Dometic RM67 Parts Diagram · Replacement Refrigerator

Refrigerator · 6 assemblies · 6 diagram sheets · 243 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RM67 RV refrigerator: 6 assemblies (Replacement Refrigerator, Door Assembly RM67D, Cabinet Assembly, Switch Control, Door Assembly and more) and 243 manufacturer part numbers. 61 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Replacement Refrigerator

Components

12 items

1. #REFER, 4.3 CU FT USE N5103U; 3 WAY 43 1/4H X 23 1/2W X 24D. MFR # 6053N Superseded: see description
2. #REFER,5.5CU FT USE N510URN 2-WAY MFR # N500N Superseded: see description
3. #REFER, 5.5 CUFT. USE N5103UR 42 5/8H X 23 11/16W X 24D MFR # N5103U Superseded: see description
4. #REFER, 5 CU FT 2 WAY 40 5/16"H X 21 13/16"W X 24" MFR # RM25102N
5. #Refrigerator; Dual Compartment Refrigerator With Freezer; Flange Mount; Left Hand Hinge; 5.5 Cubic Foot; 23-11/16 Inch Width x 24 Inch Depth x 42-5/8 Inch Height; 2 Amps At 120 Volt AC/ 14.2 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LED Temperature Control Panel; Beige Trim; With Shelving And Door Bins; Door Panels Sold Separately MFR # N5103UL
6. #Refrigerator; Dual Compartment Refrigerator With Freezer; Flange Mount; Right Hand Hinge; 5.5 Cubic Foot; 23-11/16 Inch Width x 24 Inch Depth x 42-5/8 Inch Height; 2 Amps At 120 Volt AC/ 14.2 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; LED Temperature Control Panel; Beige Trim; With Shelving And Door Bins; Door Panels Sold Separately MFR # N5103UR
7. #Refrigerator Door Panel; Fits Norcold Refrigerator N510 Series; Woodgrain MFR # N510G
8. #REFER, 5.5 CUFT USE N5103URN 3-WAY MFR # N5003N Superseded: see description
9. #Refrigerator; Dual Compartment Refrigerator With Freezer; Flange Mount; Right Hand Hinge; 5.5 Cubic Foot; 23-11/16 Inch Width x 24 Inch Depth x 42-5/8 Inch Height; 2 Amps At 120 Volt AC; 2-Way Alternating Current/ LP Gas; Without Ice Maker; LED Temperature Control Panel; Beige Trim; With Shelving And Door Bins; Door Panels Sold Separately MFR # N510UR
10. #REFER, 5.5 CU FT 2WAY USE N510U 42 5/8H X 23 11/16W X 24D MFR # N510URN Superseded: see description
11. #PANEL, WOODGRAIN, USE N510G F/N510UR MFR # N510URG Superseded: see description
12. #REFER, 4.3CUFT USE N510URN; 43 1/4H X 23 1/2W X 24D 2-WAY. MFR # 6052N Superseded: see description

