Dexter Roof V2094-501-00 Parts Diagram · Explored View

Roof Vent · 2 assemblies · 6 diagram sheets · 15 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dexter Roof V2094-501-00 roof vent fan: 2 assemblies (Explored View, Replacement) and 15 manufacturer part numbers.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Explored View

Components

14 items

1. #WHITE DOME ASSEMBLY MFR # VD0449-A01
2. #12V ACCESSORIES RV; 12V MOTOR (1.5", ROUND SHAFT) FOR S MFR # BVD0218-00
3. ##4-40/ M2.6 MACHINE SCREW MFR # MACHINE SCREW
4. #HOOD PROP; FAN BLADE 6" DIAMETER, FITS .091 DI MFR # BVD0215-00
5. #OPERATOR MFR # VD0462-00
6. ##10-32 MACHINE SCREW MFR # VD0452-00
7. #MINI-ROCKER SWITCH MFR # L0108-00
8. #BIRCH WHITE SCREEN BASE MFR # VD0433-31
9. #BIRCH WHITE SCREEN MFR # VD0434-31
10. #PLASTIC OPERATOR KNOB MFR # VD0421-00
11. ##8-32 MACHINE SCREW MFR # V0423-01
12. #CEILING GARNISH MFR # VA0445TAB
13. #DOME SEAL MFR # VD0455-01
14. #Roof Vent Screw; Replacement For Ventline Roof Vent Screen Frame Screw; Fits Ventline V2092/ V2094/ V2110/ V2119/ V2128; #8-18 Thread x 5/8 Inch MFR # VA0262-00

Replacement

Components

1 item

1. #Roof Vent; Manual Opening; 14-1/4 Inch x 14-1/4 Inch; With Screen; With 12 Volt Fan; Polypropylene; With White Lid/ Two Piece Birch White Removable Screen Frame/ Screw In Mill Finish Flange MFR # V209450100
