Dometic RM3804 3 Way Refrigerator Parts Diagram · Replacement Refrigerator

Refrigerator · 7 assemblies · 7 diagram sheets · 276 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM3804 3 Way Refrigerator RV refrigerator: 7 assemblies (Replacement Refrigerator, Cabinet Assembly, Freezer Component Parts, Door Assembly, Rear View Cabinet Assembly and more) and 276 manufacturer part numbers. 76 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Replacement Refrigerator

Components

6 items

1. #REFER,8 CU FT 3 WAY 59 15/16 X 23 11/16 X 24 MFR # RM3863N
2. #REFER,8 CU FT 3WAY BLK FRM59 1 5/16 X 23 11/16 X 24 MFR # RM3863BN
3. #Refrigerator; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 7.5 Cubic Foot; 23-1/2 Inch Width x 24 Inch Depth x 59-7/8 Inch Height; 3 Amps At 120 Volt AC/ 14.8 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LCD Temperature Control Panel; With Door Ajar Alarm And Automatic Cabinet Light Shut Off; Black Doors; With Crispers/ Shelving And Door Bins MFR # N8413BK
4. #Refrigerator / Freezer; Dual Compartment 2 Door Refrigerator With Freezer; Flush Mount; 7.5 Cubic Ft MFR # N8413SS
5. #Refrigerator / Freezer; 2 Door; Right Hand; 8 Cubic Foot; 59-7/8 Inch x 23-1/2 Inch x 24 Inch; 3 Way MFR # N8413N
6. #REFER,8 CU FT 3-WAY WHITE 59 7/8"H X 23 1/2"W X 24"D MFR # N8413WH

