Diagrams › Dometic › Brisk Air 57915622 13,500 BTU Dometic Brisk Air 57915622 13,500 BTU Parts Diagram · Adb # 3107210019
Air Conditioner · 16 assemblies · 16 diagram sheets · 248 parts · by Andrew Strick, mobile RV technician
OEM exploded parts diagrams for the Dometic Brisk Air 57915622 13,500 BTU rooftop air conditioner: 16 assemblies (Adb # 3107210019, Adb # 3107206017, Analog T-stat Kit / S, Center, Comfort Control, Adb # 3107206009 and more) and 248 manufacturer part numbers. 77 parts are marked as superseded — the description gives the replacement number to order instead.
On rooftop units the model and serial plate is under the shroud on the base pan, and a second label usually sits on the ceiling assembly behind the return-air grille. Dometic model numbers are 8 digits (e.g. 57915.xxx); write down the full number including any suffix, because shrouds and control boards change with it.
Adb # 3107210019
Dometic Brisk Air 57915622 13,500 BTU adb # 3107210019 — parts list sheet Full-resolution diagram + every part number →
Components 32 items # Air Conditioner Filter; Use With Duo-Therm/Dometic Air Conditioners; 16 Inch x 11-3/4 Inch MFR # 457722 Superseded: see description # APPLIANCE COMPONENTS RV; Parts Bag Polar White MFR # 3107194015 # SCREW (3 REQ.) MFR # 307987001 # DECAL, FIELD WIRING MFR # 3106515004 # TEMPLATE, CEILING (SW) MFR # 3107193009 # PLATE, ESCUTCHEON MFR # 3107217006 # PLATE, RELAY KIT MFR # 3107575007 # DECAL FIELD WIRING MFR # 3107764007 # APPLIANCE COMPONENTS RV; Duct Upper MFR # 316450000 # ATTACHMENT TAPE GREY-EACH MFR # 06384 # APPLIANCE COMPONENTS RV; Parts Bag Asm Shell White MFR # 3107194007 # Air Conditioner Filter; Use With Dometic RV Air Conditioners; MERV 6 Rating; 13-1/2 Inch Length x 7.375 Inch Width x 3/4 Inch Depth; Removes Dust/ Pollen/ Pet Dander MFR # AC105G Superseded: see description # DUCT,DISCHARGE USE 316450000 MFR # 316450 Superseded: see description # AIRBOX,COMPLETE SHELL WHITE MFR # 3107210001 # FILTER RETURN AIR(UNIVER MFR # 3108015003 # FILTER,AIR USE 3108015003 MFR # 3107190005 Superseded: see description # SPACER, FIBER MFR # 3105677011 # Air Conditioner Filter; Use With DV8 Air Conditioners; Also Use New Part Number 457722 MFR # 2401175 Superseded: see description # APPLIANCE COMPONENTS RV; Airbox Complete Polar Whi MFR # 3107210019 # SCREW 8-18 X .625 MFR # 312096004 # APPLIANCE COMPONENTS RV; Bolt Mounting Use 331151 MFR # 3106756012 Superseded: see description # Screw; For Use With Dometic Air Conditioner Ceiling Assembly; 1/4 Inch-20 x 7 Inch Length; Hex; Pack Of 4 MFR # 3311511000 Superseded: see description # APPLIANCE COMPONENTS RV; Plug Hole Shell White MFR # 3104931005 # APPLIANCE COMPONENTS RV; Connector Cable MFR # 20010000 # GRILLE, RETURN USE 3313107034 PLR WHT MFR # 3107053005 Superseded: see description # GRILLE RETURN AIR SVC KIT MFR # 3313107034 # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650000 # AWNING-REPAIR PARTS RV; Extension Lower Duct MFR # 313605003 # FOAM TAPE (22.5" REQ.) SHELL WHITE MFR # 3107890 # LOUVER ASM MFR # 3107189007 # APPLIANCE COMPONENTS RV; Shell Airbox Polar White MFR # 3107188033 # APPLIANCE COMPONENTS RV; Shell Airbox Shell White MFR # 3107188025
Adb # 3107206017
Dometic Brisk Air 57915622 13,500 BTU adb # 3107206017 — parts list sheet Full-resolution diagram + every part number →
Components 32 items # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650000 # SWITCH,POSITION ROTARY ***USE 49-9715*** MFR # 3105273001 Superseded: see description # FILTER,AIR USE 3108015003 MFR # 3107190005 Superseded: see description # Screw; For Use With Dometic Air Conditioner Ceiling Assembly; 1/4 Inch-20 x 7 Inch Length; Hex; Pack Of 4 MFR # 3311511000 Superseded: see description # APPLIANCE COMPONENTS RV; Connector Cable MFR # 20010000 # SCREW,16-24X.38 PCR MFR # 317224001 # Air Conditioner Filter; Use With Dometic RV Air Conditioners; MERV 6 Rating; 13-1/2 Inch Length x 7.375 Inch Width x 3/4 Inch Depth; Removes Dust/ Pollen/ Pet Dander MFR # AC105G Superseded: see description # APPLIANCE COMPONENTS RV; Bolt Mounting Use 331151 MFR # 3106756012 Superseded: see description # Air Conditioner Ceiling Assembly Service Kit; Replacement For Dometic 579/ 590/ 591/ 595/ 600/ 630015 Series Air Conditioners; Press On; Round; Polar White MFR # 3104931013 # SCREW 8-18 X .625 MFR # 312096004 # Air Conditioner Ceiling Assembly Rotary Switch; For Dometic 3314851.000 Series Ceiling Assembly; On-Off And Fan Speed Control; 8 Position Switch; Without Knob; Single MFR # 3313107025 # ATTACHMENT TAPE GREY-EACH MFR # 06384 # GRILLE RETURN AIR SVC KIT MFR # 3313107034 # GRILLE, RETURN USE 3313107034 PLR WHT MFR # 3107053005 Superseded: see description # Air Conditioner Ceiling Assembly Thermostat; Replacement For Dometic Duo-Therm Manual Air Conditioner Ceiling Assembly MFR # 3313107000 # T-STAT USE 