Suburban Sw Series SW6DEL Parts Diagram · Exploded View

Water Heater · 2 assemblies · 2 diagram sheets · 79 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Suburban Sw Series SW6DEL RV water heater: 2 assemblies (Exploded View, Replacement Water Heater) and 79 manufacturer part numbers. 16 parts are marked as superseded — the description gives the replacement number to order instead.

The rating plate is inside the exterior access door, usually on the left of the burner area. Suburban model numbers encode capacity and ignition (e.g. SW6DE = 6 gal, DSI, electric); the serial number dates the board and thermostat generation.

Exploded View

Components

75 items

1. #Ignition Control Circuit Board - Quiet Start - Fits Suburban Water Heaters MFR # 520814MC
2. #Water Heater Control Circuit Board Cover; For Suburban Water Heater 520814 (After Serial Number 953900766) MFR # 90487
3. #APPLIANCE COMPONENTS RV; Bushing Snap 1/2" MFR # 70270
4. #APPLIANCE COMPONENTS RV; Jct Box Dc MFR # 90517
5. #Water Heater Flue Box; For Suburban Water Heater SW-10DEL/ SW-12DEL/ SW-16DEL/ SW-3P/ SW-4D/ SW-4P/ SW-6D/ SW-6DE/ SW-6DEL/ SW-6DEM/ SW-6DM/ SW-6P/ SW-6PE/ SW-6PER/ SW-6PR; With Flue Box Back Only MFR # 101682
6. #APPLIANCE COMPONENTS RV; Front Flue Collector MFR # 101607
7. #APPLIANCE COMPONENTS RV; Front Flue Collector MFR # 101776
8. #APPLIANCE COMPONENTS RV; T&P Valve MFR # 161157
9. #CAMCO T & P VALVE 3/4IN W/ 4IN PROBE COATED, 150PSI, BULK MFR # 10471
10. #Water Heater Pressure Relief Valve; For Suburban All SW And V Series; 3/4 Inch Male NPT; Also Use New Number 525045 MFR # 161230 Superseded: see description
11. #Water Heater Pressure Relief Valve; For Suburban All SW And V Series; 3/4 Inch Male NPT MFR # 525045
12. #Screw; Furnace Blower Screw; #10 x 1/4 Inch; Single MFR # 121577
13. #Water Heater Thermostat Cover; Replacement For Suburban Water Heater Thermostat/ Limit Switch; Also Use New Number 525022 MFR # 90562 Superseded: see description
14. #Water Heater Thermostat Cover Gasket; For Suburban SW Series Water Heater MFR # 70987
15. #Water Heater Thermostat Access Plug; For Suburban Water Heater Thermostat; Black; Single; Also Use New Number 525027 MFR # 70874 Superseded: see description
16. #Furnace Ignition Electrode Bracket; For Suburban SW-Series Water Heater MFR # 63187
17. #Water Heater Electrode; For Suburban SW-Series Water Heater; 2-Prong; Also Use New Number 525005 MFR # 232258 Superseded: see description
18. #Water Heater Electrode; For Suburban SW-Series Water Heater; 2-Prong MFR # 232258MC
19. #Water Heater Element Cover; For Suburban SW-Series Water Heaters; With Gasket MFR # 090681
20. #Water Heater Element Cover; For Suburban SW-Series Water Heaters; Also Use New Number 090681 MFR # 70988 Superseded: see description
21. #Water Heater Burner Mounting Bracket; Replacement For Suburban Water Heaters MFR # 063827
22. #Water Heater Burner; For Use With Suburban Direct Spark Ignition Water Heater MFR # 011030 Superseded: see description
23. #Water Heater Burner; For Suburban 6 Gallon Water Heater SW-Series (After Serial Number 953401118All)/ 10 Gallon SW-Series (After Serial Number 953601021); With Orifice; Also Use New Number 525023 MFR # 10843 Superseded: see description
24. #Water Heater Burner Orifice; For Use With Suburban Direct Spark Ignition Water Heater Gas Valve Part Number 161255; Number 61 MFR # 180323 Superseded: see description
25. #APPLIANCE COMPONENTS RV; Element Heating 1500W 12 MFR # 520571
26. #APPLIANCE COMPONENTS RV; 1000W Element MFR # 520570
27. #Water Heater Element; Screw-In; 1440 Watt; 110 Volt; With Gasket MFR # 520789
28. #Water Heater Element; For Use WIth Suburban SW Series Water Heaters; Screw-In; 1440 Watt; 120 Volt; With Gasket MFR # 520900 Superseded: see description
29. #Water Heater Anode Rod; For Suburban Aluminum Water Heaters; 9 Inch Length x 3/4 Inch Pipe Thread; Magnesium; Also Use New Number 233514 MFR # 232767 Superseded: see description
30. #Water Heater Anode Rod; For Suburban Aluminum Water Heaters; 9 Inch Length x 3/4 Inch Pipe Thread; Magnesium MFR # 233514
31. #Water Heater Anode Rod; For Suburban Aluminum Water Heaters; 9 Inch Length x 3/4 Inch Pipe Thread; Aluminum MFR # 232768
32. #ANODE 9.5'X.75' MPT BULK LDFRE MFR # 69717
33. #APPLIANCE COMPONENTS RV; GROMMET MFR # 71246
34. #Water Heater Element Switch; For Suburban Water Heater SW10PE/ SW10PER MFR # 232362
35. #Water Heater Gas Inlet Elbow; For Suburban Water Heater SW4-D; 90 Degree; Also Use New Number 525025 MFR # 170374 Superseded: see description
36. #Water Heater Gas Inlet Elbow; For Suburban Water Heater SW4-D; 90 Degree; 3/8 Inch; Single MFR # 525025
37. #Water Heater Gas Valve Mounting Bracket; For Suburban Water Heater SW4-D MFR # 63243