Cabinet Assembly

Components

92 items

1. #S,HINGE,UPR,CLASSIC MFR # 2931291013
2. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
3. #S,WASHER,ADJUSTABLE,28*33MM MFR # 2931292011
4. #BOARD, CIRCUIT UPPER 3/W MFR # 2931309013
5. #APPLIANCE COMPONENTS RV; Panel Operating 3/W Upper; FOR 2 WAY USE 2931295022 MFR # 2931295014 Superseded: see description
6. #APPLIANCE COMPONENTS RV; Cover Front Rm3804/2 MFR # 2931294017
7. #APPLIANCE COMPONENTS RV; Label Installation MFR # 2931304006
8. #Dometic RM2193 RM2652 Refrigerator Cooling Unit MFR # 2930132069
9. #HINGE, CENTER MFR # 2931290015
10. #SUPPORT MFR # 2930774019
11. #S,HINGE PIN,UPR,RM2604 MFR # 2931288019
12. #HINGE, LOWER LH RM26 04 MFR # 2931283010
13. #HINGE, LOWER RH MFR # 2931283028
14. #S,HINGE PIN,MID,25MM MFR # 2931287011
15. #S,HINGE PIN,LWR,RM2604,24-2810 MFR # 2931286013
16. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM2410/ RM2604/ RM2612/ RM2620/ RM2804/ RM2807/ RM2820/ RM3604/ RM3607/ RM3804/ RM4804005/ RM4804006 Model Refrigerator; M4 x 12; Zinc Plated MFR # 7243291619
17. #Plate, Covering Freezer MFR # 2930486036
18. #APPLIANCE COMPONENTS RV; Runner Right MFR # 2931281014
19. #APPLIANCE COMPONENTS RV; Runner Left MFR # 2931281022
20. #COVER, PLATE RM38 04 MFR # 2931282046
21. #APPLIANCE COMPONENTS RV; Insulation RM3801 MFR # 2930711029
22. #Refrigerator Thermostat Cover MFR # 2931285015
23. #REINFORCEMENT MFR # 2931504019
24. #Refrigerator Vent Cover Back Plate MFR # 2930664012
25. #PLUG MFR # 2931284018
26. #Screw Cover; Replacement For RM2611/ RM2620/ RM2607 Refrigerators; Use To Cover Screws For A Finished Look; Press On; Round; Dark Gray MFR # 2931284026 Superseded: see description
27. #S,STRIKE 9*35*24MM MFR # 2931511014
28. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
29. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
30. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
31. #PLUG, COVER; USE 2931510032 GREY BROWN MFR # 2930736034 Superseded: see description
32. #DECAL, 3-WAY MFR # 2931314005
33. #Refrigerator Shelf; Replacement For Dometic RM1300/ RA1302/ RM2807/ RM2811/ RM2812/ RM2820/ RM3804/ RM3807 Model Refrigerator; Freezer Compartment MFR # 2007535038
34. #SHELF, FREEZER MFR # 2007535012
35. #Flange, Cooling Use 2007605013 MFR # 2007605005 Superseded: see description
36. #Refrigerator Cooling Unit; Use With Dometic RM2807/ RM3807/ RM2820/ RM3807/ RM2811/ RM2807/ RM1303/ RM4804 Model Refrigerators MFR # 2007605013 Superseded: see description
37. #SHELF USE 2930133117 MFR # 2930133042 Superseded: see description
38. #APPLIANCE COMPONENTS RV; Shelf Milk MFR # 2930133117
39. #APPLIANCE COMPONENTS RV; Bolt Freezer Mounting MFR # 7252330134
40. #APPLIANCE COMPONENTS RV; Shelf Wire 7.5" X 19 3/4" MFR # 2002652267
41. #APPLIANCE COMPONENTS RV; Shelf Wire 11 5/8" X 19 3 MFR # 2002652259
42. #Nut; Replacement For Dometic RM2807/ RM2811/ RM2612 Model Refrigerators MFR # 7312314409
43. #NUT USE 7312314409 MFR # 7314314134 Superseded: see description
44. #PLATE RETAINING MFR # 2007649011
45. #Ice Cube Tray; Use With Dometic RM361/ RM36A/ RM2607 Refrigerators; Plastic MFR # 2943422002 Superseded: see description
46. #S,TRAY,ICE CUBE-RM2510 MFR # 2930400003
47. #Lock, Shelf Use 2007393024 N MFR # 2007393016 Superseded: see description
