Coleman Mach 3 48203C8665 Roughneck Parts Diagram

Air Conditioner · 1 diagram sheet · 31 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagram for the Coleman Mach 3 48203C8665 Roughneck rooftop air conditioner: 31 manufacturer part numbers. 4 parts are marked as superseded — the description gives the replacement number to order instead.

On rooftop units the model and serial plate is under the shroud on the base pan, and a second label usually sits on the ceiling assembly behind the return-air grille. Dometic model numbers are 8 digits (e.g. 57915.xxx); write down the full number including any suffix, because shrouds and control boards change with it.

Exploded View

Components

31 items

1. #SCREWS PKG OF 4 MFR # 67925111
2. #SHROUD ARCTIC WHITE MFR # 8335A5261
3. #APPLIANCE COMPONENTS RV; SNUBBER, COMPRESSOR MFR # 67703011
4. #TOP BRACE ASSEMBLY MFR # 48203-550
5. #Air Conditioner Compressor Mounting Hardware; Replacement For Coleman 48203C8665/ 48203C8695 Model Air Conditioners; Clamp; Single MFR # 48203-301
6. #Air Conditioner Compressor Overload Protector; For Use With Coleman Mach 8 Series Air Conditioners MFR # 14500321 Superseded: see description
7. #Air Conditioner Compressor; For Use With Coleman Mach 3 Plus EZ Series Air Conditioners MFR # 1450-4209 Superseded: see description
8. #A/C COMPONENTS RV; COMPRESSOR MOUNTING PACKAGE MFR # 8333-3081
9. #MOUNTING PLATE MFR # 8333-115
10. #SRO MOTOR PKG MFR # 1468A3069
11. #Coleman Mach Air Conditioner Heat Pump Reversing Valve Solenoid Coil MFR # 67333221
12. #Cooling Fan Shroud; For Use With Coleman Mach Air Conditioners; Silver MFR # 67921071 Superseded: see description
13. #A/C COMPONENTS RV; CONDENSER COIL PACKAGE MFR # 1452-2071
14. #GASKET KIT 14 X 14 MFR # 83323301
15. #A/C COMPONENTS RV; BASEPAN/SCROLL PACKAGE MFR # 8433-5011
16. #CAP TUBE MFR # 48203B135
17. #COPPER TEE MFR # 1454-305
18. #APPLIANCE COMPONENTS RV; Drain Hose MFR # 48203C131
19. #SUCTION LINE MFR # 48203B130
20. #CAPACITOR RUN MFR # 14995761
21. #CAPACITOR FAN MFR # 14995461
22. #Air Conditioner Wiring Harness; For Use With Coleman 7632A896/ 7333B888 Model Air Conditioners MFR # 8333B3751 Superseded: see description
23. #IMPELLER PKG MFR # 14721091
24. #SCROLL BLOCK MFR # 8333-325
25. #Air Conditioner Drain Pan; Replacement For Coleman Mach 48204/ 48254/ 48253/ 48004/ 48014/ 48204 Model Air Conditioner MFR # 8335A3501
26. #APPLIANCE COMPONENTS RV; Door Wire Box MFR # 8333109
27. #SIDE PANEL (LEFT) MFR # 8333-507
28. #APPLIANCE COMPONENTS RV; Bracket Shroud (Req 3) MFR # 8333B1551
29. #Air Conditioner Evaporator Cover; Replacement For Coleman Mach 48254/ 48207/ 48213/ 48004/ 48008/ 48058/ 8535/ 8534/ 48204/ 48208/ 8333 Model Air Conditioner; Center Panel MFR # 8333A5061
30. #SIDE PANEL (RIGHT) MFR # 8333-505
31. #EVAPORATOR COIL MFR # 1452-2081
