Coleman Park Model 46413-812 24V Parts Diagram · Exploded View › Sn Beginning W1501 & Higher

Air Conditioner · 2 assemblies · 2 diagram sheets · 64 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Coleman Park Model 46413-812 24V rooftop air conditioner: 2 assemblies (Exploded View › Sn Beginning W1501 & Higher, Exploded View › Sn Beginning W1501 & Lower) and 64 manufacturer part numbers. 3 parts are marked as superseded — the description gives the replacement number to order instead.

On rooftop units the model and serial plate is under the shroud on the base pan, and a second label usually sits on the ceiling assembly behind the return-air grille. Dometic model numbers are 8 digits (e.g. 57915.xxx); write down the full number including any suffix, because shrouds and control boards change with it.

Exploded View › Sn Beginning W1501 & Higher

Components

49 items

1. #TOP W/INSULATION MFR # 6633602
2. #BLOCK,SCROLL TOP MFR # 6633325
3. #DOOR, BLOWER PAINTED MFR # 6633393
4. #BLOCK,SCROLL SIDE MFR # 6633326
5. #PANEL,END W/INSULATION MFR # 6633608
6. #BULKHEAD MFR # 6633A603
7. #COVER, ELECTRIC BOX PAINTED MFR # 6633390
8. #FILLER PLATE (PAINTED) MFR # 6633399
9. #BASEPAN, PAINTED MFR # 6633A601
10. #BULKHEAD,OUTDOOR MFR # 6633A104
11. #CORNER PANEL (PAINTED) MFR # 6633395
12. #CORNER POST (PAINTED) MFR # 6633396
13. #GRILL, PAINTED MFR # 6633402
14. #BACK PANEL (PAINTED) MFR # 6633397
15. #ID BLOWER MOTOR (PKGD) MFR # 1468A3129
16. #MOUNT,MOTOR USE 6795A3021 MFR # 67953021 Superseded: see description
17. #APPLIANCE COMPONENTS RV; MOUNT,MOTOR MFR # 6795A3021
18. #Air Conditioner Condenser Fan Motor Service Kit; Replacement For All The Models Of Coleman Mach Air Conditioner; With Grommet/ Washer MFR # 6795A3031
19. #I.D. BLOWER VENTURI MFR # 6795151
20. #SCROLL,BLOWER MFR # 6633520
21. #Air Conditioner Blower Wheel; For Use With All The Models Of Coleman Mach Air Conditioner; Indoor Air Blower Wheel MFR # 14721021 Superseded: see description
22. #EVAPORATOR COIL MFR # 1452A157
23. #PLATE,BLOCK OFF MFR # 6633111
24. #BRACKET,PAN MFR # 6633112
25. #PAN,DRAIN MFR # 6633350
26. #Air Conditioner Condenser; Replacement For Coleman 46413-812 Series Air Conditioner MFR # 14521791
27. #APPLIANCE COMPONENTS RV; Od Motor Grommet Pkg. MFR # 12120361
28. #OUTDOOR MOTOR MOUNT MFR # 6633A3011
29. #MOTOR OUTSIDE MFR # 14683189
30. #Air Conditioner Compressor; Replacement For Coleman 48203-8666 Series Air Conditioners With Serial Number Beginning 1501 And Later MFR # 14504219
31. #Air Conditioner Compressor Mounting Hardware; Replacement For Coleman Mach 6746A/ 6749/ 7330/ 6757/ 6759/ 6770D/ 6701B/ 6759B Model Air Conditioner MFR # 67593081
32. #SUCTION LINE MFR # 46413A130
33. #DISCHARGE LINE MFR # 46413A131
34. #WIRING & SERVICE ACCESSORYS RV; LIQUID LINE ASSEMBLEY/FILTER MFR # 46413535
35. #APPLIANCE COMPONENTS RV; CAPILLARY TUBE MFR # 46413135
36. #Air Conditioner Capacitor; For Use With Coleman Air Conditioners; Run Capacitor; 370 Volts AC; 7.5 MFD MFR # 14995471 Superseded: see description
37. #Air Conditioner Capacitor; Run Capacitor; Replacement For Coleman Models 67 MFR # 14995421
38. #CAPACITOR RUN MFR # 14995761
39. #GROUND LUG MFR # 1216228
40. #TERMINAL BOARD MFR # 6331322
41. #TRANSFORMER MFR # 14603521
42. #Air Conditioner Relay; For Coleman Mach 46413 Model Air Conditioner MFR # 1460A1061
43. #RELAY COMPRESSOR MFR # 14601171
44. #RELAY BRACKET MFR # 6633115
45. #BLADE FAN MFR # 1472A5011
46. #OVERLOAD MFR # 14600241
47. #HIGH PRESSURE SWITCH MFR # 464135321
48. #DUCT CONN F/PARK MODEL MFR # 66336151
49. #DRAIN TUBE MFR # 46413520

