Dometic RMD10.5XT Product # 921074192 Parts Diagram · Replacement

Refrigerator · 4 assemblies · 4 diagram sheets · 45 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic RMD10.5XT Product # 921074192 RV refrigerator: 4 assemblies (Replacement, Door Assembly, Housing Assembly, Cooling Generator) and 45 manufacturer part numbers.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Replacement

Components

1 item

1. #Refrigerator / Freezer;;Model RMD10.5XT; Dual Compartment Refrigerator With Freezer; Permanent Bolt MFR # 9600026498

Door Assembly

Components

11 items

1. #cover strip MFR # 289070902
2. #cover ledge MFR # 289078619
3. #cover ledge MFR # 289078618
4. #bottle shelf MFR # 289078622
5. #shelf MFR # 289078621
6. #decoration plate MFR # 289078674
7. #decoration plate MFR # 289078673
8. #door gasket MFR # 289078620
9. #fridge door MFR # 289081034
10. #freezer door MFR # 289080907
11. #retainer MFR # 289078623

Housing Assembly

Components

13 items

1. #APPLIANCE COMPONENTS RV; CRISPER MFR # 289078608
2. #divider crisper MFR # 289078610
3. #KIT DRAIN HOSE CONNECTION MFR # 292334710
4. #REAR EVAPORATOR MFR # 289078600
5. #grating MFR # 289078607
6. #grating MFR # 289078606
7. #lighting MFR # 289073100
8. #DROP PROFILE MFR # 289078611
9. #Cover, hinge plate MFR # 289078678
10. #cover cap MFR # 289078613
11. #SENSOR MFR # 289078625
12. #NTC MFR # 289078612
13. #control panel MFR # 289078667

Cooling Generator

Components

20 items

1. #APPLIANCE COMPONENTS RV; RM 8551 ABSORPTION REFRIGERATOR 12 MFR # RM8551R2F
2. #Refrigerator; Single Compartment Refrigerator; Left Hinge Door; 3.74 Cubic Foot (3.53 Cubic Foot With Freezer Compartment); 32.48 Inch Height x 20.74 Inch Width x 23-1/2 Inch Depth; 110 Volt AC/ 12 Volt DC; 3 Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; Black Frame; With Coated Sheet Steel/ Positive Lock System/ Automatic Front Frame Heater/ Solid Steel Frame/ CFC/HCFC-Free Foam Insulation/ LED Interior Light/ Magnetic Seal MFR # RM8551LF
3. #cooling unit MFR # 289076905
4. #HELIX MFR # 292621264
5. #KITCHEN SUPPLIES RV; GAS BURNER, WITH GAS VALVE, CBS3, D MFR # 289063432
6. #T-PIECE COMPLETE; 95 MILLIMETER MFR # 295244450
7. #FIXING BURNER; 10SCREWS/ 10WASHERS MFR # 295246161
8. #RIVET MFR # 241255999
9. #BRUSH CLEANER D=7MM MFR # 241248180
10. #COVER CONNECTION BRICK MFR # 241209332
11. #IGNITION CABLE MFR # 210657830
12. #HEATER MFR # 289076300
13. #heater MFR # 289076202
14. #CONNECTION WIRING MFR # 289023614
15. #Relay with connection wiring MFR # 289078629
16. #VENTILATOR COMPLETE MFR # 210651195
17. #fan MFR # 289080600
18. #APPLIANCE COMPONENTS RV; THERMOSTAT,VENTILATOR MFR # 2412906204
19. #connection brick complete MFR # 289069133
20. #CONNECTION WIRING MFR # 289076620
