Dometic Tw Series TW70003 Parts Diagram · Front View

Refrigerator · 3 assemblies · 3 diagram sheets · 36 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic Tw Series TW70003 RV refrigerator: 3 assemblies (Front View, Replacement Refrigerator, Rear View) and 36 manufacturer part numbers. 9 parts are marked as superseded — the description gives the replacement number to order instead.

The model and product number (PR#/product #) label is inside the fresh-food compartment on the side or ceiling wall. On Dometic absorption units the product number decides the cooling unit, control board and door panels, so match parts to it, not just to the RM model.

Front View

Components

12 items

1. #LATCH,TRAVEL USE 2904817018 RM2301 MFR # 2904817000 Superseded: see description
2. #Appliance Components RV; Hinge Rh MFR # 2007622059
3. #LATCH,TRAVEL USE 2904817000 RM2301 MFR # 2931140012 Superseded: see description
4. #Appliance Components RV; Hinge Lh MFR # 2007621044
5. #HINGE, ASM., LOWER RH MFR # 3100782014
6. #APPLIANCE COMPONENTS RV; Catch Travel Strike MFR # 2931111021
7. #Refrigerator Door Hinge Pin; Use With Dometic Refrigerator Model RB2405 MFR # 2007313006 Superseded: see description
8. #SHELF MFR # 3100976004
9. #APPLIANCE COMPONENTS RV; Bushing Door Hinge Lower MFR # 2002619001
10. #CATCH,TRAVEL BLACK MFR # 2904817018
11. #SCREW,LATCH 2501 MFR # 2931112011
12. #APPLIANCE COMPONENTS RV; Plug Masking MFR # 2930132051

Replacement Refrigerator

Components

12 items

1. #REFER 3.1 CU FT USE 72-4880; 2 WAY 30 7/8H X 23 1/2W X 24D. MFR # 442N Superseded: see description
2. #Refrigerator; Single Compartment Adjustable For Refrigerator; Flange Mount; Right Hand Hinge; 1.7 Cubic Foot; 17-1/2 Inch Width x 21-1/4 Inch Depth x 20-5/8 Inch Height; 1.4 Amps At 120 Volt AC/ 11.7 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; Without Ice Maker; Taupe Door; With Shelving MFR # 323TR
3. #RECON REFER, 1.7 CU.FT 2WAY 20 5/8H X 17 1/2W X 16 1/2D MFR # 322TR
4. #RECON REFER 3.1CUFT.2WAY; 30 7/8H X 23 1/2W X 24D. MFR # 442R
5. #REFER 3.1CU FT USE 72-4880; 30 7/8" X 23 1/2" X 24" 3WAY MFR # 443N Superseded: see description
6. #RECON REFER 1.7 CU FT 3 W BLK 20 5/8H X 17 1/2W X 21 1/4D MFR # 323R
7. #RECON REFER 1.7 CU FT 3 WAY 20 5/8"H X 17 1/2"W X 21 1/4"D MFR # 323BGR
8. #RECON REFER 3.1 CU FT 3 WAY, 30 7/8W X 23 1/2H X 24D MFR # 443R
9. #REFER, 1.7 CU FT.3WAY ***USE 72-4823*** MFR # 323TN Superseded: see description
10. #Refrigerator; Single Compartment Refrigerator With Freezer; Flange Mount; Right Hand Hinge; 2.7 Cubic Foot; 20-1/2 Inch Width x 21-3/8 Inch Depth x 29-3/4 Inch Height; 1.5 Amps At 120 Volt AC/ 12 Amps At 12 Volt DC; 3-Way Alternating Current/ Direct Current/ LP Gas; With Ice Maker MFR # N3003R
11. #REFER, 1.7 CU FT 2W USE 323TN 20 5/8 X 17 1/4 X 21 1/4 MFR # 322N Superseded: see description
12. #REFER, 1.7 CU FT 3WAY USE 323TN 20 5/8 X 17 1/4 X 21 1/4 MFR # 323N Superseded: see description

Rear View

Components

12 items

1. #COMPRESSOR MFR # 3101443004
2. #DECAL, FIELD WIRING MFR # 3101446007
3. #BOX, ELECT- USE 2904716004 MFR # 3101452005 Superseded: see description
4. #DRIER DN1070 MFR # 3100521008
5. #PANEL, BACK MFR # 3100415003
6. #RELIEF, STRAIN MFR # 302994006
7. #BRACKET, THERMOSTAT MFR # 3101480006
8. #MOTOR, FAN PE2033Q MFR # 3101444002
9. #BLADE, FAN MFR # 3100518004
10. #COIL, CONDENSER MFR # 3100520000
11. #T-STAT MFR # 3100985005
12. #Leveling System Hydraulic Pump; Used With 725 Series Class A Leveling System; 12 Volt DC; 125 Amps; MFR # AP47565