48. #S,CASING LID,OUTER,WHT,RM2410, MFR # 2007393024
49. #APPLIANCE COMPONENTS RV; Lock Shelf Use 2007392026 MFR # 2007392018 Superseded: see description
50. #Dometic RM2652 Refrigerator Lower Door Bin MFR # 2007392026
51. #Refrigerator Crisper Bin; Replacement For Dometic RM2801/ RM2802/ RM3800 Model Refrigerators; White MFR # 2002726129
52. #CRISPER, SMOKE USE 2002726129 RM2810 MFR # 2002726095 Superseded: see description
53. #CRISPER, SMOKE USE 2002726095 MFR # 2002726020 Superseded: see description
54. #APPLIANCE COMPONENTS RV; PAN, DRIP MFR # 2007610013
55. #Tray, Drip Use 2007610013 MFR # 2007610005 Superseded: see description
56. #COVER, CONTROLS USE 2004044091 MFR # 2004044075 Superseded: see description
57. #COVER, LIGHT SWITCH MFR # 2004044109
58. #COVER, LIGHT USE 2004044091 MFR # 2004044083 Superseded: see description
59. #2004044091 MFR # 2004044091
60. #S,SWITCH,DR LIGHT,DMR702 MFR # 3850959010
61. #Lead T-Stat MFR # 2930735010
62. #Refrigerator Thermostat Control Knob; Use With Dometic Refrigerator Model RM2603 MFR # 2930625039 Superseded: see description
63. #CLIP, SPRING USE 2901183026 F/KNOB MFR # 163382005 Superseded: see description
64. #Refrigerator Control Knob; Replacement For Dometic RM2200A/ RM2201/ RM3804 Refrigerators; Thermostat Control Knob MFR # 2901183026
65. #RETAINER, T-STAT INCL UDES LOCK PIN MFR # 2004042004
66. #SHADE, LAMP MFR # 2004043002
67. #TRAY, MILK USE 2930136011 MFR # 2930136003 Superseded: see description
68. #APPLIANCE COMPONENTS RV; Shelf Tray MFR # 2930136011
69. #LAMP, COMPLETE MFR # 29307440l2
70. #BULB 2/PK MFR # 2007290006
71. #APPLIANCE COMPONENTS RV; BULB PKG, 12V-10W MFR # 200729000P
72. #Appliance Components RV; Bar L Approx 15" 460-66 MFR # 2007337039
73. #Bar, L Approx 9" RM1300 MFR # 2007337070
74. #Appliance Components RV; Bar Freezer Shelf MFR # 2007537000
75. #RETAINER USE 2930693045 MFR # 2930693037 Superseded: see description
76. #Refrigerator Door Rail; Replacement For Dometic NDR1272/ NDR1282 Refrigerators MFR # 2930693045
77. #S WIRE SHELF RAILS/HOLDERS MFR # 2007372111
78. #APPLIANCE COMPONENTS RV; Cover Capillary MFR # 2004056012
79. #INDEX,T-STAT MFR # 2001354030
80. #CLAMP 2800 MFR # 2002798003
81. #Strip, Deco Use 2005111360 RM3601 MFR # 2005111071 Superseded: see description
82. #Strip, Deco Use 2055366013 MFR # 2005111360 Superseded: see description
83. #Strip, Decor Use 2005111071 MFR # 2005111113 Superseded: see description
84. #Appliance Components RV; Strip Decoration MFR # 2055366013
85. #Appliance Components RV; Decoration Strip MFR # 2005111121
86. #Screw; Replacement For Dometic NDR1272/ NDR1282/ NDR1292/ RM1282/ RM1301/ RM2600/ RM2820/ RM3600 Model Refrigerator; Retaining Plate Screw MFR # 2930487000
87. #PIN,RETAINING MFR # 2001281019
88. #Refrigerator Thermostat Control Assembly; Use With Dometic Refrigerator Models RM2804/ RM3800/ RM3801 MFR # 2930814021MC Superseded: see description
89. #T-STAT, ELECTRIC USE 2930814021 MFR # 2930814013 Superseded: see description
90. #T-STAT USE 2930814021 MFR # K50P1336 Superseded: see description
91. #APPLIANCE COMPONENTS RV; T-Stat Electric MFR # 2930814021
92. #Refrigerator Shelf; Use With Dometic Refrigerator Model RM3807; Plastic MFR # 2931117051 Superseded: see description