3313107000 MFR # 3100781008 Superseded: see description # Air Conditioner Ceiling Assembly; For Duo-Therm Air Conditioner Brisk Air Model 57915622; Non-Ducted System; With Manual Control MFR # 3107188017 # LOUVER ASM MFR # 3107189007 # APPLIANCE COMPONENTS RV; Box Control MFR # 3107196002 # CAP, CONN HOUSING MFR # 3106624012 # APPLIANCE COMPONENTS RV; Duct Upper MFR # 316450000 # CAP, CONN. HOUSING (3-POLE) MFR # 3106624004 # Air Conditioner Ceiling Assembly Control Knob; For Dometic Duo-Therm Air Conditioners; Set Of 2 MFR # 3313107024 # Refrigerator Power Cord Strain Relief Bushing; Use With Duo-Therm Air Conditioner Basement Model 39115601 MFR # 302994002 Superseded: see description # RELIEF,STRAIN USE 302994002 MFR # 32994002 Superseded: see description # APPLIANCE COMPONENTS RV; Knob Control MFR # 3107052007 # BOX,JUNCTION MFR # 3107220018 # APPLIANCE COMPONENTS RV; Parts Bag Polar White MFR # 3107194015 # BOX,JUNCTION USE 3107220018 MFR # 3104154004 Superseded: see description # COVER , CONTROL BOX MFR # 308146000 # DEACAL, FIELD WIRING MFR # 3105024008 # BOX, CONTROL MFR # 3105027035
Analog T-stat Kit / S
Dometic Brisk Air 57915622 13,500 BTU analog t-stat kit / s — parts list sheet Full-resolution diagram + every part number →
Components 20 items # Air Conditioner Control Box Assembly; For Dometic Duo-Therm Air Conditioner; With Heat/ Cool Wall Thermostat MFR # 3107541009 # A/C COMPONENTS RV; CTRL KIT, CT STD-C/F-BLK MFR # 3316230714 # Wall Thermostat; Single Zone; Cool/ Furnace; Programmable; LCD Display; 12 Volt DC; With Low/ High/ Auto Fan Speed Control; With Auto/ On Mode Fan Control; Polar White; With Control Board; Also Use New Number 3316230.700 MFR # 3316230000 Superseded: see description # T-STAT,H/C USE 46-4105 MFR # F7251 Superseded: see description # Wall Thermostat; Single Zone; For Cool/ Furnace Control; Programmable; LCD Readout; 12 Volt DC; With High/ Low/ Auto Fan Speed Control; White Case MFR # 3313192000 # Wall Thermostat; For Cool/ Furnace Control; Programmable; LCD Readout; 12 Volt DC; With High/ Low/ Auto Fan Speed Control; White Case; WIth Control Box MFR # 3313189000 # CONTROL KIT,ANALOG USE 46-4225 (10) HEAT/COOL MFR # F7431 Superseded: see description # Wall Thermostat; For Cool/ Furnace Control; Programmable; LCD Readout; 12 Volt DC; With High/ Low/ Auto Fan Speed Control; Black Case; With Control Box MFR # 3313189015 # Wall Thermostat; Heat/ Cool Modes; Analog Type MFR # 3106995032 # Wall Thermostat; Single Zone; Cool/ Furnace/ Heat Strip; Programmable; LCD Display; 12 Volt DC; With Low/ High/ Auto Fan Speed Control; With Auto/ On Mode Fan Control; Polar White; With Control Board MFR # 3316232000 # APPLIANCE COMPONENTS RV;;Control Kit Lcd Cool/Fu MFR # 3313189049 # CONTROL KIT,ANALOG HT/COOL/HS ***USE 50-0775*** MFR # 3107541017 Superseded: see description # CONTROL KIT,(10)USE 46-4226 ANALOG HEAT/COOL/HS MFR # F7239 Superseded: see description # null MFR # 3107546008 # APPLIANCE COMPONENTS RV; Board Kit Relay MFR # 3106997020 # APPLIANCE COMPONENTS RV; Board Control MFR # 3106997012 # Air Conditioner Relay; Use With Dometic Duo-Therm Air Conditioner And Cool/ Furnace Thermostat MFR # 3106997004 Superseded: see description # BOARD KIT,RELAY(10)USE 46-4114 MFR # F7003 Superseded: see description # APPLIANCE COMPONENTS RV; Bolt Mounting 1/4-20 X 8 MFR # 3106756020 # APPLIANCE COMPONENTS RV; Screw T 10-24X.50Phcr MFR # 312194002
Center, Comfort Control
Dometic Brisk Air 57915622 13,500 BTU center, comfort control — parts list sheet Full-resolution diagram + every part number →
Components 9 items # CONTROL,COLD USE3312303005 STAG# 49-8912 MFR # 3109409001 # BOARD,A/C POWER USE 3311557000 OR 49-8697 MFR # 3109229009 Superseded: see description # COMFORT CTRL MFR # 3106463007 # Air Conditioner Retrofit Kit; 5 Button Comfort Control Center Upgrade Kit; Polar White; With Control Box/ Operating Instructions MFR # 3310014000 # Air Conditioner Retrofit Kit; 4 To 5 Button Comfort Control Center Conversion Kit; Polar White; With Power Module Board/ Thermostat/ Freeze Sensor MFR # 3310009000 # Wall Thermostat; 5 Button; White MFR # 3109228001 # APPLIANCE COMPONENTS RV; CENTER,COMFORT CONTROL BL MFR # 3109228019 # Air Conditioner Retrofit Kit; Conversion Of 4-Button To 5-Button Comfort Control Center Conversion Kit MFR # 3310017003 # BOARD KIT CCC MFR # 3311557000
Adb # 3107206009
Dometic Brisk Air 57915622 13,500 BTU adb # 3107206009 — parts list sheet Full-resolution diagram + every part number →
