Fan-Tastic Upgrade Kit / Upgrade Kits Parts Diagram

Roof Vent · 3 diagram sheets · 9 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Fan-Tastic Upgrade Kit / Upgrade Kits roof vent fan: 9 manufacturer part numbers. 3 parts are marked as superseded — the description gives the replacement number to order instead.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Fan-Tastic Upgrade Kit / Upgrade Kits exploded view

Components

9 items

1. #Roof Vent Upgrade Kit; Fan-Tastic Vent; Use To Upgrade An Existing Manual Vent To Powered Vent; For Fan-Tastic Vent Model 6600; With Rain Sensor/ Prewired Interior Assembly With Electronics/ Auto Lift Motor/ Arm/ Handheld Remote With Two AA Batteries And Remote Wall Cradle MFR # K6600R417WH Superseded: see description
2. #Roof Vent Upgrade Kit; Fan-Tastic ™; Use To Upgrade Any 12 Volt Fan-Tastic Vents To 3350 Series Vent; White Base With Smoke Dome; With Rain Sensor/ Auto Lift Motor/ Auto Lift Arm/ Pre-Wired Interior Assembly With Electronics/ Pop N Lock Screen MFR # 803359 Superseded: see description
3. #UPGRADE TO 7350 KIT, OFF WHITE MFR # 807358
4. #VENTILATION RV; UPGRAD KIT-7300SERIES WHT MFR # 807359
5. #UPGRADE TO 1250 MFR # 801259
6. #UPGRADE TO 1250 KIT, OFF WHITE MFR # 801258
7. #Roof Vent Upgrade Kit; Fan-Tastic ™; Use To Upgrade Any 12 Volt Fan-Tastic Vents To 2250 Series Vent; White Base With Smoke Dome; With Manual Lift Motor/ Pre-Wired Interior Assembly/ Pop N Lock Screen/ Built-In Thermostat/ 3 Speed Fan Selection/ Reverse Air Flow MFR # 802259 Superseded: see description
8. #UPGRADE TO 2250 KIT, OFF WHITE MFR # 802258
9. #UPGRADE TO 3350 KIT, OFF WHITE MFR # 803358