Freezer Component Parts

Components

14 items

1. #Shelf MFR # 2931924019
2. #Side Plate MFR # 2931921015
3. #Pop Rivet MFR # 7727822033
4. #Plate MFR # 2007649029
5. #Icemaker; Use 3108701552 MFR # 2931971028 Superseded: see description
6. #APPLIANCE COMPONENTS RV; Icemaker Replacement Kit MFR # 3108701552
7. #SCREW, RX5X12, Z. PL. MFR # 7241327019
8. #APPLIANCE COMPONENTS RV; Screw Hinge MFR # 7241325617
9. #Shelf, Wire for Ice Bucket RM2807 MFR # 2931923011
10. #Bucket, Ice MFR # 2930880022
11. #Tube, Water (Metal) MFR # 2931922013
12. #Nut M6M5, Zinc Plated MFR # 7312314011
13. #Ice Maker Kits Complete MFR # 2931967018
14. #Ice Maker Kits Complete MFR # 2931997015

Door Assembly

Components

42 items

1. #APPLIANCE COMPONENTS RV; Door Freezer MFR # 2931182113
2. #Gasket Kit; Contains: 1 - 3376008 Gasket 15-1/2 x 21; 1 - 3376009 Gasket 22 x 36; 1 - DC732RTV 3/16" Tube Silicone; 1 - 6141 6-Yard Gasket Tape; 1 - Instruction Sheet MFR # 3108700018D
3. #Refrigerator Gasket; Replacement For Dometic RM2804/ RM2807/ RM2810/ RM3804 Refrigerators; Door Gasket; Brown MFR # 3108700018
4. #APPLIANCE COMPONENTS RV; Door Refer Lower Rm3804 MFR # 2931181115
5. #Refrigerator Door Hinge Bushing; Replacement For Dometic RM7130/ RM2607/ RM2652 Refrigerators; Fits Top Hinge MFR # 2931171017
6. #Refrigerator Door Handle Screw; Replacement For Dometic RM2310/ RM2410/ RM2510/ RM2604/ RM2607/ RM2811/ RM3604/ RM3804/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006 Model Refrigerator MFR # 2931510032
7. #Refrigerator Shelf; Use With Dometic RM2607/ RM100/ RA1302 Refrigerators; Juice Rack; Beige MFR # 2930533019 Superseded: see description
8. #Screw, B4x16, Zinc Plated MFR # 72952290l2
9. #APPLIANCE COMPONENTS RV; Handle Door MFR # 2931199026
10. #HANDLE RM2804 USE 2931199026 MFR # 2931199018 Superseded: see description
11. #Screw RXS, B4x10, Zinc Plated MFR # 72952250l0
12. #HOLDER,BOTTLE USE 2930715053 GREY/BEIGE 7" MFR # 2930715038 Superseded: see description
13. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
14. #HOLDER,BOTTLE USE 2930715061 GREY/BEIGE 8" MFR # 2930715046 Superseded: see description
15. #Refrigerator Shelf Support; Replacement For Dometic RM2620/ RM2353/ RM2354 Refrigerators; 8 Inch; White MFR # 2930715061
16. #Cover, Handle MFR # 29311960l4
17. #LABEL, INSTRUCTION MFR # 2002356000
18. #Shelf MFR # 29305340l7
19. #Door, Dairy; Use 2930540022 MFR # 2930541129 Superseded: see description
20. #Door, Dairy; Use 2930540022 MFR # 2930541095 Superseded: see description
21. #Door, Dairy LH MFR # 2930540030
22. #Door, Dairy; Use 2930540022 MFR # 2930541091 Superseded: see description
23. #APPLIANCE COMPONENTS RV; Cover Butter Rh MFR # 2930540022
24. #Door, Dairy; Use 2930540014 MFR # 2930541101 Superseded: see description
25. #Door, Dairy; Use 2930540014 MFR # 2930541103 Superseded: see description
26. #Door, Dairy RH Smoked; Specs: For RM3807 Product #'s 921602301, 921602401, 921602501, 921602601; Use Part# 2930540014 MFR # 2930540014 Superseded: see description
27. #Strip, Decoration MFR # 29311630l4
28. #Strip, Deco LWR; Use For RM3804 MFR # 2931163030 Superseded: see description
29. #Strip, Decoration Upper; Use For RM3804 MFR # 2931163014 Superseded: see description
30. #BOX, ICE WHITE MFR # 2930536020
31. #Box, Freezer; Use 2930536020 MFR # 2930536012 Superseded: see description
32. #Lid MFR # 29305370l0
33. #Bracket, Butter Compartment MFR # 29305940l1
34. #SHELF, DOOR USE 2930558057 MFR # 2930558024 Superseded: see description
35. #APPLIANCE COMPONENTS RV; Shelf Freezer Door MFR # 2930558057
36. #APPLIANCE COMPONENTS RV; Rack Wire MFR # 2001734009
37. #APPLIANCE COMPONENTS RV; Shelf Door Clear MFR # 2001732136
38. #APPLIANCE COMPONENTS RV; Shelf Door Use 2001732136 MFR # 2001732144 Superseded: see description
39. #Washer MFR # 29315120l2
40. #APPLIANCE COMPONENTS RV; Insert Hinge (Beige) MFR # 2931512020
41. #PANELS,DOOR BLACK PLEXIGLASS SET OF 2 MFR # RM3804L
42. #Panels, Door Woodgrain Top & Bottom Panels MFR # RM3804G

Rear View Cabinet Assembly

Components

21 items

1. #PLATE, MOUNTING MFR # 2931995019
2. #Valve, Water MFR # 2932148022
3. #VALVE, WATER USE 2932148022 RM7030 MFR # 2931972042 Superseded: see description
4. #VALVE KIT WATER MFR # 3108706114
5. #S,NUT,PLASTIC,1/4" TB,7-16"-20 MFR # 2930839010
6. #APPLIANCE COMPONENTS RV; Insert Water Hose MFR # 3108708185
7. #INSERT,SOLENOID USE 3108708185 MFR # 2930841016 Superseded: see description
8. #STRIP, TERMINAL 6 POS. MFR # 2930327008
9. #COVER MFR # 2931994012
10. #STRIP (PROTECTOR PLASTIC) MFR # 2930718099
11. #Refrigerator Water Supply Line; Replacement For Norcold 1200/ 1210/ 2117/ N1095/ N641/ N84X Series Refrigerator Icemaker; 68 Inch Length MFR # 617869
12. #Ice Maker Water Inlet Hose; Replacement For Dometic RM2862/ RM4872/ RM7030/ RM7832/ NDR1062 Model Refrigerator Ice Maker; 5 Foot Length; Plastic MFR # 3108705637
13. #HOSE,WATER USE 3108705637 SELL BY THE FOOT MFR # 3108705306 Superseded: see description
14. #Hose, Water MFR # 2930905035
15. #WARNING LABEL MFR # 2931975003
16. #WIRING DIAGRAM MFR # 2931996009
17. #APPLIANCE COMPONENTS RV; Connection Water MFR # 2930916024
18. #POP RIVET MFR # 7227836090
19. #DOOR DECORATION STRIP MFR # 2931163089
20. #TERMINAL BLOCK,Y MFR # 2931963017
21. #WIRE CONNECTOR MFR # 2400297012