Components 42 items # PLUG, FEMALE MFR # 314471000 # Air Conditioner Filter; Use With Duo-Therm/Dometic Air Conditioners; 16 Inch x 11-3/4 Inch MFR # 457722 Superseded: see description # SHELL,AIRBOX SHEL L WHITE MFR # 3104234004 # Air Conditioner Ceiling Assembly Thermostat; Replacement For Dometic Duo-Therm Manual Air Conditioner Ceiling Assembly MFR # 3313107000 # PLATE,COVER RV A/C SHELL WHITE MFR # 316659 # Screw; For Use With Dometic Air Conditioner Ceiling Assembly; 1/4 Inch-20 x 7 Inch Length; Hex; Pack Of 4 MFR # 3311511000 Superseded: see description # WELDMENT, JUNCTION BOX MFR # 3104161017 # Air Conditioner Filter; Use With DV8 Air Conditioners; Also Use New Part Number 457722 MFR # 2401175 Superseded: see description # APPLIANCE COMPONENTS RV; Knob Control MFR # 3107052007 # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650 # T-STAT USE 3313107000 MFR # 3100781008 Superseded: see description # Rivet; Replacement For Dometic Brisk Model Air Conditioner; Push/ Pull Rivet MFR # 3108700307 # APPLIANCE COMPONENTS RV; Connector Cable MFR # 20010000 # ATTACHMENT TAPE GREY-EACH MFR # 06384 # APPLIANCE COMPONENTS RV; Decal Air Box MFR # 3104083005 # Air Conditioner Filter; Use With Dometic RV Air Conditioners; MERV 6 Rating; 13-1/2 Inch Length x 7.375 Inch Width x 3/4 Inch Depth; Removes Dust/ Pollen/ Pet Dander MFR # AC105G Superseded: see description # SWITCH,ROTARY USE 20250 *N* MFR # 20250000 Superseded: see description # AIRBOX,COMPLETE USE 3107206009 SHELL WHITE MFR # 3105023000 Superseded: see description # APPLIANCE COMPONENTS RV; Box Control MFR # 3107196002 # BOLT,A/C USE 3106756012 MFR # 3100375058 Superseded: see description # FILTER,AC USE 3108015003 MFR # 308166 Superseded: see description # APPLIANCE COMPONENTS RV; Template MFR # 315427001 # Air Conditioner Ceiling Assembly Rotary Switch; For Dometic 3314851.000 Series Ceiling Assembly; On-Off And Fan Speed Control; 8 Position Switch; Without Knob; Single MFR # 3313107025 # SWITCH,POSITION ROTARY ***USE 49-9715*** MFR # 3105273001 Superseded: see description # LOUVER USE 310138 MFR # 310138000 Superseded: see description # KNOB, T-STAT USE 3107052007 2 REQUIRED MFR # 3100364011 Superseded: see description # Air Conditioner Ceiling Assembly Control Knob; For Dometic Duo-Therm Air Conditioners; Set Of 2 MFR # 3313107024 # FILTER RETURN AIR(UNIVER MFR # 3108015003 # SWITCH,POSITION USE 3105273001 ROTARY MFR # 3106077005 Superseded: see description # BOX,CONTROL USE 3107196002 MFR # 3105026029 Superseded: see description # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650000 # DOOR,RETURN AIR SHELL WHITE MFR # 3104071000 # RELIEF,STRAIN USE 302994002 MFR # 32994002 Superseded: see description # APPLIANCE COMPONENTS RV; Bolt Mounting Use 331151 MFR # 3106756012 Superseded: see description # CAP, CONN. HOUSING (6 POLE) MFR # 314471001 # BUSHING,SNAP-IN MFR # 301028040 # EXTENSION, DUCT MFR # 313606000 # AIRBOX,COMPLETE SHELL WHITE MFR # 3107206009 # APPLIANCE COMPONENTS RV; Parts Bag Shell White MFR # 3105043008 # APPLIANCE COMPONENTS RV; Switch Rotary Use 3106077 MFR # 20250 Superseded: see description # LOUVER ASM 2REQUIRED MFR # 310138 # Refrigerator Power Cord Strain Relief Bushing; Use With Duo-Therm Air Conditioner Basement Model 39115601 MFR # 302994002 Superseded: see description
Adb # 3105023018
Dometic Brisk Air 57915622 13,500 BTU adb # 3105023018 — parts list sheet Full-resolution diagram + every part number →
Components 54 items # APPLIANCE COMPONENTS RV; Box Control MFR # 3107196002 # BOX,CONTROL ASM USE 3105026029 MFR # 3105026011 Superseded: see description # APPLIANCE COMPONENTS RV; Knob Control MFR # 3107052007 # SHELL,AIRBOX SHEL L WHITE MFR # 3104234004 # APPLIANCE COMPONENTS RV; Parts Bag Shell White MFR # 3105043008 # KNOB, T-STAT USE 3107052007 2 REQUIRED MFR # 3100364011 Superseded: see description # DOOR,RETURN AIR SHELL WHITE MFR # 3104071000 # SWITCH,ROTARY USE 20250 *N* MFR # 20250000 Superseded: see description # DOOR,RETURN AIR PW WITH FILTER MFR # 3104071018 # SWITCH,POSITION USE 3105273001 ROTARY MFR # 3106077005 Superseded: see description # Air Conditioner Ceiling Assembly Rotary Switch; For Dometic 3314851.000 Series Ceiling Assembly; On-Off And Fan Speed Control; 8 Position Switch; Without Knob; Single MFR # 3313107025 # AIRBOX,COMPLETE USE 3104234004 MFR # 3104234020 Superseded: see description # Air Conditioner Ceiling Assembly Control Knob; For Dometic Duo-Therm Air Conditioners; Set Of 2 MFR # 3313107024 # APPLIANCE COMPONENTS RV; Switch Rotary Use 3106077 MFR # 20250 Superseded: see description # SWITCH,POSITION ROTARY ***USE 49-9715*** MFR # 3105273001 Superseded: see description # BOX,CONTROL USE 3107196002 MFR # 3105026029 Superseded: see description # BUSHING,SNAP-IN MFR # 301028040 # EXTENSION, DUCT MFR # 313606000 # Air Conditioner Filter; Use With Duo-Therm/Dometic Air Conditioners; 16 Inch x 11-3/4 Inch MFR # 457722 Superseded: see description # Air Conditioner Ceiling Assembly Thermostat; Replacement For Dometic Duo-Therm Manual Air Conditioner Ceiling Assembly MFR # 3313107000 # FILTER,AC USE 3108015003 MFR # 308166 Superseded: see description # FILTER RETURN AIR(UNIVER MFR # 3108015003 # T-STAT USE 