Heng's Zephyr Parts Diagram · Exploded view

Roof Vent · 2 assemblies · 4 diagram sheets · 15 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Heng's Zephyr roof vent fan: 2 assemblies (Parts List) and 15 manufacturer part numbers.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Heng's Zephyr exploded view

Components

5 items

1. #Roof Vent; Zephyr; Fits All 14 Inch x 14 Inch Roof Openings; High Velocity; White MFR # SV1113G4
2. #ZEPHYR PWR VENT WHITE MFR # SV1112G4
3. #Roof Vent; Zephyr; Fits All 14 Inch x 14 Inch Roof Openings; High Velocity; Clear MFR # SV0113G4
4. #Roof Vent; Zephyr; For 14 Inch x 14 Inch; With Screen; With Fan; White Screen/ Smoke Lid; 12 Volt 3 Speed Switch; High/ Medium/ Low Fan Settings; Reversible Air Flow; With 5 Inch Square Garnish And Collar MFR # SV4112G4
5. #Roof Vent; Manual Opening; Fits All 14 Inch x 14 Inch Roof Openings; With Fan; Clear; With 5 Inch Garnish And Weather Tight Seal MFR # SV0112G4

Parts List

Components

10 items

1. #FAN ACCESSORIES ELECTRIC; FAN BLADE MFR # SV9002
2. #CRANK HANDLE BLACK FOR SUPER VENT MFR # SV9009
3. #ROOF VENT FAN RV; MOTOR FOR SUPER VENT MFR # SV9001
4. #VENTILATION RV; VENT OPERATOR MFR # SV9003
5. #APPLIANCE COMPONENTS RV; REPLACEMENT LID, CLEAR, SUPER VENT MFR # SV9006-C1
6. #VENTILATION RV; REPLACEMENT LID WHITE SUPER VENT MFR # SV9007-C1
7. #CONNECTING ROD BEARING; CRANK ASSEMBLY MFR # SV9005
8. #VENTILATION RV; ZEPHHR SMOKE LID ONLY MFR # SV9008-C1
9. #SEALS; BLACK BULB SEAL FOR SUPER VENT MFR # SV9004
10. #WIRING & SERVICE ACCESSORYS RV; REMOTE CONTROL FOR SUPER VENT MFR # SV9015