Door Assembly RM67D

Components

24 items

1. #DOOR, WITHOUT COMPARTMENTS MFR # 2002773055
2. #APPLIANCE COMPONENTS RV; Bushing Door Hinge Lower MFR # 2002619001
3. #GASKET MFR # 2002626063
4. #STRIP, DECOR; Use 2002675110 MFR # 2002675011 Superseded: see description
5. #STRIP, DECORATION MFR # 2002675110
6. #NAME PLATE "ROYAL DOMETIC" MFR # 2002676019
7. #FASTENING PLATE MFR # 2002777004
8. #Refrigerator Door Bin; Replacement For Dometic RM47D/ RM75/ RM760/ RM763/ RM36A/ M28C Model Refrigerator; Journal Axle Only MFR # 2001170014
9. #SHAFT USE 2001170014 MFR # 2001170006 Superseded: see description
10. #APPLIANCE COMPONENTS RV; Door Dairy Brown MFR # 2002258149
11. #DOOR, DAIRY USE 2002258149 MFR # 2002258073 Superseded: see description
12. #NAME PLATE DOMETIC MFR # 2002256002
13. #SHELF USE 2000571220 MFR # 2000571105 Superseded: see description
14. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description
15. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
16. #APPLIANCE COMPONENTS RV; Holder Btlwhite MFR # 2002794168
17. #HOLDER, BOTTLE USE 2002794168 BROWN MFR # 2002794010 Superseded: see description
18. #Refrigerator Shelf Support; Replacement For Dometic RM2620/ RM2353/ RM2354 Refrigerators; 8 Inch; White MFR # 2930715061
19. #HOLDER, BOTTLE USE 2002794168 MFR # 2002794002 Superseded: see description
20. #Refrigerator Shelf Support; Replacement For Dometic RM2354/ RM2353/ RM2510 Refrigerators; 7 Inch; White MFR # 2930715053
21. #SHELF,DOOR USE 2002261242 BROWN/BLACK MFR # 2002261143 Superseded: see description
22. #SHELF, DOOR USE 2002261143 MFR # 2002261101 Superseded: see description
23. #Refrigerator Shelf; Replacement For Dometic RM2300/ RM2500/ RM661/ RM66E/ RM66F/ RM2353/ RM2352/ RM2510/ RM2351/ RB2405/ RM77D/ RM2333 Series Refrigerators MFR # 2002261242
24. #LABEL, INSTRUCTION MFR # 2002356000