Icemaker Exploded View

Components

15 items

1. #CYCLE, ICEMAKER USE 3108701552 MFR # 3101979007 Superseded: see description
2. #APPLIANCE COMPONENTS RV; Icemaker Replacement Kit MFR # 3108701552
3. #Ice Maker Water Cup; For U-Line 402-CO2075FF/ U-CO29FF/ 402 BI 2015 MFR # 544304
4. #BEARING AND INLET MFR # 3101286007
5. #APPLIANCE COMPONENTS RV; Ejector 627169 MFR # 3101287005
6. #STRIPPER, ICE MFR # 3101288003
7. #AXLE BRACKET EXT 2' MFR # 2506
8. #APPLIANCE COMPONENTS RV; Switch Micro Use 2506 MFR # 3102807009 Superseded: see description
9. #APPLIANCE COMPONENTS RV; T-Stat MFR # 3101290009
10. #T-STAT USE 3101290009 327047 MFR # 310129009 Superseded: see description
11. #MOTOR/TIMER USE 3108701552 RM4804 MFR # 3101292005 Superseded: see description
12. #APPLIANCE COMPONENTS RV; Motor MFR # 3108703475
13. #APPLIANCE COMPONENTS RV; Cam MFR # 3101295008
14. #APPLIANCE COMPONENTS RV; Gear MFR # 3101296006
15. #Ice Maker Support Housing Cover; Use With Dometic Refrigerator Model RM7832; White MFR # 2930874025 Superseded: see description

