Dometic RM46 Model RM46E Parts Diagram · Gas-electric Parts

Refrigerator · 5 assemblies · 5 diagram sheets · 192 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM46 Model RM46E RV refrigerator: 5 assemblies (Gas-electric Parts, Cabinet Assembly, Refrigerator Replacement, Door Assembly, Switch Control) and 192 manufacturer part numbers. 48 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Gas-electric Parts

Components

45 items

1. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
2. #TURN PROTECTION MFR # 2002766000
3. #SCREW MFR # 7298285402
4. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
5. #SCREW USE 7295285402 MFR # 7295285014 Superseded: see description
6. #COVER MFR # 2007170000
7. #SEALING RING MFR # 2002224018
8. #WASHER RM36E MFR # 7344974014
9. #APPLIANCE COMPONENTS RV; Clamp MFR # 2002438006
10. #SPRING WASHER, FBB 5.1, Z. PL. MFR # 7351146019
11. #SCREW RXS B6X5 MFR # 7295275015
12. #TAB CONNECTOR, STRAIGHT MFR # 7603857009
13. #BLOCK, TERMINAL RM36 - RM100 MFR # 581557709
14. #SCREW, KCS 5.5X5, Z. PL. MFR # 7232250311
15. #FLUE CHANNEL MFR # 2007165000
16. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
17. #T-STAT USE K50P1291 MFR # 2890032002 Superseded: see description
18. #T-STAT, ELECTRIC REPLACES: IS A USE # F/C302C, 2890032028, 2930758012, 50464, 671054120, 671401147, 172821027, C302B. FOR TRAV'LER MDLS 301-40 & 301-90 USE C... MFR # K50P1291 Superseded: see description
19. #APPLIANCE COMPONENTS RV; THERMOSTAT MFR # 2930758012
20. #Refrigerator Thermostat Control Knob; Replacement For Dometic RM47D/ RM66F/ RM66/ RM66D/ RM67D/ RM36E/ RM100/ RM76D/ RM66E/ RM67/ RM46E Series Refrigerators MFR # 2002423032
21. #BRACKET T-STAT MFR # 2890034008
22. #SCREW #17 MFR # 7241289011
23. #CABLE F/T-STAT MFR # 173193020
24. #APPLIANCE COMPONENTS RV; Cover W/Screw MFR # 581565728
25. #TAB CONNECTOR, ANGLE MFR # 7604855002
26. #BOTTOM FOR BURNER PROTECTION MFR # 2007169002
27. #SCREWS RM10 0 MFR # 7241328017
28. #CONDUCTOR, LIGHT MFR # 2002222004
29. #PIEZO LIGHTER MFR # 440
30. #IGNITER,PIEZO **ALT 72-8227 14-1/2" LOT440 MFR # 2002609028
31. #Igniter; Use On Dometic Refrigerators; Piezo Spark MFR # 2002609036MC Superseded: see description
32. #LIGHTER,PIEZO ALT 2002609036MC MFR # 2002609036
33. #ELECTRODE,SQUARE USE 2002436000MC MFR # 2002436000 Superseded: see description
34. #Igniter Electrode; Use On Dometic Old M And RM Model Refrigerators; With Mounting Screw/ Gasket/ 2 Probes MFR # 2002436000MC Superseded: see description
35. #ELECTRODE USE 2002436000 MFR # 2002436002 Superseded: see description
36. #APPLIANCE COMPONENTS RV; Packing MFR # 2002304000
37. #APPLIANCE COMPONENTS RV; Holder Igniter MFR # 2002305007
38. #APPLIANCE COMPONENTS RV; Shaft 15" MFR # 2002300008
39. #RING,SEALING MFR # 2002224000
40. #WASHER 6.0, Z.PL. MFR # 7344909012
41. #APPLIANCE COMPONENTS RV; Rod Pull 4-6 Cubic Feet MFR # 2002226005
42. #SCREW USE 7295279405 MFR # 7295279017 Superseded: see description
43. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
44. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
45. #ELEMENT, HEATING 135w/110V 2WIRE 5/16 X 4 1/2 MFR # CS000009