Cabinet Assembly

Components

69 items

1. #APPLIANCE COMPONENTS RV; Plate Hinge MFR # 2002349005
2. #SPACER MFR # 2002266019
3. #SCREWS RM10 0 MFR # 7241328017
4. #PIN,LOCKING USE 2001281019 MFR # 2001281001 Superseded: see description
5. #PIN,RETAINING MFR # 2001281019
6. #APPLIANCE COMPONENTS RV; Plate Hinge Rh MFR # 2002350003
7. #Refrigerator Door Hinge Pin; Use With Dometic Refrigerator Model RM66; Fits Upper Hinge 2000544-00/3 MFR # 2000544003 Superseded: see description
8. #Refrigerator Thermostat Cover Plate; Replacement For Dometic RM2452/ RGE400/ RM36/ RM360/ RM2510/ RM2552/ RM2332/ RM2353/ RM2452 Model Refrigerator; Clamp MFR # 2890050004
9. #APPLIANCE COMPONENTS RV; Screw MFR # 7295344407
10. #RADIATOR FLANGE, RH, HGT 150MM (C.5-7/8") MFR # 2002756001
11. #RADIATOR FLANGE, RH MFR # 2002299002
12. #SCREW, RXS B10 X 16, STAINLESS (EAR. VERSION) MFR # 7295412402
13. #SNAP SPRING MFR # 2000547006
14. #SCREW MFR # 7295281658
15. #WARNING LABEL MFR # 2007048008
16. #CABINET BASE MFR # 2002533087
17. #APPLIANCE COMPONENTS RV; Retainer MFR # 2002624001
18. #TRAY,ICE W/RELEASER MFR # 2002337000
19. #STOP,SHELF MFR # 2002635007
20. #Dometic RM2652 Refrigerator Door Panel Assembly MFR # 2002236004
21. #Appliance Components RV; Spring, Freezer Door LH MFR # 2002237002
22. #Spring, Freezer Door RH MFR # 2002237010
23. #Refrigerator Door Hinge Pin; Replacement For Dometic RM2451/ RM2301/ RM2352/ RM2410/ RM2501/ RM2551/ RM2354/ RM2510/ RM2552 Series Refrigerators MFR # 2002238000
24. #SHUTTER,BROWN; USE 2002239271 MFR # 2002239164 Superseded: see description
25. #DOOR,FREEZER USE 2002239271 BROWN MFR # 2002239032 Superseded: see description
26. #S,LID,FRZ,RM2410,RM2350 MFR # 2002239271
27. #DOOR, FREEZER USE 45-5219 WHITE MFR # 2002239008 Superseded: see description
28. #DOOR,FREEZER WHITE MFR # 2002239263
29. #SCREW USE 7295286657 MFR # 7295285659 Superseded: see description
30. #APPLIANCE COMPONENTS RV; Screw MFR # 7295286657
31. #Refrigerator Door Hinge Plate; Replacement For Dometic RM66E/ RM67/ RM66D/ RM2352/ RM663/ RM66F/ RM2501/RM2301/ RM2354/ RM2351 Series Refrigerators; Polar White MFR # 2002244008
32. #S,GASKET,EVAP FLAP,6"*17",WHT MFR # 2000917019
33. #SHELF MFR # 2002651137
34. #WIRE SHELF RM4-6'S MFR # 2002651103
35. #FLAP MFR # 2001659016
36. #N/A DECORATION STRIP MFR # 2002479026
37. #SHELF,LOWER USE 2002652226 MFR # 2002652002 Superseded: see description
38. #APPLIANCE COMPONENTS RV; Shelf Wire 12"W X 17 7/ MFR # 2002652226
39. #APPLIANCE COMPONENTS RV; Level Spirit MFR # 2007645019
40. #LEVEL USE 2007645019 MFR # 2007645001 Superseded: see description
41. #APPLIANCE COMPONENTS RV; Pin Hinge Lower MFR # 2002367007
42. #PLATE,PROTECTION MFR # 2002625016
43. #TRAY,DRIP WHITE MFR # 2000919056
44. #WASHER,LOCK F/UPPER HINGE MFR # 7352160019
45. #PLUG, FACE WHITE MFR # 2002352009
46. #WASHER, 5.4, STAINLESS MFR # 7344890400
47. #INSTRUCTION PLATE MFR # 2007008010
48. #KNOB,LIGHTER YELLOW MFR # 2002724009
49. #KNOB,PIEZO MFR # 2002669006
50. #APPLIANCE COMPONENTS RV; Knob Pull Off MFR # 3002168031
51. #KNOB USE 3002168031 MFR # 2002722003 Superseded: see description
52. #Refrigerator Thermostat Control Knob; Replacement For Dometic RM47D/ RM66F/ RM66/ RM66D/ RM67D/ RM36E/ RM100/ RM76D/ RM66E/ RM67/ RM46E Series Refrigerators MFR # 2002423032
53. #KNOB,T-STAT GAS USE 2002423024 YELLOW MFR # 2002725022 Superseded: see description
54. #KNOB,T-STAT GAS 2002423032 BROWN MFR # 2002423024
55. #Refrigerator Control Knob; Use With Dometic Refrigerator Model RM66E; Power Selector Knob MFR # 2002423040 Superseded: see description
56. #S,KNOB 3-W SWITCH,BRN/BLK MFR # 2002423057
57. #KNOB, SWITCH *USE 2002423057 3W YEL MFR # 2002725055 Superseded: see description
58. #KNOB,ELECTRIC USE 2002423032 T-STAT YELLOW MFR # 2002725030 Superseded: see description
59. #PANEL,CONTROL YELLOW MFR # 2002664007
60. #PANEL,CONTROL YELLOW MFR # 2002664056
61. #LOCK NUT SNJ 1915 MFR # 7337813062
62. #CRISPER MFR # 2000577011
63. #APPLIANCE COMPONENTS RV; Crisper RM76 - 77'S 7-3/4 MFR # 2000578043
64. #LID, CRISPER M70 RM7 MFR # 2000579009
65. #FITTING LAMP COMPLETE MFR # 2002751002
66. #LAMP,6 VOLT MFR # 140315003
67. #LAMP,GLASS MFR # 2002748008
68. #APPLIANCE COMPONENTS RV; Bracket MFR # 2002749006
69. #FRONT FACE, BEIGE MFR # 2002346100

