Ventline / Dexter Non-powered Roof Vents V2110 Series Parts Diagram · Replacement Vent

Roof Vent · 2 assemblies · 6 diagram sheets · 40 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Ventline / Dexter Non-powered Roof Vents V2110 Series roof vent fan: 2 assemblies (Replacement Vent, Exploded View) and 40 manufacturer part numbers. 5 parts are marked as superseded — the description gives the replacement number to order instead.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Replacement Vent

Components

9 items

1. #NO GENERIC NAME; Vent Non-Powered; FOR POLAR WHITE USE V21104100 , COACH WHITE V21102100 MFR # V21103100 Superseded: see description
2. #Roof Vent; Manual Opening; 14-1/4 Inch x 14-1/4 Inch; With Screen; Without Fan; Polypropylene; With Metal Lid And Birch White Screen Frame/ Radius Corner Polar White Ceiling Trim Ring Part Number VA0445-26 MFR # V2110SP23
3. #Roof Vent; Manual Opening; 14-1/4 Inch x 14-1/4 Inch; With Screen; Without Fan; Polypropylene; With Metal Lid And Polar White Screen MFR # 211060100
4. #Manual Opening; 14-1/4 Inch x 14-1/4 Inch; With Screen; Without Fan; Polypropylene And Low Profile Metal; With Metal Lid/ Two Piece Polar White Removable Screen Frame/ Painted White Flange MFR # V2110-601-46
5. #Roof Vent; Manual Opening; 14-1/4 Inch x 14-1/4 Inch; Aluminum; With 2-1/8 Inch Trim Ring MFR # 22-0148
6. #Roof Vent; For 14 Inch x 14 Inch Vents; Polar White; Aluminum MFR # V2110SP24
7. #Roof Vent; Manual Opening; 14-1/4 Inch x 14-1/4 Inch; With Screen; Without Fan; Polypropylene; With Metal Lid And Birch White Screen MFR # 211050100
8. #Roof Vent; Manual Opening; FOR COACH WHITE V21102100 , FOR BIRCH WHITE V21103100 MFR # V21104100
9. #VENT NON POWERED COL.WHITE RADIUS CORNERS MFR # V21102100

Exploded View

Components

31 items

1. #Roof Vent Lid; Fits 14 Inch x 14 Inch Standard Roof Vents; Low Profile Metal; Radius Cornered; Single MFR # BV053400
2. #Roof Vent Lid; For Ventline Trailer Roof Vent Part Number V2094 Made Before 2008; 14-1/4 Inch x 14-1/4 Inch; Continuous Hinge; Smoke; Polypropylene; Old Style Round Profile; Single MFR # BV055403
3. #Roof Vent Lid; For Ventline Trailer Roof Vent Part Number V2094 Made Before 2008; 14-1/4 Inch x 14-1/4 Inch; Continuous Hinge; White; Polypropylene; Old Style Round Profile; Single MFR # BV055401
4. #Roof Vent Crank Handle; Replacement For Ventline Old Style Rounded Dome Roof Vents; Single Straight Arm; 6-5/8 Inch Arm Length; With Operator/ Knob/ Mounting Screw; Single MFR # BV011504
5. #Roof Vent Lift Arm Clip; For Ventline Roof Vent V2110/ V2092/ V2094 MFR # VA280
6. #Roof Vent Screw; Replacement For Ventline Roof Vent Crank Handel Mounting Screw; Fits V2110 Stove Vent Hood; #10-24 Thread x 7/16 Inch MFR # C013200
7. #Roof Vent Screen Frame; Replacement For Ventline 14 Inch x 14 Inch Roof Vent Models; Polar White Screen Frame MFR # BVA044441
8. #Roof Vent Screen Frame; Replacement For Ventline 14 Inch x 14 Inch Roof Vent Models; Polar White Screen Frame MFR # BVA044441R
9. #Roof Vent Screen Frame; Replacement For Ventline Roof Vent 2-Piece Models V2092/ V2110/ V2119/ V2310/ V2392/ V2094; 14 Inch x 14 Inch; Polar White MFR # VA044421
10. #Roof Vent Screen Frame; Replacement For Ventline Roof Vent 2-Piece Models V2092/ V2110/ V2119/ V2310/ V2392/ V2094; 14 Inch x 14 Inch; Polar White MFR # BVC057341
11. #VENTILATION RV; FRAME & SCREEN- BIRCH WHITE MFR # VA044401
12. #VENTILATION RV; FRAME & SCREEN- BIRCH WHI MFR # BVA044431
13. #SCREEN, ROOF VENT USE BVA044421 COLONIAL WHITE MFR # BVA044421 Superseded: see description
14. #Roof Vent Screen Frame; For Ventline Roof Vent V2092/ V2099/ V2392/ V2399; Birch White MFR # VA044431
15. #Roof Vent Screw; Replacement For Ventline Roof Vent Screen Frame Screw; Fits Ventline V2092/ V2094/ V2110/ V2119/ V2128; #8-18 Thread x 5/8 Inch MFR # VA026200
16. #Roof Vent Lift Arm Knob; Replacement Roof Vent Crank Handle V2092/ V2110/ V2094/ V2128/ V2525; Black; Plastic; With Screw Camper MFR # VA467
17. #Roof Vent Lift Arm Knob; Replacement Roof Vent Crank Handle; Black; Plastic; With Screw Camper; Single MFR # BVD042100
18. #Roof Vent Lift Arm Knob; Replacement Roof Vent Crank Handle V2092/ V2110/ V2094/ V2128/ V2525; Black; Plastic; With Screw Camper MFR # BVD042115
19. #Roof Vent Screw; Replacement For Ventline Roof Vent Knob Mounting Screw; Fits Ventline V2094/ V2110; #8-32 Thread x 3/4 Inch MFR # V042301
20. #Roof Vent Trim Ring; 14-1/4 Inch x 14-1/4 Inch; 2-1/8 Inch Depth; With Radius Corner; Birch White MFR # VA044526
21. #Roof Vent Screw; Replacement For Ventline Roof Vent Knob Mounting Screw; #8-32 Thread x 1-1/2 Inch MFR # VA44520
22. #GARNISH RAD. USE VA044535 COACH WHITE 3 7/8" to 5 1/4" MFR # VA44519 Superseded: see description
23. #GARNISH RADIUS CORNER COL.WHITE MFR # VA044510
24. #GARNISH USE VA04420 RADIUS CORNERS COL.WHITE MFR # VA044513 Superseded: see description
25. #Roof Vent Trim Ring; 14-1/4 Inch x 14-1/4 Inch; 2-1/8 Inch Depth; With Radius Corner; Polar White MFR # VA044534
26. #GARNISH USE VA044536 3 1/8" MFR # VA044512 Superseded: see description
27. #Roof Vent Trim Ring; 14-1/4 Inch x 14-1/4 Inch; 1-1/8 Inch Depth; With Radius Corner; Birch White MFR # VA044525
28. #Roof Vent Trim Ring; 14-1/4 Inch x 14-1/4 Inch; 4-1/8 Inch Depth; With Radius Corner; Birch White MFR # VA044528
29. #Roof Vent Trim Ring; 14-1/4 Inch x 14-1/4 Inch; 1-1/8 Inch Depth; With Radius Corner; Polar White MFR # VA044533
30. #Roof Vent Trim Ring; 14-1/4 Inch x 14-1/4 Inch; 3-1/8 Inch Depth; With Radius Corner; Polar White MFR # VA044535
31. #GARNISH, WHT 4-5/32" LEG 14X 14 RADIUS VENT MFR # VA44529
