superseded: see description
42. #Refrigerator Thermostat Control Knob; Use With Dometic Refrigerator Model RM2603 MFR # 2930625039 Superseded: see description
43. #T-STAT USE 2930814021 MFR # K50P1336 Superseded: see description
44. #T-STAT USE K50P1336 MFR # K50P1317 Superseded: see description
45. #APPLIANCE COMPONENTS RV; Level Spirit MFR # 2007645019
46. #Refrigerator Door Hinge; Replacement For Dometic RM2803/ RM4801/ RM2601 Refrigerators; Fits Upper Door Side MFR # 2930613001
47. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
48. #WASHER 'R' (.5') RUBBER MFR # WASHER
49. #SHADE, LAMP MFR # 2004043002
50. #TRAY, MILK USE 2930136011 MFR # 2930136003 Superseded: see description
51. #APPLIANCE COMPONENTS RV; Shelf Tray MFR # 2930136011
52. #APPLIANCE COMPONENTS RV; Light 12V MFR # 2930744012
53. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
54. #BULB 2/PK MFR # 2007290006
55. #Bar, L Approx 9" RM1300 MFR # 2007337070
56. #Refrigerator Evaporator Door Torsion Bar; Use With Dometic RM2800/ RM2801 Model Refrigerators; 16-1/2 Inch Length MFR # 2007337047 Superseded: see description
57. #Appliance Components RV; Bar Freezer Shelf MFR # 2007537000
58. #RETAINER USE 2930693045 MFR # 2930693029 Superseded: see description
59. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
60. #APPLIANCE COMPONENTS RV; Pushbutton Lh MFR # 2930980012
61. #Push Button Switch; On/ Off Switch; Middle; Panel Mount MFR # 2930980020
62. #INDEX MFR # 2001354022
63. #Plate, Covering Freezer MFR # 2930486036
64. #Strip, Deco Use 2005111360 RM3601 MFR # 2005111071 Superseded: see description
65. #Appliance Components RV; Strip Decoration MFR # 2055366013
66. #Appliance Components RV; Decoration Strip MFR # 2005111121
67. #Strip, Deco Use 2055366013 MFR # 2005111360 Superseded: see description
68. #PLATE, LEFT SIDE MFR # 2930603002
69. #Refrigerator Support Rail; Replacement For Dometic RM3801/ RM2603/ RM3800 Refrigerators; Left Hand Side MFR # 2930601006
70. #BASE FRONT MFR # 2930600016
71. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
72. #PIN,RETAINING MFR # 2001281019
73. #Refrigerator Door Hinge Pin; Use With Dometic Refrigerator Model RM2301; Fits Bottom Hinge MFR # 2930614009 Superseded: see description
74. #0 MFR # PROTECTING PLATE
75. #Refrigerator Control Knob; For Use With Dometic RM2602/ RM2603/ RM2802/ RM2803/ RM3501/ RM3601/ RM3801 And RM4801 Refrigerator Models; Push Button MFR # 2930980038 Superseded: see description

Vibration Suppression Kit

Components

1 item

1. #VIBRATION SUSPENSION KIT PRICED PER FOOT MFR # 3108704515