Switch Control

Components

17 items

1. #THERMOSTAT CABLE MFR # 2002591036
2. #BLOCK, TERMINAL USE 2930463001 MFR # 7627203560 Superseded: see description
3. #APPLIANCE COMPONENTS RV; Block Terminal 4 Large MFR # 2930463001
4. #Screw, RXS B6X25, Z. Pl. MFR # 7295287010
5. #SWITCH ASM 3 WAY MFR # 2007176007
6. #PLATE USE 2007176007 MFR # 2002589006 Superseded: see description
7. #SWITCH, CONTROL 3-WAY MFR # 2002681027
8. #SWITCH MFR # 2002697007
9. #SWITCH, SELECTOR MFR # 2007034024
10. #SPRING USE 2007176007 MFR # 2002665004 Superseded: see description
11. #SEALING RING MFR # 7356819115
12. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
13. #SCREW USE 7295279405 MFR # 7295279017 Superseded: see description
14. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
15. #PROTECTION COVER MFR # 2002698005
16. #CABLE W/FUSE RM66 MFR # 2002702005
17. #APPLIANCE COMPONENTS RV; Fuse 16 Amp MFR # 2002578009

Door Assembly

Components

24 items

1. #APPLIANCE COMPONENTS RV; Gasket Doorscrew-In 21 1/ MFR # 2001111067
2. #DOOR LINER MFR # 2002379044
3. #SCREW MFR # 7295279652
4. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
5. #DOOR FRAME, ANODIZED ALM., GOLD MFR # 2002342075
6. #APPLIANCE COMPONENTS RV; Bushing Door Hinge Lower MFR # 2002619001
7. #DOOR FRAME, COMPLETE ANODIZED ALUM. MFR # 2002343107
8. #NAME PLATE (GAS/ELECTRIC DOMETIC) MFR # 2002708002
9. #DOOR PLATE, INSULATED MFR # 2002250005
10. #DOOR FRAME, LOWER ANODIZED ALM., GOLD MFR # 2002340079
11. #APPLIANCE COMPONENTS RV; Holder Bottle Wht MFR # 2001730007
12. #Refrigerator Shelf; Replacement For Dometic RM2300/ RM2500/ RM661/ RM66E/ RM66F/ RM2353/ RM2352/ RM2510/ RM2351/ RB2405/ RM77D/ RM2333 Series Refrigerators MFR # 2002261242
13. #SHELF,DOOR USE 2002261242 BROWN/BLACK MFR # 2002261143 Superseded: see description
14. #SHELF, DOOR USE 2002261143 MFR # 2002261101 Superseded: see description
15. #REINFORCING STRIP VERTICAL RM45A MFR # 2001585047
16. #REINFORCING STRIP HORIZONTAL RM45A MFR # 2001586029
17. #LABEL, INSTRUCTION MFR # 2002356000
18. #APPLIANCE COMPONENTS RV; Door Dairy Brown MFR # 2002258149
19. #DOOR, DAIRY USE 2002258149 MFR # 2002258073 Superseded: see description
20. #Refrigerator Door Bin; Replacement For Dometic RM47D/ RM75/ RM760/ RM763/ RM36A/ M28C Model Refrigerator; Journal Axle Only MFR # 2001170014
21. #SHAFT USE 2001170014 MFR # 2001170006 Superseded: see description
22. #S,SHELF,DR,WHT,2410/2510/2620 MFR # 2000571253
23. #SHELF USE 2000571220 MFR # 2000571105 Superseded: see description
24. #SHELF, UPPER USE 2000571253 RM2410 FOR DOOR SHELF RETAINER USE 2000571170 DOOR TAKES 3 SHELVES. DEALER DOES NOT HAVE TO ORDER ALL THREE SHELVES. THE DOOR ITSELF JUST TAKES 3 OF T... MFR # 2000571220 Superseded: see description

