Fan-Tastic / Dometic 800 Non-powered Parts Diagram

Roof Vent · 1 diagram sheet · 12 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagram for the Fan-Tastic / Dometic 800 Non-powered roof vent fan: 12 manufacturer part numbers.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Fan-Tastic / Dometic 800 Non-powered exploded view

Components

12 items

1. #Roof Vent; Fan-Tastic ™; Manual Opening; For 14 Inch x 14 Inch; Without Fan; Off White Dome; High Density UV-Stable Polyethylene MFR # 800801
2. #MANUAL OPENING; FOR 14 INCH X 14 INCH; WITHOUT FAN; SMOKE DOME; HIGH DENSITY UV-STABLE POLYETHYLENE MFR # 800901
3. #EZ BREEZE; FIXED DOME WITH SIDE VENTS; 12 VOLT; FOR 14 INCH X 14 INCH OPENINGS MFR # 800600
4. #MANUAL OPENING; FOR 14 INCH X 14 INCH; WITHOUT FAN; WHITE OPAQUE DOME MFR # 800800
5. #Roof Vent; Fan-Tastic ™; Manual Opening; For 14 Inch x 14 Inch; With Screen; With 3-Speed/ Reverse Fan; Smoke Dome/ White High Profile Base; High Density UV-Stable Polyethylene; With Vent Assembly/ Installation Hardware; Single MFR # 810316
6. #MANUAL OPENING; FOR 14 INCH X 14 INCH; WITHOUT FAN; SMOKE DOME MFR # 800900
7. #EZ-BREEZE; MANUAL OPENING SIDE VENTS; NON-POWERED; FOR 14 INCH X 14 INCH OPENINGS MFR # 800501
8. #EZ-BREEZE; MANUAL OPENING SIDE VENTS; NON-POWERED; FOR 14 INCH X 14 INCH OPENINGS MFR # 800500
9. #Roof Vent; Fan-Tastic ™; Manual Opening; For 14 Inch x 14 Inch; With 3-Speed Fan; Smoke Dome/ White High Profile Base; High Density UV-Stable Polyethylene MFR # 801201
10. #EZ-BREEZE; MANUAL OPENING SIDE VENTS; NON-POWERED; FOR 14 INCH X 14 INCH OPENINGS MFR # ATW800500
11. #null MFR # A1U8004WH
12. #EZ BREEZE; FIXED DOME WITH SIDE VENTS; 12 VOLT; FOR 14 INCH X 14 INCH OPENINGS MFR # 800601
