Ventline / Dexter Refrigerator Roof Vents / Outlet Fans & Vents 5 Inch X 24 Inch Roof Vents Parts Diagram

Roof Vent · 3 diagram sheets · 7 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Ventline / Dexter Refrigerator Roof Vents / Outlet Fans & Vents 5 Inch X 24 Inch Roof Vents roof vent fan: 7 manufacturer part numbers. 2 parts are marked as superseded — the description gives the replacement number to order instead.

Vent model labels are on the interior garnish frame or on the fan housing behind the screen. Lid, motor and lift-kit parts differ between manual, 12 V and thermostatic models of the same size, so confirm which you have.

Parts List

Components

7 items

1. #FLANGE WITH SCREEN USE V052300 MFR # V52302 Superseded: see description
2. #VENT, REFER POLAR WHITE MFR # V20223W
3. #VENT,REFER USE V20223W COLONIAL WHITE MFR # V20221CW Superseded: see description
4. #Refrigerator Vent Cover; For 5 Inch Length x 24 Inch Width Roof Vent; White MFR # V020303
5. #Refrigerator Vent Base; For Ventilation Of RV Refrigerator Unit; 5 Inch Width x 24 Inch Length; With Screen MFR # V052300
6. #SCREEN FOR V2022 ASSEMBLY (V0523-02 FLG) MFR # V020702
7. #Refrigerator Vent Cover; Replacement Cap For Dometic Refrigerators Vent Base Part Number V020303; 24 Inch Length x 5 Inch Width; Colonial White MFR # V020301