Gas & Electric Parts

Components

119 items

1. #Refrigerator Grommet; Replacement For Dometic DM2652/ DM2662/ DM2663/ DM2852/ DM2862/ DM3862; Charging Plug MFR # 2002301006
2. #TURN PROTECTION MFR # 2002766000
3. #SCREW USE 7295285402 MFR # 7295285014 Superseded: see description
4. #Refrigerator Support Rail Screw; Replacement For Dometic RM3662/ RM2652/ RM2607 Refrigerator Models; Terminal Block Screw; RXS; B6 x 19; Stainless Steel MFR # 7295285402
5. #SCREW MFR # 7298285402
6. #SEALING RING MFR # 2002224018
7. #WASHER RM36E MFR # 7344974014
8. #APPLIANCE COMPONENTS RV; Clamp MFR # 2002438006
9. #SPRING WASHER, FBB 5.1, Z. PL. MFR # 7351146019
10. #SCREW RXS B6X5 MFR # 7295275015
11. #TAB CONNECTOR, STRAIGHT MFR # 7603857009
12. #BLOCK, TERMINAL RM36 - RM100 MFR # 581557709
13. #SCREW, KCS 5.5X5, Z. PL. MFR # 7232250311
14. #BOX, FLUE MFR # 2002472005
15. #Refrigerator Power Cord Strain Relief Bushing; Replacement For Dometic RGE400 Refrigerators MFR # 561014010
16. #T-STAT,ELECTRIC USE K50P1291 MFR # 2890032028 Superseded: see description
17. #T-STAT, ELECTRIC REPLACES: IS A USE # F/C302C, 2890032028, 2930758012, 50464, 671054120, 671401147, 172821027, C302B. FOR TRAV'LER MDLS 301-40 & 301-90 USE C... MFR # K50P1291 Superseded: see description
18. #APPLIANCE COMPONENTS RV; THERMOSTAT MFR # 2930758012
19. #BRACKET T-STAT MFR # 2890034008
20. #SCREW #17 MFR # 7241289011
21. #CABLE F/T-STAT MFR # 173193020
22. #APPLIANCE COMPONENTS RV; Cover W/Screw MFR # 581565728
23. #TAB CONNECTOR, ANGLE MFR # 7604855002
24. #CONNECTION BLOCK MFR # 2400297004
25. #SCREWS RM10 0 MFR # 7241328017
26. #CONDUCTOR, LIGHT MFR # 2002222004
27. #PIEZO LIGHTER MFR # 440
28. #IGNITER,PIEZO **ALT 72-8227 14-1/2" LOT440 MFR # 2002609028
29. #LIGHTER,PIEZO ALT 2002609036MC MFR # 2002609036
30. #Igniter; Use On Dometic Refrigerators; Piezo Spark MFR # 2002609036MC Superseded: see description
31. #ELECTRODE USE 2002436000 MFR # 2002436002 Superseded: see description
32. #Igniter Electrode; Use On Dometic Old M And RM Model Refrigerators; With Mounting Screw/ Gasket/ 2 Probes MFR # 2002436000MC Superseded: see description
33. #ELECTRODE,SQUARE USE 2002436000MC MFR # 2002436000 Superseded: see description
34. #APPLIANCE COMPONENTS RV; Packing MFR # 2002304000
35. #APPLIANCE COMPONENTS RV; Holder Igniter MFR # 2002305007
36. #APPLIANCE COMPONENTS RV; Shaft 15" MFR # 2002300008
37. #RING,SEALING MFR # 2002224000
38. #WASHER RM66 MFR # 7344908012
39. #APPLIANCE COMPONENTS RV; Rod Pull 4-6 Cubic Feet MFR # 2002226005
40. #SCREW USE 7295279405 MFR # 7295279017 Superseded: see description
41. #Screw; Use 7295279512 MFR # 7295279405 Superseded: see description
42. #APPLIANCE COMPONENTS RV; Screw Rxs B6 X 10 MFR # 7295279512
43. #Element, Heating 135W 110/12V 3WR 11/16 X 4 3/4 MFR # CS000034
