Dometic Penguin 610115405 13,500 BTU Parts Diagram · Shroud W-ele Mch Led Wall T-st

Air Conditioner · 3 assemblies · 3 diagram sheets · 145 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic Penguin 610115405 13,500 BTU rooftop air conditioner: 3 assemblies (Shroud W-ele Mch Led Wall T-st, Opt. El. Ht Kt 3-101121-014, Inst.pts W-elec Ctl In T-stat) and 145 manufacturer part numbers. 44 parts are marked as superseded — the description gives the replacement number to order instead.

On rooftop units the model and serial plate is under the shroud on the base pan, and a second label usually sits on the ceiling assembly behind the return-air grille. Dometic model numbers are 8 digits (e.g. 57915.xxx); write down the full number including any suffix, because shrouds and control boards change with it.

Shroud W-ele Mch Led Wall T-st

Components

94 items

1. #DECAL,SHROUD USE 3109274005 MFR # 3102888009 Superseded: see description
2. #SHROUD USE 3107746004 SHELL WHITE MFR # 3102515008 Superseded: see description
3. #APPLIANCE COMPONENTS RV; Foam Kit MFR # 3312081000
4. #SHROUD SHELL WHITE <S MFR # 3308046006
5. #APPLIANCE COMPONENTS RV; Shroud Use 3308046006 MFR # 3107746004 Superseded: see description
6. #CAPACITOR,RUN/FAN DUO 579.7/58915.305/55908.00 MFR # F8046
7. #PTCR KIT MFR # 3310731009
8. #BRACKET USE 3100876006 MFR # 3100877004 Superseded: see description
9. #RELAY, START USE 3310731009 PTCR MFR # 3100876006 Superseded: see description
10. #RELAY, PTCR USE3310731009 (START) OR STAG# 49-8609 MFR # 3100876006D
11. #Air Conditioner Capacitor; Run/ Fan Capacitor MFR # 3100248339
12. #Air Conditioner Capacitor; Start Capacitor; 88 To 106 Micro Farad; 250 Volt AC; 50 To 60 HZ; 1-1/2 Inch Diameter x 4-3/8 Inch Height; Black MFR # 3100236219
13. #COVER,EVAPORATOR MFR # 3102514803
14. #DECAL MFR # 316655
15. #PANEL, CAPACITOR (*,**) MFR # 3101627028
16. #STRAIN RELIEF MFR # 31028025
17. #TUBE,CAPILLARY .600 X 610 MFR # 3100245400
18. #APPLIANCE COMPONENTS RV; Drier Filter MFR # 3101863003
19. #APPLIANCE COMPONENTS RV; Bulkhead Compressor MFR # 3102511007
20. #APPLIANCE COMPONENTS RV; Plate Close Off MFR # 3100256001
21. #TAPE, FOAM SOLD IN 63&quot; PIECE MFR # 3102669052
22. #TAPE,FOAM USE 3102669045 SOLD BY THE INCH MFR # 3102669003 Superseded: see description
23. #TAPE FOR SEAL USE 3102669052 69 INCHES MFR # 3102669045 Superseded: see description
24. #MOTOR,FAN USE 3108702372 MFR # 3100991003 Superseded: see description
25. #MOTOR,FAN USE 3108702372 MFR # 3104413004 Superseded: see description
26. #MOTOR KIT W/CAP&BRKT MFR # 3108706924
27. #MOTOR KIT USE 3108706924 W/ CAP AND BRACKETS MFR # 3108702372 Superseded: see description
28. #APPLIANCE COMPONENTS RV; Bracket Motor Mount MFR # 3100258007
29. #SERVICE KIT F/MOTOR MFR # 3310725001
30. #GROMMET, MOTOR MOUNTING ***USE 49-8471*** MFR # 3100230022 Superseded: see description
31. #BLOWER, SIDE/REAR MFR # 3100261001
32. #BLOWER,SCROLL MFR # 3100260003
33. #BLOWER,SIDE & FRONT 60-61 MFR # 3100259005
34. #APPLIANCE COMPONENTS RV; Gasket Roof .69X1.5 X MFR # 3100286016
35. #GASKET, 16&quot; X 1.5&quot; MFR # 316462000
36. #APPLIANCE COMPONENTS RV; Gasket Roof For A/C MFR # 3100286032
37. #APPLIANCE COMPONENTS RV; Wheel Blower Use 33101800 MFR # 3102449000 Superseded: see description
38. #APPLIANCE COMPONENTS RV; Wheel Blower Use 33101800 MFR # 3100386006 Superseded: see description