Gas-electric

Components

92 items

1. #Refrigerator Cooling Unit; Use With Dometic RM2800/ RM2801/ RM2802/ RM2803/ RM2810/ RM3800/ RM3801/ RM3802/ RM3803/ RM3804 Model Refrigerators MFR # 5528 Superseded: see description
2. #REMAN C/U USE 5528 MFR # 2934901097R Superseded: see description
3. #APPLIANCE COMPONENTS RV; Cooling Unit MFR # 2934901097N
4. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
5. #Refrigerator Cooling Unit Cap; Use With Dometic RM Series 2 Way And 3 Way/ Servel/ Americana/ Americana Plus/ Royale Refrigerators MFR # 2933557007 Superseded: see description
6. #APPLIANCE COMPONENTS RV; Screw MFR # 7241328611
7. #SCREW USE 7295279405 MFR # 7295279017 Superseded: see description
8. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
9. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
10. #DECAL RM3804 MFR # 2931503003
11. #DECAL RM38 04 MFR # 2007574029
12. #LABEL, IMPORTANT MFR # 2007689009
13. #LABEL, CAUTION RM48 01 MFR # 2930750001
14. #APPLIANCE COMPONENTS RV; Protect Splash MFR # 2930810011
15. #CORD, FLEXIBLE USE 2002699037 MFR # 2002699029 Superseded: see description
16. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
17. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
18. #HOSE, DRAIN MFR # 2931133017
19. #TRAY, EVAPORATION MFR # 2931134015
20. #APPLIANCE COMPONENTS RV; Plate Protection 3800/36 MFR # 2930786013
21. #Refrigerator Vent Cover Back Plate; Use With Dometic RM2807/ RM2812/ RM4804 Refrigerators MFR # 2930784018 Superseded: see description
22. #DECAL, WARNING 2807/4801 MFR # 2002577001
23. #APPLIANCE COMPONENTS RV; Nut Orifice MFR # 140207044
24. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
25. #APPLIANCE COMPONENTS RV; Knob Gas Valve MFR # 2004067217
26. #Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM2600/ RM2610/ NDR1282 Model Refrigerator MFR # 2007457001
27. #APPLIANCE COMPONENTS RV; Wire Lead 2604 MFR # 2007668029
28. #COCK, GAS USE 2007709047 MFR # 2007709013 Superseded: see description
29. #BOARD, MODULE MFR # 3106375015
30. #APPLIANCE COMPONENTS RV; Gas Valve & Board Kit MFR # 3108705272
31. #Refrigerator Power Supply Circuit Board; Replacement For Dometic Earlier Refrigerator Series Micro P-24 2-Way\ Micro P-24 3-Way\ Micro P-26; 3 Way; With Built In Microcontroller\ Self-Resetting Circuit Breaker MFR # MICROP246PLUS
32. #APPLIANCE COMPONENTS RV; Circuit Board, Refrigerator, Dometic MFR # MICROP1338REV5
33. #VALVE, GAS USE 3108706023 MFR # 2007709047 Superseded: see description
34. #APPLIANCE COMPONENTS RV; Valve Kit Shut Off W/Pro MFR # 3108706023
35. #VALVE, SOLENOID USE 2007719020 MFR # 2007719012 Superseded: see description
36. #VALVE, SOLENOID USE 3108705272 MFR # 2007719020 Superseded: see description
37. #Thermocouple; Use On Dometic Refrigerator Model RM3800 MFR # 2930326018MC Superseded: see description
38. #Thermocouple MFR # 2931496091MC
39. #T-COUPLE USE 2931496026 RM3801,3601,2802 MFR # 2930326018 Superseded: see description
40. #THERMOCOUPLE (350MM) MFR # 2931496091
41. #T-Couple Use 2931496091 MFR # 2931496026 Superseded: see description
42. #STRIP, TERMINAL 6 POS. MFR # 2930327008
43. #Wire, Lead RM3804 MFR # 2931509018
44. #Wire, Lead RM3804 MFR # 2930352014
45. #Refrigerator Insulation; Use With Dometic RM3804/4804/2802 Series Refrigerators MFR # 2931052019 Superseded: see description
46. #APPLIANCE COMPONENTS RV; Block Terminal 4 Large MFR # 2930463001
47. #BOX, COMPONENT MFR # 2930642042
48. #RETAINER MFR # 2930648015
49. #Refrigerator Burner Box Cover; Replacement For Dometic RM2600/ S520014/ RM7030 Refrigerators MFR # 2930651019
50. #COVER MFR # 2930653015
51. #Refrigerator Thermocouple Bracket; Replacement For Dometic RM2820/ RM2812/ RM2611 Refrigerators MFR # 2930660010
52. #APPLIANCE COMPONENTS RV; Pipe Gas MFR # 2930685017
53. #APPLIANCE COMPONENTS RV; Burner W/Electrode MFR # 2930697020
54. #DOMETIC ELECTRODE 663-763 MFR # 2930379009
55. #IGNITER ELECTRODE FOR DOMETIC REFRIGERATORS MFR # 2930379009MC