44. #ELEMENT, HEATING 150W/110V 2WIRE 11/16 X 4 3/4; SUGGESTED ALTERNATE FOR DOMETIC: NOT A DOMETIC ORIGINAL MFR # CS000017
45. #Refrigerator Cooling Unit Heater Element; Use With Dometic Refrigerator Model RM4; 110/12 Volt; 135 Watts MFR # 173708009MC Superseded: see description
46. #APPLIANCE COMPONENTS RV; Element Heating 150W/110V; WHEN INVENTORY IS DEPLETED, ORDER ALTERNATE P# CS000017 MFR # 173713017
47. #APPLIANCE COMPONENTS RV; Element Heating Alts Ava MFR # 173708009
48. #BUSHING MFR # 149585010
49. #Screw, RXS B6X25, Z. Pl. MFR # 7295287010
50. #PROTECTION PLATE MFR # 2002445001
51. #Refrigerator Gas Valve; Replacement For Dometic RM36E/ RM46D/ RM66D/ RM77D/ RM46E/ RM47/ RM60/ RM100/ RM36A/ RM67/ RM75/ RM76/ RM45A/ RM60A Series Refrigerators; Gas Control Valve MFR # 2002227003
52. #SPRING WASHER MFR # 7351136010
53. #APPLIANCE COMPONENTS RV; Glass Sight 2002220-00/8 MFR # 2002220008
54. #SWITCH 2 WAY RM46-66 MFR # 2002670020
55. #SWITCH, CONTROL 3-WAY MFR # 2002681027
56. #APPLIANCE COMPONENTS RV; Switch 110V MFR # 172168007
57. #COVER MFR # 173101007
58. #SPRING USE 2007176007 MFR # 2002665004 Superseded: see description
59. #SWITCH ASM 3 WAY MFR # 2007176007
60. #SEALING RING MFR # 7356819115
61. #WASHER MFR # 2002351001
62. #Screw, RXS B6X16, Z.PL. MFR # 7295283019
63. #INSULATION - NLA MFR # 2002442008
64. #VALVE, CUT OFF USE 172807000 MFR # 671059860 Superseded: see description
65. #APPLIANCE COMPONENTS RV; Valve Gas MFR # 172807000
66. #VALVE, GAS USE 2007430008 MFR # 2901885000 Superseded: see description
67. #SHUT OFF VALVE FOR DOMETIC REFRIGERATORS MFR # 2007430008MC
68. #S,VALVE,GAS SHUT OFF,RM2410, MFR # 2007430008
69. #Baffle, Flue MFR # 2890028000
70. #Screw MFR # 7295340017
71. #APPLIANCE COMPONENTS RV; Filter Gas MFR # 172810004
72. #T-STAT, GAS USE V35P0111013 MFR # 2890031038 Superseded: see description
73. #T-STAT, GAS MFR # V35P0111013
74. #T-STAT, GAS USE 2890031038 MFR # 2890031020 Superseded: see description
75. #APPLIANCE COMPONENTS RV; Screw Bypass Alt 1728190 MFR # 172819021
76. #Thermostat Bypass Screw; Replaces #17 Bypass Screw On Ranco Gas Thermostat MFR # 172819021MC
77. #APPLIANCE COMPONENTS RV; Spring MFR # 2002381008
78. #THERMOCOUPLE, 18" MFR # 169372002MC
79. #THERMOCOUPLE-JUNKERS 29" USE 47-1302 MFR # 454 Superseded: see description
80. #QUICK CHECK MFR # 423
81. #T-COUPLE, 18" ALT 72-8143 CAN USE 50484MC UNTIL GONE. IF THEY NEED THE NUT (169386000) IF INSTALLING THIS T-COUPLE IN A FRIDGIKING REFER, YOU MUST ALSO ORDER THE SPLIT FITT... MFR # 169372000 Superseded: see description
82. #T-COUPLE, 24" (10+) USE 47-1302 IS A USE # FOR 169372002,169372000, 50484 WHEN USING TO REPLACE FRIGIKING TCOUPLE PART # 3800503 YOU MUST ALSO ORDER: 1 OF PART # SPLITFITTING AND... MFR # 290031 Superseded: see description