3313107000 MFR # 3100781008 Superseded: see description # Air Conditioner Filter; Use With Dometic RV Air Conditioners; MERV 6 Rating; 13-1/2 Inch Length x 7.375 Inch Width x 3/4 Inch Depth; Removes Dust/ Pollen/ Pet Dander MFR # AC105G Superseded: see description # ATTACHMENT TAPE GREY-EACH MFR # 06384 # KIT SVC AIR FILTER MFR # 3313107103 # LOUVER USE 310138 MFR # 310138000 Superseded: see description # LOUVER ASM 2REQUIRED MFR # 310138 # CAP, CONN. HOUSING (6 POLE) MFR # 314471001 # PLUG, FEMALE MFR # 314471000 # RELIEF,STRAIN USE 302994002 MFR # 32994002 Superseded: see description # Rivet; Replacement For Dometic Brisk Model Air Conditioner; Push/ Pull Rivet MFR # 3108700307 # Refrigerator Power Cord Strain Relief Bushing; Use With Duo-Therm Air Conditioner Basement Model 39115601 MFR # 302994002 Superseded: see description # BOX,JUNCTION MFR # 3107220018 # BOX,JUNCTION USE 3107220018 MFR # 3104154004 Superseded: see description # APPLIANCE COMPONENTS RV; Decal Air Box MFR # 3104083005 # WELDMENT, JUNCTION BOX MFR # 3104161017 # COVER, CONTROL BOX COMPLETE SHELL WHITE MFR # 308146 # BOX, CONTROL COMPLETE POLAR WHITE MFR # 3105027019 # BOX, CONTROL COMPLETE SHELL WHITE MFR # 3105027001 # APPLIANCE COMPONENTS RV; Connector Cable MFR # 20010000 # BAG ASM., PARTS COMPLETE POLAR WHITE MFR # 3105615003 # AIRBOX,COMPLETE USE 3107206017 POLAR WHITE MFR # 3105023018 Superseded: see description # APPLIANCE COMPONENTS RV; Bolt Mounting Use 331151 MFR # 3106756012 Superseded: see description # Air Conditioner Ceiling Assembly; For Use With Duo-Therm 57908521 Model Air Conditioner; Manual; Polar White MFR # 3107206017 Superseded: see description # PLATE,COVER RV A/C SHELL WHITE MFR # 316659 # AIRBOX,COMPLETE SHELL WHITE MFR # 3107206009 # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650 # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650000 # AIRBOX,COMPLETE USE 3107206009 SHELL WHITE MFR # 3105023000 Superseded: see description # BOLT,A/C USE 3106756012 MFR # 3100375058 Superseded: see description # Screw; For Use With Dometic Air Conditioner Ceiling Assembly; 1/4 Inch-20 x 7 Inch Length; Hex; Pack Of 4 MFR # 3311511000 Superseded: see description # BOX ASM USE 3105026011 MFR # 3105026003 Superseded: see description # PLATE,COVER POLAR WHITE MFR # 316659001
Adb # 3107206014
Dometic Brisk Air 57915622 13,500 BTU adb # 3107206014 — parts list sheet Full-resolution diagram + every part number →
Components 37 items # FILTER RETURN AIR(UNIVER MFR # 3108015003 # Air Conditioner Ceiling Assembly Rotary Switch; For Dometic 3314851.000 Series Ceiling Assembly; On-Off And Fan Speed Control; 8 Position Switch; Without Knob; Single MFR # 3313107025 # SCREW,16-24X.38 PCR MFR # 317224001 # APPLIANCE COMPONENTS RV; Bolt Mounting Use 331151 MFR # 3106756012 Superseded: see description # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650000 # Air Conditioner Filter; Use With DV8 Air Conditioners; Also Use New Part Number 457722 MFR # 2401175 Superseded: see description # Air Conditioner Filter; Use With Duo-Therm/Dometic Air Conditioners; 16 Inch x 11-3/4 Inch MFR # 457722 Superseded: see description # Air Conditioner Ceiling Assembly Service Kit; Replacement For Dometic 579/ 590/ 591/ 595/ 600/ 630015 Series Air Conditioners; Press On; Round; Polar White MFR # 3104931013 # AWNING-REPAIR PARTS RV; Extension Lower Duct MFR # 313605003 # ATTACHMENT TAPE GREY-EACH MFR # 06384 # Air Conditioner Filter; Use With Dometic RV Air Conditioners; MERV 6 Rating; 13-1/2 Inch Length x 7.375 Inch Width x 3/4 Inch Depth; Removes Dust/ Pollen/ Pet Dander MFR # AC105G Superseded: see description # Screw; For Use With Dometic Air Conditioner Ceiling Assembly; 1/4 Inch-20 x 7 Inch Length; Hex; Pack Of 4 MFR # 3311511000 Superseded: see description # APPLIANCE COMPONENTS RV; Connector Cable MFR # 20010000 # Air Conditioner Ceiling Assembly; For Use With Duo-Therm 57908521 Model Air Conditioner; Manual; Polar White MFR # 3107206017 Superseded: see description # SWITCH,POSITION ROTARY ***USE 49-9715*** MFR # 3105273001 Superseded: see description # SCREW 8-18 X .625 MFR # 312096004 # FILTER,AIR USE 3108015003 MFR # 3107190005 Superseded: see description # GRILLE RETURN AIR SVC KIT MFR # 3313107034 # Air Conditioner Ceiling Assembly; For Duo-Therm Air Conditioner Brisk Air Model 57915622; Non-Ducted System; With Manual Control MFR # 3107188017 # Air Conditioner Ceiling Assembly Thermostat; Replacement For Dometic Duo-Therm Manual Air Conditioner Ceiling Assembly MFR # 3313107000 # GRILLE, RETURN USE 3313107034 PLR WHT MFR # 3107053005 Superseded: see description # T-STAT USE 3313107000 MFR # 3100781008 Superseded: see description # CAP, CONN HOUSING MFR # 3106624012 # LOUVER ASM MFR # 3107189007 # APPLIANCE COMPONENTS RV; Box Control MFR # 3107196002 # APPLIANCE COMPONENTS RV; Duct Upper MFR # 316450000 # CAP, CONN. HOUSING (3-POLE) MFR # 3106624004 # RELIEF,STRAIN USE 302994002 MFR # 32994002 Superseded: see description # APPLIANCE COMPONENTS RV; Knob Control MFR # 3107052007 # Air Conditioner Ceiling Assembly Control Knob; For Dometic Duo-Therm Air Conditioners; Set Of 2 MFR # 3313107024 # Refrigerator Power Cord Strain Relief Bushing; Use With Duo-Therm Air Conditioner Basement Model 39115601 MFR # 302994002 Superseded: see description # BOX,JUNCTION MFR # 3107220018 # APPLIANCE COMPONENTS RV; Parts Bag Polar White MFR # 3107194015 # BOX,JUNCTION USE 3107220018 MFR # 3104154004 Superseded: see description # COVER , CONTROL BOX MFR # 308146000 # DEACAL, FIELD WIRING MFR # 3105024008 # BOX, CONTROL MFR # 3105027035