Cabinet Assembly

Components

56 items

1. #S,LOCK PIN MFR # 2002759005
2. #SPACER MFR # 2002266019
3. #SCREWS RM10 0 MFR # 7241328017
4. #PIN,LOCKING USE 2001281019 MFR # 2001281001 Superseded: see description
5. #PIN,RETAINING MFR # 2001281019
6. #APPLIANCE COMPONENTS RV; Plate Hinge Rh MFR # 2002536007
7. #HOLDER MFR # PIN, LOCKING USE 2001281019
8. #Refrigerator Door Hinge Pin; Use With Dometic Refrigerator Model RM66; Fits Upper Hinge 2000544-00/3 MFR # 2000544003 Superseded: see description
9. #Refrigerator Thermostat Cover Plate; Replacement For Dometic RM2452/ RGE400/ RM36/ RM360/ RM2510/ RM2552/ RM2332/ RM2353/ RM2452 Model Refrigerator; Clamp MFR # 2890050004
10. #SCREW USE 7295344407 MFR # 7295344118 Superseded: see description
11. #APPLIANCE COMPONENTS RV; Screw MFR # 7295344407
12. #RADIATOR FLANGE, RH MFR # 2002299002
13. #RADIATOR FLANGE MFR # 2002298004
14. #Refrigerator Door Panel Retainer; Use With Dometic Refrigerator Model RM361 MFR # 2007336007 Superseded: see description
15. #SCREW B10X16 Z. PL. MFR # 140245010
16. #SNAP SPRING MFR # 2000547006
17. #SCREW MFR # 7295281658
18. #WARNING LABEL MFR # 2007048008
19. #CABINET BASE MFR # 2002533087
20. #TRAY,ICE W/RELEASER MFR # 2002337000
21. #STOP,SHELF MFR # 2002635007
22. #Dometic RM2652 Refrigerator Door Panel Assembly MFR # 2002236004
23. #Dometic RM2652 RM2652RB Refrigerator Door Bin Shelf MFR # 2002236012
24. #Appliance Components RV; Spring, Freezer Door LH MFR # 2002237002
25. #Spring, Freezer Door RH MFR # 2002237010
26. #Refrigerator Door Hinge Pin; Replacement For Dometic RM2451/ RM2301/ RM2352/ RM2410/ RM2501/ RM2551/ RM2354/ RM2510/ RM2552 Series Refrigerators MFR # 2002238000
27. #S,LID,FRZ,RM2410,RM2350 MFR # 2002239271
28. #SHUTTER,BROWN; USE 2002239271 MFR # 2002239164 Superseded: see description
29. #DOOR,FREEZER USE 2002239271 BROWN MFR # 2002239032 Superseded: see description
30. #APPLIANCE COMPONENTS RV; Screw MFR # 7295286657
31. #SCREW USE 7295286657 MFR # 7295285659 Superseded: see description
32. #Refrigerator Door Hinge Plate; Replacement For Dometic RM66E/ RM67/ RM66D/ RM2352/ RM663/ RM66F/ RM2501/RM2301/ RM2354/ RM2351 Series Refrigerators; Polar White MFR # 2002244008
33. #S,GASKET,EVAP FLAP,6"*17",WHT MFR # 2000917019
34. #SHELF MFR # 2002651137
35. #FLAP MFR # 2001659016
36. #PLUG MFR # 2007097005
37. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
38. #SHELF,LOWER USE 2002652226 MFR # 2002652002 Superseded: see description
39. #APPLIANCE COMPONENTS RV; Pin Hinge Lower MFR # 2002367007
40. #PLATE,PROTECTION MFR # 2002625016
41. #TRAY,DRIP WHITE MFR # 2000919056
42. #WASHER,LOCK F/UPPER HINGE MFR # 7352160019
43. #APPLIANCE COMPONENTS RV; Plug Face Beige MFR # 2002352017
44. #INSTRUCTION PLATE MFR # 2007297001
45. #INSTRUCTION PLATE MFR # 2007296003
46. #KNOB,PIEZO MFR # 2002669006
47. #APPLIANCE COMPONENTS RV; Knob Pull Brown MFR # 2002426027
48. #KNOB,T-STAT GAS 2002423032 BROWN MFR # 2002423024
49. #Refrigerator Thermostat Control Knob; Replacement For Dometic RM47D/ RM66F/ RM66/ RM66D/ RM67D/ RM36E/ RM100/ RM76D/ RM66E/ RM67/ RM46E Series Refrigerators MFR # 2002423032
50. #S,KNOB 3-W SWITCH,BRN/BLK MFR # 2002423057
51. #Refrigerator Control Knob; Use With Dometic Refrigerator Model RM66E; Power Selector Knob MFR # 2002423040 Superseded: see description
52. #PANEL,CONTROL YELLOW MFR # 2002664056
53. #LOCK NUT SNJ 1915 MFR # 7337813062
54. #LEVEL USE 2007645019 MFR # 2007645001 Superseded: see description
55. #APPLIANCE COMPONENTS RV; Level Spirit MFR # 2007645019
56. #APPLIANCE COMPONENTS RV; Bar L Approx 14.5" Rm360 MFR # 2007337021

