Roof Vent · 3 diagram sheets · 5 parts · by Andrew Strick, mobile RV technician
OEM exploded parts diagrams for the Ventline / Dexter Exterior Wall F-rangehoods V2009-2018 Louvered Vents roof vent fan: 5 manufacturer part numbers.
Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.
Replacement › Exhaust Outlet
Ventline / Dexter Exterior Wall F-rangehoods V2009-2018 Louvered Vents replacement › exhaust outlet — parts list sheet 1 of 3 Full-resolution diagram + every part number →
Ventline / Dexter Exterior Wall F-rangehoods V2009-2018 Louvered Vents replacement › exhaust outlet — parts list sheet 2 of 3 Full-resolution diagram + every part number →
Ventline / Dexter Exterior Wall F-rangehoods V2009-2018 Louvered Vents replacement › exhaust outlet — parts list sheet 3 of 3 Full-resolution diagram + every part number →
Components 5 items # EXTERIOR WALL VENT,BLACK 1 3/4" COLLAR MFR # V201855 # Stove Vent Hood Exhaust Outlet; Non Locking Louvered; 10-1/2 Inch Width x 3-3/4 Inch Height; 1-3/4 Inch Collar Opening; Colonial White; Polystyrene Plastic MFR # V201802 # Stove Vent Hood Exhaust Outlet; Non Locking Louvered; 10-1/2 Inch Width x 3-3/4 Inch Height; 1/2 Inch Collar Opening; Polar White; Polystyrene Plastic MFR # V200901 # Stove Vent Hood Exhaust Outlet; Non Locking Louvered; 10-1/2 Inch Width x 3-3/4 Inch Height; 1-3/4 Inch Collar Opening; Polar White; Polystyrene Plastic MFR # V201801 # Stove Vent Hood Exhaust Outlet; Non Locking Louvered; 10-1/2 Inch Width x 3-3/4 Inch Height; 1/2 Inch Collar Opening; Colonial White; Polystyrene Plastic MFR # V200902