38. #Water Heater Gas Valve Mounting Bracket; For Use With Suburban Gas Valve Part Number 161255 MFR # 063779 Superseded: see description
39. #Water Heater Gas Valve; For Use With Suburban Direct Spark Ignition Water Heater; -3/8 Inch NPT Inlet; 1/8 Inch 27 NPT Outlet; 12 Volt DC MFR # 161306 Superseded: see description
40. #Water Heater Gas Valve; For Suburban Water Heater (From Serial Number 92110443 To 953401118); 3/8 Inch NPT Inlet x 3/8 Inch NPT Outlet MFR # 161071
41. #Water Heater Gas Valve; For Use With Suburban Direct Spark Ignition Water Heater; -3/8 Inch NPT Inlet; 1/8 Inch 27 NPT Outlet; 12 Volt DC; Also Use New Number 161306 MFR # 161255 Superseded: see description
42. #Gas Valve Solenoid; White Rodgers; Fits To Suburban Water Heater Gas Valve 161109; 0.48 Amp/ 12 Volt DC; Maximum 1/2 PSI; With 2 Solenoids/ 2 Wire Ties/ Instructions MFR # 521072
43. #Water Heater Gas Valve; For Suburban 6 Gallon SW-Series Water Heater; 3/8 Inch NPT Inlet x 1/4 Inch Loxit Outlet; Also Use New Number 525042 MFR # 161109 Superseded: see description
44. #Gas Valve Solenoid; Seven Universe; Fits To Suburban Water Heater Gas Valve 161109; 0.48 Amp/ 12 Volt DC; Maximum 1/2 PSI; With 2 Solenoids/ 2 Wire Ties/ Instructions MFR # 521073
45. #Water Heater Manifold Outlet; For Suburban Water Heater DSI Models SW6D/ SW10D (After Serial Number 953401118); Fits Unit With A Pilot MFR # 171420
46. #Screw; For Suburban Water Heater SW4D/ SW6D/ SW6DE/ SW6DEM/ SW6DM/ SW16D/ SW16DE/ SW16DEM/ SW6DEL/ SW10DEL/ SW12DEl/ SW16DEL/ SW16V/ SW16VE; #8-32 x 3/8 Inch; Hex Slot MFR # 121958
47. #Water Heater Thermostat Switch; For SW Series Suburban Water Heater; Hi-Limit; 12 Volt; With Reset Switch; 130 Degree MFR # 232282
48. #Water Heater Thermostat Switch; For Suburban Water Heater (After Serial Number 940900091); Limit; 120 Volt; Without Reset Switch; 130 Degree MFR # 232306
49. #Water Heater Thermostat Switch - Fits Suburban Water Heaters MFR # 232306MC
50. #APPLIANCE COMPONENTS RV; COV JCT BOX MFR # 90576
51. #Water Heater Gas Line Grommet; For Suburban Water Heater SW4D/ SW6D/ SW6DE MFR # 70989
52. #APPLIANCE COMPONENTS RV; BUSHING SNAP MFR # 231827
53. #APPLIANCE COMPONENTS RV; Bushing Snap 7/8" MFR # 230218
54. #Nut; Replacement For Suburban SW4D Model Water Heaters; Keps; 6 Point; #10 - 24; Green MFR # 121576
55. #Water Heater Insulation; For 6 Gallon Suburban Water Heater SW6D/ SW6DE; With Banding Kit MFR # 520868
56. #Water Heater Power Switch; For Suburban Gas-Electric Water Heaters; Wall Mounted MFR # 232881
57. #Water Heater Power Switch; For Suburban Gas-Electric Water Heaters; Wall Mount; White; With Reset Button MFR # 232882
58. #Water Heater Power Switch; For Suburban Water Heater; Wall Mount; Black; With Reset Button MFR # 233111
59. #Screw; For Suburban Water Heater SW4D/ SW6D/ SW6DE; 8 Milimeter-4 x 1/2 Hex; Hex Head MFR # 121943
60. #APPLIANCE COMPONENTS RV; Brkt Burner MFR # 63444
61. #Water Heater Manifold Outlet Connector; For Suburban Water Heater SW-Series; 1/4 Inch NPT; Brass; Single; Also Use New Number 525030 MFR # 171463 Superseded: see description
62. #Water Heater Relay - Fits Suburban Water Heaters SW6DEL/SW10DEL/SW12DEL/SW16DEL MFR # 232948MC
63. #Water Heater Relay; For Suburban Water Heater SW6DEL/ SW10DEL/ SW12DEL/ SW16DEL MFR # 232948
64. #Water Heater Access Door; For Suburban 4/ 6 Gallon Water Heater; Flush Mount; Polar White; Galvanized Steel MFR # 6255APW
65. #Water Heater Access Door; For Suburban 6 Gallon Water Heater; Flush Mount; Black; With Hinge/ Door Latch/ Mounting Hardware MFR # 6255AEB
66. #Water Heater Access Door Grille; Water Heater Door Screen; For Suburban 6 Gallon Standard Water Heater; 7 Inch Width x 6 Inch Length MFR # 030742
67. #Water Heater Access Door; For Suburban 6 Gallon Water Heater; Standard; Polar White; Galvanized Steel MFR # 6261APW
68. #Water Heater Access Door; For Suburban 6 Gallon Water Heater; Polar White; With Flange Kit 520781/ Two Filler Flange MFR # 520787
69. #Water Heater Access Door; For Suburban 4/ 6 Gallon Water Heater; Flush Mount; Colonial White; Galvanized Steel MFR # 6255ACW
70. #APPLIANCE COMPONENTS RV; Clip Latch MFR # 062920
71. #Water Heater Access Door; For Suburban 6 Gallon Water Heater; Standard; Colonial White; Galvanized Steel MFR # 6261ACW
72. #NOT AVAILABLE MUST REPLACE WATER HEATER MFR # INNERTANK
73. #Water Heater Access Door Grille; Water Heater Door Screen; For Suburban 6 Gallon Standard Water Heater; 6-1/4 Inch Width x 6-1/2 Inch Length; Flush Mount MFR # 030747
74. #Water Heater Access Door; For Suburban Water Heater 4 Gallon Or 6 Gallon; Tough Black; Corrosion-Resistant Steel; With Water Heater Mounting Flange MFR # 6261AEB
75. #Water Heater Electrode Wire; For Suburban Water Heater SW4D/ SW6D/ SW6DE; With Boot And Spade Connector MFR # 232456