Refrigerator Replacement

Components

12 items

1. #RECON REFER 4.2 CU FT 3 WAY MFR # 6053R
2. #RECON REFER 4.3 CU FT 2 WAY, 43 1/4H X 23 1/2W X 24D. MFR # 6052R
3. #REFER, 4.3CUFT USE N510URN; 43 1/4H X 23 1/2W X 24D 2-WAY. MFR # 6052N Superseded: see description
4. #REFER 3.1 CU FT USE 72-4880; 2 WAY 30 7/8H X 23 1/2W X 24D. MFR # 442N Superseded: see description
5. #PANEL, WOODGRAIN, USE N510G F/N510UR MFR # N510URG Superseded: see description
6. #Refrigerator; Single Compartment Refrigerator With Freezer; Flange Mount; Right Hand Hinge; 2.7 Cubic Foot; 20-1/2 Inch Width x 21-3/8 Inch Depth x 29-3/4 Inch Height; 1.5 Amps At 120 Volt AC/ 12 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; With Ice Maker MFR # N3003R
7. #Refrigerator; Dual Compartment Refrigerator With Freezer; Flange Mount; Right Hand Hinge; 5.5 Cubic Foot; 23-11/16 Inch Width x 24 Inch Depth x 42-5/8 Inch Height; 2 Amps At 120 Volt AC/ 14.2 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LED Temperature Control Panel; Beige Trim; With Shelving And Door Bins; Door Panels Sold Separately MFR # N5103UR
8. #RECON REFER 3.1CUFT.2WAY; 30 7/8H X 23 1/2W X 24D. MFR # 442R
9. #REFER, 5.5 CUFT. USE N5103UR 42 5/8H X 23 11/16W X 24D MFR # N5103U Superseded: see description
10. #RECON REFER 3.1 CU FT 3 WAY, 30 7/8W X 23 1/2H X 24D MFR # 443R
11. #Refrigerator; Dual Compartment Refrigerator With Freezer; Flange Mount; Right Hand Hinge; 5.5 Cubic Foot; 23-11/16 Inch Width x 24 Inch Depth x 42-5/8 Inch Height; 2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LED Temperature Control Panel; Beige Trim; With Shelving And Door Bins; Door Panels Sold Separately MFR # N510U
12. #REFER, 5.5 CU FT 2WAY USE N510U 42 5/8H X 23 11/16W X 24D MFR # N510URN Superseded: see description