Adb # 3107210001
Dometic Brisk Air 57915622 13,500 BTU adb # 3107210001 — parts list sheet Full-resolution diagram + every part number →
Components 32 items # SPACER, FIBER MFR # 3105677011 # Air Conditioner Filter; Use With Dometic RV Air Conditioners; MERV 6 Rating; 13-1/2 Inch Length x 7.375 Inch Width x 3/4 Inch Depth; Removes Dust/ Pollen/ Pet Dander MFR # AC105G Superseded: see description # APPLIANCE COMPONENTS RV; Duct Upper MFR # 316450000 # APPLIANCE COMPONENTS RV; Airbox Complete Polar Whi MFR # 3107210019 # APPLIANCE COMPONENTS RV; Parts Bag Asm Shell White MFR # 3107194007 # PLATE, RELAY KIT MFR # 3107575007 # FILTER,AIR USE 3108015003 MFR # 3107190005 Superseded: see description # FILTER RETURN AIR(UNIVER MFR # 3108015003 # AIRBOX,COMPLETE SHELL WHITE MFR # 3107210001 # DECAL, FIELD WIRING MFR # 3106515004 # DECAL FIELD WIRING MFR # 3107764007 # SCREW (3 REQ.) MFR # 307987001 # APPLIANCE COMPONENTS RV; Parts Bag Polar White MFR # 3107194015 # PLATE, ESCUTCHEON MFR # 3107217006 # DUCT,DISCHARGE USE 316450000 MFR # 316450 Superseded: see description # ATTACHMENT TAPE GREY-EACH MFR # 06384 # Air Conditioner Filter; Use With Duo-Therm/Dometic Air Conditioners; 16 Inch x 11-3/4 Inch MFR # 457722 Superseded: see description # Air Conditioner Filter; Use With DV8 Air Conditioners; Also Use New Part Number 457722 MFR # 2401175 Superseded: see description # TEMPLATE, CEILING (SW) MFR # 3107193009 # APPLIANCE COMPONENTS RV; Connector Cable MFR # 20010000 # GRILLE RETURN AIR SVC KIT MFR # 3313107034 # APPLIANCE COMPONENTS RV; Plug Hole Shell White MFR # 3104931005 # Screw; For Use With Dometic Air Conditioner Ceiling Assembly; 1/4 Inch-20 x 7 Inch Length; Hex; Pack Of 4 MFR # 3311511000 Superseded: see description # APPLIANCE COMPONENTS RV; Bolt Mounting Use 331151 MFR # 3106756012 Superseded: see description # SCREW 8-18 X .625 MFR # 312096004 # AWNING-REPAIR PARTS RV; Extension Lower Duct MFR # 313605003 # GRILLE, RETURN USE 3313107034 PLR WHT MFR # 3107053005 Superseded: see description # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650000 # FOAM TAPE (22.5" REQ.) SHELL WHITE MFR # 3107890 # LOUVER ASM MFR # 3107189007 # APPLIANCE COMPONENTS RV; Shell Airbox Shell White MFR # 3107188025 # APPLIANCE COMPONENTS RV; Shell Airbox Polar White MFR # 3107188033
Adb # 3105023000
Dometic Brisk Air 57915622 13,500 BTU adb # 3105023000 — parts list sheet Full-resolution diagram + every part number →
Components 53 items # Wall Thermostat; For Cool/ Furnace Control; Programmable; LCD Readout; 12 Volt DC; With High/ Low/ Auto Fan Speed Control; White Case; WIth Control Box MFR # 3313189000 # Air Conditioner Ceiling Assembly Rotary Switch; For Dometic 3314851.000 Series Ceiling Assembly; On-Off And Fan Speed Control; 8 Position Switch; Without Knob; Single MFR # 3313107025 # SWITCH,POSITION USE 3105273001 ROTARY MFR # 3106077005 Superseded: see description # Wall Thermostat; Single Zone; Cool/ Furnace; Programmable; LCD Display; 12 Volt DC; With Low/ High/ Auto Fan Speed Control; With Auto/ On Mode Fan Control; Polar White; With Control Board; Also Use New Number 3316230.700 MFR # 3316230000 Superseded: see description # SWITCH,ROTARY USE 20250 *N* MFR # 20250000 Superseded: see description # BUSHING,SNAP-IN MFR # 301028040 # Air Conditioner Control Box Assembly; For Dometic Duo-Therm Air Conditioner; With Heat/ Cool Wall Thermostat MFR # 3107541009 # Wall Thermostat; For Cool/ Furnace Control; Programmable; LCD Readout; 12 Volt DC; With High/ Low/ Auto Fan Speed Control; Black Case; With Control Box MFR # 3313189015 # CONTROL KIT,ANALOG USE 46-4225 (10) HEAT/COOL MFR # F7431 Superseded: see description # SWITCH,POSITION ROTARY ***USE 49-9715*** MFR # 3105273001 Superseded: see description # DOOR,RETURN AIR SHELL WHITE MFR # 3104071000 # A/C COMPONENTS RV; CTRL KIT, CT STD-C/F-BLK MFR # 3316230714 # APPLIANCE COMPONENTS RV; Switch Rotary Use 3106077 MFR # 20250 Superseded: see description # Air Conditioner Ceiling Assembly Thermostat; Replacement For Dometic Duo-Therm Manual Air Conditioner Ceiling Assembly MFR # 3313107000 # FILTER,AC USE 3108015003 MFR # 308166 