Thetford Aqua Magic 1400 Parts Diagram · 02525 Vacuum Breaker

Toilet · 3 assemblies · 9 diagram sheets · 63 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Thetford Aqua Magic 1400 RV toilet: 3 assemblies (02525 Vacuum Breaker, Exploded View, 02617 Mechanism) and 63 manufacturer part numbers. 3 parts are marked as superseded — the description gives the replacement number to order instead.

Thetford and Dometic toilet model numbers are on a sticker at the back of the base or under the bowl rim. The same family (Aqua-Magic, 300/310) has high- and low-profile versions with different valves and seals.

02525 Vacuum Breaker

Components

6 items

1. #BREAKER,VACUUM MFR # 2538
2. #LP/25 LEAF KIT MFR # 2512
3. #07-C SPRINTER RV DELUXE WINDSHIELD COVER W/ ROLL-UP WINDOWS MFR # 2523
4. #SEAL (SMALL) MFR # 2331TH
5. #SEAL (LARGE) MFR # 2537T
6. #PLATE,INSERT MFR # 2533

Exploded View

Components

17 items

1. #SEAT, TOILET MFR # 2498
2. #CLS B W/S CVR FORD TRANSIT 17-18 MFR # 2525
3. #WIRE, PRIMARY 6 GA 100' WHITE MFR # 2563
4. #TOILET COMPONENTS RV; Clamp MFR # 33247
5. #ELBOW MFR # 2575
6. #TRIGGER JEEP JK FUSEBOX CONTROLLER MFR # 2010
7. #BIG DADDY 20 1/2' MFR # 2300
8. #ULT PLUS HSE & FTG UPGRADE KIT MFR # 52300
9. #TUBE TRAP 1400 MFR # 2518
10. #WELL NUT MFR # 2146T
11. #HOSE,VACUUM INLET MFR # 2864
12. #RIDE RT RAM 2500 2WD14-17 MFR # 2598
13. #Toilet Seal; Replacement For Electra Magic ® Model 80 Recirculating Toilets/ Aqua-Magic ® Galaxy/ Aqua-Magic ® Starlite Permanent Toilets; Closet Flange Seal; Rubber; Single MFR # 33239
14. #Toilet Seal; Closet Flange Seal; 9/16 Inch; Rubber Sponge; Single MFR # 20676
15. #SIDE VIEW MIRROR MFR # 2125
16. #TOILET COMPONENTS RV; Mech. Repair Pkuse 83-816 MFR # 33003
17. #TOILET COMPONENTS RV; Hopper Seal (Old) MFR # 2489

02617 Mechanism

Components

42 items

1. #01-C CHEVY RV CLASS C DELUXE WINDSHIELD COVER ROLL-UP WINDOWS & MIRROR CUT-OUTS MFR # 2509
2. #HOSE CLAMP MFR # 2602
3. #TOILET COMPONENTS RV; Clamp MFR # 33247
4. #RIDE RITE TRANSIT 235 WDUAL WHEEL MFR # 2603
5. #MALE HOSE INSERT MFR # 2608T
6. #ZSERIES 2'OILGAUGE 100PSI MFR # 2604
7. #VALVE SEAT MFR # 2521T
8. #R.RITE SILVERADO-GMC 1500 2&4WD2019 MFR # 2609
9. #SWIVEL FEMALE INSERT MFR # 2607T
10. #BALL VALVE 1400 SERIES MFR # 2396
11. #BALL VALVE "O" RING MFR # 2625T
12. #TOILET COMPONENTS RV; Glide Ring MFR # 2422
13. #GLIDE RING MFR # 33245
14. #SPRING MFR # 2395
15. #FOOT PEDAL 1400 MFR # 2387
16. #BALL VALVE DRIVE ARM MFR # 2392T
17. #TOILET COMPONENTS RV; Retainer Ring MFR # 2394
18. #BUSHING MFR # 2270T
19. #32 1/4 IN POLAR WHITE VINYL SPARE TIRE COVER MFR # 1752
20. #A.GAGE CONS.OIL/WAT/VOLTS MFR # 2397
21. #N/A ARM,PEDAL MFR # 2416M
22. #TOILET COMPONENTS RV; Screw MFR # 1663
23. #COVER MFR # 2442T
24. #ELEC TEMP REPLC SENDER MFR # 2385
25. #UNIV CLR VIEW FUEL FILTER MFR # 2369
26. #BLADE,MECHANISM USE 33053 MFR # 24502 Superseded: see description
27. #KIT, SVC MOUNT SAIL SWITCH M-L MFR # 33053
28. #BLADE USE 24502 MFR # 2383 Superseded: see description
29. #FORD F150 WITH SCALES PACKAGE (2WD/ MFR # 2627
30. #Toilet Flush Mechanism Repair Kit; Used For Aqua-Magic ® Galaxy/ Aqua-Magic ® Starlite Permanent Toilets MFR # 8368
31. #NA SCREW MFR # 2694T
32. #A.GAGE CONS.OIL/VLTS/WAT MFR # 2399
33. #TENSION WASHER RETAINER MFR # 2401T
34. #GROOVE PIN MFR # 2623T
35. #PUSH LINK USE 8986 MFR # 2390 Superseded: see description
36. #APPLIANCE COMPONENTS RV; LARGE HEAT EXCHANGER SERVICE KIT MFR # 33302
37. #TOILET COMPONENTS RV; Push Link MFR # 8986
38. #TOILET COMPONENTS RV; Screw MFR # 2388
39. #TUBE TRAP 1400 MFR # 2518
40. #MALE HOSE INSERT MFR # 2432T
41. #TRAP TUBE SPRING MFR # 2528T
42. #29 3/4 IN POLAR WHITE VINYL SPARE TIRE COVER MFR # 1754