Door Assembly

Components

115 items

1. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
2. #TURN PROTECTION MFR # 2002766000
3. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
4. #SCREW USE 7295285402 MFR # 7295285014 Superseded: see description
5. #SCREW MFR # 7298285402
6. #COVER MFR # 2007170000
7. #SEALING RING MFR # 2002224018
8. #WASHER RM36E MFR # 7344974014
9. #APPLIANCE COMPONENTS RV; Clamp MFR # 2002438006
10. #SPRING WASHER, FBB 5.1, Z. PL. MFR # 7351146019
11. #SCREW RXS B6X5 MFR # 7295275015
12. #TAB CONNECTOR, STRAIGHT MFR # 7603857009
13. #BLOCK, TERMINAL RM36 - RM100 MFR # 581557709
14. #SCREW, KCS 5.5X5, Z. PL. MFR # 7232250311
15. #FLUE CHANNEL MFR # 2007165000
16. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
17. #APPLIANCE COMPONENTS RV; THERMOSTAT MFR # 2930758012
18. #T-STAT, ELECTRIC REPLACES: IS A USE # F/C302C, 2890032028, 2930758012, 50464, 671054120, 671401147, 172821027, C302B. FOR TRAV'LER MDLS 301-40 & 301-90 USE C... MFR # K50P1291 Superseded: see description
19. #Refrigerator Thermostat Control Knob; Replacement For Dometic RM47D/ RM66F/ RM66/ RM66D/ RM67D/ RM36E/ RM100/ RM76D/ RM66E/ RM67/ RM46E Series Refrigerators MFR # 2002423032
20. #T-STAT USE K50P1291 MFR # 2890032002 Superseded: see description
21. #BRACKET T-STAT MFR # 2890034008
22. #SCREW #17 MFR # 7241289011
23. #CABLE F/T-STAT MFR # 173193020
24. #APPLIANCE COMPONENTS RV; Cover W/Screw MFR # 581565728
25. #TAB CONNECTOR, ANGLE MFR # 7604855002
26. #BOTTOM FOR BURNER PROTECTION MFR # 2007169002
27. #SCREWS RM10 0 MFR # 7241328017
28. #CONDUCTOR, LIGHT MFR # 2002222004
29. #IGNITER,PIEZO **ALT 72-8227 14-1/2" LOT440 MFR # 2002609028
30. #PIEZO LIGHTER MFR # 440
31. #Igniter; Use On Dometic Refrigerators; Piezo Spark MFR # 2002609036MC Superseded: see description
32. #LIGHTER,PIEZO ALT 2002609036MC MFR # 2002609036
33. #ELECTRODE,SQUARE USE 2002436000MC MFR # 2002436000 Superseded: see description
34. #ELECTRODE USE 2002436000 MFR # 2002436002 Superseded: see description
35. #Igniter Electrode; Use On Dometic Old M And RM Model Refrigerators; With Mounting Screw/ Gasket/ 2 Probes MFR # 2002436000MC Superseded: see description
36. #APPLIANCE COMPONENTS RV; Packing MFR # 2002304000
37. #APPLIANCE COMPONENTS RV; Holder Igniter MFR # 2002305007
38. #APPLIANCE COMPONENTS RV; Shaft 15" MFR # 2002300008
39. #RING,SEALING MFR # 2002224000
40. #WASHER 6.0, Z.PL. MFR # 7344909012
41. #APPLIANCE COMPONENTS RV; Rod Pull 4-6 Cubic Feet MFR # 2002226005
42. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
43. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
44. #SCREW USE 7295279405 MFR # 7295279017 Superseded: see description
45. #ELEMENT, HEATING 135w/110V 2WIRE 5/16 X 4 1/2 MFR # CS000009
46. #ELEMENT,HEATING, ALT 48-9502 135w/110V 2WIRE 5/16 X 4 1/2 MFR # 173718016
47. #HEATING ELEMENT-12VDC/135W MFR # 173723016
48. #BURNER PROTECTION MFR # 2007166008
49. #APPLIANCE COMPONENTS RV; Orifice #39Lp MFR # 2890039155
