Ventline / Dexter Refrigerator Roof Vents / Outlet Fans & Vents 5 Inch X 20 Inch Roof Vents Parts Diagram · Replacement
Roof Vent · 2 assemblies · 6 diagram sheets · 9 parts · by Andrew Strick, mobile RV technician
OEM exploded parts diagrams for the Ventline / Dexter Refrigerator Roof Vents / Outlet Fans & Vents 5 Inch X 20 Inch Roof Vents roof vent fan: 2 assemblies (Replacement, Parts List) and 9 manufacturer part numbers. 1 part is marked as superseded — the description gives the replacement number to order instead.
Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.