83. #T-COUPLE, 24" USE 72-0146 (DUPLICATE PART#) REPLACES: IS A USE # FOR 1639372002,330300,41511512,3800503SPECS: IF YOU ARE USING THIS T-COUPLE FOR INSTAMATIC OR COLD STAR: THIS IS THE JU... MFR # 169372002 Superseded: see description
84. #Thermocouple; 27 Inch Length; With 2 Metric Thermocouple Nuts SUGGESTED ALTERNATE: THIS PART IS NOT AN OE ORIGINAL BUT CAN BE USED AS AN ALTERNATE FOR P#50484. SINCE THIS IS NOT AN ORIGINAL PART, IT... MFR # 50484MC
85. #THERMOCOUPLE MFR # 169372000MC
86. #VALVE, SAFETY USE 293165 MFR # 170755003 Superseded: see description
87. #Refrigerator Gas Valve; Replacement For Dometic Refrigerator Gas Valves 0170755003/ 2000999009/ 2922006016; Use On Dometic Refrigerators Including RM2553/ RM2453/ RM2330 And RM4601; Safety Gas Valve MFR # 2931656017MC Superseded: see description
88. #VALVE, SAFETY MFR # 293165
89. #Refrigerator Gas Valve; Use On Dometic Refrigerators; Safety Gas Valve MFR # 170755003MC Superseded: see description
90. #VALVE, SAFETY CV100041 NATURAL PIPE THREADING MFR # 8332921160100
91. #S,VALVE,THERMO ELEC,4601,S410G MFR # 2931656017
92. #MAGNET,SAFETY USE 2931656017 MFR # 2000999009 Superseded: see description
93. #Refrigerator Door Latch Plate Screw; Replacement For Dometic RM1272/ RM1282 Model Refrigerator; M4 x 6 Pan MFR # 7241285019
94. #NUT, T-COUPLE ALT 45-3744 MFR # 169386000
95. #Nut; Use To Mount 0169372002 Thermocouple On Older RV Refrigerators; 3/8 Inch Female Thread SUGGESTED ALTERNATE F/DOMETIC: THIS PART IS NOT A DOMETIC ORIGINAL BUT CAN BE USED AS AN ALTERNATE TO THE DOMETIC P#169386000. MFR # 169386000MC Superseded: see description
96. #LID MFR # 2890053008
97. #SPACER SLEEVE MFR # 173344011
98. #SPACER NUT MFR # 170827000
99. #TUBE, BURNER MFR # 2890010008
100. #APPLIANCE COMPONENTS RV; Base Burner; *** Nla *** MFR # 2890009000
101. #NUT, LOCK USE 272562000 MFR # 173366006 Superseded: see description
102. #APPLIANCE COMPONENTS RV; NUT LOCK MFR # 272562000
103. #CONNECTION PIECE MFR # 2002479009
104. #APPLIANCE COMPONENTS RV; PLUG SCREWS FOR HOUSING MFR # 169380003
105. #APPLIANCE COMPONENTS RV; Ferrule Gas Line Use 2001 MFR # 173213000 Superseded: see description
106. #APPLIANCE COMPONENTS RV; Line Gas Inlet MFR # 2890024009
107. #NUT, UNION FEMALE MFR # 2902553003
108. #NUT, UNION USE 2902553003 MFR # 173215005 Superseded: see description
109. #ORIFICE, #52 MFR # 2002660187
110. #BRACKET MFR # 2002469001
111. #COVER, BURNER MFR # 2002476014
112. #COOLING UNIT MFR # 9283514009
113. #REMAN COOLING UNITS RM67 R&R (UPS) MFR # 9283514009R
114. #COOLING UNIT FILLING VESSEL COVER KIT, BLK MFR # 1732280084
115. #CORD, POWER USE 2002699110 MFR # 2002699037 Superseded: see description
116. #PLUG W/CORD USE 2002699037 MFR # 2002699003 Superseded: see description
117. #CORD, FLEXIBLE USE 2002699037 MFR # 2002699029 Superseded: see description
118. #S,CORD,AC POWER,1000MM,RM2351 MFR # 2002699110
119. #BRACKET,BURNER MFR # 2002493001