Replacement Water Heater

Components

12 items

1. #Water Heater; Gas-Electric; Model Number SW6DEL; 6 Gallon Tank; Electronic Ignition; 1440 Watts; 12000 BTU; 12.69 Inch Width x 12.69 Inch Height x 19.19 Inch Depth; With 120 Volt AC Element And Gasket/ 12 Volt DC Relay; Non Portable MFR # 5240A
2. #Water Heater; Gas-Electric; Model Number SW6DEL; 6 Gallon Tank; Electronic Ignition; 1440 Watts; 12000 BTU; 16-7/32 Inch Width x 16-7/32 Inch Height x 22-1/4 Inch Depth; With Pressure Relief Valve/ Electrode/ Burner Assembly/ 120 Volt AC Element And Gasket/ Anode Rod/ 12 Volt DC Thermostat Hi-Limit Switch/ Ignition Lead/ 120 Volt AC Thermostat Hi-Limit Switch/ Relay/ Element Switch; Non Portable MFR # 5129A
3. #Water Heater Power Switch; For Suburban Gas-Electric Water Heaters; Wall Mount; White; With Reset Button MFR # 232882
4. #Water Heater Power Switch; For Suburban Water Heater; Wall Mount; Black; With Reset Button MFR # 233111
5. #Water Heater Access Door; For Suburban 4/ 6 Gallon Water Heater; Flush Mount; Colonial White; Galvanized Steel MFR # 6255ACW
6. #Water Heater Access Door; For Suburban 6 Gallon Water Heater; Standard; Colonial White; Galvanized Steel MFR # 6261ACW
7. #Water Heater Access Door; For Suburban 4/ 6 Gallon Water Heater; Flush Mount; Polar White; Galvanized Steel MFR # 6255APW
8. #Water Heater Access Door; For Suburban 6 Gallon Water Heater; Flush Mount; Black; With Hinge/ Door Latch/ Mounting Hardware MFR # 6255AEB
9. #Water Heater Access Door;;For Suburban 6 Gallon Water Heater; Polar White; With Flange Kit 520781/ MFR # SBB520818
10. #Water Heater Access Door; For Suburban Water Heater 4 Gallon Or 6 Gallon; Tough Black; Corrosion-Resistant Steel; With Water Heater Mounting Flange MFR # 6261AEB
11. #Water Heater Access Door;;For Suburban 6 Gallon Water Heater; White; With Flange 520781/ Standard M MFR # SBB520787
12. #Water Heater Access Door; For Suburban 6 Gallon Water Heater; Standard; Polar White; Galvanized Steel MFR # 6261APW