50. #ORIFICE, #39 USE 2890039155 MFR # 2002660153 Superseded: see description
51. #ORIFICE, #43 MFR # 2002660161
52. #PROTECTION PLATE MFR # 2002445001
53. #Refrigerator Gas Valve; Replacement For Dometic RM36E/ RM46D/ RM66D/ RM77D/ RM46E/ RM47/ RM60/ RM100/ RM36A/ RM67/ RM75/ RM76/ RM45A/ RM60A Series Refrigerators; Gas Control Valve MFR # 2002227003
54. #SPRING WASHER MFR # 7351136010
55. #APPLIANCE COMPONENTS RV; Glass Sight 2002220-00/8 MFR # 2002220008
56. #SWITCH 2 WAY RM46-66 MFR # 2002670020
57. #APPLIANCE COMPONENTS RV; Control Switch 2 Way MFR # 2002670012
58. #APPLIANCE COMPONENTS RV; Switch 110V MFR # 172168007
59. #COVER MFR # 173101007
60. #SPRING USE 2007176007 MFR # 2002665004 Superseded: see description
61. #SWITCH ASM 3 WAY MFR # 2007176007
62. #SEALING RING MFR # 7356819115
63. #WASHER MFR # 2002351001
64. #Screw, RXS B6X16, Z.PL. MFR # 7295283019
65. #INSULATION - NLA MFR # 2002442008
66. #VALVE, CUT OFF USE 172807000 MFR # 671059860 Superseded: see description
67. #APPLIANCE COMPONENTS RV; Valve Gas MFR # 172807000
68. #S,VALVE,GAS SHUT OFF,RM2410, MFR # 2007430008
69. #VALVE, GAS USE 2007430008 MFR # 2901885000 Superseded: see description
70. #SHUT OFF VALVE FOR DOMETIC REFRIGERATORS MFR # 2007430008MC
71. #BAFFLE,FLUE MFR # 2007172006
72. #BRACKET MFR # 2002469001
73. #APPLIANCE COMPONENTS RV; Filter Gas MFR # 172810004
74. #T-STAT, GAS USE 2890031038 MFR # 2890031020 Superseded: see description
75. #T-STAT, GAS USE V35P0111013 MFR # 2890031038 Superseded: see description
76. #T-STAT, GAS MFR # V35P0111013
77. #APPLIANCE COMPONENTS RV; Screw Bypass Alt 1728190 MFR # 172819021
78. #Thermostat Bypass Screw; Replaces #17 Bypass Screw On Ranco Gas Thermostat MFR # 172819021MC
79. #APPLIANCE COMPONENTS RV; Spring MFR # 2002381008
80. #QUICK CHECK MFR # 423
81. #Thermocouple; 27 Inch Length; With 2 Metric Thermocouple Nuts SUGGESTED ALTERNATE: THIS PART IS NOT AN OE ORIGINAL BUT CAN BE USED AS AN ALTERNATE FOR P#50484. SINCE THIS IS NOT AN ORIGINAL PART, IT... MFR # 50484MC
82. #T-COUPLE, 24" (10+) USE 47-1302 IS A USE # FOR 169372002,169372000, 50484 WHEN USING TO REPLACE FRIGIKING TCOUPLE PART # 3800503 YOU MUST ALSO ORDER: 1 OF PART # SPLITFITTING AND... MFR # 290031 Superseded: see description
83. #T-COUPLE, 18" ALT 72-8143 CAN USE 50484MC UNTIL GONE. IF THEY NEED THE NUT (169386000) IF INSTALLING THIS T-COUPLE IN A FRIDGIKING REFER, YOU MUST ALSO ORDER THE SPLIT FITT... MFR # 169372000 Superseded: see description
84. #THERMOCOUPLE MFR # 169372000MC
85. #T-COUPLE, 24" USE 72-0146 (DUPLICATE PART#) REPLACES: IS A USE # FOR 1639372002,330300,41511512,3800503SPECS: IF YOU ARE USING THIS T-COUPLE FOR INSTAMATIC OR COLD STAR: THIS IS THE JU... MFR # 169372002 Superseded: see description
86. #THERMOCOUPLE-JUNKERS 29" USE 47-1302 MFR # 454 Superseded: see description
87. #THERMOCOUPLE, 18" MFR # 169372002MC
88. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Gas Valves 0170755003/ 2000999009/ 2922006016; Use On Dometic Refrigerators Including RM2553/ RM2453/ RM2330 And RM4601; Safety Gas Valve MFR # 2931656017MC Superseded: see description