39. #Air Conditioner Blower Wheel; Replacement For Dometic CAL136207/ CAL136302/ CAL61005/ CAL61001/ CAM135001 Series Air Conditioners; Plastic MFR # 3310180000
40. #SUPPORT, PC BOARD (3 REQ.) MFR # 3101623001
41. #APPLIANCE COMPONENTS RV; Pan Base MFR # 3103179002
42. #PAN,BASE USE 3103179002 MFR # 3101885030 Superseded: see description
43. #BULKHEAD, EVAPORATOR MFR # 3100254030
44. #Air Conditioner Control Box Assembly; For Dometic DuoTherm Air Conditioners; With Power Module Board/ DC Power Supply Board/ Cable Adapter/ Fiberglass Sleeve/ In-Line Coupler/ Control Cable/ Freeze Control Sensor/ Comfort Control Center Wall Thermostat/ Operating Instructions MFR # 3307713010
45. #BOARD, CIRCUIT USE 3307713010 MFR # 3104233006 Superseded: see description
46. #BOARD,PC MAIN USE 3104233006 MFR # 3104232008 Superseded: see description
47. #BOARD,MODULE USE 3104233006 MFR # 3101626004 Superseded: see description
48. #DECAL, WIRING MFR # 3102719006
49. #DECAL, WIRING MFR # 3102900002
50. #DECAL, WIRING MFR # 3101894016
51. #APPLIANCE COMPONENTS RV; Decal Field Wiring MFR # 3102899006
52. #WIRING DECAL MFR # 3101968
53. #DECAL FOR AIR BOX CONTROL 39015.601/.602 MFR # 3100384001
54. #APPLIANCE COMPONENTS RV; Cover Electrical MFR # 3102510009
55. #APPLIANCE COMPONENTS RV; Insulation Housing Bottom MFR # 3100294002
56. #APPLIANCE COMPONENTS RV; Bulkhead Electrical Box MFR # 3102532029
57. #CLAMP MFR # 318723
58. #CONDUIT 6100* MFR # 3100838022
59. #ANTI SHORT DEVICE MFR # 37760002
60. #PLUG 4 POLE MFR # 314470005
61. #ROOF A/C GASKET KIT MFR # 3310718006
62. #A/C GASKET 14IN X 14IN UNIVERSAL MFR # 25071
63. #A/C SEAL, 14 X 14 WHITE MFR # A101414
64. #GASKET, GREY, 14 X 14 MFR # 6759A3281
65. #GASKET, ROOF USE 3310718006 KIT MFR # 3100247 Superseded: see description
66. #GASKET,INSULATION EVAP MFR # 3102527011
67. #INSULATION, EVAP CLOSE-OFF SPLIT & MFR # 3102527003
68. #PLATE EVAP CLOSE- MFR # 3102512013
69. #APPLIANCE COMPONENTS RV; Plate Close Off MFR # 3102512005
70. #PAN,DRAIN MFR # 3102967001
71. #PAN,DRAIN FOAM MFR # 3102513003
72. #INSULATION USE 3108903000 EVAP.BULKHEAD MFR # 3102516022 Superseded: see description
73. #INSULATION,EVAP.USE 3102516022 MFR # 3102516006 Superseded: see description
74. #APPLIANCE COMPONENTS RV; Insulation Set MFR # 3108903000
75. #HOUSING,EVAPORATOR BLOWER MFR # 3100300007
76. #APPLIANCE COMPONENTS RV; Wheel Blower Use 33103780 MFR # 3100385008 Superseded: see description
77. #COIL,EVAP.USE 3104573005 620015.308 MFR # 3102533001 Superseded: see description
78. #APPLIANCE COMPONENTS RV; Coil Evaporator MFR # 3104573005
79. #APPLIANCE COMPONENTS RV; Bracket Mounting MFR # 3100297005
80. #NUT W/MTG CLIP USE 3100280027 MFR # 3100280019 Superseded: see description
81. #APPLIANCE COMPONENTS RV; Nut W/Clip Requires 3 MFR # 3100280027
82. #COMPRESSOR *N* MFR # 31064630006
83. #COMPRESSOR USE 3106430006 MFR # 3102863002 Superseded: see description
84. #COMPRESSOR MFR # 3106430006
85. #SWITCH,OVERLOAD MFR # 3100250244
86. #APPLIANCE COMPONENTS RV; Line Discharge MFR # 3102564014
87. #GROMMET 3REQUIRED MFR # 3102324005
88. #Air Conditioner Compressor Mounting Hardware; For Duo-Therm Air Conditioner Penguin Model 620525421; Compressor Mounting Sleeve MFR # 3100239098
89. #PLATE, COMPRESSOR, MTG. MFR # 3102593005
90. #SPRING MFR # 3102594003
91. #APPLIANCE COMPONENTS RV; Plate Compressor MFR # 3102590019
92. #APPLIANCE COMPONENTS RV; Tube Copper MFR # 3102563016
93. #USHING, SNAP-IN MFR # 31028037
94. #GASKET USE 3100286016 MFR # 316462 Superseded: see description