Superseded: see description # FILTER RETURN AIR(UNIVER MFR # 3108015003 # Wall Thermostat; Single Zone; Cool/ Furnace/ Heat Strip; Programmable; LCD Display; 12 Volt DC; With Low/ High/ Auto Fan Speed Control; With Auto/ On Mode Fan Control; Polar White; With Control Board MFR # 3316232000 # ATTACHMENT TAPE GREY-EACH MFR # 06384 # T-STAT USE 3313107000 MFR # 3100781008 Superseded: see description # CONTROL KIT,ANALOG HT/COOL/HS ***USE 50-0775*** MFR # 3107541017 Superseded: see description # Air Conditioner Filter; Use With Duo-Therm/Dometic Air Conditioners; 16 Inch x 11-3/4 Inch MFR # 457722 Superseded: see description # Air Conditioner Filter; Use With DV8 Air Conditioners; Also Use New Part Number 457722 MFR # 2401175 Superseded: see description # Air Conditioner Filter; Use With Dometic RV Air Conditioners; MERV 6 Rating; 13-1/2 Inch Length x 7.375 Inch Width x 3/4 Inch Depth; Removes Dust/ Pollen/ Pet Dander MFR # AC105G Superseded: see description # CONTROL KIT,(10)USE 46-4226 ANALOG HEAT/COOL/HS MFR # F7239 Superseded: see description # APPLIANCE COMPONENTS RV;;Control Kit Lcd Cool/Fu MFR # 3313189049 # LOUVER ASM 2REQUIRED MFR # 310138 # LOUVER USE 310138 MFR # 310138000 Superseded: see description # CAP, CONN. HOUSING (6 POLE) MFR # 314471001 # PLUG, FEMALE MFR # 314471000 # RELIEF,STRAIN USE 302994002 MFR # 32994002 Superseded: see description # Refrigerator Power Cord Strain Relief Bushing; Use With Duo-Therm Air Conditioner Basement Model 39115601 MFR # 302994002 Superseded: see description # WELDMENT, JUNCTION BOX MFR # 3104161017 # Rivet; Replacement For Dometic Brisk Model Air Conditioner; Push/ Pull Rivet MFR # 3108700307 # BOX ASM USE 3105026011 MFR # 3105026003 Superseded: see description # KNOB, T-STAT USE 3107052007 2 REQUIRED MFR # 3100364011 Superseded: see description # APPLIANCE COMPONENTS RV; Connector Cable MFR # 20010000 # Screw; For Use With Dometic Air Conditioner Ceiling Assembly; 1/4 Inch-20 x 7 Inch Length; Hex; Pack Of 4 MFR # 3311511000 Superseded: see description # AIRBOX,COMPLETE SHELL WHITE MFR # 3107206009 # APPLIANCE COMPONENTS RV; Template MFR # 315427001 # APPLIANCE COMPONENTS RV; Knob Control MFR # 3107052007 # APPLIANCE COMPONENTS RV; Box Control MFR # 3107196002 # PLATE,COVER RV A/C SHELL WHITE MFR # 316659 # BOLT,A/C USE 3106756012 MFR # 3100375058 Superseded: see description # EXTENSION, DUCT MFR # 313606000 # SHELL,AIRBOX SHEL L WHITE MFR # 3104234004 # APPLIANCE COMPONENTS RV; Parts Bag Shell White MFR # 3105043008 # BOX,CONTROL USE 3107196002 MFR # 3105026029 Superseded: see description # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650000 # APPLIANCE COMPONENTS RV; Decal Air Box MFR # 3104083005 # Air Conditioner Ceiling Assembly Control Knob; For Dometic Duo-Therm Air Conditioners; Set Of 2 MFR # 3313107024 # AIRBOX,COMPLETE USE 3107206009 SHELL WHITE MFR # 3105023000 Superseded: see description # Air Conditioner Control Box Assembly; Replacement For Dometic Brisk Air CAS/ 546/ 548/ 557/ 558/ 559/ 570/ 578/ 579 Series Air Conditioners MFR # 313650 # APPLIANCE COMPONENTS RV; Bolt Mounting Use 331151 MFR # 3106756012 Superseded: see description
Shroud & Main Components
Dometic Brisk Air 57915622 13,500 BTU shroud & main components — parts list sheet Full-resolution diagram + every part number →
Components 84 items # SCREW,SHOULDER MFR # 3102834003 # Air Conditioner Shroud Mounting Screw; For Use With Dometic Brisk Model Air Conditioner MFR # 3310724004 Superseded: see description # APPLIANCE COMPONENTS RV; Screw Shroud MFR # 313685001 # DECAL,SHROUD USE 3101380016 MFR # 3101380008 Superseded: see description # DECAL,SHROUD MFR # 3101380016 # SHROUD 12' MFR # 3309518003 # SHROUD 10" SHELL USE 49-9199 WHITE CLOSED END MFR # 3308781008 Superseded: see description # APPLIANCE COMPONENTS RV; Extension Formed Shroud MFR # 3102812017 # APPLIANCE COMPONENTS RV; Shroud Asm Use 3309518003 MFR # 3103144006 Superseded: see description # SHROUD ASM USE 3309518003 POLAR WHITE MFR # 3103147009 Superseded: see description # SHROUD KIT CLOSED END SW MFR # 3309364028 # SHROUD ASM,GREY USE 3309518003 MFR # 3103148007 Superseded: see description # DECAL, FIELD WIRING MFR # 3105052017 # COVER, CONDENSER COIL MFR # 309383000 # APPLIANCE COMPONENTS RV; Brace Bulkhead MFR # 3100357023 # APPLIANCE COMPONENTS RV; Insulation Foam MFR # 3105014066 # COVER,EVAP.USE 3310592000 MFR # 314885002 Superseded: see description # APPLIANCE COMPONENTS RV; Coil Condenser MFR # 3103014001 # APPLIANCE COMPONENTS RV; Compressor Asm 57915-603 MFR # 3104465004 # COVER,TERMINAL USE 3108072004 MFR # 3103799007 Superseded: see description # APPLIANCE COMPONENTS RV; Cover Terminal MFR # 3108072004 # GASKET,COVER MFR # 3103800003 # Air Conditioner Compressor Overload Protector; For Use With Dometic 57915.603/ 57915.613 Model Air Conditioner MFR # 3100250277 Superseded: