Thetford Aqua Magic 038 30-40 Parts Diagram · Exploded View

Toilet · 3 assemblies · 9 diagram sheets · 56 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Thetford Aqua Magic 038 30-40 RV toilet: 3 assemblies (Exploded View, 03626 Mechanism I, 03626 Mechanism II) and 56 manufacturer part numbers. 9 parts are marked as superseded — the description gives the replacement number to order instead.

Thetford and Dometic toilet model numbers are on a sticker at the back of the base or under the bowl rim. The same family (Aqua-Magic, 300/310) has high- and low-profile versions with different valves and seals.

Exploded View

Components

30 items

1. #SEAT COVER MFR # 3715T
2. #TOILET COMPONENTS RV; Hinge Post Sl/Sh White MFR # 371762
3. #POST,HINGE USE 371762 WHITE ONLY MFR # 371704 Superseded: see description
4. #PIN, HINGE MFR # 5212
5. #Toilet Seat Hinge Pin; Replacement For Aqua Magic ® Galaxy; Single MFR # 33326
6. #TOILET COMPONENTS RV; HINGE PIN MFR # 12986
7. #WELL NUT MFR # 3225T
8. #OPTIONAL HAND SPRAY MFR # 2542T
9. #TOILET COMPONENTS RV; Clamp MFR # 33247
10. #CLAMP (4) MFR # 3752T
11. #HUSKY ADJ MOUNT STEP PLATFORM MFR # 33257
12. #HOPPER ASSEMBLY TALL SPEC. GD, WT, IVORY MFR # 5611
13. #SIDE VIEW MIRROR MFR # 5610
14. #SEAT,IVORY GL/GH SERIES MFR # 848710
15. #SEAT,WHITE USE 848762 MFR # 848704 Superseded: see description
16. #SEAT,PARCHMENT USE 848762 MFR # 848757 Superseded: see description
17. #TOILET COMPONENTS RV; Seat--Gl/Gh White MFR # 848762
18. #TOILET COMPONENTS RV; Seat Whitesl /Sh & Gl/Gh MFR # 33015
19. #SEAT MFR # 8487
20. #SEAT,GOLD MFR # 848703
21. #VACUUM BREAKER COVER SPEC, GD, WT, IVORY MFR # 3716T
22. #MECHANISM ASSEMBLY MFR # 3626
23. #TOILET COMPONENTS RV; Screw #03994 MFR # 3994
24. #FOOT PEDAL MFR # 3636
25. #SCREW (2) MFR # 1663T
26. #SCREW (2) MFR # 3648
27. #TOILET COMPONENTS RV; Double Pedal Package Parc MFR # 20930
28. #PEDAL PKG USE 20930 DOUBLE MFR # 9866 Superseded: see description
29. #HITCH 2' RECEIVER SELECT CHRYSLER MFR # 2020
30. #TOILET COMPONENTS RV; Nut MFR # 33238

03626 Mechanism I

Components

26 items

1. #TOILET COMPONENTS RV; Dump Pedal Spring MFR # 2802
2. #HITCH PIN 1/2' BULK MFR # 33253
3. #VALVE PKG,BALL OLD MFR # 9869
4. #COVER-TJ-METAL TOP MFR # 2777T
5. #PLATE,LEVER USE 33320 MFR # 5044T Superseded: see description
6. #KIT, SVC DOOR GASKET SMALL MFR # 33320
7. #PUP PLANK XL SPORT - CAMO MFR # 33250
8. #TOILET COMPONENTS RV; Spring MFR # 33252
9. #TOILET COMPONENTS RV; Spring MFR # 2801
10. #APPLIANCE COMPONENTS RV; LARGE HEAT EXCHANGER SERVICE KIT MFR # 33302
11. #TOILET COMPONENTS RV; Push Link MFR # 8986
12. #TOILET COMPONENTS RV; Retainer Ring MFR # 2394
13. #PEDAL ARM ASSEMBLY MFR # 5043
14. #TOILET COMPONENTS RV; Arm Pedal Use 33351 MFR # 19266 Superseded: see description
15. #ARM, PEDAL USE 19266 MFR # 3603 Superseded: see description
16. #PEDAL ARM USE 83-8950 MFR # 33351 Superseded: see description
17. #SCREW MFR # 8535T
18. #TOILET COMPONENTS RV; Nut MFR # 33238
19. #HITCH 2' RECEIVER SELECT CHRYSLER MFR # 2020
20. #TOILET COMPONENTS RV; Bushing-- MFR # 3749
21. #HUSKY 2-5/16' PINTLE COMBO 20K/10T MFR # 33258
22. #TOILET COMPONENTS RV; Cotter Pin MFR # 3765
23. #Toilet Cotter Pin; Replacement For Aqua Magic ® Starlite/ Galaxy Permanent Toilet MFR # 33259
24. #TOILET COMPONENTS RV; Screw MFR # 2388
25. #BASE & COVER ASSEMBLY MFR # 5613
26. #RIDRITE F250/350/450 2017 MFR # 2600

03626 Mechanism II

Components

9 items

1. #HITCH 2' RECEIVER SELECT CHRYSLER MFR # 2020
2. #TOILET COMPONENTS RV; Nut MFR # 33238
3. #PEDAL PKG USE 20930 DOUBLE MFR # 9866 Superseded: see description
4. #SCREW (2) MFR # 3648
5. #TOILET COMPONENTS RV; Double Pedal Package Parc MFR # 20930
6. #SIDE VIEW MIRROR MFR # 3925
7. #TOILET COMPONENTS RV; Screw Use 3925 MFR # 33266 Superseded: see description
8. #FOOT PEDAL MFR # 3636
9. #TOILET COMPONENTS RV; Screw #03994 MFR # 3994