Exploded View › Sn Beginning W1501 & Lower

Components

51 items

1. #TOP W/INSULATION MFR # 6633602
2. #BLOCK,SCROLL TOP MFR # 6633325
3. #DOOR,BLOWER MFR # 6633113
4. #BLOCK,SCROLL SIDE MFR # 6633326
5. #PANEL,END W/INSULATION MFR # 6633608
6. #BULKHEAD MFR # 6633A603
7. #COVER,ELECTRIC BOX MFR # 6633110
8. #FILLER PLATE (PAINTED) MFR # 6633399
9. #BASEPAN MFR # 6633B501
10. #BULKHEAD,OUTDOOR MFR # 6633104
11. #CORNER PANEL (PAINTED) MFR # 6633395
12. #CORNER POST (PAINTED) MFR # 6633396
13. #GRILL MFR # 6633A302
14. #BACK PANEL (PAINTED) MFR # 6633397
15. #ID BLOWER MOTOR (PKGD) MFR # 1468A3129
16. #APPLIANCE COMPONENTS RV; MOUNT,MOTOR MFR # 6795A3021
17. #MOUNT,MOTOR USE 6795A3021 MFR # 67953021 Superseded: see description
18. #Air Conditioner Condenser Fan Motor Service Kit; Replacement For All The Models Of Coleman Mach Air Conditioner; With Grommet/ Washer MFR # 6795A3031
19. #I.D. BLOWER VENTURI MFR # 6795151
20. #SCROLL,BLOWER MFR # 6633520
21. #Air Conditioner Blower Wheel; For Use With All The Models Of Coleman Mach Air Conditioner; Indoor Air Blower Wheel MFR # 14721021 Superseded: see description
22. #EVAPORATOR COIL MFR # 14521811
23. #PLATE,BLOCK OFF MFR # 6633111
24. #BRACKET,PAN MFR # 6633112
25. #PAN,DRAIN MFR # 6633350
26. #Air Conditioner Condenser; Replacement For Coleman 46413-812 Series Air Conditioner MFR # 14521791
27. #APPLIANCE COMPONENTS RV; Od Motor Grommet Pkg. MFR # 12120361
28. #OUTDOOR MOTOR MOUNT MFR # 6633A3011
29. #MOTOR OUTSIDE MFR # 14683189
30. #COMPRESSOR (TECUMSEH) MFR # 14504029
31. #Air Conditioner Compressor Mounting Hardware; Replacement For Coleman Mach 6746A/ 6749/ 7330/ 6757/ 6759/ 6770D/ 6701B/ 6759B Model Air Conditioner MFR # 67593081
32. #SUCTION LINE MFR # 46413130
33. #DISCHARGE LINE MFR # 46413131
34. #LIQUID LINE MFR # 6633132
35. #CAP TUBE MFR # 46413133
36. #Air Conditioner Capacitor; For Use With Coleman Air Conditioners; Run Capacitor; 370 Volts AC; 7.5 MFD MFR # 14995471 Superseded: see description
37. #Air Conditioner Capacitor; Run Capacitor; Replacement For Coleman Models 67 MFR # 14995421
38. #Air Conditioner Capacitor; Hard Start Kit; Replacement For Coleman 46413/ 48203/ 48204/ 48207/ 48208/ 48213/ 48253/ 48254/ 48257/ 48263/ 48264/ 48268/ 6633/ 6636/ 7333/ 7633/ 8333/ 8335/ 8433/ 8534/ 8535/ 8632/ 8633/ 9013/ 9021/ 9031/ 9201/ 9202/ 9232/ 6799/ 46515/ 48004/ 48008/ 48014/ 48058/ 48064/ 48068/ 6535/ 6537/ 8534/ 8535/ 9001/ 9002/ 9003/ 9013/ 9014/ 9022/ 9023/ 9024/ 9032/ 9033/ 9034 Model Air Conditioner; 88-108 MicroFarad; With Capacitor/ PTCR (Positive Temperature Co-Efficient Resistor)/ Bracket/ Wires MFR # 8333a-9021c
39. #Coleman Mach 8 Thermostat 12V Heat/Cool Single Stage MFR # 8333A9021
40. #CAPACITOR RUN MFR # 14995721
41. #GROUND LUG MFR # 1216228
42. #TERMINAL BOARD MFR # 6331322
43. #TRANSFORMER MFR # 14603521
44. #Air Conditioner Relay; For Coleman Mach 46413 Model Air Conditioner MFR # 1460A1061
45. #RELAY COMPRESSOR MFR # 14601171
46. #RELAY BRACKET MFR # 6633115
47. #BLADE FAN MFR # 1472A5011
48. #OVERLOAD MFR # 14600511
49. #HIGH PRESSURE SWITCH MFR # 464135321
50. #DUCT CONN F/PARK MODEL MFR # 66336151
51. #DRAIN TUBE MFR # 46413520