Opt. El. Ht Kt 3-101121-014

Components

11 items

1. #HEAT STRIP,NON-DUCTED MFR # 3101121030
2. #ELEMENT,HEAT USE 3101121022 MFR # 3101124 Superseded: see description
3. #HEAT KIT USE 3101121030 MFR # 3101121022 Superseded: see description
4. #APPLIANCE COMPONENTS RV; Switch Auto Limit 130F MFR # 3101123002
5. #SLEEVING MFR # 3100394083
6. #PLUG,MALE 3 POLE RVA 60 MFR # 314470
7. #APPLIANCE COMPONENTS RV; Harness Wire Use 6223 MFR # 3101829004 Superseded: see description
8. #HARNESS,WIRE (250) SERVICE HEAT KIT MFR # 6223
9. #GUARD, HEAT MFR # 3101143
10. #ELECTRIC BOX MFR # 3101125007
11. #RELIEF,STRAIN USE 302994012 MFR # 32994012 Superseded: see description

Inst.pts W-elec Ctl In T-stat

Components

43 items

1. #TEMPLATE USE 318542015 MFR # 3100265010 Superseded: see description
2. #APPLIANCE COMPONENTS RV; Ceiling Asm MFR # 318542015
3. #INSULATION USE 3107133005 MFR # 3100287006 Superseded: see description
4. #INSULATION,CEILING TEMPLATE MFR # 3107133005
5. #DUCT USE 3100342017 MFR # 3100342009 Superseded: see description
6. #Air Conditioner Duct Collar; For Dometic Duo-Therm CAL 61.205/ CAL 136.205 Model Air Conditioner MFR # 3100342017
7. #APPLIANCE COMPONENTS RV; Box Junction MFR # 3100275001
8. #Water Heater Junction Box Cover; For Roof Top Heat Pump Model 630025.321C/ 630025.321D MFR # 3100278013
9. #BOX FRONT, RH MFR # 3100277015
10. #Air Conditioner Power Supply Connector; For Dometic Ceiling Assembly Control Box MFR # 314471
11. #PLUG,FEMALE 4 POLE RVA 61 MFR # 314471004
12. #APPLIANCE COMPONENTS RV; Back Box 600312/3115 MFR # 318704000
13. #TUBE,CAPILLARY .600 X 610 MFR # 3100245400
14. #APPLIANCE COMPONENTS RV; Louver Asm 2 Req. MFR # 3100289002
15. #APPLIANCE COMPONENTS RV; Filter Air Use 3100281P00 MFR # 3100281009 Superseded: see description
16. #APPLIANCE COMPONENTS RV; FILTER,AIR 2 PACK MFR # 3100281P009
17. #Air Conditioner Ceiling Assembly Grille; Use With Duo-Therm 610012404/ 610012405/ 620525321 Model Air Conditioners; Return Air; Shell White MFR # 3100270002 Superseded: see description
18. #DECAL, LEFT SIDE SWITCH MFR # 3101395006
19. #DECAL, RIGHT SIDE SWITCH MFR # 3101394009