see description # NUT, FLANGE MFR # 306342004 # COIL,EVAPORATOR SING LE INLET/OUTLET MFR # 3107338000 # LINE, SUCTION MFR # 3104236009 # APPLIANCE COMPONENTS RV; Tube Capillary .070" X 44 MFR # 3100245517 # LINE, DISCHARGE MFR # 3103825000 # BLADE,FAN USE 317937 317937 MFR # 317937000 Superseded: see description # BLADE, FAN PLASTIC ***USE 49-9558*** MFR # 3107914008 Superseded: see description # BLADE,FAN USE 3107914008 MFR # 317937 Superseded: see description # SERVICE KIT F/MOTOR MFR # 3310725001 # GROMMET, MOTOR MOUNTING ***USE 49-8471*** MFR # 3100230022 Superseded: see description # SPACER,MOTOR USE3310725001 OR STAG# 49-8471 MFR # 308046002 # NUT, FLANGE ***USE 498471*** MFR # 306342003 Superseded: see description # AWNING-REPAIR PARTS RV; Support Motor MFR # 3103844027 # MOTOR KIT,FAN USE 3108706916 MFR # 3108701365 Superseded: see description # MOTOR KIT MFR # 3108706916 # APPLIANCE COMPONENTS RV; Bulkhead For Condensor MFR # 317923001 # BLOCKS, FOAM MFR # 3100587009 # Air Conditioner Bulkhead Plate; Replacement For Duo-Therm 57908321/ 59016626/ 57915403 Model Air Conditioners MFR # 3107478004 # APPLIANCE COMPONENTS RV; Cover Electric Box MFR # 3100828007 # GASKET, ROOF USE 3310718006 KIT MFR # 3100247 Superseded: see description # ROOF A/C GASKET KIT MFR # 3310718006 # A/C GASKET 14IN X 14IN UNIVERSAL MFR # 25071 # A/C SEAL, 14 X 14 WHITE MFR # A101414 # GASKET, GREY, 14 X 14 MFR # 6759A3281 # GASKET USE 3100247 MFR # 3100247000 Superseded: see description # APPLIANCE COMPONENTS RV; Channel Front MFR # 3102811001 # APPLIANCE COMPONENTS RV; Connector Plug MFR # 3106625019 # Wire Plug Connector; Replacement For Dometic Air Conditioner Compressor; 6 Pole MFR # 3310734003 # APPLIANCE COMPONENTS RV; Sleeve MFR # 318087009 # APPLIANCE COMPONENTS RV; Insulation Kit MFR # 3104152008 # Air Conditioner O-Ring; Replacement For Duo-Therm 39045522/ 57915336/ 39045601 Model Air Conditioners; Fits Air Conditioner Blower Wheel Inlet MFR # 3106415007 # WHEEL, BLOWER PLASTIC ***USE 49-9655*** MFR # 3104887009 Superseded: see description # WHEEL BLOWER MFR # 3313107033 # Air Conditioner Capacitor; Hard Start Capacitor; For 15000 BTU Air Conditioner Units MFR # 3310727007 # STARTER KIT (120) USE 49-8350 MFR # F6866 Superseded: see description # KIT,HARD START USE 3310727007 MFR # 3106732005 Superseded: see description # HOUSING,BLOWER USE 3100865033 MFR # 3101145005 Superseded: see description # APPLIANCE COMPONENTS RV; Housing Blower MFR # 3100865033 # BULKHEAD,EVAPORATOR MFR # 3100831076 # PAN KIT,BASE 12" MFR # 3108700323 # CAPACITOR, FAN/RUN ***USE 49-9656*** MFR # 3100248420 Superseded: see description # CAPACITOR,FAN/RUN USE 46-2342 MFR # F8048 Superseded: see description # CAPACITOR 30/50MFD MFR # 3313107027 # APPLIANCE COMPONENTS RV; Strain Relief MFR # 302994017 # BOX,ELECTRICAL USE 3100827066 MFR # 3100827058 Superseded: see description # SLEEVE,COMP.USE 3100239122 MOUNTING MFR # 3100239056 Superseded: see description # APPLIANCE COMPONENTS RV; Sleeve Compressor MFR # 3100239122 # GROMMET MFR # 3100238207 # NUT,FLANGE 5/16"-18 X 1.75 MFR # 306342002 # LINE, PROCESS MFR # 20309004 # CONTROL,COLD USE3312303005 STAG# 49-8912 MFR # 3109409001 # APPLIANCE COMPONENTS RV; Relay Kit Bimetal T-Stat MFR # 3104998004 # COMFORT CTRL MFR # 3106463007 # APPLIANCE COMPONENTS RV; HARNESS KIT,WIRE AGS MFR # 3109311005 # Wall Thermostat; 5 Button; White MFR # 3109228001 # AIRBOX,COMPLETE SHELL WHITE MFR # 3107206009 # RELAY KIT,BIMETAL THERMOSTAT MFR # 3104998020 # AIRBOX,COMPLETE USE 3107206009 SHELL WHITE MFR # 3105023000 Superseded: see description # Air Conditioner Ceiling Assembly; For Use With Duo-Therm 57908521 Model Air Conditioner; Manual; Polar White MFR # 3107206017 Superseded: see description # Air Conditioner Retrofit Kit; 4 To 5 Button Comfort Control Center Conversion Kit; Polar White; With Power Module Board/ Thermostat/ Freeze Sensor MFR # 3310009000 # HARNESS KIT (50) USE 46-4803 WIRE AGS MFR # F9127 Superseded: see description
Return Air Assembly
Dometic Brisk Air 57915622 13,500 BTU return air assembly — parts list sheet Full-resolution diagram + every part number →