56. #S,SCREW,RXS,3.5*6.5ZPBC-4-14CF MFR # 3858002052
57. #Screw Use 3858002052 MFR # 7295221019 Superseded: see description
58. #Wire, Lead (2 Wire) MFR # 2930728023
59. #Lead, One Wire RM4801 MFR # 2930729039
60. #Appliance Components RV; Lead Wire (1 Wire) MFR # 2930729047
61. #APPLIANCE COMPONENTS RV; Protector Washer MFR # 2930811019
62. #Dometic RM2652 RM2662 Gas Valve Assembly MFR # 2932759018
63. #Lead, 3 Way 6 Pin (Has 6 Wire) RM3801 MFR # 2930799024
64. #Block Terminal Small 3 Poi MFR # 7627202562
65. #HOLDER, FUSE MFR # 7628801230
66. #DOMETIC REIGNITOR RM1303 MFR # 2931132019
67. #Refrigerator Reigniter Board; Use With Dometic Models With Separate Reignitor Board MFR # REIGNITOR MODULE Superseded: see description
68. #Refrigerator Reigniter Board; Fits Dometic Refrigerator Models RM1272/ RM1301/ RM1303/ RM2192/ RM2500/ RM2510/ RM2552/ RM2553/ RM2600/ RM2601/ RM2602/ RM2603/ RM2604/ RM2607/ RM2610/ RM2611/ RM2612/ RM2620/ RM2652/ RM2800/ RM2801/ RM2803/ RM2804/ RM2807/ RM2810/ RM2811/ RM2812/ RM2820/ RM2852/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604/ RM3607/ RM3662/ RM3663/ RM3800/ RM3801/ RM3804/ RM3807/ RM3862/ RM3863/ RM4801/ RM4804/ RM4872/ RM4873/ RM661/ RM663/ RM7030/ RM7130 MFR # 2931132019MC
69. #Retainer MFR # 2930661018
70. #Refrigerator Gas Valve; Refrigerator Burner Orifice; Replacement For Dometic RM1301/ RM1303/ RM2800/ RM2802/ RM2803/ RM2810/ RM23804 Series Refrigerators; \#58 MFR # 2007419217
71. #Dometic RM2652 Refrigerator Main Control Board MFR # 3850730569
72. #LEAD,10 WIRE MFR # 2930782095
73. #NO GENERIC NAME; Fuse 3 Amp Buss S (5) MFR # AGC3
74. #APPLIANCE COMPONENTS RV; Link Fuse 3 Amp Use AGC3 MFR # 7628211943 Superseded: see description
75. #APPLIANCE COMPONENTS RV; Insert MFR # 7628802212
76. #CAP FLUE MFR # 2931540013
77. #Refrigerator Cooling Unit Baffle Diffuser; Replacement For Dometic RM2811/ RM2812/ RM3807/ RM2801/ RM3801/ RM4804/ RM3607 Series Refrigerators MFR # 2007590066
78. #APPLIANCE COMPONENTS RV; Lead 7 Wire MFR # 2930990060
79. #Refrigerator Cooling Unit Heater Element; Use With Dometic Refrigerator Models RM3600/ RM3800; 12 Volt; 215 Watts MFR # 173757022MC Superseded: see description
80. #ELEMENT, HEATING **ALT 72-8720 215W 12V; 17.9 Amps 3/8" DIA 4 1/4" LONG; Is a use # for 173757022D MFR # 173757022 Superseded: see description
81. #ELEMENT, HEATING *ALT 72-8720 215W 12V; Suggested Alternate For Dometic: This part is not a Dometic original but can be used as an alternate to the Dometic P#173757089. MFR # CHX17748
82. #ELEMENT, HEATING 215W 12V; Suggested Alternate P# CHX17748 is available if original is out of stock; Is a use # for 173757022 MFR # 173757089 Superseded: see description
83. #ELEMENT, HEATING 120V 325W MFR # CS000022
84. #APPLIANCE COMPONENTS RV; Element Heating Use 48-9 MFR # 173742081 Superseded: see description
85. #Refrigerator Power Supply Circuit Board; Replacement For Dometic Refrigerators; 3 Way MFR # MICROP243
86. #Refrigerator Interface Circuit Board; Replacement Control Board For Dometic Refrigerators; AC/ DC/ Gas Operation MFR # MICROP246
87. #BOARD, MODULE 3W USE 3108705272 MFR # 2931308015 Superseded: see description
88. #APPLIANCE COMPONENTS RV; Strip MFR # 2930718024
89. #APPLIANCE COMPONENTS RV; Relay 12V MFR # 2930385006
90. #Refrigerator Relay; Use On Dometic Refrigerator Models QCS135B/ RM100/ RM1303/ RM1350-921148302/ RM1350-921148307/ RM1350-921148319/ RM1350-921148320/ RM2354-921145025/ RM2354-921145027/ RM2354-921145030/ RM2354-921145031/ RM2354-921145051/ RM2354-921145052/ RM2454-921140114/ RM2454-921140115/ RM3500/ RM3501/ RM3600/ RM3601/ RM3604-921580101/ RM3604-921580201/ RM3800/ RM3801/ RM3804-921600101/ RM3804-921600301/ RM4801/ RM4804/ RM4804002/ RM4804004/ RM4804005/ RM4804006/ RM4804006/ RM663/ RM76/ RM763/ RM76D/ RM77/ RM77D MFR # 2930385006MC Superseded: see description
91. #LEAD, 4 WIRE MFR # 2930783028
92. #Clip Use 2930651019 MFR # 2931325019 Superseded: see description