20. #BOARD, CONTROL USE 3307713010 MFR # 3101625014 Superseded: see description
21. #Air Conditioner Control Box Assembly; For Dometic DuoTherm Air Conditioners; With Power Module Board/ DC Power Supply Board/ Cable Adapter/ Fiberglass Sleeve/ In-Line Coupler/ Control Cable/ Freeze Control Sensor/ Comfort Control Center Wall Thermostat/ Operating Instructions MFR # 3307713010
22. #BOARD,CONTROL USE 3101625014 MFR # 3101625006 Superseded: see description
23. #DECAL,T-STAT HEAT/COOL MFR # 3101838039
24. #DECAL,T-STAT MFR # 3101838005
25. #DECAL,T-STAT NO HEAT 5891 5.602/603 MFR # 3101838021
26. #DECAL,T-STAT USE 3101838039 MFR # 3101838013 Superseded: see description
27. #APPLIANCE COMPONENTS RV; Base T-Stat 610 62001 MFR # 3103808006
28. #COVER USE 3103809004 AND 3103808006 THERMOSTAT 610 MFR # 3101620007 Superseded: see description
29. #COVER,T-STAT MFR # 3103809004
30. #BASE USE 3103809004 AND 3103808006 THERMOSTAT 610 MFR # 3101621005 Superseded: see description
31. #BOLT,MOUNTING USE 3106756012 6.25&quot; LONG MFR # 3100375025 Superseded: see description
32. #APPLIANCE COMPONENTS RV; Bolt Mounting Use 331151 MFR # 3106756012 Superseded: see description
33. #Screw; For Use With Dometic Air Conditioner Ceiling Assembly; 1/4 Inch-20 x 7 Inch Length; Hex; Pack Of 4 MFR # 3311511000 Superseded: see description
34. #Air Conditioner Wiring Harness; For Penguin Roof Mount Air Conditioner; 15 Foot Length MFR # 3101632010
35. #Air Conditioner Wiring Harness; For Penguin Roof Mount Air Conditioner; 30 Foot Length MFR # 3101632036
36. #APPLIANCE COMPONENTS RV; Cable 25' Use 3101632036 MFR # 3101632028 Superseded: see description
37. #APPLIANCE COMPONENTS RV; Parts Bag Asm MFR # 3101582009
38. #T-STAT USE 3103187005 MFR # 3101633802 Superseded: see description
39. #FOR MODELS 58915-301/302/601/602 59016503 610115305 NOT NORMALLY REQUIRED. ORDER INDIVIDUAL PARTS. T-STAT COMPLETE 3103187005. THE 6" ADAPTER CABL... MFR # 3103187005
40. #DECAL, WIRING MFR # 3102719006
41. #APPLIANCE COMPONENTS RV; Template MFR # 318681801
42. #APPLIANCE COMPONENTS RV; Airbox MFR # 318542016
43. #APPLIANCE COMPONENTS RV; Shell Airbox Shell Whit MFR # 3101390023