Components 22 items # Air Conditioner Ceiling Assembly Grille; For Dometic Air Conditioners; 17-1/16 Inch Length x 17-1/16 Inch Width; Polar White; With Return Air Kit/ Filter MFR # 3107867016 # GRILLE USE 3107867008 INSIDE SHROUD (EGGSHELL) MFR # 3105148013 Superseded: see description # Air Conditioner Ceiling Assembly Grille; For Dometic Air Conditioners; 17-1/16 Inch Length x 17-1/16 Inch Width; Shell White; With Return Air Kit/ Filter MFR # 3107867008 # GRILLE,RETURN AIR GRAY MFR # 3105148021 # TEMPLATE, CEILING MFR # 3105148005 # Air Conditioner Filter; Replacement For Dometic Air Conditioners With Quick Cool Ducted Return Air Package; 12 Inch x 16 Inch; Hand Washable; Single MFR # 3108701373 # Air Conditioner Filter; Use With Dometic RV Air Conditioners; MERV 6 Rating; 13-1/2 Inch Length x 7.375 Inch Width x 3/4 Inch Depth; Removes Dust/ Pollen/ Pet Dander MFR # AC105G Superseded: see description # Air Conditioner Filter;;Use With Duo-Therm/Dometic Air Conditioners; 16 Inch x 1-3/4 Inch MFR # 3105012003 Superseded: see description # ATTACHMENT TAPE GREY-EACH MFR # 06384 # Air Conditioner Filter; Use With DV8 Air Conditioners; Also Use New Part Number 457722 MFR # 2401175 Superseded: see description # FILTER RETURN AIR(UNIVER MFR # 3108015003 # Air Conditioner Filter; Use With Duo-Therm/Dometic Air Conditioners; 16 Inch x 11-3/4 Inch MFR # 457722 Superseded: see description # Air Conditioner Installation Kit; Use With Dometic Air Conditioners; Foam; Adhesive Back; 18 Inch x 7 Inch x 1/8 Inch MFR # 3105014009 Superseded: see description # Air Conditioner Ceiling Assembly Grille; For Use With Dometic Air Conditioner Ducted Quick Cool Brisk Return Air; Shell White; 14-1/8 Inch Length x 7-5/8 Inch Width MFR # 3105007029 Superseded: see description # GRILLE RETURN AIR MFR # 3104928001 # GRILLE,RETURN USE 3105007029 MFR # 3104928027 Superseded: see description # GRILLE,RETURN USE 3105007029 MFR # 3104928019 Superseded: see description # Air Conditioner Ceiling Assembly Service Kit; Parts Bag For Dometic Ceiling Assemblies; With Two 3104931005 Shell White Hole Plugs/ Two 3104931013 Polar White Hole Plugs/ Two 3104931021 Gray Hole Plugs/ Six 312096014 Screws MFR # 3108701381 # GRILLE,RTRN AIR USE 3105007037 SHELL WHITE MFR # 3105007003 Superseded: see description # GRILLE,RET.AIR USE 3105007045 POLAR WHITE MFR # 3105007011 Superseded: see description # APPLIANCE COMPONENTS RV; GRILLE, RETURN AIR SHELL MFR # 3105007037 # A/C COMPONENTS RV; GRILLE, RETURN AIR MFR # 3105007045
Remote Sensor
Dometic Brisk Air 57915622 13,500 BTU remote sensor — parts list sheet Full-resolution diagram + every part number →
Components 8 items # SENSOR CAP, TAN MFR # 3313107065 # APPLIANCE COMPONENTS RV; Cap Sensor MFR # 3106488012 # APPLIANCE COMPONENTS RV; Cap Svc Kit White MFR # 3313107064 # APPLIANCE COMPONENTS RV; KIT,SVC SENSOR CAP BLACK MFR # 3313107066 # SENSOR FOR 3106486008 MFR # 3106484004 # NYLOCLIP MFR # 304203001 # SCREW #4-24 X .62 (2 REQ.) MFR # 312096005 # SCREW #8-18 X .5 MFR # 312096014
Ducted A-c Replacement
Dometic Brisk Air 57915622 13,500 BTU ducted a-c replacement — parts list sheet Full-resolution diagram + every part number →
Components 12 items # GRILLE,RETURN AIR GENESIS SHELL WHITE MFR # 3308120504 # CONTROL KIT,ANALOG USE 46-4225 (10) HEAT/COOL MFR # F7431 Superseded: see description # GRILLE,RTRN AIR USE 3105007037 SHELL WHITE MFR # 3105007003 Superseded: see description # APPLIANCE COMPONENTS RV; HARNESS KIT,WIRE AGS MFR # 3109311005 # COMFORT CTRL MFR # 3106463007 # Wall Thermostat; Single Zone; Cool/ Furnace; Programmable; LCD Display; 12 Volt DC; With Low/ High/ Auto Fan Speed Control; With Auto/ On Mode Fan Control; Polar White; With Control Board; Also Use New Number 3316230.700 MFR # 3316230000 Superseded: see description # APPLIANCE COMPONENTS RV; GRILLE, RETURN AIR SHELL MFR # 3105007037 # APPLIANCE COMPONENTS RV;;Control Kit Lcd Cool/Fu MFR # 3313189049 # AIR CONDITIONER USE 57915N BRISK AIR CW MFR # 57915522N Superseded: see description # CONTROL KIT,ANALOG HT/COOL/HS ***USE 50-0775*** MFR # 3107541017 Superseded: see description # CONTROL KIT,(10)USE 46-4226 ANALOG HEAT/COOL/HS MFR # F7239 Superseded: see description # Air Conditioner Control Box Assembly; For Dometic Duo-Therm Air Conditioner; With Heat/ Cool Wall Thermostat MFR # 3107541009
Elec. Control 3106481.009
Dometic Brisk Air 57915622 13,500 BTU elec. control 3106481.009 — parts list sheet Full-resolution diagram + every part number →
Components 7 items # APPLIANCE COMPONENTS RV; Bolt Mounting 1/4-20 X 8 MFR # 3106756020 # BOLT,ANCHOR .25-10X8 USE 3106756020 MFR # 3100375066 Superseded: see description # ELECTRONIC KIT CCC MFR # 3109226005 # HARNESS KIT (50) USE 46-4803 WIRE AGS MFR # F9127 Superseded: see description # APPLIANCE COMPONENTS RV; HARNESS KIT,WIRE AGS MFR # 3109311005 # ELECTRONIC KIT,USE 3109226005 MFR # 3106481009 Superseded: see description # APPLIANCE COMPONENTS RV; Washer Flat Steel .188X.6 MFR # 309513015
Heat Strip Kit
Dometic Brisk Air 57915622 13,500 BTU heat strip kit — parts list sheet Full-resolution diagram + every part number →
Components 9 items # APPLIANCE COMPONENTS RV; Element Heating MFR # 3104615004 # HEAT STRIP,NON-DUCTED MFR # 3101121030 # HEAT KIT USE 3101121030 MFR # 3101121022 Superseded: see description # APPLIANCE COMPONENTS RV; Switch Limit MFR # 3104613009 # SLEEVING MFR # 3100394083 # PLUG,MALE 3-POLE MFR # 314470000 # APPLIANCE COMPONENTS RV; Guard Kit Heat MFR # 3101143000 # ELECTRIC BOX MFR # 3101125007 # APPLIANCE COMPONENTS RV; Strain Relief MFR # 302994012
