Ventline / Dexter Exterior Wall F-rangehoods V2111 Vent W-damper Parts Diagram

Roof Vent · 3 diagram sheets · 6 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Ventline / Dexter Exterior Wall F-rangehoods V2111 Vent W-damper roof vent fan: 6 manufacturer part numbers.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Replacement › Exhaust Outlet

Components

6 items

1. #Stove Vent Hood Exhaust Outlet; Non Louvered Locking; 10-1/2 Inch Width x 3-3/4 Inch Height; 5/8 Inch Collar Opening; Polar White; Polystyrene Plastic MFR # V211103
2. #Stove Vent Hood Exhaust Outlet; Non Louvered Locking; 10-1/2 Inch Width x 3-3/4 Inch Height; 1-3/4 Inch Collar Opening; Nu-Tru White; Polystyrene Plastic MFR # V211111
3. #Stove Vent Hood Exhaust Outlet; Non Louvered Locking; 10-1/2 Inch Width x 3-3/4 Inch Height; 1-3/4 Inch Collar Opening; Polar White; Polystyrene Plastic MFR # V211113
4. #Stove Vent Hood Exhaust Outlet; Non Louvered Locking; 10-1/2 Inch Width x 3-3/4 Inch Height; 5/8 Inch Collar Opening; Colonial White; Polystyrene Plastic MFR # V211101
5. #Stove Vent Hood Exhaust Outlet; Non Louvered Locking; 10-1/2 Inch Width x 3-3/4 Inch Height; 1-3/4 Inch Collar Opening; Nu-Tru White; Polystyrene Plastic MFR # V211118
6. #Stove Vent Hood Exhaust Outlet; Non Louvered Locking; 10-1/2 Inch Width x 3-3/4 Inch Height; 5/8 Inch Collar Opening; Nu-Tru White; Polystyrene Plastic MFR # V211108
