Roof Vent · 7 assemblies · 9 diagram sheets · 7 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the MaxxAir original Vent Cover / Black Cover roof vent fan: 7 assemblies (Maxx Brackets, Black Cover, Smoke Cover, White Cover, Shell White Cover and more) and 7 manufacturer part numbers. 3 parts are marked as superseded — the description gives the replacement number to order instead.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Maxx Brackets

Components

1 item

1. #Roof Vent Cover Mounting Kit; MAXXAIR®; Use With Standard Maxxair Vent Cover; Bolt-On; With Bracket MFR # 225000 Superseded: see description

Black Cover

Components

1 item

1. #Roof Vent Cover; MAXXAIR®; Exterior Mount; Dome Type Ventilation Cover; Vented On One Side; For 14 Inch x 14 Inch Vents; 19-1/4 Inch Length x 18-1/2 Inch Width; Black; Polyethylene; Also Use New Number 00-933052 MFR # 933069 Superseded: see description

Smoke Cover

Components

1 item

1. #Roof Vent Cover; MAXXAIR®; Exterior Mount; Dome Type Ventilation Cover; Vented On One Side; For 14 Inch x 14 Inch Vents; 19-1/4 Inch Length x 18-1/2 Inch Width; Smoke; Polyethylene MFR # 933067

White Cover

Components

1 item

1. #Roof Vent Cover; MAXXAIR®; Exterior Mount; Dome Type Ventilation Cover; Vented On One Side; For 14 Inch x 14 Inch Vents; 19-1/4 Inch Length x 18-1/2 Inch Width; White; Polyethylene; Single; Also Use New Number 00-933051 MFR # 933066 Superseded: see description

Shell White Cover

Components

1 item

1. #Roof Vent Cover; Exterior Mount; Dome Type Ventilation Cover; Vented On One Side; For 14 Inch x 14 Inch Vents; 19-1/4 Inch Length x 18-1/2 Inch Width; Shell White/ Almond; Polyethylene MFR # 933068

Champagne Cover

Components

1 item

1. #MAXXAIR STD VENT CHAMPAGNE MFR # 933071

Silver Cover

Components

1 item

1. #VENTILATION RV; STD VENT COVER GRAY MFR # 933070