89. #Refrigerator Gas Valve; Use On Dometic Refrigerators; Safety Gas Valve MFR # 170755003MC Superseded: see description
90. #VALVE, SAFETY USE 293165 MFR # 170755003 Superseded: see description
91. #VALVE, SAFETY MFR # 293165
92. #VALVE, SAFETY CV100041 NATURAL PIPE THREADING MFR # 8332921160100
93. #MAGNET,SAFETY USE 2931656017 MFR # 2000999009 Superseded: see description
94. #S,VALVE,THERMO ELEC,4601,S410G MFR # 2931656017
95. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM1272/ RM1282 Model Refrigerator; M4 x 6 Pan MFR # 7241285019
96. #Nut; Use To Mount 0169372002 Thermocouple On Older RV Refrigerators; 3/8 Inch Female Thread SUGGESTED ALTERNATE F/DOMETIC: THIS PART IS NOT A DOMETIC ORIGINAL BUT CAN BE USED AS AN ALTERNATE TO THE DOMETIC P#169386000. MFR # 169386000MC Superseded: see description
97. #NUT, T-COUPLE ALT 45-3744 MFR # 169386000
98. #END PIECE MFR # 2007094002
99. #SPACER SLEEVE MFR # 173344011
100. #SPACER NUT MFR # 170827000
101. #TUBE, BURNER MFR # 2890010008
102. #APPLIANCE COMPONENTS RV; Base Burner; *** Nla *** MFR # 2890009000
103. #APPLIANCE COMPONENTS RV; NUT LOCK MFR # 272562000
104. #NUT, LOCK USE 272562000 MFR # 173366006 Superseded: see description
105. #HOUSING, PRESSURE TEST - NLA MFR # 2002470009
106. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
107. #APPLIANCE COMPONENTS RV; Ferrule Gas Line Use 2001 MFR # 173213000 Superseded: see description
108. #APPLIANCE COMPONENTS RV; Line Gas Inlet MFR # 2890024009
109. #NUT, UNION USE 2902553003 MFR # 173215005 Superseded: see description
110. #NUT, UNION FEMALE MFR # 2902553003
111. #REMAN COOLING UNIT RM46E (UPS) MFR # 9283101006R
112. #COOLING UNIT RM46E 319A UPS MFR # 9283191006N
113. #REMAN COOLING UNIT, Use 9283101006R MFR # 9283191006R Superseded: see description
114. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
115. #BRACKET,BURNER MFR # 2002493001

Switch Control

Components

17 items

1. #BLOCK, TERMINAL USE 2930463001 MFR # 7627203560 Superseded: see description
2. #APPLIANCE COMPONENTS RV; Block Terminal 4 Large MFR # 2930463001
3. #Screw, RXS B6X25, Z. Pl. MFR # 7295287010
4. #PLATE USE 2007176007 MFR # 2002589006 Superseded: see description
5. #SWITCH ASM 3 WAY MFR # 2007176007
6. #SWITCH 3 WAY MFR # 2007176015
7. #WASHER MFR # 7341178601
8. #SWITCH, TOGGLE USE 2007176007 MFR # 2007490002 Superseded: see description
9. #SPRING USE 2007176007 MFR # 2002665004 Superseded: see description
10. #SEALING RING MFR # 7356819115
11. #SCREW USE 7295279405 MFR # 7295279017 Superseded: see description
12. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
13. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
14. #PROTECTION COVER MFR # 2002698013
15. #CABLE USE 2007176007 F/ T -STAT MFR # 2002705008 Superseded: see description
16. #FUSE CABLE USE 2007176007 MFR # 2007173004 Superseded: see description
17. #APPLIANCE COMPONENTS RV; Fuse 16 Amp MFR # 2002578009
