Diagrams › Ventline / Dexter › Attic Fans V2067 Series Ventline / Dexter Attic Fans V2067 Series Parts Diagram
Roof Vent · 3 diagram sheets · 16 parts · by Andrew Strick, mobile RV technician
OEM exploded parts diagrams for the Ventline / Dexter Attic Fans V2067 Series roof vent fan: 16 manufacturer part numbers. 5 parts are marked as superseded — the description gives the replacement number to order instead.
Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.
Exploded View
Ventline / Dexter Attic Fans V2067 Series exploded view — parts list sheet 1 of 3 Full-resolution diagram + every part number →
Ventline / Dexter Attic Fans V2067 Series exploded view — parts list sheet 2 of 3 Full-resolution diagram + every part number →
Ventline / Dexter Attic Fans V2067 Series exploded view — parts list sheet 3 of 3 Full-resolution diagram + every part number →
Components 16 items # Fan Blade; For Ventline 12 Volt Standard Roof Ventadomes; Counter-Clockwise Rotation; 6 Inch Diameter x 1/8 Inch D Shaft; Single MFR # BVA016300 # Fan Blade; For Ventline 110 Volt 7 Inch Insert Fans; 6-1/2 Inch Diameter; Single MFR # BVA031200 # Exhaust Fan Thermostat; Replacement For Roof Mounted Attic Fans; With Connecting Wire MFR # VA050800 # THERMOSTAT FOR V2066 ALT VA050803 NO LONGER AVAILABLE. ALTERNATE VA050800. THIS WILL WORK BUT THE FAN WILL OPERATE AT DIFFERENT TEMPERATURES (ON/OFF AT 105 & 90 DEGREES - OLD WAS 75 ... MFR # VA050803 # NO GENERIC NAME; T-Stat F/V2067 MFR # VA050802 # HUMIDISTAT USE V029100 ATTIC FAN MFR # V29101 Superseded: see description # APPLIANCE COMPONENTS RV; Humidistat On 70% Off 6 MFR # V029100 # MOTOR,115V USE CD019000 MFR # CD018800 Superseded: see description # Stove Vent Hood Fan Motor; For 2 Speed 100 CMF Stove Vent Hood; 110 Volt AC; CSA Listed MFR # BVD027800 # MOTOR,FAN USE 31-1765 For all 120V AC Range Hood Motors: The VD0278-00 2-Speed Motor has replaced all 120V AC Range Hood Motors used in the past such as CD0190-00, VD0275-0... MFR # CD019000 Superseded: see description # VENTILATION RV; 110V Multi-Purpose Motor MFR # BVD027500 # MOTOR USE CD019000 MFR # CD19000 Superseded: see description # HUMIDIFAN W/FLANGE AT 12 DEGREE ANGLE MFR # V206602 # FAN,ATTIC W/T-STAT THIS COMES IN PACKAGE OF 4. COST IN COMPUTER IS SET AT EACH. MFR # V206700 # FAN,ATTIC (HUMIDIFAN) WITH HUMIDISTAT WHITE MFR # V214646W # FAN,ATTIC (HUMIDIFAN) W/HUMIDISTAT BLACK GABLE HUMIDIFAN, WITH HUMIDISTAT, BLACK IS A USE # FOR V214630B MFR # V214643B Superseded: see description
