Dometic Penguin 641815HXX1C0 13,500 BTU Parts Diagram · Replacement

Air Conditioner · 2 assemblies · 2 diagram sheets · 20 parts · by Andrew Strick, mobile RV technician

OEM exploded parts diagrams for the Dometic Penguin 641815HXX1C0 13,500 BTU rooftop air conditioner: 2 assemblies (Replacement, Exploded View) and 20 manufacturer part numbers. 3 parts are marked as superseded — the description gives the replacement number to order instead.

On rooftop units the model and serial plate is under the shroud on the base pan, and a second label usually sits on the ceiling assembly behind the return-air grille. Dometic model numbers are 8 digits (e.g. 57915.xxx); write down the full number including any suffix, because shrouds and control boards change with it.

Replacement

Components

1 item

1. #Air Conditioner; Penguin II; Fits 14 Inch x 14 Inch Opening; 410A Refrigerant Cooling; 13500 BTU; 12.3 Amp Compressor Draw; Low Profile 11-1/4 Inch Height; Polar White; With Built-In Comfort Control Center II (CCCII) Electronic Board/ Requires Comfort Control Center II (CCCII) Wall Thermostat And Ceiling Assembly; 101 Pounds MFR # 64185HX1C0

Exploded View

Components

19 items

1. #Air Conditioner Shroud; Replacement Shroud For Dometic Penguin II Model Air Conditioners; Polar white MFR # 3314471001
2. #Air Conditioner Foam Block Kit; Use With Dometic 640310C451/ 640312.831/ 459516.711/ 641716.301 Model Air Conditioners MFR # 3310726009 Superseded: see description
3. #APPLIANCE COMPONENTS RV; KIT,SVC DECAL,WARNING MFR # 3310735000
4. #Air Conditioner Compressor Mounting Hardware; Replacement For Dometic Air Conditioners MFR # 3310733005
5. #ROOF A/C GASKET KIT MFR # 3310718006
6. #S,PARTS,MOTOR MFR # 3311599.000
7. #KIT,SVC COMPRESSOR GROMMET MFR # 3313107.111
8. #APPLIANCE COMPONENTS RV; KIT,SVC FAN MOTOR MFR # 3314471011
9. #PTCR KIT MFR # 3310731009
10. #Air Conditioner Shroud Mounting Screw; For Use With Dometic Brisk Model Air Conditioner MFR # 3310724004 Superseded: see description
11. #Air Conditioner Wiring Harness; For Use With Dometic Penguin Model Air Conditioner; Ambient Sensor Cord; 26 Inch Length MFR # 3311731000 Superseded: see description
12. #A/C COMPONENTS RV; KIT,SVC WHEEL EVAP BLWR MFR # 3314471005
13. #APPLIANCE COMPONENTS RV; KIT SVC CAPACITOR 55/15 MFD MFR # 3314471017
14. #HARD START KIT MFR # 3311883000
15. #THERMISTOR KIT WIRE HARNE MFR # 3312303005
16. #BOARD PCB CCC2 MFR # 3312022000
17. #KIT SVC WHEEL CONDENSER BLWR MFR # 3314471014
18. #APPLIANCE COMPONENTS RV; KIT,SVC CONDENSER HOUSING MFR # 3314471008
19. #APPLIANCE COMPONENTS RV; KIT,SVC UPR EVAP HOUSING MFR # 3314471009
