Fan-Tastic / Dometic 4000 Non-powered Parts Diagram

Roof Vent · 1 diagram sheet · 5 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagram for the Fan-Tastic / Dometic 4000 Non-powered roof vent fan: 5 manufacturer part numbers.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Fan-Tastic / Dometic 4000 Non-powered exploded view

Components

5 items

1. #VENTILATION RV;;Bucking Bronco Hitch Box MFR # 4000
2. #VENTILATION RV; 1250 SERIES VENT WHITE MFR # 801250
3. #VENTILATION RV;;Manual Lift Exhaust Fan MFR # 4000BT
4. #VENTILATION RV;;Fan-Tastic Vent W/Reverse MFR # 4000RCD45W
5. #Roof Vent; Fan-Tastic Vent; Manual Opening; Wall Mounted Controls; For 14 Inch x 14 Inch Openings; With Screen; With 3-Speed Fan; Smoke Dome With White High Profile Base; UV Stabilized Resin MFR # 4000R
